MONITOR STRATEGY
| Related DTCs | P2102: Throttle actuator current (low current) P2103: Throttle actuator current (high current) |
| Required Sensors / Components (Main) | Throttle actuator (throttle body assembly) |
| Required Sensors / Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | P2102: 2 seconds P2103: 25 times |
| MIL Operation | Immediately |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs are not present | None |
| Throttle actuator | ON |
| Duty-cycle ratio to open throttle actuator | 80% or more |
| Throttle actuator power supply | 8 V or higher |
| Motor current change during latest 0.016 seconds | Less than 0.2 A |
| Throttle actuator | ON |
| Either of the following conditions 1 or 2 is met | |
| 1. Throttle actuator power supply | 8 V or higher |
| 2. Throttle actuator power | ON |
TYPICAL MALFUNCTION THRESHOLDS
| Throttle actuator current | Below 0.5 A |
| Either of the following conditions is met | Condition 1 or 2 |
| 1. Hybrid IC diagnosis signal | Fail |
| 2. Hybrid IC current limiter monitor port | Fail |
Scheme 514
Scheme 514: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine.
- With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
- Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2102 or P2103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When either of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.
Scheme 515
Scheme 515: WIRING DIAGRAM
| Related DTCs | P2111: Throttle actuator stuck open P2112: Throttle actuator stuck closed |
| Required Sensors / Components (Main) | Throttle actuator (throttle body assembly) |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or more |
| Duty-cycle to close throttle | 80% or more |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| All of the following conditions are met | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or more |
| Duty-cycle to open throttle | 80% or more |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
| *: System guard is ON when the following conditions set | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or higher |
| Throttle actuator fail | Not detected |
| Throttle position sensor voltage change | No change |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| Throttle position sensor voltage change | No change |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
Scheme 516
Scheme 516: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2111 or P2112.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, fully depress and release the accelerator pedal quickly.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When either of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.
PROCEDURE
- INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. If necessary, clean the throttle body assembly and then check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 3 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine, and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve). Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P2111 or P2112 is output B B --> See step 4 A --> See step 5
- REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-393423-S42932276002011040700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
| Related DTCs | P2118: Throttle actuator power supply |
| Required Sensors / Components (Main) | Throttle actuator, throttle valve (throttle body assembly), ETCS fuse |
| Required Sensors / Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | 0.8 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 8 V or higher |
| Electronic throttle actuator power | ON |
| Throttle actuator power supply voltage (+BM) | Below 4 V |
COMPONENT OPERATING RANGE
| Throttle actuator power supply voltage (+BM) | 11 to 14 V |
Scheme 517
Scheme 517: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine.
- Slowly depress the accelerator pedal, raise the engine speed to approximately 2500 rpm for approximately 5 seconds, and then idle the engine [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC or other DTCs relating to electronic throttle control system malfunctions, are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly. Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.
Scheme 518
Scheme 518: WIRING DIAGRAM
| Related DTCs | P2119: Electronic throttle control system malfunction |
| Required Sensors / Components (Main) | Throttle actuator (throttle body assembly) |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| System guard* judge condition | ON |
| *System guard is ON when the following conditions set | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or more |
| Throttle actuator fail | Not detected |
| Either of the following conditions A or B is met | |
| A. Commanded closed throttle position - current closed throttle position | 0.3 V or higher for 1 second |
| B. Commanded open throttle position - current open throttle position | 0.3 V or higher for 0.6 seconds |
Scheme 519
Scheme 519: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine.
