Location Of Fuses On Relay Panel - From July 2005
| Fuse Location | Function/Component |
|---|
| A | S43- Power Window Circuit Breaker, (30A) |
| B | Not Used |
| C | S130- Secondary Air Injection (AIR) Pump Fuse, (10A) (1) -S329- Rear Spoiler Motor Fuse (30A) (2) |
| (1) From July 2005. (2) Vehicles with 1.8L engines, model years 2003-05. |
| (2) | Vehicles with 1.8L engines, model years 2003-05. |
IDENTIFYING FUSES ON RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005)
Location Of Fuses On Thirteen Position Auxiliary Relay Panel - Above Relay Panel - From July 2005
Note. The thirteen position auxiliary relay panel is located above the lower relay panel.
| Fuse Location | Function/Component |
|---|
| F | Not Used |
| G | Not Used |
| H | S111- Alarm System and Anti-theft Immobilizer Fuse, (15A) |
| H | S338- Telematics Fuse (15A) |
| J | S283- Brake Vacuum Pump Fuse (20A) (1) (2) |
| J | S337- Mechatronic Direct Shift Gearbox (DSG) Fuse (20A) (3) (4) |
| (1) Only vehicles with automatic transmission. (2) From model year 2004. (3) Vehicles with 1.9L engine code BEW. (4) Only vehicles with Direct Shift Gearbox (DSG) 02E. |
| (1) | Only vehicles with automatic transmission. |
| (3) | Vehicles with 1.9L engine code BEW. |
| (4) | Only vehicles with Direct Shift Gearbox (DSG) 02E. |
IDENTIFYING FUSES ON THIRTEEN POSITION AUXILIARY RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005)
Location Of Relays On Thirteen Position Auxiliary Relay Panel - Above Relay Panel
The thirteen position auxiliary relay panel is located above the lower relay panel.
Scheme 13
Scheme 13: Location Of Relays On Thirteen Position Auxiliary Relay Panel - Above Relay Panel
| Relay Location | Function/Component |
|---|
| 1 | J434- Starter Lock/Clutch Pedal Switch Relay (449) (1) (2) |
| 2 | Not Used |
| 3 | J219- Back-Up Light Relay (53) (3) |
| 4 | J5- Fog Light Relay (53) |
| 4 | J207- Starting Interlock Relay (465) (1) |
| 5 | J17- Fuel Pump (FP) Relay (53) (5) |
| 6 | Not Used |
| 7 | J89- Daytime Running Lights Change over Relay (173) (6) (7) |
| 8 | J99- Heated Mirror Relay (53) (7) (1) -J677- Fuel Filler Lid Unlock Relay (53) |
| 9 | J641- Alarm Horn Relay (8) |
| 10 | J237- Alarm System Light Flasher Relay (8) |
| 10 | J135- Third Speed Coolant Fan Control (FC) Relay (100) (9) |
| 10 | J17- Fuel Pump (FP) Relay (53) (10) |
| 10 | J299- Secondary Air Injection (AIR) Pump Relay (100) (11) |
| 10 | J359- Preheating Coolant, Low Heat Output Relay (100) (12) |
| 11 | J226- Park/Neutral Position (PNP) Relay (126) (13) (3) |
| 11 | J207- Starting interlock Relay (176), From model year 2005 (13) |
| 12 | J317- Power Supply relay (terminal 30, B+)(109) (15) |
| 13 | J360- Preheating Coolant High Heat Output Relay (53) (12) |
| (1) Vehicles with manual transmission. (2) Vehicles with 2.5L engine code BPS (ULEV) (3) Vehicles with Direct Shift Automatic Transmission (DSG) 02E. () Vehicles with 2.5L engine, code BPR (SULEV). (5) Vehicles with 1.9L engine, code BEW, from July 2005 (model year 2006). (6) Only vehicles with Daytime Running Lights. (7) Only USA/CAN. (8) Vehicles with Telematics. (9) Vehicles with 1.8L engine, code AWV, AWP, BKF, BNU. (10) Vehicles with 1.9L engine, code BEW, from model year 2004 to model year 2005. (11) Vehicles with 2.5L engine, code BPR, BPS. (12) Vehicles with 1.9 L engine, code BEW, from June 2003 to December 2006. (13) Vehicles with 6 speeds automatic transmission 09G, with Tiptronic. () From model year 2005. (15) Vehicles with 1.9L engine, code ALH, BEW. Note: The number(s) in parentheses indicates production control number stamped on relay housing. |
| (1) | Vehicles with manual transmission. |
| (2) | Vehicles with 2.5L engine code BPS (ULEV) |
| (3) | Vehicles with Direct Shift Automatic Transmission (DSG) 02E. |
| () | Vehicles with 2.5L engine, code BPR (SULEV). |
| (5) | Vehicles with 1.9L engine, code BEW, from July 2005 (model year 2006). |
| (6) | Only vehicles with Daytime Running Lights. |
| (8) | Vehicles with Telematics. |
| (9) | Vehicles with 1.8L engine, code AWV, AWP, BKF, BNU. |
| (10) | Vehicles with 1.9L engine, code BEW, from model year 2004 to model year 2005. |
| (11) | Vehicles with 2.5L engine, code BPR, BPS. |
| (12) | Vehicles with 1.9 L engine, code BEW, from June 2003 to December 2006. |
| (13) | Vehicles with 6 speeds automatic transmission 09G, with Tiptronic. |
| (15) | Vehicles with 1.9L engine, code ALH, BEW. |
IDENTIFYING RELAYS ON THIRTEEN POSITION AUXILIARY RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE)
Location Of Inside Housing Relays - Engine Compartment - Left Side
Inside housing relays, in engine compartment, left side, to the left of brake fluid reservoir, inside housing, from model year 2003 to model year 2005.
Scheme 14
Scheme 14: Location Of Inside Housing Relays - Engine Compartment - Left Side
| Relay Location | Function/Component |
|---|
| 1 | J299- Secondary Air Injection (AIR) Pump Relay (100) (1) (2) |
| 2 | J271- Motronic Engine Control Module (ECM) Power Supply Relay (428)(429) (3) (4) |
| 1 | J360- Preheating Coolant, High Heat Output Relay (100) (5) |
| 2 | J359- Preheating Coolant, Low Heat Output Relay (53) (5) |
| (1) Engine 1.8L, code AWV, AWP BKF, BNU. (2) Engine 2.0L, code AVH, AZG, BEV. (3) Engine 1.8L, code AWV, AWP BKF, BNU. (4) Engine 2.0L, code AVH, AZG, BEV, BHP. (5) Engine 1.9L, codes ALH, BEW, from model year 2003 to model year 2005. Note: The number(s) in parentheses indicates production control number stamped on relay housing. |
| (1) | Engine 1.8L, code AWV, AWP BKF, BNU. |
| (2) | Engine 2.0L, code AVH, AZG, BEV. |
| (3) | Engine 1.8L, code AWV, AWP BKF, BNU. |
| (4) | Engine 2.0L, code AVH, AZG, BEV, BHP. |
| (5) | Engine 1.9L, codes ALH, BEW, from model year 2003 to model year 2005. |
IDENTIFYING INSIDE HOUSING RELAYS (ENGINE COMPARTMENT - LEFT SIDE)
Location Of Additional Relay Panel In Plenum Chamber, Center - From June 2003 To December 2006
The additional relay panel is located in the center of the plenum chamber in the engine compartment. The Automatic Glow Time Control Module (-J179-) is located at the additional relay panel, refer to illustration below.
Scheme 15
Scheme 15: Location Of Additional Relay Panel In Plenum Chamber, Center - From June 2003 To December 2006
