ENGINE CODE

Engines are identified by a 3-letter code stamped on the engine. For engine code locations (Scheme 16)- (Scheme 19). Engine codes are also located on the vehicle data plate.

Note. Engine number for 1.8L turbo can be found on mating flange between engine and transmission. Additionally there is a sticker on cylinder head (valve) cover with engine code and serial number.

Scheme 16

Scheme 16: ENGINE CODE

Note. Engine code for 1.9L TDI is located between diesel injection pump and exhaust manifold, on engine block. Additionally there is a sticker on the timing belt guard containing engine code and serial number. Engine code is also included on vehicle data plate.

Scheme 17

Note. Engine code and serial number for 2.0L is located can be found on flange between engine/transmission. Additionally there is a sticker on the timing belt guard containing engine code and serial number. Engine code is also included on vehicle data plate.

Scheme 18

Note. Engine code - arrow A - and engine number - arrow B ("serial number") 2.5L is located on rear side of engine, above partition of cylinder block/upper section of oil pan.

Scheme 19

WARNING

Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. On no account should fuses be repaired (e.g. with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause a fire.

FUSE ARRANGEMENTS ON FUSE BRACKET/BATTERY - ENGINE COMPARTMENT

The fuse bracket is assembled on top of the battery on the left side of engine compartment.

Scheme 20

Scheme 20: FUSE ARRANGEMENTS ON FUSE BRACKET/BATTERY - ENGINE COMPARTMENT

Fuse No.	Wiring ID.	Rating (Amps)	Function/Component	Signal
1	S162	50A	V101- Secondary Air Injection (AIR) Pump Motor (1) -J359- Preheating Coolant, Low Heat Output Relay (2) -J360- Preheating Coolant, High Heat Output Relay (2)	30
2	S163	50A	J17- Fuel Pump (FP) Relay (17/30) -J370- Glow Plug Activation Control Module (3)	30
3	S164	40A	J293- Coolant Fan Control (FC) Control Module C1781, (T4e/1) -V7- Coolant Fan	30
4	S176	110A	J59- Load Reduction Relay, (7/30)	30a
5	S177	110A 150A	C- Gen (GEN) (90 Amp) -C- Generator (GEN) (120 Amp)	30
6	S178	30A	J104- A35 Control Module (T47a/1)	30
7	S179	30A	J104- ABS Control Module, (T47a/32)	30
8	S180	30A	F18- Coolant Fan Control (FC) Thermal Switch -J293- Coolant Fan Control (FC) Control Module C1781, (T4e/3)	30
9	T3-3 Pin Connector		From: -J104- ABS Control Module (T47a/1) to T3/1 (S178) -J104- ABS Control Module (T47a/32) to T3/2 (S179) -J293- Coolant Fan Control (FC) Control Module (T4a/3) to T3/3 (S180)	30
(1) Only vehicles with Secondary Air Injection (AIR) Pump. (2) Only Diesel engines with manual transmission. (3) Only Diesel engines. Note: The number(s) in parentheses indicates production control number stamped on relay housing.

(1)	Only vehicles with Secondary Air Injection (AIR) Pump.

(2)	Only Diesel engines with manual transmission.

(3)	Only Diesel engines.

FUSE IDENTIFICATION (ON FUSE BRACKET/BATTERY)

FUSE ARRANGEMENTS IN FUSE PANEL, INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005

Fuse (holder) panel "S" is located behind trim panel on far left side of dashboard. (Scheme 21)

Note. Fuses from S23 to S44 are identified with additional prefix 2, in wiring diagram. For Example, fuse S23 on fuse panel is listed as S223 in wiring diagram.

Scheme 21

Scheme 21: FUSE ARRANGEMENTS IN FUSE PANEL, INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005

