FUSE COLOR IDENTIFICATION
| Fuse Color | Amp Rating |
|---|
| Black | 1A |
| Violet | 2A |
| Lilac | 3A |
| Beige | 5A |
| Brown | 7.5A |
| Red | 10A |
| Blue | 15A |
| Yellow | 20A |
| White | 25A |
| Green | 30A |
| Orange | 40A |
| Red | 50A |
| Blue | 60A |
| Transparent | 80A |
Scheme 11
Scheme 11: Overview Of Fuses
| Location No. | Description | Refer to |
|---|
| 1 | Fuse Arrangements On Fuse Panel/Battery | FUSE ARRANGEMENTS IN FUSE BRACKET/BATTERY - ENGINE COMPARTMENT |
| 2 | Fuse Arrangements On Relay Panel | FUSES ON RELAY PANEL |
| Relay Arrangements On Thirteen Position Auxiliary Relay Panel Above Relay Panel | RELAYS ON THIRTEEN POSITION AUXILIARY RELAY PANEL |
| Fuse Arrangements On Thirteen Position Auxiliary Relay Panel | FUSE ARRANGEMENTS ON THIRTEEN POSITION AUXILIARY RELAY PANEL |
| 3 | Fuse Arrangements In Fuse Panel, Instrument Panel, Left Side | FUSE ARRANGEMENTS IN FUSE PANEL, INSTRUMENT PANEL - LEFT SIDE |
Scheme 12
Scheme 12: Overview Of Relays
| Location No. | Description | Refer to |
|---|
| 1 | Identifying Relay Panel (Located below the Thirteen Position Auxiliary Relay Panel) | LOCATION OF RELAYS ON RELAY PANEL |
| 1 | Identifying Thirteen Position Auxiliary Relay Panel (Located above the Relay Panel) | LOCATION OF RELAYS ON THIRTEEN POSITION AUXILIARY RELAY PANEL - Above Relay Panel |
| 2 | Inside Housing Relay (Engine compartment near brake fluid reservoir) | LOCATION OF INSIDE HOUSING RELAYS - ENGINE COMPARTMENT - LEFT SIDE |
| 3 | Additional Relay Panel (In plenum chamber engine compartment) | LOCATION OF ADDITIONAL RELAY PANEL IN PLENUM CHAMBER, CENTER - FROM JUNE 2003 TO DECEMBER 2006 |
