Engine Mechanical: Overview Toyota Sienna II рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. INSPECT ENGINE COOLANT Inspect the engine coolant (See «ON-VEHICLE INSPECTION»(/toyota/sienna/ii-2005-2010/remont/cooling-system-mechanical/#engine-cooling-system) ).
2. INSPECT ENGINE OIL Inspect the engine oil (See «ON-VEHICLE INSPECTION»(ref-282120-S14159757662008032900000) ).
3. INSPECT BATTERY Inspect the battery (See «ON-VEHICLE INSPECTION»(ref-282138-S29162257172008032900000) ).
4. INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Remove the air cleaner filter element sub-assembly. Visually check that there is no dirt, blockage, and/or damage to the air cleaner filter element. HINT: If there is any dirt or a blockage in the air cleaner filter element, clean it with compressed air. If any dirt or a blockage remains even after cleaning the air cleaner filter element with compressed air, replace it.
5. INSPECT SPARK PLUG Inspect the spark plugs (See «ON-VEHICLE INSPECTION»(ref-282119-S40607079252008032900000) ).
6. INSPECT VALVE LASH ADJUSTER NOISE Rev up the engine several times. Check that the engine does not emit unusual noises. If unusual noises occur, warm up the engine and idle it for over 30 minutes. Then repeat this procedure. HINT: If any defects or problems are found during the inspection above, perform lash adjuster inspection (See «INSPECTION»(ref-282118-S28166806962008032900000) ).
7. INSPECT IGNITION TIMING Warm up the engine. When using the intelligent tester: Check the ignition timing. Connect the intelligent tester to the DLC3. Enter DATA LIST mode with the intelligent tester. Ignition timing: 8 to 12° BTDC at idle HINT: Refer to the intelligent tester operator's manual for help when selecting the DATA LIST. When not using the intelligent tester: Check the ignition timing. Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3. SST 09843-18040 NOTE: Confirm the terminal numbers before connecting them. Connection with a wrong terminal can damage the engine. Turn off all electrical systems before connecting the terminals. Perform this inspection after the cooling fan motor is turned off. Remove the V-bank cover. Pull out the red lead wire harness. Connect the tester terminal of the timing light to the red lead wire as shown in the illustration. NOTE: Use a timing light which can detect the first signal. Check the ignition timing at idle. Ignition timing: 8 to 12° BTDC at idle NOTE: When checking the ignition timing, the transmission should be in neutral. HINT: Run the engine at 1000 to 1300 rpm for 5 seconds, and then check that the engine rpm returns to idle speed. Disconnect terminals 13 (TC) and 4 (CG) of the DLC3. Check the ignition timing at idle. Ignition timing: 7 to 24° BTDC at idle Confirm that the ignition timing moves to the advanced angle side when the engine rpm is increased. Remove the timing light.
8. INSPECT ENGINE IDLE SPEED Warm up the engine. When using the intelligent tester: Check the idle speed. Connect the intelligent tester to the DLC3. Enter DATA LIST mode with the intelligent tester. Idle speed: 600 to 700 rpm NOTE: When checking the idle speed, the transmission should be in neutral. Check the idle speed with the cooling fan off. Switch off all accessories and air conditioning before connecting the intelligent tester. HINT: Refer to the intelligent tester operator's manual for further details. When not using the intelligent tester: Check the idle speed. Using SST, connect the tachometer test probe to terminal 9 (TAC) of the DLC3. SST 09843-18030 Check the idle speed. Idle speed: 600 to 700 rpm
9. INSPECT COMPRESSION Warm up and stop the engine. Disconnect the injector connectors. Remove the intake air surge tank (See «REMOVAL»(/toyota/sienna/ii-2005-2010/remont/testing-diagnostics/#engine-control-system) ). Remove the 6 ignition coils. Remove the 6 spark plugs. Check the cylinder compression pressure. Insert a compression gauge into the spark plug hole. While cranking the engine, measure the compression pressure. Compression pressure: 1.3 MPa (13 kgf/cm 2 , 189 psi) Minimum pressure: 0.98 MPa (10 kgf/cm 2 , 142 psi) Difference between each cylinder: 0.1 MPa (1.0 kgf/cm 2 , 15 psi) NOTE: Always use a fully charged battery to obtain an engine speed of 250 rpm or more. Check the other cylinders' compression pressure in the same way. This measurement must be done as quickly as possible. If the cylinder compression is low, pour a small amount of engine oil into the cylinder through the spark plug hole and inspect again. HINT: If adding oil increases the compression, the piston rings and/or cylinder bore may be worn or damaged. If pressure stays low, a valve may be stuck or seated improperly, or there may be leakage in the gasket. Install the 6 spark plugs. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) Install the 6 ignition coils. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Install the intake air surge tank (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/testing-diagnostics/#engine-control-system) ).
10. INSPECT CO/HC Start the engine. Run the engine at 2500 rpm for approximately 180 seconds. Insert the CO/HC meter testing probe at least 40 cm (1.3 ft.) into the tailpipe during idling. Check CO/HC concentration at idle and/or 2500 rpm. HINT: Check regulations and restrictions in your area when performing 2 mode CO/HC concentration testing (engine check at both idle speed and at 2500 rpm). If the CO/HC concentration does not comply with regulations, perform troubleshooting in the order given below. Check air fuel ratio sensor and heated oxygen sensor operation. See the table below for possible causes, and then inspect and repair. CO AND HC SPECIFICATIONS CO HC Problems Causes Normal High Rough idle Faulty ignitions: Incorrect timing Fouled, shorted or improperly gapped plugs Incorrect valve clearance Leaks in intake and exhaust valves Leaks in cylinders Low High Rough idle (fluctuating HC reading) Vacuum leaks: PCV hoses Intake manifold Throttle body Brake booster line Lean mixture causing misfire High High Rough idle (black smoke from exhaust) Restricted air filter Plugged PCV valve Faulty SFI system: Faulty fuel pressure regulator Defective ECT sensor Defective MAF meter Faulty ECM Faulty injectors Faulty throttle position sensor

Scheme 6

Scheme 7

Scheme 8

1. REMOVE FRONT WHEEL RH
2. REMOVE FRONT FENDER APRON SEAL RH (See «REMOVAL»(ref-282118-S19305882932008032900000) )
3. REMOVE V-RIBBED BELT Using SST, release the belt tension by turning the belt tensioner counterclockwise, and remove the V-ribbed belt from the belt tensioner. SST 09249-63010 While turning the belt tensioner counterclockwise, align with its holes, and then insert the 5 mm bi-hexagon wrench into the holes to fix the V-ribbed belt tensioner.

