Air Conditioning: Removal & Installation Toyota Sequoia I рестайлинг

REMOVE DRIVE BELT

Loosen the drive belt tension by turning the drive belt tensioner counterclockwise, and remove the drive belt.

Scheme 169

REPLACEMENT

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM
2. REPLACE FAULTY TUBE OR HOSE NOTE: Cap the openings immediately to keep moisture or dirt out of the system.
3. TIGHTEN JOINT OF BOLT OR NUT TO SPECIFIED TORQUE NOTE: Do not exceed specified torque. TIGHTENING TORQUE SPECIFICATIONS Part Tightened N.m kgf.cm ft.lbf Receiver at Liquid tube 5.4 55 48 in.lbf Condenser at Discharge hose 5.4 55 48 in.lbf Condenser at Liquid tube 5.4 55 48 in.lbf Compressor at Discharge hose 10 100 7 Compressor at Suction hose 10 100 7 Liquid and suction tube (Nut) 5.4 55 48 in.lbf Liquid and suction tube at Rear A/C unit 5.4 55 48 in.lbf
4. EVACUATE AIR IN REFRIGERATION SYSTEM AND CHARGE SYSTEM WITH REFRIGERANT Specified amount: Single A/C: 750 +/- 50 g (26.45 +/- 1.76 oz.) Dual A/C: 1050 +/- 50 g (37.03 +/- 1.76 oz.)
5. INSPECT FOR LEAKAGE OF REFRIGERANT Using a gas leak detector, check for leakage of refrigerant.
6. INSPECT AIR CONDITIONING OPERATION

Scheme 170

Scheme 171

1. INSPECT FOR LEAKAGE OF REFRIGERANT Remove the console box assembly. Remove the glove compartment door. Remove the lower No. 2 finish panel. Remove the heater to register duct No. 4. Remove the lower LH finish panel. Remove the lower cover (See «REMOVAL»(ref-227653-S13326720002006040600000) ). Remove the blower controller. Disconnect the connector. Remove the 2 screws and blower motor linear controller. Using a gas leak detector, check for leakage. If there is leakage, check the tightening torque at the joints or check the evaporator. Install the blower motor linear controller with the 2 screws. Install the lower cover. Install the lower LH finish panel. Install the lower No.2 finish panel. Install the glove compartment door (See «INSTALLATION»(ref-227653-S25032492792006040600000) ).
2. INSPECT EXPANSION VALVE Set the manifold gauge set. Run the engine. Check quantity of gas with the sight glass in refrigeration cycle. Run the engine at 1,500 RPM for at least 5 minutes. Then check that the high pressure reading is 1.37 to 1.57 Mpa (14 to 16 kgm/cm 2 , 199 to 228 psi). Check the expansion valve. If the expansion valve is faulty, the low pressure reading will drop to 0 kPa (0 kgf/cm 2 , 0 psi). HINT: When the low pressure reading drops to 0 kPa (0 kgf/cm 2 , 0 psi), there is no difference in temperature between the IN and OUT sides of the receiver.
3. INSPECT THERMISTOR RESISTANCE Disconnect the connector. Measure the resistance between terminals. Standard resistance: 1,500 ohm at 25° C (77° F) If resistance is not as specified, replace the thermistor.

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM HINT: At the time of installation, refer to the following: Evacuate air from the refrigeration system. Charge the system with refrigerant and inspect for leakage of refrigerant. Specified amount: Single A/C: 750 +/- 50 g (26.45 +/- 1.76 oz.) Dual A/C: 1050 +/- 50 g (37.03 +/- 1.76 oz.)
2. DISCONNECT LIQUID AND SUCTION TUBE Using SST, remove the 2 piping clamps. SST 09870-00015 (Suction tube) 09870-00025 (Liquid tube) Install SST to the piping clamp. HINT: Confirm the directions of the piping clamp claw and SST using the illustration on the caution label. Push down SST and release the clamp lock. NOTE: Be careful not to deform the tubes, when pushing SST. Pull SST slightly and push the release lever, then remove the piping clamp with SST. Remove the piping clamp from SST. Disconnect both tubes. NOTE: Do not use tools like a screwdriver to remove the tube. Cap the openings immediately to keep moisture or dirt out of the system. HINT: At the time of reassembly, refer to the following: Lubricate 4 new O-rings with compressor oil and install them to the tubes. After connection, check the claw of the piping clamp is securely engaged.
3. REMOVE CONSOLE UPPER PANEL
4. REMOVE REAR CONSOLE BOX
5. REMOVE FRONT CONSOLE BOX
6. REMOVE GLOVE COMPARTMENT PARTS
7. REMOVE LOWER NO. 2 FINISH PANEL
8. REMOVE LOWER LH FINISH PANEL
9. REMOVE LOWER COVER (See «REMOVAL»(ref-227653-S13326720002006040600000) )
10. REMOVE NO. 4 HEATER TO REGISTER DUCT
11. REMOVE COOLING UNIT Disconnect the connectors. Remove the 3 screws and the bolt, then the cooling unit.

