Air Conditioning: Component Locations Volkswagen Touareg I

Automatic HVAC System 14 illustrations ~763 words

HEATER AND A/C UNIT MOTOR LOCATIONS, 4 ZONE

Note. A- shows the motor location on the left side of the heater and A/C unit. -B- shows the motor location on the right side of the heater and A/C unit.

Scheme 35

Scheme 35: HEATER AND A/C UNIT MOTOR LOCATIONS, 4 ZONE
Scheme 35: HEATER AND A/C UNIT MOTOR LOCATIONS, 4 ZONE
  1. Defroster Door Motor -V107- With the Defroster Door Motor Position Sensor -G135-. Removing and installing, refer to «DEFROSTER DOOR -V107- OR FRONT AIR DISTRIBUTION -V145-, MANUAL A/C SYSTEM»(ref-499053-S23589877512012083100000) .
  2. Left Side Vent Motor -V299- With Left Front Defrost/Upper Body Shut-Off Door Motor Position Sensor -G318-. Removing and installing, refer to «LEFT SIDE VENT 4 ZONE -V299- OR SIDE VENT 2 ZONE -V262- CLIMATRONIC»(ref-499053-S20203378322012083100000) .
  3. Left Vent Adjustment Motor -V110- With Left Front Upper Body Outlet Position Sensor -G387-. Removing and installing, refer to «LEFT CENTER VENT 4 ZONE -V110- OR CENTER VENT ADJUSTMENT -V102- 2 ZONE CLIMATRONIC»(ref-499053-S20649011822012083100000) .
  4. Left Footwell Door Motor -V108- With the Left Footwell Door Motor Position Sensor -G139-. Removing and installing, refer to «LEFT FOOTWELL -V108- OR FOOTWELL DOOR -V261-, 2 AND 4 ZONE CLIMATRONIC»(ref-499053-S19900641662012083100000) .
  5. Left Temperature Door Motor -V158- With Left Temperature Regulator Door Motor Position Sensor -G220-. Removing and installing, refer to «LEFT TEMPERATURE DOOR -V158»(ref-499053-S34918840552012083100000) .
  6. Right Center Vent Motor -V111- With Right Front Upper Body Outlet Position Sensor -G388-. Removing and installing, refer to «RIGHT CENTER VENT -V111- AND RIGHT SIDE VENT -V300»(ref-499053-S10171842372012083100000) .
  7. Right Side Vent Motor -V300- With Right Front Defrost/Upper Body Shut-Off Door Motor Position Sensor -G317 -. Removing and installing, refer to «RIGHT CENTER VENT -V111- AND RIGHT SIDE VENT -V300»(ref-499053-S10171842372012083100000) .
  8. Right Temperature Door Motor -V159- With Right Temperature Regulator Door Motor Position Sensor -G221-. Removing and installing, refer to «RIGHT TEMPERATURE DOOR -V159»(ref-499053-S42476664062012083100000) .
  9. Right Footwell Door Motor -V109- With Right Footwell Door Motor Position Sensor -G140-. Removing and installing, refer to «RIGHT FOOTWELL DOOR -V109- AND RIGHT TEMPERATURE DOOR -V159»(ref-499053-S32637384572012083100000) .

HEATER AND A/C UNIT MOTOR LOCATIONS, 2 ZONE

Note. A- shows the motor location on the left side of the heater and A/C unit. -B- shows the motor location on the right side of the heater and A/C unit.