Scheme 9

1. INSPECT V-RIBBED BELT Visually check the V-ribbed belt for excessive wear, frayed cords, etc. If any defect has been found, replace the V-ribbed belt. HINT: Cracks on the rib side of a V-ribbed belt are considered acceptable. If the drive belt has chunks missing from its ribs, it should be replaced. HINT: A "new belt" is a belt which has been used for less than 5 minutes with the engine running. A "used belt" is a belt which has been used for 5 minutes or more with the engine running.
2. INSPECT V-RIBBED BELT TENSIONER ASSEMBLY Check that nothing gets caught in the tensioner by turning it clockwise and counterclockwise. If a malfunction exists, replace the tensioner.

Scheme 10

1. INSTALL V-RIBBED BELT Install the V-ribbed belt. Using SST, turn the belt tensioner counterclockwise and remove the bar. SST 09249-63010 If it is difficult to install the V-ribbed belt, perform the following procedure: Put the V-ribbed belt on every pulley except the tensioner pulley as shown in the illustration. While releasing the belt tension by turning the belt tensioner counterclockwise, put the V-ribbed belt on the tensioner pulley. NOTE: Put the backside of the V-ribbed belt on the tensioner pulley and idler pulley. Check that the V-ribbed belt is properly set to each pulley. After installing the V-ribbed belt, check that it fits properly in the ribbed grooves. Confirm that the belt has not slipped out of the grooves on the bottom of the crank pulley by hand.
2. INSTALL FRONT FENDER APRON SEAL RH (See «INSTALLATION»(ref-282118-S40760919202008032900000) )
3. INSTALL FRONT WHEEL RH Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. REMOVE FRONT WHEEL RH
2. REMOVE FRONT FENDER APRON SEAL RH (See «REMOVAL»(ref-282118-S19305882932008032900000) )
3. REMOVE V-RIBBED BELT (See «REMOVAL»(ref-282118-S17149964562008032900000) )
4. REMOVE CRANKSHAFT PULLEY Using SST, loosen the crankshaft pulley bolt. SST 09213-70011 (09213-70020), 09330-00021 Using SST, remove the crankshaft pulley bolt and crankshaft pulley. SST 09950-50013 (09951 -05010, 09952-05010, 09953-05020, 09954-05021)
5. REMOVE TIMING CHAIN CASE OIL SEAL Using a screwdriver, pry out the oil seal. HINT: Tape the screwdriver tip before use. NOTE: After the removal, check the crankshaft for damage. If it is damaged, smooth the surface with 400-grit sandpaper.

Scheme 15

Scheme 16

1. INSTALL TIMING CHAIN CASE OIL SEAL Apply MP grease to a new oil seal lip. Using SST and a hammer, tap in the oil seal until its surface is flush with the timing chain cover edge. SST 09223-22010,09506-35010 NOTE: Keep the lip free of foreign matter. Do not tap the oil seal at an angle.
2. INSTALL CRANKSHAFT PULLEY Align the pulley set key with the key groove of the pulley, and slide on the pulley. Using SST, install the pulley bolt. SST 09213-70011 (09213-70020), 09330-00021 Torque: 250 N*m (2550 kgf*cm, 184 ft.*lbf)
3. INSTALL V-RIBBED BELT (See «INSTALLATION»(ref-282118-S19865219352008032900000) )
4. INSTALL FRONT FENDER APRON SEAL RH (See «INSTALLATION»(ref-282118-S40760919202008032900000) )
5. INSTALL FRONT WHEEL RH Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY (for 2WD) HINT: See «REMOVAL»(ref-282123-S29950818542008032900000).
2. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY (for 4WD) HINT: See «REMOVAL»(ref-282124-S18647114842008032900000).
3. REMOVE DRIVE PLATE AND RING GEAR SUB-ASSEMBLY Using SST, hold the crankshaft. SST 09213-70011 (09213-70020), 09330-00021 Remove the 8 bolts, front spacer, drive plate and rear spacer.
4. REMOVE ENGINE REAR OIL SEAL Using a knife, cut off the oil seal lip. Using a screwdriver, pry out the oil seal. NOTE: Be careful not to damage the crankshaft. Tape the screwdriver tip before use.

Scheme 21

Scheme 22

Scheme 23

1. INSTALL ENGINE REAR OIL SEAL Apply MP grease to a new oil seal lip. Using SST and a hammer, tap in the oil seal. SST 09223-15030, 09950-70010 (09951 -07150) Oil seal tap in depth: -0.5 to 0.5 mm (-0.020 to 0.020 in.)
2. INSTALL DRIVE PLATE AND RING GEAR SUB-ASSEMBLY Using SST, hold the crankshaft. SST 09213-70011 (09213-70020), 09330-00021 Apply adhesive to 2 or 3 threads of the mounting bolt end. Adhesive: Part No. 08833-00070, THREE BOND 1324 or equivalent Install the front spacer, drive plate and rear spacer on the crankshaft. Install and tighten the 8 mounting bolts uniformly in several steps. Torque: 83 N*m (850 kgf*cm, 61 ft.*lbf)
3. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for 2WD) HINT: See «REMOVAL»(ref-282124-S18647114842008032900000).
4. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for 4WD) HINT: See «INSTALLATION»(ref-282123-S32069079032008032900000).