Scheme 22

Fuse No.	Wiring ID.	Rating (Amp)	Function/Component	Signal
1	S1	10A	J99- Heated Mirror Relay (1) -J131- Drivers Heated Seat Control Module, (T6/5) -J132- Front Passengers Heated Seat Control Module, (T6b/5) -W6- Glove Compartment Light -Z20/ Z21- Washer Nozzle Heaters	X
2	S2	10A	E3 - Emergency Flasher Switch, (T8d/7) -M5/ M7 - Left/Right Front Turn Signal Lamp -M6/ M8 - Left/Right Rear Turn Signal Lamp	X
3	S3	5A	E1 - Light Switch -E20- Instrument Panel Illumination Dimmer Switch, (T3k/2) -J5- Fog Light Relay (4/86)	58
4	S4	5A	X - License plate light	58
5	S5	7.5A	E45- Cruise Control Switch (T10s/6) (2) -E159- Fresh Air/Recirculating Flap Switch, (T8n/5) (3) -E231- Outside Heated Mirror Switch -F36- Clutch Pedal Switch, (T4m/3) (4) -F47- Brake Pedal Switch, (T4y/3) -G65- High Pressure Sensor, (T3c/3) -J89- Daytime Running Lights Change-over Relay (T9c/8) -J255- Climatronic Control Module, (T16c/9) -J293- Coolant Fan Control (FC) Control Module (T14/9) -J386- Driver Door Control Module, (T18d/3) -R- Radio (T8g/4) (5) -T16- 16 Pin Connector (OBD), (T16/1) (6) -V35- Right Coolant Fan (T4b/2) -V48- Left Headlamp Beam Adjustment Motor (7) -V49- Right Headlamp Beam Adjustment Motor (7)	15
6	S6	5A	J393- Comfort System Central Control Module (T23/5)	15
7	S7	10A	F4- Back-Up Light Switch -F125- Multi-Function Transmission Range (TR) Switch (T10t/10) (8) -F189- Tiptronic Switch, (T8s/7) (8) -G22- Speedometer Vehicle Speed Sensor (VSS) -J226- Park/Neutral Position (PNP) Relay, (T9/5) (9) -K142 - Selector Lever Position P/N Indicator Lamp -M16 / M17- Left/Right Back-Up Lamps -T16- 16 Pin Connector (OBD), (T16/1)	15
8	S8		Not Used
9	S9	5A	E256- ASR/ESP Button, (T6j/6) -J104- ABS Control Module (T47a/4) -G85- Steering Angle Sensor (T6k/5) (10)	15
10	S10	10A	J285- Instrument Cluster Control Module, (T32/30) -J393- Comfort System Central Control Module, (T23/17) (11) -R- Radio, (T8g/4) -Y2- Digital Clock	86s
11	S11	5A	J285- Instrument Cluster Control Module, (T32/1) -N110- Shift Lock Solenoid	15
12	S12	7.5A	T16- 6 Pin Connector (OBD), (T16/16) (5)	30
13	S13	10A	F- Brake Light Switch (T4y/1)	30
14	S14	10A	J220 - Motronic Engine Control Module (ECM), in plenum chamber, center, (T121/62) -J271- Motronic Engine Control Module (ECM) Power Supply -J393- Comfort System Central Control Module (T23/22) (11)	30
15	S15	5A	G85- Steering Angle Sensor, (T6k/4) (10) -J217- Transmission Control Module (TCM), (T68/45) -J217- Transmission Control Module (TCM) vehicles with Tiptronic -J285- Instrument Cluster Control Module (T32/23) (21) -Y2- Digital Clock, (T10d/10) (13)	30
16	S16	10A	J293- Coolant Fan Control (FC) Control Module, (T14a/4) (12)	30
17	S17		Not Used
18	S18	15A	J5- Fog Lamp Relay, (6/85) -J285- Instrument Cluster Control Module (T32/17) -J607- Right High/Low Beam Switch-Over Relay (7) -M32- Right High Beam Headlamp (T12b/4)	56a
19	S19	15A	J606- Left High/Low Beam Switch-Over Relay (7) -M30- Left High Beam Headlamp	56a
20	S20	10A	J607- Right High/Low Beam Switch-Over Relay (7) -M31- Right Low Beam Headlamp (T12b/9)	56b
21	S21	10A	J606- Left High/Low Beam Switch-Over Relay (7) -M29- Left Low Beam Headlamp (T12a/9)	56b
22	S22	5A	J285- Instrument Cluster Control Module, (T32/26) -M3- Right Parking Lamp (T12b/8) -M22- Right Brake/Taillight Lamp (T3b/1) -M34- Right Front Side Marker Lamp -M36- Front Turn Signal/Side Marker Lamp -M38- Right Rear Side Marker Lamp	58r
23	S23	5A	J285- Instrument Cluster Control Module, (T32/27) -M1- Left Parking Lamp (T12a/8) -M21- Left Brake/Taillight Lamp (T3a/1) -M33- Left Front Side Marker Lamp -M35- Left Front Turn Signal/Side Marker Lamp -M37- Left Rear Side Marker Lamp	58l
24	S24	20A	E22- Windshield Wiper/Washer Switch (T8c/8) -J31-Wiper/Washer Intermittent Relay (T18a/13)	X
25	S25	25A	E9- Fresh Air Blower Switch (T6p/2)	X
26	S26	25A	E15- Rear Window Defogger Switch (T6f/5) -Z1- Heated Rear Window	X
27	S27	15A	U1- Cigarette Lighter from model year 2007 -J29- Blocking Diode, from model year 2007	X
27	S27	20A	J29- Blocking Diode (13) -U18- 12V Socket 2, (T3o/3) (13) -U19- 12V Socket 3, (T3ab/2) (13)	X
28	S28	15A	G6 - Transfer Fuel Pump (FP)	87
29	S29	15A	J220- Motronic Engine Control Module (ECM), (T121/3) -J220- Motronic Engine Control Module (ECM) (T121/21) (3) -J248- Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM), (T121/37) -J623- Engine Control Module (ECM), (T80/4) (15) -N30, N31, N33, N83- Fuel Injectors -N83- Cylinder 5 Fuel Injector (3)	30