Scheme 179

Scheme 180

1. REMOVE BLOWER MOTOR LINEAR CONTROLLER Remove the 2 screws and blower motor linear controller.
2. SEPARATE UPPER AND LOWER UNIT CASES Disconnect the connector clamp of the thermistor from the upper unit case. Using a knife, cut off each packing. Remove the clip, 6 screws, and grommet. Separate the upper and lower unit cases, then pull out the thermistor from the evaporator.
3. REMOVE EVAPORATOR FROM LOWER UNIT CASE HINT: At the time of reassembly, refer to the following: If the evaporator is replaced, add compressor oil to the compressor. Add 40 to 50 cc (1.4 to 1.7 fl.oz.) Compressor oil: ND-OIL 8 or equivalent
4. REMOVE EXPANSION VALVE Using a hexagon wrench (5.0 mm (0.20 in.)), remove the 2 bolts and separate the expansion valve, evaporator and tubes. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) HINT: At the time of reassembly, refer to the following item: Lubricate 4 new O-rings with compressor oil and install them to the tubes and valve.

INSTALLATION

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 181

Scheme 182

Scheme 183

Scheme 184

1. REMOVE COOLING UNIT (See «REMOVAL»(ref-227667-S30963996192006040600000) )
2. DRAIN ENGINE COOLANT FROM RADIATOR HINT: It is not necessary to drain out all the coolant.
3. DISCONNECT WATER VALVE CONTROL CABLE FROM WATER VALVE (See «REMOVAL»(ref-227667-S11367954142006040600000) )
4. DISCONNECT WATER HOSES FROM HEATER RADIATOR PIPES Using pliers, grip the claws of the clips and slide the clips along the hose. Disconnect the water hoses. Remove the grommet. HINT: At the time of installation, refer to the following: Push the water hose onto the heater radiator pipe up to the second ridge on the pipe. Install the hose clip to the position shown in the illustration.
5. REMOVE INSTRUMENT PANEL AND REINFORCEMENT (See «REMOVAL»(ref-227653-S13326720002006040600000) )
6. REMOVE DEFROSTER NOZZLE AND HEATER TO REGISTER DUCT
7. REMOVE HEATER UNIT Remove the 3 screws and heater unit.

Scheme 185

1. REMOVE HEATER RADIATOR Remove the 3 screws and 3 clamps. Pull out the heater radiator. Remove the 2 screws and 2 clips, then disconnect the heater radiator pipes.
2. REMOVE AIR VENT DUCT Remove the 3 screws and duct.
3. REMOVE AIR OUTLET SERVOMOTOR Remove the 3 screws and servomotor.
4. REMOVE AIR MIX SERVOMOTOR Remove the 3 screws and servomotor.
5. REMOVE ASPIRATOR HOSE

Scheme 186

1. INSPECT FINS FOR BLOCKAGE If the fins are clogged, clean them with compressed air.
2. INSPECT AIR OUTLET SERVOMOTOR OPERATION Connect the positive (+) lead from the battery to terminal 2 and the negative (-) lead to terminal 1. Connect the negative (-) lead from the battery to each terminal and check that the shaft rotates at each position, as shown in the illustration. SHAFT POSITIONS REFERENCE Connected terminal Position 4 DEF 5 F/D 6 FOOT 7 B/L 8 FACE