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

1. DISCHARGE FUEL SYSTEM PRESSURE (See «REMOVAL»(ref-282130-S04614499162008032900000) )
2. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-282137-S30833749012008032900000) )
3. REMOVE BATTERY Disconnect the negative battery terminal. Disconnect the positive battery terminal. Loosen the nut, and remove the bolt and battery clamp. Remove the battery and battery tray.
4. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
5. REMOVE FRONT WHEELS
6. REMOVE NO. 1 ENGINE UNDER COVER ASSEMBLY Remove the 8 bolts, 4 clips and No. 1 engine under cover assembly.
7. REMOVE FRONT FENDER APRON SEAL RH Remove the 2 bolts, clip and front fender apron seal RH.
8. REMOVE FRONT FENDER APRON SEAL LH Remove the 2 bolts, clip and front fender apron seal LH.
9. DRAIN ENGINE OIL (See «REPLACEMENT»(ref-282120-S40619786932008032900000) )
10. DRAIN ENGINE COOLANT (See «REPLACEMENT»(/toyota/sienna/ii-2005-2010/remont/cooling-system-mechanical/#engine-cooling-system) )
11. DRAIN AUTOMATIC TRANSAXLE FLUID (See «REMOVAL»(ref-282123-S35324199902008032900000) )
12. REMOVE FRONT WIPER ARM HEAD CAP (See «REMOVAL»(ref-282135-S06482974872008032900000) )
13. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH (See «REMOVAL»(ref-282135-S06482974872008032900000) )
14. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH (See «REMOVAL»(ref-282135-S06482974872008032900000) )
15. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «REMOVAL»(ref-282135-S06482974872008032900000) )
16. REMOVE FRONT WIPER MOTOR AND LINK ASSEMBLY (See «REMOVAL»(ref-282135-S06482974872008032900000) )
17. REMOVE NO. 1 COWL TOP TO COWL BRACE INNER Remove the 2 bolts, 2 clips and No. 1 cowl top to cowl brace inner.
18. REMOVE FRONT OUTER COWL TOP PANEL SUB-ASSEMBLY Remove the nut, and separate the fuel pump resistor. Remove the 2 clips, and separate the engine wire. Remove the 7 bolts and front outer cowl top panel sub-assembly.
19. REMOVE V-BANK COVER SUB-ASSEMBLY Hold the front of the V-bank cover and raise it to disengage the 2 clips on the front of the cover. Continue to raise the cover to disengage the clip on the rear of the cover and remove the cover. NOTE: Attempting to disengage both front and rear clips at the same time may cause the cover to break.
20. REMOVE NO. 2 AIR CLEANER INLET Disconnect the vacuum switching valve clamp. Disconnect the 2 vacuum hoses. Remove the 2 bolts and No. 2 air cleaner inlet.
21. REMOVE NO. 1 AIR CLEANER INLET Remove the bolt and No. 1 air cleaner inlet.
22. REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See «REMOVAL»(ref-282133-S03062470472008032900000) )
23. REMOVE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Remove the air cleaner filter element sub-assembly.
24. REMOVE AIR CLEANER CASE SUB-ASSEMBLY Disconnect the vacuum switching valve connector. Disconnect the vacuum hose. Remove the 3 bolts and air cleaner case.
25. REMOVE AIR CLEANER BRACKET Remove the 2 bolts and air cleaner bracket.
26. REMOVE INTAKE AIR RESONATOR SUB-ASSEMBLY Remove the clip, bolt and intake air resonator.
27. REMOVE NO. 2 ENGINE MOUNTING STAY RH Remove bolt, 2 nuts and No. 2 engine mounting stay RH.
28. REMOVE ENGINE MOVING CONTROL ROD Remove the 3 bolts and engine moving control rod.
29. DISCONNECT NO. 1 FUEL VAPOR FEED HOSE Remove the clamp and disconnect the No. 1 fuel vapor feed hose.
30. DISCONNECT RADIATOR INLET HOSE Using pliers, grip the claws of the clip and slide the clip to disconnect radiator inlet hose from the water outlet.
31. DISCONNECT RADIATOR OUTLET HOSE Using pliers, grip the claws of the clip and slide the clip to disconnect the radiator outlet hose from the water inlet.
32. DISCONNECT HEATER WATER OUTLET HOSE B Using pliers, grip the claws of the clip and slide the clip to disconnect heater water inlet hose B from the water inlet.
33. DISCONNECT HEATER WATER INLET HOSE B Using pliers, grip the claws of the clip and slide the clip to disconnect heater water outlet hose B from the water outlet.
34. DISCONNECT FUEL TUBE SUB-ASSEMBLY Remove the No. 1 fuel pipe clamp. Disconnect the fuel tube from the fuel pipe while pinching part A with your fingers as shown in the illustration. NOTE: Check for contamination in the pipe and around the connector. Clean if necessary and then disconnect the connector. Disconnect the connector by hand. Do not bend, fold or rotate the nylon tube. If the pipe and connector are stuck together, push and pull the connector until it becomes free. Put the pipe and connector ends in vinyl bags to prevent damage and contamination.
35. DISCONNECT NO. 1 OIL COOLER INLET HOSE Using pliers, grip the claws of the clip and slide the clip to disconnect the No. 1 oil cooler inlet hose from the No. 1 oil cooler inlet tube.
36. REMOVE NO. 1 OIL COOLER OUTLET HOSE Using pliers, grip the claws of the clip and slide the clip to disconnect the No. 1 oil cooler outlet hose from the No. 1 oil cooler outlet tube.
37. DISCONNECT TRANSMISSION CONTROL CABLE ASSEMBLY Remove the nut from the control shaft lever. Disconnect the transmission control cable assembly from the control shaft lever. Remove the clip and disconnect the transmission control cable assembly from the control cable bracket. Disconnect the control cable from the control cable clamp.
38. DISCONNECT RETURN TUBE SUB-ASSEMBLY Using pliers, grip the claws of the 2 clips and slide the 2 clips to disconnect the 2 return tube sub-assemblies. Drain the power steering fluid. NOTE: Take care not to damage the hose protector.
39. DISCONNECT NO. 1 OIL RESERVOIR TO PUMP HOSE Using pliers, grip the claws of the clip and slide the clip to disconnect the No. 1 oil reservoir to pump hose from the oil reservoir tank.
40. DISCONNECT ENGINE WIRE Disconnect the engine wire from the engine room junction block. Remove the nut and separate the wire harness. Using a screwdriver, unlock the engine room junction block. Pull the engine room junction block upward. Remove the bolt and 2 clamps from the body. Remove the 2 bolts and 2 ground cables. Disconnect the engine wire from the ECM and passenger side junction block.
41. DISCONNECT UNION TO CHECK VALVE HOSE Using pliers, grip the claws of the clip and slide the clip to disconnect the union to check valve hose.
42. REMOVE CENTER EXHAUST PIPE ASSEMBLY (for 4WD) Remove the center exhaust pipe assembly (See «REMOVAL»(/toyota/sienna/ii-2005-2010/remont/exhaust/#engine-exhaust-assembly) ).
43. REMOVE FRONT EXHAUST PIPE ASSEMBLY (for 4WD) Remove the front exhaust pipe assembly (See «REMOVAL»(/toyota/sienna/ii-2005-2010/remont/exhaust/#engine-exhaust-assembly) ).
44. REMOVE FRONT EXHAUST PIPE ASSEMBLY (for 2WD) Remove the front exhaust pipe assembly (See «REMOVAL»(/toyota/sienna/ii-2005-2010/remont/exhaust/#engine-exhaust-assembly) ).
45. REMOVE PROPELLER WITH CENTER BEARING SHAFT ASSEMBLY (See «REMOVAL»(/toyota/sienna/ii-2005-2010/remont/driveshaft-universal-joints/#propeller-shaft) )
46. DISCONNECT FRONT STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-282140-S10637578252008032900000) )
