Seat Frames (Hatchback): Overview Volkswagen Beetle A4

Seats 9 illustrations ~274 words

Scheme 46

Scheme 46: FRONT BACKREST ASSEMBLY OVERVIEW
Scheme 46: FRONT BACKREST ASSEMBLY OVERVIEW
  1. Right Seat Trim
  2. Bolt for Right Trim
  3. Right Cover Cap
  4. Seat
  5. Backrest
  6. Left Cover Cap
  7. Adjusting Knob (Backrest)
  8. Cover Qty. 2
  9. Bolt Qty. 2
  10. Adjusting Lever (Seat Height)
  11. Left Seat Trim
  12. Bolt for Left Trim

Scheme 47

Scheme 47: SEAT HEIGHT ADJUSTMENT ASSEMBLY OVERVIEW
Scheme 47: SEAT HEIGHT ADJUSTMENT ASSEMBLY OVERVIEW
  1. Seat Trim Right front
  2. Bolt
  3. Right Cover Cap
  4. Seat
  5. Backrest
  6. Transfer Rod For backrest adjustment
  7. Adjustment Knob For lumbar support
  8. Left Cover Cap
  9. Spacer Ring
  10. Adjustment Knob For backrest
  11. Cover Qty. 2
  12. Bolt Qty. 2
  13. Adjusting Lever For seat height
  14. Seat Trim Left front
  15. Seat Height Adjusting Element
  16. Tension Spring Qty. 2
  17. Bolt

Scheme 48

Scheme 48: PASSENGER SIDE FIRE EXTINGUISHER BRACKET ASSEMBLY OVERVIEW
Scheme 48: PASSENGER SIDE FIRE EXTINGUISHER BRACKET ASSEMBLY OVERVIEW
  1. Passenger Seat
  2. Combination Nut
  3. Screw
  4. Fire Extinguisher
  5. Fire Extinguisher Bracket
  6. Bolt Qty. 2

Scheme 49

Scheme 49: BACKREST FRAME ASSEMBLY OVERVIEW THROUGH 04/03 AND CONVERTIBLE
Scheme 49: BACKREST FRAME ASSEMBLY OVERVIEW THROUGH 04/03 AND CONVERTIBLE
  1. Backrest Frame
  2. Actuating Lever
  3. Catches
  4. Bolt 20 Nm Insert with locking fluid D 000 600 A2
  5. Cable Guide
  6. Cable
  7. Spring

Scheme 50

Scheme 50: BACKREST FRAME ASSEMBLY OVERVIEW FROM 05.2003
Scheme 50: BACKREST FRAME ASSEMBLY OVERVIEW FROM 05.2003
  1. Backrest Frame
  2. Active Headrest Guide
  3. Actuating Lever
  4. Backrest Release Cable Removing «BACKREST RELEASE CONTROL CABLE FROM 05.2003»(ref-492768-S42923096062012080600000)
  5. Lumbar Support Frame Removing «LUMBAR SUPPORT FRAME FROM 05.2003»(ref-492768-S39850781592012080600000)
  6. Catches
  7. Bolt 20 Nm Insert with locking fluid D 000 600 A2
  8. Spring

Scheme 51

Scheme 51: ONE PIECE BACKREST LOCK ASSEMBLY OVERVIEW
Scheme 51: ONE PIECE BACKREST LOCK ASSEMBLY OVERVIEW
  1. Release Rod
  2. Catches
  3. Bolts
  4. Rear Bulkhead
  5. Cushion
  6. Cover
  7. Cushion Wire
  8. Button
  9. Connecting Rod
  10. Clips

Scheme 52

Scheme 52: PASS-THROUGH HATCH ASSEMBLY OVERVIEW, CONVERTIBLE
Scheme 52: PASS-THROUGH HATCH ASSEMBLY OVERVIEW, CONVERTIBLE
  1. Cover
  2. Bolt 20 Nm Only for vehicles with ski bag.
  3. Ski Sack Tether Only for vehicles with ski bag.
  4. Pass-through
  5. Bolt Qty: 4 10 Nm
  6. Lid

Scheme 53

Scheme 53: RIGHT TWO PIECE BACKREST LOCK ASSEMBLY OVERVIEW
Scheme 53: RIGHT TWO PIECE BACKREST LOCK ASSEMBLY OVERVIEW
  1. Release Rod
  2. Clips
  3. Cushion
  4. Cover
  5. Cushion Wire
  6. Button
  7. Bolts
  8. Rear Bulkhead
  9. Catches
  10. Connecting Rod

Scheme 54

Scheme 54: LEFT TWO PIECES BACKREST LOCK ASSEMBLY OVERVIEW
Scheme 54: LEFT TWO PIECES BACKREST LOCK ASSEMBLY OVERVIEW
  1. Release Rod
  2. Connecting Rod
  3. Catches
  4. Bolts
  5. Rear Bulkhead
  6. Mounting Pins
  7. Cushion
  8. Cushion Wire
  9. Cover
  10. Button Must be removed together with cover and upholstery. Refer to «LEFT BACKREST COVER AND CUSHION ASSEMBLY OVERVIEW»(ref-492836-S41865895972012080600000)
  11. Clip
  12. Operating Rod
  13. Release Rod
  14. Clips