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM HINT: At the time of installation, refer to the following item: Evacuate air from the refrigeration system. Charge the system with refrigerant and inspect for leakage of refrigerant. Specified amount: Dual A/C: 1050 +/- 50 g (37.03 +/- 1.76 oz.)
2. DRAIN ENGINE COOLANT FROM RADIATOR HINT: It is not necessary to drain out all coolant.
3. REMOVE REAR SEAT OUTER BELT FLOOR ANCHORS
4. REMOVE BACK DOOR SCUFF PLATE
5. REMOVE REAR DOOR SCUFF PLATE RH
6. REMOVE UPPER BACK DOOR GARNISH
7. REMOVE REAR WINDOW SIDE GARNISH RH
8. REMOVE REAR QUARTER TRIM PANEL RH
9. REMOVE QUARTER PILLAR GARNISH RH
10. DISCONNECT LIQUID AND SUCTION TUBES Remove the 2 bolts and disconnect both tubes. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) NOTE: Cap the openings immediately to keep moisture or dirt out of the system. HINT: At the time of installation, refer to the following: Lubricate 2 new O-rings with compressor oil and install them to the tubes.
11. DISCONNECT WATER HOSES FROM HEATER PIPES Grip the claws of the hose clip and slide the hose clip along the hose. Disconnect the water hoses. HINT: At the time of installation, please refer to the following items. Push the water hose onto the heater radiator pipe up to the second ridge on the pipe. Install a hose clip to the position shown in the illustration.
12. REMOVE REAR A/C UNIT Remove the 3 clips and cover. Remove the 2 air ducts. Disconnect the connectors and wire harness clamps. Remove the 3 bolts and rear A/C unit.

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

1. REMOVE BLOWER MOTOR
2. REMOVE POWER TRANSISTOR
3. REMOVE THERMISTOR
4. REMOVE WATER VALVE Remove the packing. Remove the 3 screws and 2 brackets. Grip the claws of the hose clips and slide the hose clips along the hoses. Disconnect the water hoses and pipes. Remove the 2 screws and 2 clamps. Remove the 3 screws and water valve.
5. REMOVE DRAIN HOSE
6. REMOVE EXPANSION VALVE Remove the 4 screws and 2 brackets. Pry out the packing. HINT: At the time of installation, refer to the following: Do not refuse the packing. Using a hexagon wrench (5.0mm (0.20 in.)), remove the 2 bolts and expansion valve. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) NOTE: Cap the openings immediately to keep moisture or dirt out of the system. HINT: At the time of installation, refer to the following: Lubricate 2 new O-rings with compressor oil and install them to the tube and valve. Remove the holder and disconnect the heat sensing tube. Loosen the 2 nuts and remove the expansion valve. Torque: Nut A: 13 N.m (135 kgf.cm, 10 ft.lbf) Nut B: 22 N.m (235 kgf.cm, 16 ft.lbf) HINT: At the time of installation, refer to the following: Lubricate 2 new O-rings with compressor oil and install them to the expansion valve.
7. REMOVE EVAPORATOR Remove the 8 screws and cover. Pull out the evaporator.
8. REMOVE AIR OUTLET SERVOMOTOR Using a screwdriver, release the claw and remove the plate. HINT: Tape the screwdriver tip before use. Remove the 3 screws and servomotor.
9. SEPARATE REAR A/C UNIT Remove the 2 screws, clamp and blower case. Remove the 10 screws and separate the A/C unit. Remove the sliding door and shaft. Remove the heater radiator and insulator.

Scheme 202

1. INSPECT EVAPORATOR Check evaporator fins for blockage. If the fins are clogged, clean them with compressed air. NOTE: Never use water to clean the evaporator. Check fitting for cracks or scratches. If necessary, repair or replace.
2. INSPECT HEATER RADIATOR Inspect fins for blockage. If the fins are clogged, clean them with compressed air.
3. INSPECT WATER VALVE SERVOMOTOR CIRCUIT (See «DTC 47: WATER VALVE DAMPER CONTROL SERVOMOTOR CIRCUIT»(ref-227582-S13506368642006040600000) )
4. INSPECT AIR OUTLET SERVOMOTOR OPERATION Connect the positive (+) lead from the battery to terminal 7 and the negative (-) lead to terminal 8. Connect the negative (-) lead from the battery to each terminal and check that the shaft rotates at each position, as shown in the illustration. SHAFT POSITIONS REFERENCE Connected terminal Position 1 FOOT 2 B/L2 3 B/L1 4 FACE 2 5 FACE 1

Scheme 203

Scheme 204

Scheme 205

1. ASSEMBLE REAR A/C UNIT Install the insulator and heater radiator. Install the shaft and sliding door. Assemble the A/C unit and install the 10 screws. Install the blower case, clamp and 2 screws.
2. INSTALL AIR OUTLET SERVOMOTOR Align marking A on the grid part of the case with the side of sliding door rack B. Install the servomotor with the 3 screws. HINT: The projection on the gear (marking B) shall be positioned vertically.
3. INSTALL EVAPORATOR
4. INSTALL EXPANSION VALVE
5. INSTALL WATER VALVE
6. INSTALL THERMISTOR
7. INSTALL POWER TRANSISTOR
8. INSTALL BLOWER MOTOR