47. DISCONNECT FRONT STABILIZER LINK ASSEMBLY RH HINT: Use the same procedures described for the LH side.
48. REMOVE FRONT AXLE HUB NUT LH (See «REMOVAL»(ref-282140-S10637578252008032900000) )
49. REMOVE FRONT AXLE HUB NUT RH HINT: Use the same procedures described for the LH side.
50. DISCONNECT FRONT SPEED SENSOR LH (See «REMOVAL»(ref-282140-S10637578252008032900000) )
51. DISCONNECT FRONT SPEED SENSOR RH HINT: Use the same procedures described for the LH side.
52. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-282140-S10637578252008032900000) )
53. DISCONNECT TIE ROD ASSEMBLY RH HINT: Use the same procedures described for the LH side.
54. SEPARATE FRONT SUSPENSION LOWER NO. 1 ARM LH (See «REMOVAL»(ref-282140-S10637578252008032900000) )
55. SEPARATE FRONT SUSPENSION LOWER NO. 1 ARM RH HINT: Use the same procedures described for the LH side.
56. SEPARATE FRONT AXLE ASSEMBLY LH (See «REMOVAL»(ref-282140-S10637578252008032900000) )
57. SEPARATE FRONT AXLE ASSEMBLY RH HINT: Use the same procedures described for the LH side.
58. DISCONNECT STEERING INTERMEDIATE SHAFT SUB-ASSEMBLY
59. DISCONNECT DISCHARGE HOSE SUB-ASSEMBLY (See «REMOVAL»(ref-282137-S39944606562008032900000) )
60. DISCONNECT SUCTION HOSE SUB-ASSEMBLY (See «REMOVAL»(ref-282137-S39944606562008032900000) )
61. REMOVE ENGINE ASSEMBLY WITH TRANSAXLE Set the engine lifter. Remove the 6 bolts, 2 nuts, and frame side rail plates RH and LH. Remove the 6 bolts, 2 nuts, and front suspension member brace rear RH and LH. Operate the engine lifter, then remove the engine assembly from the vehicle. NOTE: Make sure that the engine is clear of all wiring and hoses.
62. REMOVE V-RIBBED BELT (See «REMOVAL»(ref-282118-S17149964562008032900000) )
63. REMOVE VANE PUMP ASSEMBLY Disconnect the power steering oil pressure switch connector. Remove the 2 nuts. Loosen the bolt A. Remove the bolt B. Remove the bolt A and vane pump assembly.
64. REMOVE FRONT STABILIZER BAR (for 4WD) HINT: See «REMOVAL»(ref-282141-S39582275072008032900000).
65. REMOVE POWER STEERING LINK Remove the 2 bolts and power steering link with vane pump.
66. INSTALL ENGINE HANGERS Install the 2 engine hangers with the 4 bolts as shown in the illustration. Part No.: No. 1 Engine hanger 12281-31120 No. 2 Engine hanger 12282-31100 Bolts 91671-10825 Torque: 33 N*m (337 kgf*cm, 24 ft.*lbf) Attach the engine sling device and hang the engine with the chain block.
67. REMOVE FRONT FRAME ASSEMBLY Disconnect the active mount VSV connector and harness clamp. Remove the 2 nuts and disconnect the engine mounting insulators RH and LH. Remove the bolt and disconnect the engine mounting insulator FR. Remove the 2 bolts and separate the engine mounting insulator RR (for 4WD).
68. REMOVE FRONT DRIVE SHAFT ASSEMBLY LH (See «REMOVAL»(ref-282140-S10637578252008032900000) )
69. REMOVE FRONT DRIVE SHAFT ASSEMBLY RH (for 2WD) (See «REMOVAL»(ref-282140-S10637578252008032900000) )
70. REMOVE FRONT DRIVE SHAFT ASSEMBLY RH (for 4WD) (See «REMOVAL»(ref-282140-S10637578252008032900000) )
71. REMOVE ENGINE WIRE
72. REMOVE STARTER ASSEMBLY (See «REMOVAL»(ref-282132-S21195305772008032900000) )
73. REMOVE ENGINE FRONT MOUNTING BRACKET (See «REMOVAL»(ref-282123-S29950818542008032900000) )
74. REMOVE MANIFOLD STAY Remove the bolt, nut, and manifold stay.
75. REMOVE TRANSFER STIFFENER PLATE RH (See «REMOVAL»(ref-282124-S18647114842008032900000) )
76. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY (for 2WD) HINT: See «REMOVAL»(ref-282123-S29950818542008032900000).
77. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY (for 4WD) «REMOVAL»(ref-282124-S18647114842008032900000)
78. REMOVE DRIVE PLATE AND RING GEAR SUB-ASSEMBLY (See «REMOVAL»(ref-282118-S34743904582008032900000) )
79. SECURE ENGINE Secure the engine onto an engine stand with the bolts. Remove the engine hangers.
80. REMOVE VENTILATION HOSE Using pliers, grip the claws of the 2 clips and slide the 2 clips to remove the ventilation hose.
81. REMOVE INTAKE AIR SURGE TANK ASSEMBLY Disconnect the 2 water by-pass hoses from the throttle with motor body assembly (*1). Disconnect the vapor feed hose (*2). Disconnect the throttle with motor body assembly connector and clamp (*3). Disconnect the No. 1 ventilation hose. Disconnect the connector. Remove the 4 bolts, No. 1 surge tank stay and throttle body bracket. Using a 5 mm socket hexagon wrench, remove the 4 bolts. Remove the 2 nuts and intake air surge tank (*4). Remove the gasket from the intake air surge tank (*5).
82. REMOVE IGNITION COIL ASSEMBLY Remove the 6 bolts and 6 ignition coils.
83. REMOVE NO. 2 ENGINE MOUNTING STAY RH Remove the bolt and No. 2 engine mounting stay RH.
84. REMOVE INTAKE MANIFOLD Uniformly loosen and remove the 6 bolts and 4 nuts. Remove the intake manifold and 2 gaskets.
85. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY RH Disconnect the A/F sensor connector clamp. Uniformly loosen and remove the 6 nuts. Remove the manifold and gasket.
86. REMOVE OIL LEVEL GAUGE GUIDE SUB-ASSEMBLY Remove the oil level gauge. Remove the 2 bolts, No. 1 and No. 2 oil level gauge guides. Remove the O-rings from the oil level gauge guide.
87. REMOVE NO. 2 MANIFOLD STAY Remove the bolt, nut and No. 2 manifold stay.
88. REMOVE NO. 2 EXHAUST MANIFOLD HEAT INSULATOR Remove the 3 bolts and No. 2 insulator.
89. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY LH Uniformly loosen and remove the 6 nuts. Remove the manifold and gasket.
90. REMOVE ENGINE MOUNTING BRACKET RH Remove the engine mounting bracket and 3 bolts.
91. REMOVE DRIVE SHAFT BEARING BRACKET (for 2WD) Remove the 3 bolts and drive shaft bearing bracket.
92. REMOVE ENGINE MOUNTING BRACKET RR (for 4WD) Remove the 3 bolts and engine mounting bracket RR.
93. REMOVE GENERATOR ASSEMBLY (See «REMOVAL»(ref-282138-S18712029282008032900000) )
94. REMOVE COOLER COMPRESSOR ASSEMBLY
95. REMOVE V-RIBBED BELT TENSIONER ASSEMBLY Remove the 5 bolts and V-ribbed belt tensioner assembly.
96. REMOVE NO. 2 TIMING GEAR COVER Remove the 2 bolts and No. 2 timing gear cover.
97. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY Remove the bolt, plate and No. 2 idler pulley sub-assembly.
98. REMOVE WATER PUMP PULLEY (See «REMOVAL»(/toyota/sienna/ii-2005-2010/remont/cooling-system-mechanical/#engine-cooling-system) )
99. REMOVE NO. 1 ENGINE FRONT MOUNTING BRACKET LH Remove the 6 bolts and No. 1 engine front mounting bracket LH.
100. REMOVE RADIO SETTING CONDENSER Remove the 2 bolts and 2 radio setting condensers.
101. REMOVE NO. 1 VACUUM SWITCHING VALVE ASSEMBLY Remove the bolt and No. 1 vacuum switching valve.
102. REMOVE ENGINE OIL PRESSURE SWITCH ASSEMBLY Using a 24 mm deep socket wrench, remove the engine oil pressure switch assembly.
103. REMOVE KNOCK CONTROL SENSOR (See «REMOVAL»(/toyota/sienna/ii-2005-2010/remont/testing-diagnostics/#engine-control-system) )
104. REMOVE ENGINE COOLANT TEMPERATURE SENSOR Using a 19 mm deep socket wrench, remove the EFI engine coolant temperature sensor and gasket.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