- Idle the engine for 20 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2119.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, fully depress and release the accelerator pedal 3 times.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC, as well as other DTCs relating to electronic throttle control system malfunctions is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly. Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2119 is output A DTC P2119 and other DTCs are output B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Disconnect the throttle body assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (M+) - 1 (M-) 20°C (68°F) 0.3 to 100 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Throttle Body Assembly) Reconnect the throttle body assembly connector. NG --> See step 6 OK: Go to next step
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Allow the engine to idle for 20 seconds or more. Fully depress and release the accelerator pedal 3 times quickly. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. HINT: The output voltage of the throttle position sensor can be checked using the Techstream. Variations in the output voltage indicate that the throttle actuator is in operation. To check the output voltage using the Techstream, enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Position No. 1. Result Result Proceed to DTC is not output A DTC P2119 is output B B --> See step 6 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
- REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-393423-S42932276002011040700000)
| Related DTCs | P2195: Air fuel ratio sensor (Bank 1) signal stuck lean P2196: Air fuel ratio sensor (Bank 1) signal stuck rich |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Heated oxygen sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds: Sensor voltage detection monitor 3 seconds: Sensor current detection monitor |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0016 (VVT System Bank 1 - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater - Sensor 1) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0401 (EGR System (Closed)) P0451, P0452, P0453, P1451, P1452, P1453 (EVAP System) P0505 (Idle speed control) |
| Time after engine start | 30 seconds or more |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed-loop |
SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)
| Time after engine start | 30 seconds or more |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed-loop |
SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)
| Battery voltage | 11 V or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Air fuel ratio sensor status | Activated |
| Continuous time of fuel cut | 3 to 10 seconds |
SENSOR CURRENT DETECTION MONITOR (P2195, P2196)
| Heated oxygen sensor voltage | Rises from less than 0.21 V to 0.59 V or more |
| Air fuel ratio sensor voltage | More than 3.8 V |
SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)
| Heated oxygen sensor voltage | Falls from 0.59 V or more to less than 0.21 V |
| Air fuel ratio sensor voltage | Less than 2.8 V |
SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)
| Air fuel ratio sensor current | 3.6 mA or more |
SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION P2195)
| Air fuel ratio sensor current | Less than 1.57 mA |
SENSOR CURRENT DETECTION MONITOR (LOW SIDE MALFUNCTION P2196)
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
CONFIRMATION DRIVING PATTERN
| WARNING | Strictly observe posted speed limits, traffic laws, and road conditions when performing these drive patterns. |
This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
Scheme 520
Scheme 521
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine, and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
- On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine and ECT / Data List / All Data / Idle Fuel Cut.
- Drive the vehicle at between 47 and 75 mph (75 and 120 km/h) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Move the shift lever in B [C].
- Accelerate the vehicle to 47 mph (75 km/h) or more by depressing the accelerator pedal for at least 10 seconds [D].
- Soon after performing step [D] above, release the accelerator pedal for at least 8 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 2500 rpm or more (fuel injection returns at 1000 rpm).
- Allow the vehicle to decelerate until the vehicle speed decreases to less than 6 mph (10 km/h).
- Repeat steps [C] through [E] above at least 3 times in one driving cycle.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [F].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2195 or P2196.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 522
Scheme 522: WIRING DIAGRAM
| Related DTCs | P2237: Air fuel ratio sensor open circuit between A1A+ and A1A- P2238: Air fuel ratio sensor short circuit between A1A+ and A1A- P2238: Air fuel ratio sensor short circuit between A1A+ and GND P2238: Air fuel ratio sensor low impedance P2239: Air fuel ratio sensor short circuit between A1A+ and +B P2252: Air fuel ratio sensor short circuit between A1A- and GND P2253: Air fuel ratio sensor short circuit between A1A- and +B |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Engine coolant temperature sensor Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 seconds: P2237 (Air fuel ratio sensor open circuit between A1A+ and A1A-), P2238 (Air fuel ratio sensor low impedance) 5 seconds: Others |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0016 (VVT System Bank 1 - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater - Sensor 1) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0401 (EGR System (Closed)) P0451, P0452, P0453, P1451, P1452, P1453 (EVAP System) P0505 (Idle speed control) |
| Monitor runs whenever following DTCs are not present | None |
| Estimated sensor temperature | 450 to 550°C (842 to 1022°F) |
| Engine | Running |
| Battery voltage | 11 V or more |
P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)