30	S30	20A	J245- Power Sunroof Control Module (T6s/4)	30
31	S31	20A	F125- Multi-Function Transmission Range (TR) Switch (T8a/7) -J217- Transmission Control Module (TCM), (T68/23) -J217- Transmission Control Module (TCM) (T52/27) (16) -J539- Brake Booster Control Module, (T6k/3) -J539- Brake Booster Control Module, (T6j/3) (17)	15
32	S32	10A	N30, N31, N33, N83- Fuel Injectors (15) -N280- A/C Compressor Regulator Valve (3)	87
32	S32	15A (18)	J248- Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM), (T121/2) -N146- Quantity Adjuster	87
33	S33		Not Used
34	S34	10A	J52- Glow Plug Relay (19) -N18- EGR Vacuum Regulator Solenoid Valve (19) -N75- Wastegate Bypass Regulator Valve -N108- Cold Start Injector (19) -N239- Intake Manifold Flap Change-over Valve (19) -N205- Camshaft Adjustment Valve 1 (19) -N249- Turbocharger Recirculating Valve (19)	87
35	S35	30A	U19- 2V Socket 3 (in luggage compartment)	30
36	S36	15A	E23 - Fog Lamp Switch, (T17/2)	X
37	S37	20A	J220- Motronic Engine Control Module (ECM), (T121/62) (20) -J248- Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM), (T121/88) (19) -J271- Motronic Engine Control Module (ECM) Power Supply Relay (T9/2) (20) , and (2/30) (15) -J623- Engine Control Module (ECM), (T80/15) (15) -J283- Brake Vacuum Pump Fuse	30
38	S38	15A	E204- Remote Tank Flap Switch -E233- Rear Lid Remote Control Lock Switch -J386- Driver Door Control Module, (T29/19) (11) -J387- Front Passenger Door Control Module, (T29a/19) (11)	30
39	S39	15A	E3- Emergency Flasher Switch, (T8d/8)	30
40	S40	20A	H2- High Tone Horn -H7- Low Tone Horn -J4- Horn Relay (3/30)	30
41	S41	15A	U1- Cigarette Lighter -U5- 12V Socket -U18- 12V Socket 2 (T3o/3) (22) -U19- 12V Socket 2 (T3ab/2) (22)	30
42	S42	25A	R- Radio (T8a/5 T8a/7)	30
43	S43 (3)	10A	G39- Heated Oxygen Sensor (HO2S) (T6w/4) -G70- Mass Air Flow (MAF) Sensor / G42 Intake Air Temperature (IAT) Sensor (T5j/2) -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4ao/1) -G465- Oxygen Sensor (02S) in Center Three Way Catalytic Converter, (TWC), Bank 1 (T4v/1) (14) -J299- Secondary Air Injection (AIR) Pump Relay, (1/30) -N80- Evaporative Emission (EVAP) Canister Purge Regulator Valve (T2/1) -N112- Secondary Air Injection (AIR) Solenoid Valve -V144- Leak Detection Pump (LDP), (T3d/3)	87
43	S43	10A	G39- Heated Oxygen Sensor (HO2S) (T4s/1), Eng. Code CBPA -G39- Heated Oxygen Sensor (HO2S) (T6/1), Eng. Code BEJ -G39- Heated Oxygen Sensor (HO2S) (T4c/1), Eng. Code BHP -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4ao/1), (Engine Code CBPA) -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4/1), (Engine Code BEJ) -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4d/1), (Engine Code BHP) -N80- Evaporative Emission (EVAP) Canister Purge Regulator Valve (T2/1), (Engine Code CBPA, BEJ, BHP)	87
43	S43 (23)	10A	F36- Clutch Pedal Switch, (T4m/3) -F47- Brake Pedal Switch, (14y/2) -G39- Heated Oxygen Sensor (HO2S) (T6w/4) -J359- Preheating Coolant Low Heat Output Relay (4/86) -J360- Reheating Coolant High Heat Output Relay, (3/86) -N79- Positive Crankcase Ventilation (PCV) Heating Element, (T2/1)	87
44	S44	15A	J131- Driver's Heated Seat Control Module, (T6/4) -J132- Front Passengers Heated Seat Control Module (T6b/4)	30
(1) Only vehicles without power windows. (2) Vehicles with engine BPS w/GRA. (3) Vehicles with engine codes BPS and BPR. (4) Only vehicles with manual transmission. (5) From July 2008. (6) Through June 2008. (7) Vehicles with High Intensity Gas Discharge (HID) Lamps. (8) With Tiptronic 09G. (9) With Auto Transmission 01M. (10) Only vehicles with ASR and ESP. (11) Vehicles with power windows. (12) Vehicles with engine code CBPA. (13) From July 2007. (14) Vehicles with engine codes BPR. (15) Vehicles with engine code CBPA. (16) Vehicles with automatic transmission 09G. (17) Vehicles with 1.8L engine AWV. (18) Diesel engine only. (19) Vehicles with engine codes ALH and BEW. (20) Vehicles with engine code BPS. (21) Through June 2007. (22) From July 2007 through June 2007 (23) Vehicles with engine code BEW. Note: The number(s) in parentheses indicates production control number stamped on relay housing.