1. INSPECT EXHAUST MANIFOLD SUB-ASSEMBLY LH Using a precision straightedge and feeler gauge, measure the warpage on the contact surface of the cylinder head. Maximum warpage: 0.7 mm (0.028 in.) HINT: The maximum allowable warpage of each installation surface is 0.3 mm (0.012 in.). If the warpage is greater than the maximum, replace the manifold.
2. INSPECT EXHAUST MANIFOLD SUB-ASSEMBLY RH Using a precision straightedge and feeler gauge, measure the warpage on the contact surface of the cylinder head. Maximum warpage: 0.7 mm (0.028 in.) HINT: The maximum allowable warpage of each installation surface is 0.3 mm (0.012 in.). If the warpage is greater than the maximum, replace the manifold.
3. INSPECT INTAKE AIR SURGE TANK ASSEMBLY Using a precision straightedge and feeler gauge, measure the warpage on the contact surface of the intake manifold. Maximum warpage: 2.5 mm (0.098 in.) If the warpage is greater than the maximum, replace the surge tank.
4. INSPECT INTAKE MANIFOLD Cylinder head side: Using a precision straightedge and feeler gauge, measure the surface contacting the cylinder head for warpage. Maximum warpage: 0.1 mm (0.003 in.) If the warpage is greater than the maximum, replace the intake manifold. Surge tank side: Using a precision straightedge and feeler gauge, measure the surface contacting the surge tank for warpage. Maximum warpage: 0.1 mm (0.003 in.) If the warpage is greater than the maximum, replace the intake manifold.

