FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|
| Bolts and Nuts |
| M6 | 10 |
| M7 | 15 |
| M8 | 25 |
| M10 | 40 |
| M12 | 60 |
| Engine Carrier to Body Bolt (1) | | 120 + 180° |
| Engine Mount Bracket to Cylinder Block Bolt (2) |
| | 20 |
| 40 |
| Engine Mount Bracket to Engine Mount Nut | | 75 |
| Engine Mount to Engine Carrier Bolt | | 60 |
| Torque Converter to Electro-Drive Drive Motor Nut | | 60 |
| (1) Always replace (2) For bolt clarification, see -items 4, 8 and 9- in ENGINE MOUNT, BRACKET AND CARRIER OVERVIEW |
| (2) | For bolt clarification, see -items 4, 8 and 9- in ENGINE MOUNT, BRACKET AND CARRIER OVERVIEW |
Electro-Drive Drive Motor to Engine Bolt Tightening Sequence and Specification
Scheme 483
| Item | Bolt | Nm |
|---|
| 1, 2, 3 | M12 x 70 | 65 |
| 4 | M10 x 85 with nut | 45 |
| 5, 6, 7, 8 (1) | M10 x 60 | 20 + 90° (1/4) additional turn |
| 9 | M12 x 70 | 65 |
| 10 | M12 x 60 internal multipoint bolt | 65 |
| (1) Always replace |
Transmission to Electro-Drive Drive Motor Bolt Tightening Sequence and Specification
Scheme 484
Tighten the new bolts -1 through 10- that connect the transmission to the electro-drive drive motor to 30 Nm + 90° (1/4) additional turn.