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 206

Scheme 207

1. REMOVE CONSOLE UPPER PANEL
2. REMOVE REAR CONSOLE BOX
3. REMOVE FRONT CONSOLE BOX
4. REMOVE LOWER LH FINISH PANEL
5. REMOVE GLOVE COMPARTMENT DOOR
6. REMOVE LOWER NO. 2 FINISH PANEL
7. REMOVE LOWER COVER
8. REMOVE COOLING UNIT (See «REMOVAL»(ref-227667-S30963996192006040600000) )
9. REMOVE BLOWER UNIT Disconnect the connector from the blower motor. Disconnect the connector from the air inlet servomotor. Remove the nut, bolt and blower unit.

Scheme 208

Scheme 209

1. REMOVE BLOWER MOTOR Remove the 3 screws and blower motor.
2. REMOVE AIR INLET SERVOMOTOR Remove the 3 screws and servomotor.

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 210

Scheme 211

1. SET MANIFOLD GAUGE SET (See «MANIFOLD GAUGE SET»(ref-227667-S33291989582006040600000) )
2. START ENGINE
3. INSPECT COMPRESSOR FOR METALLIC SOUND Check if a metallic sound can be heard from the compressor when the A/C switch is on. If a metallic sound cannot be heard, replace the compressor assembly.
4. INSPECT REFRIGERANT PRESSURE (See «ON-VEHICLE INSPECTION»(ref-227667-S33478172802006040600000) )
5. STOP ENGINE
6. INSPECT VISUALLY FOR LEAKAGE OF REFRIGERANT FROM SAFETY SEAL Using a gas leak detector, check for leakage of refrigerant. If there is any leakage, replace the compressor assembly.
7. REMOVE MANIFOLD GAUGE SET (See «SET OFF»(ref-227667-S08239126262006040600000) )
8. CHECK FOR LEAKAGE OF GREASE FROM CLUTCH BEARING
9. CHECK FOR SIGNS OF OIL ON PRESSURE PLATE If necessary, repair or replace.
10. INSPECT MAGNETIC CLUTCH BEARING FOR NOISE Start the engine. Check if abnormal noise is heard from near the compressor when the A/C switch is OFF. If abnormal noise is being emitted, replace the magnetic clutch.
11. INSPECT MAGNETIC CLUTCH OPERATION Disconnect the connector. Connect the positive (+) lead from the battery to terminal 3 and the negative (-) lead to body ground. Check that the magnetic clutch is energized. If operation is not as specified, replace the magnetic clutch.
12. INSPECT COMPRESSOR LOCK SENSOR RESISTANCE Disconnect the connector. Measure the resistance between terminals 1 and 2. Standard resistance: 165 to 205 ohm at 20° C (68° F) If resistance is not as specified, replace the compressor.

Scheme 212

Scheme 213

Scheme 214

1. RUN ENGINE AT IDLE SPEED WITH A/C ON FOR APPROX. 10 MINUTES
2. STOP ENGINE
3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
4. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM
5. DISCONNECT DISCHARGE AND SUCTION HOSES Remove the 2 nuts and disconnect both hoses. NOTE: Cap the openings fitting immediately to keep moisture or dirt out of the system.
6. REMOVE DRIVE BELT (See «REMOVAL»(ref-227667-S02314985392006040600000) )
7. REMOVE COMPRESSOR Disconnect the connector. Remove the 3 bolts and nut. Remove the cooler bracket. Remove the compressor.

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

1. REMOVE PRESSURE PLATE Using SST and a socket wrench, remove the shaft bolt. SST 07112-76060 Torque: 18 N.m (184 kgf.cm, 12.3 ft.lbf) Install SST on the pressure plate. SST 07112-66040 Using SST and a socket wrench, remove the pressure plate. SST 07112-66040, 07112-76060, Remove the shims from the pressure plate.
2. REMOVE ROTOR Using SST, remove the snap ring. SST 95994-10020 NOTE: The snap ring should be installed so that its beveled side faces up. Using a plastic hammer, remove the rotor from the shaft. NOTE: Be careful not to damage the pulley when tapping on the rotor.
3. REMOVE STATOR Disconnect the stator lead wire from the compressor housing. Using SST, remove the snap ring. SST 95994-10020 NOTE: The snap ring should be installed so that its beveled side faces up. Remove the stator.