| Estimated sensor temperature | 700 to 800 °C (1292 to 1472°F) |
| Engine coolant temperature | 10°C (50°F) or higher |
| Fuel cut | No executed |
P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)
| Battery voltage | 11 V or more |
| Power switch | On (IG) |
| Time after power switch is off to on (IG) | 5 seconds or more |
| Air fuel ratio sensor admittance | Below 0.002 1/ohms |
P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)
| Air fuel ratio sensor admittance | Below 0.022 1/ohms |
P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)
| A1A+ terminal voltage | 0.5 V or less |
P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND)
| A1A+ terminal voltage | More than 4.5 V |
P2239 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B)
| A1A- terminal voltage | 0.5 V or less |
P2252 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND)
| A1A- terminal voltage | More than 4.5 V |
P2253 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B)
| Difference between A1A+ terminal and A1A- terminal voltage | 0.1 V or less |
P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-)
| Air fuel ratio sensor admittance | 0.002 1/ohms or more |
| A1A+ terminal voltage | 0.5 to 4.5 V |
| A1A- terminal voltage | 0.5 to 4.5 V |
| Difference between A1A+ and A1A- terminal voltages | 0.1 to 0.8 V |
Scheme 523
Scheme 523: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine and wait 2 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [B].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2237, P2238, P2239, P2252 or P2253.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result [C]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition D24-1 (HA1A) - D28-18 (HA1A) Always Below 1 ohms D24-3 (A1A+) - D28-103 (A1A+) D24-4 (A1A-) - D28-126 (A1A-) Standard Resistance (Check for Short) Tester Connection Condition Specified Condition D24-1 (HA1A) or D28-18 (HA1A) - Body ground Always 10 kohms or higher D24-3 (A1A+) or D28-103 (A1A+) - Body ground D24-4 (A1A-) or D28-126 (A1A-) - Body ground Reconnect the air fuel ratio sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ECM) OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-393423-S37052851662011040700000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the Pending DTCs. Result Result Proceed to DTC is not output A DTC P2237, P2238, P2239, P2252 or P2253 is output B B --> See step 5 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
| Related DTC | P2420: Vent valve stuck close |
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 2 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 to 111 kPa (525 to 832 mmHg) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Less than 2.5 mph (4 km/h) |
| Power switch | OFF |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Fuel vapor-containment valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions (a) and (b) are met before Key-OFF | |
| (a). Duration that vehicle is being driven | 5 minutes or more |
| (b). Purge flow | Executed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
Key-off monitor sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa (2.25 mmHg) per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa (-1.87 mmHg) or less |
| 2. Reference pressure | 4.85 to -1.057 kPa (-36.38 to -7.92 mmHg) |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (closed) | 0.3 kPa (2.25 mmHg) or more |
3. VENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the both of the following condition is met | |
| Vacuum introduction time | 15 minutes or less |
| Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (open) | 0.3 kPa (2.25 mmHg) or more |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa (-1.87 mmHg) or less |
| 2. Reference pressure | 4.85 to -1.057 kPa (-36.38 to -7.92 mmHg) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa (6.75 mmHg) |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa (-15 mmHg) or less, or 3 kPa (22.5 mmHg) or more |
| 2. Fuel tank pressure change while TCV and vent valve are open | 0.5 kPa (3.75 mmHg) or more |
8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa (-15 to 22.5 mmHg) |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa (3.75 mmHg) or more |
10. TCV STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when TCV closed | 0.35 kPa (2.62 mmHg) or more |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement | 0.25 kPa (-1.87 mmHg) or less |
| 2. Reference pressure | 4.85 to -1.057 kPa (-36.38 to -7.92 mmHg) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa (6.75 mmHg) |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while TCV and vent valve are open | Less than 0.35 kPa (2.62 mmHg) |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa (2.25 mmHg) |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| Canister pressure change for 10 seconds after vent valve opened | Less than 0.3 kPa (2.25 mmHg) |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 524
Scheme 524: CONFIRMATION DRIVING PATTERN
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
- After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the Pending DTC [B].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
- Input the DTC: P2420.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTC | P2450: Fuel vapor-containment valve stuck open P2451: Fuel vapor-containment valve stuck closed |
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 15 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 to 111 kPa (525 to 832 mmHg) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Less than 2.5 mph (4 km/h) |
| Power switch | OFF |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Fuel vapor-containment valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions (a) and (b) are met before Key-OFF | |
| (a). Duration that vehicle is being driven | 5 minutes or more |
| (b). Purge flow | Executed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
Key-off monitor sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa (2.25 mmHg) per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa (-1.87 mmHg) or less |