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

1. INSTALL ENGINE COOLANT TEMPERATURE SENSOR Using a 19 mm deep socket wrench, install the engine coolant temperature sensor and a new gasket. Torque: 20 N*m (200 kgf*cm, 14 ft.*lbf)
2. INSTALL KNOCK CONTROL SENSOR (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/testing-diagnostics/#engine-control-system) )
3. INSTALL ENGINE OIL PRESSURE SWITCH ASSEMBLY Clean the threads of the oil pressure switch. Apply adhesive to 2 or 3 threads of the oil pressure switch. Adhesive: Part No. 08833-00080, THREE BOND 1344, LOCTITE 242 or equivalent Using a 24 mm deep socket wrench, install the oil pressure switch. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) NOTE: Do not start the engine within 1 hour after installation to prevent oil leaks.
4. INSTALL NO. 1 VACUUM SWITCHING VALVE ASSEMBLY Install the bolt and No. 1 vacuum switching valve. Torque: 10 N*m (102 kgf*cm, 7 ft.lbf)
5. INSTALL RADIO SETTING CONDENSER Install the 2 bolts and 2 radio setting condensers. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
6. INSTALL NO. 1 ENGINE FRONT MOUNTING BRACKET LH Install the No. 1 engine front mounting bracket LH with the 6 bolts. Torque: 54 N*m (551 kgf*cm, 40 ft.*lbf)
7. INSTALL WATER PUMP PULLEY (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/cooling-system-mechanical/#engine-cooling-system) )
8. INSTALL NO. 2 IDLER PULLEY SUB-ASSEMBLY Install the No. 2 idler pulley sub-assembly and cover plate with the bolt. Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
9. INSTALL NO. 2 TIMING GEAR COVER Install the No. 2 timing gear cover with the 2 bolts. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf)
10. INSTALL V-RIBBED BELT TENSIONER ASSEMBLY Temporarily install the V-ribbed belt tensioner with the 5 bolts. HINT: Each bolt length is as follows: 70 mm (2.76 in.) 33 mm (1.30 in.) Install the V-ribbed belt tensioner by tightening the bolt 1 and bolt 2 in the order shown in the illustration. Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf) Tighten the other bolts. Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
11. INSTALL GENERATOR ASSEMBLY (See «INSTALLATION»(ref-282138-S17636903212008032900000) )
12. INSTALL COOLER COMPRESSOR ASSEMBLY (See «INSTALLATION»(ref-282137-S26268437692008032900000) )
13. INSTALL ENGINE MOUNTING BRACKET RR (for 4WD) Install the engine mounting bracket RR with the 3 bolts. Torque: 64 N*m (650 kgf*cm, 47 ft.*lbf)
14. INSTALL DRIVE SHAFT BEARING BRACKET (for 2WD) Install the drive shaft bearing bracket with the 3 bolts. Torque: 64 N*m (650 kgf*cm, 47 ft.lbf)
15. INSTALL ENGINE MOUNTING BRACKET RH Install the engine mounting bracket RH with the 3 bolts. Torque: 54 N*m (551 kgf*cm, 40 ft.*lbf)
16. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY LH Install a new gasket as shown in the illustration. Install the exhaust manifold sub-assembly LH with the 6 nuts in the order shown in the illustration. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
17. INSTALL NO. 2 EXHAUST MANIFOLD HEAT INSULATOR Install the No. 2 insulator with the 3 bolts. Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf)
18. INSTALL NO. 2 MANIFOLD STAY Install the No. 2 manifold stay with the bolt and nut in the order shown in the illustration. Torque: 34 N*m (347 kgf*cm, 25 ft.*lbf)
19. INSTALL OIL LEVEL GAUGE GUIDE SUB-ASSEMBLY Install 2 new O-rings to the oil level gauge guide. Apply a light coat of engine oil to the O-rings. Push in the oil level gauge guide end into the guide hole. Install the No. 1 oil level gauge guide with the bolt. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Install the No. 2 oil level gauge guide with the bolt. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Install the oil level gauge.
20. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY RH Install a new gasket as shown in the illustration. Install the exhaust manifold sub-assembly RH with the 6 nuts in the order shown in the illustration. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
21. INSTALL INTAKE MANIFOLD NOTE: DO NOT apply oil to the bolts listed below: TIGHTENING TORQUE SPECIFICATIONS Tightening Parts Intake Manifold and Cylinder Head Sub-assembly RH Intake Manifold and Cylinder Head Sub-assembly LH Set a new gasket on each cylinder head. NOTE: Align the port holes of the gasket and cylinder head. Make sure that the gasket is installed in the correct direction. Set the intake manifold on the cylinder heads. Install and tighten the 6 bolts and 4 nuts uniformly in several steps. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
22. INSTALL NO. 2 ENGINE MOUNTING STAY RH Install the No. 2 mounting stay RH with the bolt. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
23. INSTALL IGNITION COIL ASSEMBLY Install the 6 ignition coil assemblies with the 6 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
24. INSTALL INTAKE AIR SURGE TANK ASSEMBLY NOTE: DO NOT apply oil to the bolts listed below: TIGHTENING TORQUE SPECIFICATIONS Tightening Parts Surge Tank and Intake Manifold No. 1 Surge Tank Stay and Cylinder Head Cover No. 1 Surge Tank Stay and Surge Tank Throttle Body Bracket and Cylinder Head Cover Throttle Body Bracket and Surge Tank Install a new gasket to the intake air surge tank. Using a 5 mm hexagon socket wrench, install the 4 bolts and 2 nuts. Torque: Bolt 18 N*m (184 kgf*cm, 13 ft.*lbf) Nut 16 N*m (163 kgf*cm, 12 ft.*lbf) Install the throttle body bracket, No. 1 surge tank stay and 4 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Connect the connector. Connect the No. 1 ventilation hose. Install the clamp and connect the throttle with motor body assembly connector. Connect the vapor feed hose. Connect the 2 water by-pass hoses to the throttle with motor body assembly.
25. INSTALL VENTILATION HOSE Using pliers, grip the claws of the 2 clips and slide the 2 clips to the intake air surge tank assembly and ventilation valve.
26. INSTALL ENGINE HANGERS Install the 4 bolts, and 2 engine hangers.
27. REMOVE ENGINE STAND
28. INSTALL DRIVE PLATE AND RING GEAR SUB-ASSEMBLY (See «INSTALLATION»(ref-282118-S42243544182008032900000) )
29. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for 2WD) HINT: See «REMOVAL»(ref-282124-S18647114842008032900000).
30. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for 4WD) HINT: (See «INSTALLATION»(ref-282123-S32069079032008032900000) ).
31. INSTALL TRANSFER STIFFENER PLATE RH (See «INSTALLATION»(ref-282123-S32069079032008032900000) )
32. INSTALL MANIFOLD STAY Install the bolt, nut, and manifold stay. Torque: 34 N*m (347 kgf*cm, 25 ft.*lbf)
33. INSTALL ENGINE FRONT MOUNTING BRACKET (See «INSTALLATION»(ref-282123-S32069079032008032900000) )
34. INSTALL STARTER ASSEMBLY (See «INSTALLATION»(ref-282132-S31065128472008032900000) )
35. INSTALL ENGINE WIRE
36. INSTALL FRONT DRIVE SHAFT ASSEMBLY LH (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
37. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH (for 2WD) (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
38. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH (for 4WD) (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
39. INSTALL FRONT FRAME ASSEMBLY Install the engine mounting insulators RH and LH with the 2 nuts. Torque: 95 N*m (969 kgf*cm, 70 ft.*lbf) Install the engine mounting insulator FR with the bolt. Torque: 87 N*m (887 kgf*cm, 64 ft.*lbf) Install the engine mounting insulator RR with the 2 bolts. Torque: 78 N*m (795 kgf*cm, 58 ft.*lbf) Connect the connector and clamp.
40. INSTALL POWER STEERING LINK (See «INSTALLATION»(ref-282142-S17953169122008032900000) )
41. INSTALL FRONT STABILIZER BAR HINT: (See «INSTALLATION»(ref-282141-S40709697052008032900000) ).
42. REMOVE ENGINE HANGERS Remove the 4 bolts and 2 engine hangers.
43. INSTALL VANE PUMP ASSEMBLY Install the vane pump with the 2 bolts and nut. Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf) Install the 2 pressure feed tube clamp nuts. Torque: 7.8 N*m (80 kgf*cm, 69 in.*lbf) Connect the power steering oil pressure switch connector.
44. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE Set the engine assembly with transaxle on the engine lifter. Install the engine assembly to the vehicle. Install the frame side rail plates RH and LH with the 6 bolts and 2 nuts. Torque: A 85 N*m (867 kgf*cm, 63 ft.*lbf) B 32 N*m (329 kgf*cm, 24 ft.*lbf) Install the front suspension member brace rear RH and LH with the 6 bolts and 2 nuts. Torque: A 85 N*m (867 kgf*cm, 63 ft.*lbf) B 32 N*m (329 kgf*cm, 24 ft.*lbf)
45. RECONNECT SUCTION HOSE SUB-ASSEMBLY (See «INSTALLATION»(ref-282137-S26268437692008032900000) )
46. RECONNECT DISCHARGE HOSE SUB-ASSEMBLY (See «INSTALLATION»(ref-282137-S26268437692008032900000) )
47. INSTALL STEERING INTERMEDIATE SHAFT SUB-ASSEMBLY (See «INSTALLATION»(ref-282115-S40618139042008032900000) )
48. INSTALL FRONT AXLE ASSEMBLY LH (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
49. INSTALL FRONT AXLE ASSEMBLY RH HINT: Use the same procedures described for the LH side.
50. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM LH (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
51. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM RH HINT: Use the same procedures described for the LH side.
52. INSTALL TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
53. INSTALL TIE ROD ASSEMBLY RH HINT: Use the same procedures described for the LH side.
54. INSTALL FRONT SPEED SENSOR LH (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
55. INSTALL FRONT SPEED SENSOR RH HINT: Use the same procedures described for the LH side.
56. INSTALL FRONT AXLE HUB NUT LH (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
57. INSTALL FRONT AXLE HUB NUT RH HINT: Use the same procedures described for the LH side.
58. INSTALL FRONT STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-282140-S33326540072008032900000) )
59. INSTALL FRONT STABILIZER LINK ASSEMBLY RH HINT: Use the same procedures described for the LH side.
60. INSTALL PROPELLER WITH CENTER BEARING SHAFT ASSEMBLY (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/driveshaft-universal-joints/#propeller-shaft) )
61. FULLY TIGHTEN PROPELLER WITH CENTER BEARING SHAFT ASSEMBLY (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/driveshaft-universal-joints/#propeller-shaft) )
62. INSTALL FRONT EXHAUST PIPE ASSEMBLY (for 2WD) Install the front exhaust pipe assembly (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/exhaust/#engine-exhaust-assembly) ).
63. INSTALL FRONT EXHAUST PIPE ASSEMBLY (for 4WD) Install front exhaust pipe assembly (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/exhaust/#engine-exhaust-assembly) ).
64. INSTALL CENTER EXHAUST PIPE ASSEMBLY Install center exhaust pipe assembly (See «INSTALLATION»(/toyota/sienna/ii-2005-2010/remont/exhaust/#engine-exhaust-assembly) ).
65. CONNECT ENGINE WIRE Install the 2 bolts and 2 ground cables. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf) Install the bolt and 2 clamps to the body. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf) Connect the wire to the engine room junction block. Then, install it with the nut. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf) Install the engine wire to the body with the 2 nuts. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
66. CONNECT NO. 1 OIL RESERVOIR TO PUMP HOSE Using pliers, grip the claws of the clip and slide the clip to connect the No. 1 oil reservoir to pump hose to the oil reservoir tank.
67. CONNECT RETURN TUBE SUB-ASSEMBLY Using pliers, grip the claws of the 2 clips and slide the 2 clips to connect 2 return tube sub-assemblies. NOTE: Take care not to damage the hose protector.
68. CONNECT TRANSMISSION CONTROL CABLE ASSEMBLY Connect the control cable to the control cable clamp. Install the transmission control cable assembly to the control shaft lever with the nut. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Connect the transmission control cable assembly to the bracket with a new clip.
69. CONNECT FUEL TUBE SUB-ASSEMBLY Push in the fuel tube connector to the fuel pipe until the fuel tube makes a "click" sound. NOTE: Check for damage or contamination on the connected part of the pipe. Check if the pipe and the connector are securely connected by trying to pull them apart. Install the No. 1 fuel pipe clamp.
70. CONNECT NO. 1 OIL COOLER OUTLET HOSE Using pliers, grip the claws of the clip and slide the clip to connect the No. 1 oil cooler outlet hose to the No. 1 oil cooler outlet tube.