1. INSTALL COMPRESSOR Install the compressor with the cooler bracket with the 3 bolts and nut. Torque: Bolt: 47 Nm (480 kgf.cm, 35 in.lbf) Nut: 25 Nm (255 kgf.cm, 18 in.lbf) Connect the connector.
2. CONNECT DISCHARGE AND SUCTION HOSES Connect both hoses with the 2 nuts. Torque: 10 N.m (100 kgf.cm, 7 in.lbf) NOTE: Hoses should be connected immediately after the caps have been removed. HINT: Lubricate 2 new O-rings with compressor oil and install them to the hoses.
3. INSTALL AND CHECK DRIVE BELT (See «INSTALLATION»(ref-227667-S42250104062006040600000) «DRIVE BELT»(ref-227667-S32085818202006040600000) )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
5. EVACUATE AIR FROM REFRIGERATION SYSTEM
6. CHARGE SYSTEM WITH REFRIGERANT Specified amount: Single A/C: 750 +/- 50g (26.45 +/- 1.76 oz.) Dual A/C: 1050 +/- 50g (37.03 +/- 1.76 oz.)
7. INSPECT FOR LEAKAGE OF REFRIGERANT Using a gas leak detector, check for leakage of refrigerant. If there is leakage, check the tightening torque at the joints.
8. PERFORM INITIALIZATION (See «INITIALIZATION»(ref-227563-S28331174312006040600000) ) Some systems need initialization when disconnecting the cable from the negative battery terminal.

Installation is in the reverse order of removal (See REMOVAL ).

Installation is In the reverse order of removal (See REMOVAL ).

Installations is in the reverse order of removal (See REMOVAL ).

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM HINT: At the time of installation, refer to the following: Evacuate air from the refrigeration system. Charge the system with refrigerant and inspect for leakage of refrigerant. Specified amount: Dual A/C: 1050 +/- 50 g (37.03 +/- 1.76 oz.)
2. DRAIN ENGINE COOLANT FROM RADIATOR HINT: It is not necessary to drain out all coolant.
3. REMOVE REAR SEAT OUTER BELT FLOOR ANCHORS
4. REMOVE BACK DOOR SCUFF PLATE
5. REMOVE REAR DOOR SCUFF PLATE RH
6. REMOVE UPPER BACK DOOR GARNISH
7. REMOVE REAR WINDOW SIDE GARNISH RH
8. REMOVE REAR QUARTER TRIM PANEL RH
9. REMOVE QUARTER PILLAR GARNISH RH
10. DISCONNECT LIQUID AND SUCTION TUBES Remove the 2 bolts and disconnect both tubes. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) NOTE: Cap the openings immediately to keep moisture or dirt out of the system. HINT: At the time of installation, refer to the following: Lubricate 2 new O-rings with compressor oil and install them to the tubes.
11. REMOVE AIR DUCT Remove the 3 clips and cover. Remove the 2 air ducts. Disconnect the connectors and wire harness clamps.
12. REMOVE EXPANSION VALVE Remove the 4 screws and 2 brackets. Pry out the packing. HINT: At the time of installation, refer to the following: Do not refuse the packing. Using a hexagon wrench (5.0 mm (0.20 in.)), remove the 2 bolts. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) Remove the 3 bolts. Lift the A/C unit until the tube and accessary can be removed. Remove the tube and accessary. Remove the holder and disconnect the heat sensing tube. Loosen the 2 nuts and remove the expansion valve. Torque: Nut A: 13 N.m (135 kgf.cm, 10 in.lbf) Nut B: 22 N.m (235 kgf.cm, 16 in.lbf) HINT: At the time of installation, refer to the following: Lubricate 2 new O-rings with compressor oil and install them to the expansion valve.

Installation is in the reverse order of removal (See REAR A/C EXPANSION VALVE ).

Scheme 231

1. WARM UP ENGINE
2. DISCONNECT WATER VALVE CONTROL CABLE
3. INSPECT WATER VALVE OPERATION Check that warm air comes out the vent when the water valve lever is moved to the "WARM" position. Check that cool air comes out when the water valve is moved to the "COOL" position. If operation is not as specified, replace the water valve.
4. CONNECT WATER VALVE CONTROL CABLE

Scheme 232

Scheme 233

Scheme 234

1. DRAIN ENGINE COOLANT FROM RADIATOR HINT: It is not necessary to drain out all the coolant.
2. DISCONNECT WATER VALVE CONTROL CABLE FROM WATER VALVE Disconnect the control cable.
3. DISCONNECT WATER HOSES Using pliers, grip the claws of the hose clips and slide the hose clips along the hose. Disconnect the water hoses. HINT: At the time of installation, refer to the following: Heater radiator pipe: Push the water hose onto the heater radiator pipe up to the second ridge on the pipe. Water valve: Push the water hose onto the water valve pipe till touching the body of the water valve.
4. REMOVE WATER VALVE Remove the bolt and water valve.