| 2. Reference pressure | 4.85 to -1.057 kPa (-36.38 to -7.92 mmHg) |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (closed) | 0.3 kPa (2.25 mmHg) or more |
3. VENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the both of the following condition is met | |
| Vacuum introduction time | 15 minutes or less |
| Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (open) | 0.3 kPa (2.25 mmHg) or more |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa (-1.87 mmHg) or less |
| 2. Reference pressure | 4.85 to -1.057 kPa (-36.38 to -7.92 mmHg) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa (6.75 mmHg) |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa (-15 mmHg) or less, or 3 kPa (22.5 mmHg) or more |
| 2. Fuel tank pressure change while TCV and vent valve are open | 0.5 kPa (3.75 mmHg) or more |
8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa (-15 to 22.5 mmHg) |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa (3.75 mmHg) or more |
10. TCV STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when TCV closed | 0.35 kPa (2.62 mmHg) or more |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement | 0.25 kPa (-1.87 mmHg) or less |
| 2. Reference pressure | 4.85 to -1.057 kPa (-36.38 to -7.92 mmHg) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa (6.75 mmHg) |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while TCV and vent valve are open | Less than 0.35 kPa (2.62 mmHg) |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa (2.25 mmHg) |
15. ATMOSPHERIC PRESSURE MEASUREMENT
P2450: Fuel vapor-containment valve stuck open
| One of the following conditions met fuel tank pressure is between -2 kPa (-15 mmHg) and 3 kPa (22.5 mmHg) | Condition 1 or 2 |
| 1. Fuel tank pressure change when vacuum introduction for canister | More than 0.5 kPa (3.75 mmHg) |
| 2. Canister pressure when vacuum introduction for canister was complete | Higher than reference pressure x 0.2 |
P2451: Fuel vapor-containment valve stuck close
| One of the following conditions met fuel tank pressure is between -2 kPa (-15 mmHg) and 3 kPa (22.5 mmHg) | Condition 1 or 2 |
| 1. Both of the conditions below are met | Condition (a) or (b) |
| (a) Fuel tank pressure | 2 to 3 kPa (-15 to 22.5 mmHg) |
| (b) Fuel tank pressure change when vacuum introduction for fuel tank | Less than 0.5 kPa (3.75 mmHg) |
| 2. Both of the conditions below are met | Condition (a) or (b) |
| (a) Fuel tank pressure | 2 kPa (-15 mmHg) or less or 3 kPa (22.5 mmHg) or more |
| (b) Canister pressure change when TCV is open | Less than 0.9 kPa (6.75 mmHg) |
Refer to the Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
- After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the Pending DTC [B].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
- Input the DTC: P2450 or P2451.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTC | P2610: ECM internal engine off timer performance |
| Required Sensors / Components | ECM |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Power switch | On (IG) |
| Engine | Running |
| Battery voltage | 8 V or more |
| CPU clock elapsed time | 10 minutes or more |
| Internal engine OFF timer (elapsed time from engine stop) | 10 minutes or more |
| Battery voltage | 8 V or more |
| Power switch | On (IG) |
| Internal engine OFF timer (elapsed time from engine stop) | 10 minutes or more |
| Battery voltage | 8 V or more |
| Power switch | On (IG) |
| Internal engine OFF timer (elapsed time from engine start) | Less than 7 minutes, or more than 13 minutes |
| ECM had the started record by internal engine OFF timer | Yes |
| ECM had the started record by internal engine OFF timer | No |
Scheme 525
Scheme 525: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine.
- Idle the engine for 10 minutes or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2610.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and wait for 10 minutes or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. If no pending DTC is displayed, the repair has been successfully completed. NEXT --> END
| Related DTCs | P261B: Engine coolant pump circuit performance P261C: Engine coolant pump circuit range check (low voltage) P261D: Engine coolant pump circuit range check (high voltage) |
| Required Sensors/Components (Main) | Water pump assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 15 seconds: Engine coolant pump circuit performance 3 seconds: Engine coolant pump circuit range check (low voltage, high voltage) |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 8 V or more |
| Power switch | On (IG) |
| Time after power switch off to on (IG) | More than 0.5 seconds |
| Output signal duty ratio | 40% or more |
| Monitor synchronism monitor status | Enable |
| Engine coolant temperature | 10°C (14 °F) or more |
| Engine coolant temperature circuit circuit fail (P0115, P0117, P0118) | Not detected |
| Engine coolant pump circuit range check low voltage fail (P261C) | Not detected |
| Engine coolant pump circuit range check high voltage fail (P261D) | Not detected |
P261B: ENGINE COOLANT PUMP CIRCUIT PERFORMANCE
| Output signal duty ratio | 40 to 60% |
| Engine coolant pump circuit performance fail (P261B) | Not detected |
| Engine coolant pump output terminal voltage monitor counter | 0.08 seconds or more |
P261C, P261D: ENGINE COOLANT PUMP CIRCUIT RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)
| Motor speed | Less than 900 rpm |
P261B: ENGINE COOLANT PUMP CIRCUIT PERFORMANCE
| Current engine coolant pump output terminal voltage | Low |
| Engine coolant pump output monitor | Fail |
P261C: ENGINE COOLANT PUMP CIRCUIT RANGE CHECK (LOW VOLTAGE)
| Current engine coolant pump output terminal voltage | High |
| Engine coolant pump output monitor | Fail |
P261D: ENGINE COOLANT PUMP CIRCUIT RANGE CHECK (HIGH VOLTAGE)
| Motor speed | 900 rpm or more |
Scheme 526
Scheme 526: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [B].