Scheme 36

Scheme 36: HEATER AND A/C UNIT MOTOR LOCATIONS, 2 ZONE
Scheme 36: HEATER AND A/C UNIT MOTOR LOCATIONS, 2 ZONE
  1. Defroster Door Motor -V107- With the Defroster Door Motor Position Sensor -G135-. Removing and installing, refer to «DEFROSTER DOOR -V107- OR FRONT AIR DISTRIBUTION -V145-, MANUAL A/C SYSTEM»(ref-499053-S23589877512012083100000) .
  2. Side Vent Motor -V262- Side Vent Motor Position Sensor -G469-. Removing and installing, refer to «LEFT SIDE VENT 4 ZONE -V299- OR SIDE VENT 2 ZONE -V262- CLIMATRONIC»(ref-499053-S20203378322012083100000) .
  3. Center Vent Adjustment Motor -V102- Center Vent Motor Position Sensor -G467-. Removing and installing, refer to «LEFT CENTER VENT 4 ZONE -V110- OR CENTER VENT ADJUSTMENT -V102- 2 ZONE CLIMATRONIC»(ref-499053-S20649011822012083100000) .
  4. Footwell Door Motor -V261- Footwell Door Motor Position Sensor -G468-. Removing and installing, refer to «LEFT FOOTWELL -V108- OR FOOTWELL DOOR -V261-, 2 AND 4 ZONE CLIMATRONIC»(ref-499053-S19900641662012083100000) .
  5. Left Temperature Door Motor -V158- Left Temperature Door Potentiometer/Actuator -G220-. Removing and installing, refer to «LEFT TEMPERATURE DOOR -V158»(ref-499053-S34918840552012083100000) .
  6. Right Temperature Door Motor -V159- Right Temperature Door Potentiometer/Actuator -G221-. Removing and installing, refer to «RIGHT FOOTWELL DOOR -V109- AND RIGHT TEMPERATURE DOOR -V159»(ref-499053-S32637384572012083100000) .

HEATER AND A/C UNIT MOTOR LOCATIONS, MANUAL

Note. A- shows the motor location on the left side of the heater and A/C unit. -B- shows the motor location on the right side of the heater and A/C unit.

Scheme 37

Scheme 37: HEATER AND A/C UNIT MOTOR LOCATIONS, MANUAL
Scheme 37: HEATER AND A/C UNIT MOTOR LOCATIONS, MANUAL
  1. Defroster Door Motor -V107- With the Defroster Door Motor Position Sensor -G135-. Removing and installing, refer to «DEFROSTER DOOR -V107- OR FRONT AIR DISTRIBUTION -V145-, MANUAL A/C SYSTEM»(ref-499053-S23589877512012083100000) .
  2. Front Air Distribution Motor -V145- With the Front Air Distribution Motor Position Sensor -G470-. Removing and installing, refer to «DEFROSTER DOOR -V107- OR FRONT AIR DISTRIBUTION -V145-, MANUAL A/C SYSTEM»(ref-499053-S23589877512012083100000) .
  3. Footwell Door Motor -V261- With the Footwell Door Motor Position Sensor -G468-. Removing and installing, refer to «FOOTWELL DOOR -V261- OR TEMPERATURE REGULATOR DOOR -V68-, MANUAL A/C SYSTEM»(ref-499053-S31768515402012083100000) .
  4. Temperature Regulator Door Motor -V68- With Temperature Regulator Door Motor Position Sensor -G92-. Removing and installing, refer to «FOOTWELL DOOR -V261- OR TEMPERATURE REGULATOR DOOR -V68-, MANUAL A/C SYSTEM»(ref-499053-S31768515402012083100000) .

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 38

Scheme 38: SPECIAL TOOLS
Scheme 38: SPECIAL TOOLS

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48
  1. Torque Wrench V.A.G 1331
  2. Drip Tray for Shop Crane VAS 6208
  3. Hose Clamps up to Diameter 40 mm 3093
  4. Trim Removal Wedge 3409
  5. Pry Lever T10039/1
  6. Multi-point Adapter 3400
  7. Counter-hold T10172 with Adapter T10172/1
  8. Reversible Ratchet VAS 5122
  9. Torque Wrench V.A.G 1783 (2 to 10 Nm)
  10. Evacuating and Charging Valve Adapter Set T10364
  11. Assembly Tool SW 17 V.A.G 1331/6