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 235

Scheme 236

1. AFTER INSTALLATION, CHECK WATER VALVE OPERATION Turn the ignition switch to ON. Operate temperature control switches to "MAX. COOL" and "MAX. WARM", then check water valve operation, as shown in the illustration. If operation is not as specified, proceed to the next step.
2. ADJUST WATER VALVE CONTROL CABLE Disconnect the control cable. Turn the ignition switch to ON. Set temperature control switches to "MAX. COOL". Set the water valve lever to the "COOL" position, connect the control cable and lock the clamp. HINT: Lock the clamp while lightly pushing the outer cable in the direction shown by the arrow in the illustration.

Scheme 237

Scheme 238

1. REMOVE BLOWER MOTOR Disconnect the connector. Remove the 3 screws and motor.
2. INSPECT BLOWER MOTOR OPERATION Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, then check that the motor operates smoothly. If operation is not as specified, replace the blower motor.
3. INSTALL BLOWER MOTOR Install the motor with the 3 screws. Connect the connector.

Scheme 239

Scheme 240

1. REMOVE REAR SEAT OUTER BELT FLOOR ANCHORS
2. REMOVE BACK DOOR SCUFF PLATE
3. REMOVE REAR DOOR SCUFF PLATE RH
4. REMOVE REAR WINDOW SIDE GARNISH
5. REMOVE REAR QUARTER TRIM PANEL RH
6. REMOVE BLOWER MOTOR Disconnect the blower motor connector. Remove the 3 screws and blower motor.
7. INSPECT BLOWER MOTOR OPERATION Connect the positive (+) lead from the battery to terminal 2 and the negative (-) lead to terminal 1, then check that the motor operates smoothly. If operation is not as specified, replace the blower motor.
8. INSTALL BLOWER MOTOR
9. INSTALL REAR QUARTER TRIM PANEL RH
10. INSTALL REAR WINDOW SIDE GARNISH
11. INSTALL REAR DOOR SCUFF PLATE RH
12. INSTALL BACK DOOR SCUFF PLATE
13. INSTALL REAR SEAT OUTER BELT FLOOR ANCHORS

Scheme 241

1. REMOVE GLOVE COMPARTMENT PARTS
2. REMOVE LOWER NO. 2 FINISH PANEL
3. REMOVE LOWER CENTER COVER
4. REMOVE LOWER LH FINISH PANEL
5. REMOVE NO. 4 HEATER TO REGISTER DUCT
6. REMOVE BLOWER MOTOR LINEAR CONTROLLER Disconnect the connector. Remove the 2 screws and blower motor linear controller.
7. INSPECT BLOWER MOTOR LINEAR CONTROLLER (See «BLOWER MOTOR CIRCUIT (FRONT A/C)»(ref-227582-S08033035992006040600000) )
8. INSTALL BLOWER MOTOR LINEAR CONTROLLER Install the blower motor linear controller with the 2 screws. Connect the connector.
9. INSTALL NO. 4 HEATER TO REGISTER DUCT
10. INSTALL LOWER LH FINISH PANEL
11. INSTALL LOWER CENTER COVER
12. INSTALL LOWER NO. 2 FINISH PANEL
13. INSTALL GLOVE COMPARTMENT PARTS

Scheme 242

Scheme 243

Scheme 244

1. REMOVE REAR SEAT OUTER BELT FLOOR ANCHORS
2. REMOVE BACK DOOR SCUFF PLATE
3. REMOVE REAR DOOR SCUFF PLATE RH
4. REMOVE REAR WINDOW SIDE GARNISH
5. REMOVE REAR QUARTER TRIM PANEL RH
6. REMOVE REAR POWER TRANSISTOR Disconnect the connector. Remove the 2 screws and the rear power transistor.
7. INSPECT POWER TRANSISTOR OPERATION Connect the positive (+) lead to terminal 1 through a 12 V - 3.4 W test bulb and the negative (-) lead to terminal 4. Check the test bulb lights up when another positive (+) lead is connected to terminal 2 through a 12 V - 3.4 W test bulb. If operation is not as specified, replace the power transistor.
8. INSPECT POWER TRANSISTOR RESISTANCE Measure the resistance between terminals 3 and 4. Standard resistance: 2.0 to 2.4 k ohm If resistance is not as specified, replace the power transistor.
9. INSTALL REAR POWER TRANSISTOR
10. INSTALL REAR QUARTER TRIM PANEL RH
11. INSTALL REAR WINDOW SIDE GARNISH
12. INSTALL REAR DOOR SCUFF PLATE RH
13. INSTALL BACK DOOR SCUFF PLATE
14. INSTALL REAR SEAT OUTER BELT FLOOR ANCHORS