- Idle the engine for 20 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [D].
- If the DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P261B, P261C or P261D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 527
Scheme 527: WIRING DIAGRAM
| Related DTCs | P2A00: Air fuel ratio sensor (bank 1) slow response |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor, Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0016 (VVT System Bank 1 - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater - Sensor 1) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0401 (EGR System (Closed)) P0451, P0452, P0453, P1451, P1452, P1453 (EVAP System) P0505 (Idle speed control) |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control is performed when following conditions met | |
| Battery voltage | 11 V or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Idling | OFF |
| Engine rpm | Less than 4000 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Catalyst monitor | Not yet |
| Mass air flow | 4.5 to 12 gm/sec |
| Response rate deterioration level | Less than 0.17 V |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.
Scheme 528
Scheme 528: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on ((IG).
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor.
- Check that the Status2 of O2 Sensor is Incomplete.
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at a constant speed of between 47 and 62 mph (75 and 100 km/h) for 10 minutes [B].
- Those items will change to Complete after completing the drive pattern.
- If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-393417-S09994474532011040700000) .
- Check the monitor result values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor / Details / RANGE B1S1.
- Note the value of the Monitor Result.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2A00.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2A00) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2A00 is output A DTC P2A00 and other DTCs are output B HINT: If any DTCs other than P2A00 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-393421-S10328614112011040700000) NG --> See step 14 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) See step 1 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ECM) OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the Pending DTCs. Result Result Proceed to DTC P2A00 is output A DTC is not output B B --> See step 15 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-393423-S37052851662011040700000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the Pending DTCs. Result Result Proceed to DTC P2A00 is output A DTC is not output B B --> END A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 11 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 16 OK: Go to next step
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2A00. Check the DTC judgment result. NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-393423-S37052851662011040700000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-393412-S37278285322011040700000)
| Related DTCs | P3190: Poor engine power P3191: Engine does not start |
| Required sensors/components | Main sensors: Crankshaft position sensor Related sensors: Power management control ECU |
| Frequency of operation | Continuous |
| Duration | 100 engine revolutions or 6 seconds |
| MIL operation | Immediately (MIL illumination) |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Fuel cut operation | Not operated |
| Engine speed | 650 rpm or more (varies with engine coolant temperature) |
| Communication with power management control ECU | No malfunction |
| Time for low engine torque | 100 engine revolutions or more, and 6 seconds or more (varies with engine coolant temperature) |
| Fuel level | Not empty |
| Engine start no-determination time (receive from power management control ECU) | 100 engine revolutions or more, and 6 seconds or more (varies with engine coolant temperature) |
| Fuel level | Not empty |
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P3190, P3191 AND/OR P3193) Connect the Techstream to the DLC3. Turn the power switch ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P3190, P3191 and/or P3193 are output A DTC P3190, P3191 and/or P3193, and other DTCs are output B HINT: If any other codes besides P3190, P3191 and/or P3193 are output, perform troubleshooting for those DTCs first. B --> See step 18 A: Go to next step
- CHECK SHORTAGE OF FUEL NG --> REFILL FUEL OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-393426-S19662706812011040700000) . OK No leaks in intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK FOR UNUSUAL NOISE OR VIBRATION WHEN STARTING ENGINE OR REVVING UP OK Unusual noise and vibration do not occur. NG --> REPAIR OR REPLACE MALFUNCTIONING PART OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-393429-S39769839882011040700000) . NG --> See step 17 OK: Go to next step
- INSPECT FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT Trouble Codes / Freeze Frame Data. Calculate the requested torque* and compare it with Actual Engine Torque. HINT: *: The requested torque is calculated by putting "Requested Engine Torque" and "HV Target Engine Speed" from the freeze frame data into the following formula: Requested torque = Requested Engine Torque (kW) / HV Target Engine Speed (rpm) x 6112 Standard Actual Engine Torque is 60% or more of the request torque. Result Result Proceed to NG A OK B B --> See step 8 A: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY Inspect the throttle body assembly. Refer to «ON-VEHICLE INSPECTION»(ref-393423-S23484434962011040700000) . NG --> See step 22 OK: Go to next step
- INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Inspect the mass air flow meter sub-assembly. Refer to «ON-VEHICLE INSPECTION»(ref-393423-S06013638852011040700000) . NG --> See step 19 OK: Go to next step
- INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION»(ref-393423-S42443014932011040700000) . NG --> See step 20 OK: Go to next step
- INSPECT CRANKSHAFT POSITION SENSOR Inspect the crankshaft position sensor. Refer to «INSPECTION»(ref-393423-S11834749542011040700000) . NG --> See step 21 OK: Go to next step
- REPLACE CAMSHAFT POSITION SENSOR Replace the camshaft position sensor. Refer to «REMOVAL»(ref-393423-S28940228442011040700000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P3190, P3191 OR P3193) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Allow the engine to idle for 10 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to P3190, P3191 or P3193 is output A DTC is not output B B --> END A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 15 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 24 OK: Go to next step
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Allow the engine to idle for 10 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P3190, P3191 or P3193. Check the DTC judgment result. NEXT --> END
- CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 23
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-393423-S19194059732011040700000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-393423-S17021413342011040700000)
- REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-393423-S18831488322011040700000)
- REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-393423-S42932276002011040700000)
- REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-393425-S12313155182011040700000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-393412-S37278285322011040700000)
| Related DTCs | U0293: Lost communication with power management control ECU |
| Required Sensors/Components (Main) | ECM |
| Frequency of Operation | Continuous |
| Duration | 0.576 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery Voltage | 10.5 V or more (more than 0.5 seconds) |
| Power switch | On (IG) (more than 0.5 seconds) |
| Communication signal | No signal from power management control ECU |
Scheme 529
Scheme 529: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 5 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: U0293.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 530
Scheme 530: WIRING DIAGRAM
RELATED DTCS
| DTC No. | Monitoring Item | See |
| P043E | Reference orifice low flow | Refer to DTC P043E: Evaporative Emission System Reference Orifice Clog Up; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission System Leak Detection Pump Control Circuit Low; DTC P2402: Evaporative Emission System Leak Detection Pump Control Circuit High; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P043F | Reference orifice high flow |
| P0441 | Purge VSV stuck closed Purge VSV stuck open Insufficient purge flow | Refer to DTC P0441: Evaporative Emission Control System Incorrect Purge Flow |
| P1420 | Small or 0.02 inch leak from canister | Refer to DTC P1420: Evaporative Emission Canister Small Leak; DTC P1421: Evaporative Emission Canister Gross Leak |
| P1421 | Gross leak from canister |
| P1422 | Small or 0.02 inch leak from fuel tank | Refer to DTC P1422: Fuel Tank Small Leak; DTC P1423: Fuel Tank Gross Leak |
| P1423 | Gross leak from fuel tank |
| P2401 | Vacuum pump stuck OFF | Refer to DTC P043E: Evaporative Emission System Reference Orifice Clog Up; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission System Leak Detection Pump Control Circuit Low; DTC P2402: Evaporative Emission System Leak Detection Pump Control Circuit High; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P2402 | Vacuum pump stuck ON |
| P2419 | Vent valve stuck ON (closed) |
| P2420 | Vent valve stuck OFF (vent) | Refer to DTC P2420: Evaporative Emission System Switching Valve Control Circuit High |
| P2450 | Fuel vapor-containment valve stuck open | Refer to DTC P2450: Fuel Vapor-containment Valve Stuck Open; DTC P2451: Fuel Vapor-containment Valve Stuck Close |
| P2451 | Fuel vapor-containment valve stuck closed |
- KEY-OFF MONITOR DRIVE PATTERN Connect the Techstream to the DLC3. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Confirm that the following conditions are satisfied: The fuel level is less than 90%. The altitude is less than 7874 ft. (2400 m). The vehicle is stopped (the vehicle speed is 0 mph (0 km/h)). The engine coolant temperature is 4.4 to 35°C (40 to 95°F) The intake air temperature is 4.4 to 35°C (40 to 95°F) Perform the following drive pattern: Allow the engine to idle for 5 minutes or more. Turn the power switch off and wait 5, 7 or 9.5 hours. Check the monitor status with the Techstream.
- PURGE FLOW MONITOR DRIVE PATTERN (P0441) Connect the Techstream to the DLC3. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Confirm that the following conditions are satisfied: The engine coolant temperature is more than 4.4°C (40°F). The intake air temperature is more than 4.4°C (40°F). Perform the following drive pattern: Remove and reinstall the fuel cap to release the fuel tank pressure. Warm the engine until the engine coolant temperature reaches 75°C (167°F) or more. Run the engine at 2500 rpm once. Check the monitor status using the Techstream.
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