(1)	Only vehicles without power windows.

(2)	Vehicles with engine BPS w/GRA.

(3)	Vehicles with engine codes BPS and BPR.

(4)	Only vehicles with manual transmission.

(5)	From July 2008.

(6)	Through June 2008.

(7)	Vehicles with High Intensity Gas Discharge (HID) Lamps.

(8)	With Tiptronic 09G.

(9)	With Auto Transmission 01M.

(10)	Only vehicles with ASR and ESP.

(11)	Vehicles with power windows.

(12)	Vehicles with engine code CBPA.

(13)	From July 2007.

(14)	Vehicles with engine codes BPR.

(15)	Vehicles with engine code CBPA.

(16)	Vehicles with automatic transmission 09G.

(17)	Vehicles with 1.8L engine AWV.

(18)	Diesel engine only.

(19)	Vehicles with engine codes ALH and BEW.

(20)	Vehicles with engine code BPS.

(21)	Through June 2007.

(22)	From July 2007 through June 2007

(23)	Vehicles with engine code BEW.

IDENTIFYING FUSES (INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005)

AUTOMATIC CIRCUIT BREAKERS

The electric seat adjusters or heaters (if applicable) are protected with circuit breakers which reset automatically after the circuit overload has been corrected.

Note. Whenever replacing a fuse, always consult the sticker on the inside of the fuse panel cover. It contains the most up-to-date information regarding the fuse arrangement.

FUSE ARRANGEMENTS ON RELAY PANEL, INSTRUMENT PANEL - LEFT SIDE

The relay/fuse (holder) panel is located on left side of the instrument panel, refer to COMPONENT LOCATION . The relay/fuse panel consist of a lower relay panel, the upper thirteen position auxiliary relay panel (above the relay panel) and assorted fuse locations.

Scheme 23

Scheme 23: FUSE ARRANGEMENTS ON RELAY PANEL, INSTRUMENT PANEL - LEFT SIDE

RELAY ARRANGEMENTS ON RELAY PANEL, INSTRUMENT PANEL - LEFT SIDE

For fuse number, position number, amperage rating and circuits protected, see the appropriate IDENTIFYING FUSES table under FUSES .

Scheme 24

Scheme 24: Location Of Relays On Relay Panel

Relay Location	Function/Component
1	J4- Horn Relay (53)
2	J59- Load Reduction Relay, (100)(213)
3	Not Used
4	J17- Fuel Pump (FP) Relay (409) (1) (2) (3)
5	J31- Wiper/Washer Intermittent Relay/Rain Sensor (377), (192), (389)
(1) Engine 1.8L, code AWV, AWP BKF, BNU. (2) Engine 2.0L, code AVH, AZG, BEV, BHP, CBPA (3) Engine 2.5L, code BPR, BPS Note: The number(s) in parentheses indicates production control number stamped on relay housing.

(1)	Engine 1.8L, code AWV, AWP BKF, BNU.

(2)	Engine 2.0L, code AVH, AZG, BEV, BHP, CBPA

(3)	Engine 2.5L, code BPR, BPS

IDENTIFYING RELAYS ON RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE)

Fuses & Circuit Breakers - Hatchback: Other Volkswagen Beetle A4 facelift