Scheme 245

1. REMOVE AIR MIX SERVOMOTOR Disconnect the connector. Remove the 3 screws and servomotor.
2. INSPECT AIR MIX DAMPER POSITION SERVOMOTOR (See «DTC 31: FRONT AIR MIX DAMPER POSITION SENSOR CIRCUIT»(ref-227582-S31769307642006040600000) )
3. INSPECT AIR MIX SERVOMOTOR CIRCUIT (See «DTC 41: FRONT AIR MIX DAMPER CONTROL SERVOMOTOR CIRCUIT»(ref-227582-S38440953302006040600000) )
4. INSTALL AIR MIX SERVOMOTOR

Scheme 246

Scheme 247

1. REMOVE SIDE HEATER COVER
2. REMOVE THERMISTOR Disconnect the connector and connector clamp. Using a screwdriver, pull out the sensor. HINT: Tape the screwdriver tip before use. Release the 2 claws and remove the sensor from the bracket plate.
3. INSPECT THERMISTOR (See «DTC 17: REAR EVAPORATOR TEMPERATURE SENSOR CIRCUIT»(ref-227582-S07057599042006040600000) )
4. INSTALL THERMISTOR
5. INSTALL SIDE HEATER COVER

Scheme 248

1. REMOVE SOLAR SENSOR Using a screwdriver, pull out the sensor, then disconnect the connector. HINT: Tape the screwdriver tip before use.
2. INSPECT SOLAR SENSOR CIRCUIT (See «DTC 21: SOLAR SENSOR CIRCUIT»(ref-227582-S31037583322006040600000) )
3. INSTALL SOLAR SENSOR

Scheme 249

1. REMOVE ROOM TEMPERATURE SENSOR Using a screwdriver, pull out the sensor, then disconnect the connector and aspirator hose. HINT: Tape the screwdriver tip before use.
2. INSPECT ROOM TEMPERATURE SENSOR CIRCUIT (See «CIRCUIT INSPECTION»(ref-227582-S21162826942006040600000) )
3. INSTALL ROOM TEMPERATURE SENSOR

Scheme 250

1. REMOVE ROOM TEMPERATURE SENSOR Using a screwdriver, pull out the sensor, then disconnect the connector.
2. INSPECT ROOM TEMPERATURE SENSOR CIRCUIT (See «DTC 19: REAR ROOM TEMPERATURE SENSOR CIRCUIT»(ref-227582-S10275060872006040600000) )
3. INSTALL ROOM TEMPERATURE SENSOR

Scheme 251

1. REMOVE AMBIENT TEMPERATURE SENSOR Disconnect the connector. Pull out the sensor.
2. INSPECT AMBIENT TEMPERATURE SENSOR (See «DTC 12: AMBIENT TEMPERATURE SENSOR CIRCUIT»(ref-227582-S11866921752006040600000) )
3. INSTALL AMBIENT TEMPERATURE SENSOR

Scheme 252

Scheme 253

Scheme 254

1. SET MANIFOLD GAUGE SET (See «MANIFOLD GAUGE SET»(ref-227667-S33291989582006040600000) )
2. DISCONNECT CONNECTOR
3. RUN ENGINE AT APPROX. 2,000 RPM
4. SET BLOWER SPEED CONTROL SWITCH TO "HI" POSITION
5. SET TEMPERATURE CONTROL LEVER TO "MAX. COOL" POSITION
6. A/C SWITCH ON
7. INSPECT PRESSURE SWITCH OPERATION Connect the positive (+) lead from the ohmmeter to terminal 4 and the negative (-) lead to terminal 1. Check continuity between terminals when refrigerant pressure is changed, as shown in the illustration. If operation is not as specified, replace the pressure switch.
8. Cooling fan control: INSPECT PRESSURE SWITCH OPERATION
9. STOP ENGINE AND REMOVE MANIFOLD GAUGE SET
10. CONNECT CONNECTOR TO PRESSURE SWITCH Connect the positive (+) lead from the ohmmeter to terminal 2 and the negative (-) lead to terminal 3. Check continuity between terminals when refrigerant pressure is changed, as shown in the illustration. If operation is not as specified, replace the pressure switch.
11. STOP ENGINE AND REMOVE MANIFOLD GAUGE SET
12. CONNECT CONNECTOR TO PRESSURE SWITCH