71. CONNECT NO. 1 OIL COOLER INLET HOSE Using pliers, grip the claws of the clip and slide the clip to connect the No. 1 oil cooler inlet hose to the No. 1 oil cooler inlet tube.
72. CONNECT HEATER WATER INLET HOSE B Using pliers, grip the claws of the clip and slide the clip to connect the heater water inlet hose to water outlet.
73. CONNECT HEATER WATER OUTLET HOSE B Using pliers, grip the claws of the clip and slide the clip to connect the heater water outlet hose to water outlet.
74. INSTALL RADIATOR INLET HOSE Using pliers, grip the claws of the clip and slide the clip to connect the radiator inlet hose to the water outlet.
75. INSTALL RADIATOR OUTLET HOSE Using pliers, grip the claws of the clip and slide the clip to connect the radiator outlet hose to the water inlet.
76. CONNECT UNION TO CHECK VALVE HOSE Using pliers, grip the claws of the clip and slide the clip to connect the union to check valve hose to the intake air surge tank assembly.
77. CONNECT NO. 1 FUEL VAPOR FEED HOSE Install the clamp and connect the No. 1 fuel vapor feed hose.
78. INSTALL ENGINE MOVING CONTROL ROD Temporarily install the engine moving control rod with the 3 bolts. First install the bolts A, and then the remaining bolt B. Torque: 38 N*m (388 kgf*cm, 28 ft.*lbf)
79. INSTALL NO. 2 ENGINE MOUNTING STAY RH Temporarily install the No. 2 engine mounting stay RH with the bolt. Torque: 38 N*m (388 kgf*cm, 28 ft.*lbf) Tighten the 2 nuts. Torque: 23 N*m (235 kgf*cm, 17 ft.*lbf)
80. INSTALL INTAKE AIR RESONATOR SUB-ASSEMBLY Install the intake air resonator with the bolt and clip. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
81. INSTALL AIR CLEANER BRACKET Remove the 2 bolts and air cleaner bracket. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf)
82. INSTALL BATTERY Install the battery and battery tray. Install the battery clamp with the bolt and nut. Torque: Bolt 9.0 N*m (92 kgf*cm, 80 in.*lbf) Nut 3.5 N*m (36 kgf*cm, 31 in.*lbf) Connect the positive battery terminal. Connect the negative battery terminal.
83. INSTALL AIR CLEANER CASE SUB-ASSEMBLY Install the air cleaner case with the 3 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Connect the vacuum hose. Connect the vacuum switching valve connector.
84. INSTALL AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Install the air cleaner filter element sub-assembly.
85. INSTALL AIR CLEANER CAP SUB-ASSEMBLY (See «INSTALLATION»(ref-282133-S27874880452008032900000) )
86. INSTALL NO. 1 AIR CLEANER INLET Install the No. 1 air cleaner inlet with the bolt. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf)
87. INSTALL NO. 2 AIR CLEANER INLET Install the No. 2 air cleaner inlet with the 2 clamps and 2 bolts. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf)
88. CONNECT VACUUM HOSES
89. INSTALL V-RIBBED BELT (See «INSTALLATION»(ref-282118-S19865219352008032900000) )
90. INSTALL FRONT OUTER COWL TOP PANEL SUB-ASSEMBLY Install the front outer cowl top panel sub-assembly with the 7 bolts. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) Install the 2 clips. Install the fuel pump resistor with the nut. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf)
91. INSTALL NO. 1 COWL TOP TO COWL BRACE INNER Install the No. 1 cowl top to cowl brace inner. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf)
92. INSTALL FRONT WIPER MOTOR AND LINK (See «INSTALLATION»(ref-282135-S11664405272008032900000) )
93. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY Push the ventilator louver in the direction indicated by the arrow in the illustration. Attach the 6 claws to install the ventilator louver.
94. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH (See «INSTALLATION»(ref-282135-S11664405272008032900000) )
95. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH (See «INSTALLATION»(ref-282135-S11664405272008032900000) )
96. INSTALL FRONT WIPER ARM HEAD CAP Install the front wiper arm head caps.
97. INSTALL FRONT WHEELS Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)
98. ADD ENGINE OIL (See «REPLACEMENT»(ref-282120-S40619786932008032900000) )
99. ADD ENGINE COOLANT (See «REPLACEMENT»(/toyota/sienna/ii-2005-2010/remont/cooling-system-mechanical/#engine-cooling-system) )
100. ADD AUTOMATIC TRANSAXLE FLUID
101. CHECK AUTOMATIC TRANSAXLE FLUID (See «ON-VEHICLE INSPECTION»(ref-282123-S12324538892008032900000) )
102. ADD POWER STEERING FLUID
103. BLEED POWER STEERING FLUID (See «BLEEDING»(ref-282142-S05421396942008032900000) )
104. INSPECT FOR FUEL LEAK (See «ON-VEHICLE INSPECTION»(ref-282130-S03294457302008032900000) )
105. INSPECT FOR ENGINE OIL LEAK
106. INSPECT FOR ENGINE COOLANT LEAK (See «ON-VEHICLE INSPECTION»(/toyota/sienna/ii-2005-2010/remont/cooling-system-mechanical/#engine-cooling-system) )
107. INSPECT FOR EXHAUST GAS LEAK
108. CHECK SHIFT LEVER POSITION (See «INSPECTION»(ref-282123-S14880616302008032900000) )
109. CHECK AND ADJUST FRONT WHEEL ALIGNMENT HINT: (See «ADJUSTMENT»(ref-282141-S20223518452008032900000) ).
110. CHECK IGNITION TIMING (See «ON-VEHICLE INSPECTION»(ref-282118-S18909792052008032900000) )
111. CHECK ENGINE IDLE SPEED (See «ON-VEHICLE INSPECTION»(ref-282118-S18909792052008032900000) )
112. CHECK CO/HC (See «ON-VEHICLE INSPECTION»(ref-282118-S18909792052008032900000) )
113. CHECK FUNCTION OF THROTTLE BODY ASSEMBLY (See «ON-VEHICLE INSPECTION»(/toyota/sienna/ii-2005-2010/remont/testing-diagnostics/#engine-control-system) )
114. INSTALL FRONT FENDER APRON SEAL RH Install the front fender apron seal RH with the 2 bolts and clip.
115. INSTALL FRONT FENDER APRON SEAL LH Install the front fender apron seal LH with the 2 bolts and clip.
116. INSTALL NO. 1 ENGINE UNDER COVER ASSEMBLY Install the No. 1 engine under cover sub-assembly with the 8 bolts and 4 clips.
117. INSTALL V-BANK COVER SUB-ASSEMBLY Fit the 3 retainers and install the V-bank cover.
118. CHECK ABS SPEED SENSOR SIGNAL «TEST MODE PROCEDURE»(ref-282143-S38533820582008032900000)
119. RESET MEMORY HINT: See «INITIALIZATION»(ref-282123-S03176832422008032900000).

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

See also:
• ON-VEHICLE INSPECTION
• REMOVAL
• REMOVAL
• REMOVAL
