HVAC - General Servicing: Component Locations Toyota Sequoia I

General Servicing - All Makes 4 illustrations ~109 words

LOCATION

For A/C system component locations, see illustrations. (Scheme 110)and see scheme 31.

Scheme 107: LOCATION

Scheme 109: ON-VEHICLE INSPECTION

Inspect drive belt's installation condition. Check that the drive belt fits properly in the ribbed grooves. see scheme 32
INSPECT DRIVE BELT TENSION Check that the tension is within A range on the auto tensioner scale. NOTE: When replacing the drive belt with a new one, the belt's tension should be within the B range on the belt tensioner scale. If the tension is not within the A range on the scale, replace the belt with a new one. see scheme 33