Scheme 255

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM HINT: At the time of installation, refer to the following: Evacuate air from the refrigeration system. Charge the system with refrigerant and inspect for leakage of refrigerant. Specified amount: Single A/C: 750 +/- 50 g (26.45 +/- 1.76 oz.) Dual A/C: 1050 +/- 50 g (37.03 +/- 1.76 oz.)
2. REMOVE PRESSURE SWITCH FROM LIQUID TUBE Disconnect the connector and remove the pressure switch. Torque: 10 N.m (100 kgF.cm, 7 ft.lbf) HINT: Being careful not to deform the tube, lock the switch mounted on the tube with an open end wrench and remove the switch. At the time of installation, refer to the following: Lubricate a new O-ring with the compressor oil and install it to the switch.

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 256

Scheme 257

Scheme 258

1. REMOVE RELAY Remove the heater relay. Remove the rear heater relay. Remove the condenser fan relay. Remove the magnetic clutch relay.
2. INSPECT RELAY Inspect the heater and rear heater relay for continuity. TESTER CONNECTION SPECIFIED CONDITION Condition Tester connection Specified condition Constant 1-2 3-4 Continuity Apply B+ between terminals 3 and 5. 3-5 Continuity If continuity is not as specified, replace the relay. Inspect the magnetic clutch and condenser fan for relay continuity. TESTER CONNECTION SPECIFIED CONDITION Condition Tester connection Specified condition Constant 1-2 Continuity Apply B+ between terminals 1 and 2. 3-5 Continuity If continuity is not as specified, replace the relay.

Scheme 259

1. INSPECT CONDENSER FAN OPERATION Inspect the fan operation under the following conditions, as shown in the chart. Test conditions: Start engine Blower speed control switch position "HI" Temperature control dial at "COOL" position Set manifold gauge set A/C switch ON FAN OPERATION Condition Fan operation (Fan speed) Refrigerant pressure is less than 1,520 kPa (15.5 kgf/cm 2 , 220 psi) OFF Refrigerant pressure is 1,520 kPa (15.5 kgf/cm 2 , 220 psi) or above Rotate If operation is not as specified, proceed to the next inspection.
2. INSPECT CONDENSER FAN MOTOR OPERATION Disconnect the fan connector. Connect the battery and ammeter. Check that the fan rotates smoothly, and then check the reading on the ammeter. Specified amperage: 9.2 to 11.0 A at 20° C (68° F) If operation is not as specified, replace the fan motor. If operation is as specified, check the pressure switch, cooling fan relays and water temp, switch.

Scheme 260

Scheme 261

1. Disconnect the 2 connectors.
2. Disconnect the wire harness clamp.
3. Remove the ambient temperature sensor.
4. Remove the 4 bolts and condenser fan with the fan shroud.

Scheme 262

Scheme 263

1. REMOVE FAN Remove the 3 bolts and fan.
2. REMOVE FAN MOTOR FROM FAN SHROUD Remove the 3 screws and fan motor.

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 264

Scheme 265

1. Remove the 2 screws.
2. Remove the integration control panel by pulling the portions indicated by arrows in the illustration.
3. Disconnect the connector.

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

1. REMOVE BULBS Remove the 3 bulbs.
2. REMOVE A/C AMPLIFIER Remove the 7 screws and heater control housing. Disconnect the 2 connectors. Remove the 3 screws and A/C amplifier. Remove the passenger seat belt indicator circuit.
3. REMOVE INTEGRATION CIRCUIT Remove the 2 knobs. Remove the 2 nuts and 2 washers. Remove the 8 bulbs. Remove the 7 screws and integration circuit.

Installation is in the reverse order of removal (See REMOVAL ).

Scheme 273

REMOVE HEATER CONTROL ASSEMBLY

Using a screwdriver, release the 2 claws and pull out the control switch assembly, then disconnect the connector.

HINT

Tape the screwdriver tip before use.

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

1. Remove the 2 screws and heater control switch.
2. Remove the 4 screws, A/C amplifier and PC board.
3. Remove the 3 bulbs from the PC board.
4. Remove the bulb from the A/C amplifier.

Installation is in the reverse order of removal (See REMOVAL ).
