Air Conditioning: Overview Volkswagen Touareg I

Automatic HVAC System 2 illustrations ~583 words

CLIMATRONIC PASSENGER COMPARTMENT COMPONENTS OVERVIEW

Before beginning assembly work on electrical system, perform the following

  1. Switch off all electrical consumers.
  2. Switch off ignition.
  3. Remove ignition key.

Scheme 31

Scheme 31
Scheme 31
  1. A/C Control Head -E87- "2 Zone" with Climatronic Control Module -J255
  2. A/C Control Head -E87- "4 Zone" with Climatronic Control Module -J255
  3. Left Motor Mounting Plates Motor locations on the "4 Zone" heater and A/C unit, refer to «HEATER AND A/C UNIT MOTOR LOCATIONS, 4 ZONE»(ref-499053-S34452844392012083100000) . Motor locations on the "2 Zone" heater and A/C unit, refer to «HEATER AND A/C UNIT MOTOR LOCATIONS, 2 ZONE»(ref-499053-S14456406122012083100000) .
  4. Upper Part Of Air Distribution Housing
  5. Left Front Upper Body Outlet Temperature Sensor -G385- Removing and installing, refer to «LEFT FRONT UPPER BODY VENT -G385»(ref-499053-S24531523422012083100000) .
  6. Right Front Upper Body Outlet Temperature Sensor -G386- Removing and installing, refer to «RIGHT FRONT UPPER BODY VENT -G386»(ref-499053-S34433769732012083100000) .
  7. Right Motor Mounting Plates Motor locations on the "4 Zone" heater and A/C unit, refer to «HEATER AND A/C UNIT MOTOR LOCATIONS, 4 ZONE»(ref-499053-S34452844392012083100000) . Motor locations on the "2 Zone" heater and A/C unit, refer to «HEATER AND A/C UNIT MOTOR LOCATIONS, 2 ZONE»(ref-499053-S14456406122012083100000) .
  8. Glove Compartment Cooling Hose
  9. Evaporator Temperature Sensor -G308- Removing and installing, refer to «EVAPORATOR -G308- OR EVAPORATOR VENT -G263»(ref-499053-S26699608322012083100000) .
  10. Fresh Air Intake Duct Temperature Sensor -G89- Removing and installing, refer to «FRESH AIR INTAKE DUCT TEMPERATURE SENSOR -G89»(ref-498988-S34836818452012083100000) .
  11. Front Bitron Blower Regulation Sensor -G462- Removing and installing, refer to «FRONT BITRON BLOWER REGULATION SENSOR -G462»(ref-498988-S07905714622012083100000) .
  12. Front Bitron Blower Regulation Motor -V305- Removing and installing, refer to «FRONT BITRON BLOWER REGULATION MOTOR -V305»(ref-498988-S23619497722012083100000) .
  13. Fresh/Recirculating Air Door Motor -V154- Removing and installing, refer to «FRESH/RECIRCULATING AIR DOOR MOTOR -V154»(ref-498988-S04102320962012083100000) .
  14. Dust and Pollen Filter With Activated Charcoal Filter Element Removing and installing, refer to «DUST AND POLLEN FILTER WITH ACTIVATED CHARCOAL FILTER INSERT»(ref-498988-S24352752422012083100000) .
  15. Right Footwell Vent Temperature Sensor -G262- Removing and installing, refer to «RIGHT FOOTWELL VENT -G262»(ref-499053-S40448235922012083100000) .
  16. Left Footwell Vent Temperature Sensor -G261- Removing and installing, refer to «LEFT FOOTWELL VENT -G261»(ref-499053-S42903810462012083100000) .

Scheme 32

Scheme 32: CLIMATRONIC REAR A/C DISPLAY CONTROL HEAD FUNCTION, 4 ZONE
Scheme 32: CLIMATRONIC REAR A/C DISPLAY CONTROL HEAD FUNCTION, 4 ZONE
  1. Temperature Regulator, Left Change rear left temperature setting by turning.
  2. AUTO Button, Left In automatic mode the Climatronic maintains the selected rear left interior temperature automatically. With this setting the vent air temperature, the blower speed and the air distribution are controlled automatically.
  3. Display Of Selected Interior Temperature, Left Can be changed from degrees Celsius to degrees Fahrenheit and vice versa. Refer to «Convert Degrees Celsius To Fahrenheit In Vehicles With Menu Control Elements In Windshield Washer Lever»(ref-499053-S33975987432012083100000) .
  4. Display For Blower Speed, Left In automatic operation the actual blower speed is displayed.
  5. Button - Side Window Air Distribution, Left
  6. Button - Rear and Side Window Air Distribution, Left
  7. Button - Side Window Air Distribution, Right
  8. Button - Rear and Side Window Air Distribution, Right
  9. Display For Blower Speed, Right In automatic operation the actual blower speed is displayed.
  10. Display Of Selected Interior Temperature, Right Can be changed from degrees Celsius to degrees Fahrenheit and vice versa. Refer to «Convert Degrees Celsius To Fahrenheit In Vehicles With Menu Control Elements In Windshield Washer Lever»(ref-499053-S33975987432012083100000) .
  11. AUTO Button, Right In automatic mode the Climatronic maintains the selected rear right interior temperature automatically. With this setting the vent air temperature, the blower speed and the air distribution are controlled automatically.
  12. Temperature Regulator, Right Change rear right temperature setting by turning.
  13. Button For Setting Blower Speed, Right
  14. Button - Footwell Air Distribution, Right
  15. Button - Footwell Air Distribution, Left
  16. Button For Setting Blower Speed, Left
