INSTALL DRIVE BELT

Turn the drive belt tensioner counterclockwise then install the drive belt.

Scheme 280

Scheme 281

Scheme 282

1. CONNECT CHARGE HOSE TO MANIFOLD GAUGE SET Tighten the nuts by hand. CAUTION: Do not connect the wrong hoses.
2. CONNECT QUICK DISCONNECT ADAPTERS TO CHARGING HOSES Tighten the nuts by hand.
3. CLOSE BOTH VALVES OF MANIFOLD GAUGE SET
4. REMOVE CAPS FROM SERVICE VALVES ON REFRIGERANT LINE
5. CONNECT QUICK DISCONNECT ADAPTERS TO SERVICE VALVES HINT: Push the quick disconnect adapter onto the service valve, then slide. Slide the sleeve of the quick disconnect adapter downward to lock it.

Scheme 283

1. CLOSE BOTH VALVES OF MANIFOLD GAUGE SET
2. DISCONNECT QUICK DISCONNECT ADAPTERS FROM SERVICE VALVES ON REFRIGERANT LINE HINT: Slide the sleeve of the quick disconnect adapter upward to unlock the adapter and remove it from the service valve.
3. INSTALL CAPS TO SERVICE VALVES ON REFRIGERANT LINE
