MONITOR STRATEGY

Related DTCsP0327: Knock sensor (bank 1) range check (Low voltage) P0328: Knock sensor (bank 1) range check (High voltage)
Required Sensors/Components (Main)Knock control sensor
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration1 second
MIL OperationImmediately
Sequence of OperationNone

TYPICAL ENABLING CONDITIONS

Monitor runs whenever following DTCs are not presentNone
Battery voltage10.5 V or more
Time after engine start5 seconds or more

TYPICAL MALFUNCTION THRESHOLDS

Knock sensor voltageLess than 0.5 V

KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327

Knock sensor voltageMore than 4.5 V

KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328

Scheme 572

Scheme 572: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine and wait 10 seconds.
  8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  9. Read the DTC [B].
  10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  12. Input the DTC: P0327 or P0328.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes.
  14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  15. Check the judgment result [C]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 573

Scheme 573: WIRING DIAGRAM
Related DTCsP0335: Crankshaft position sensor verify pulse input P0335: Crankshaft position sensor range check or rationality
Required Sensors/Components (Main)Crankshaft position sensor
Required Sensors/Components (Related)Camshaft position sensor
Frequency of OperationContinuous
Duration1.85 seconds: Verify pulses input (case 1) 15 seconds: Verify pulses input (case 2) 0.016 seconds: Range check or rationality
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Time after power switch off to on (IG)More than 0.5 seconds
Lost communication with power management control ECU (U0293)Not detected

P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)

Time after power switch off to on (IG)More than 0.5 seconds
Engine speed600 rpm or less
Time after starter ON to OFF3 seconds or more
Lost communication with power management control ECU (U0293)Not detected

P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)

Engine speed signalSignal input
Time after starter OFF to ON2.5 seconds or more
Camshaft position sensor circuit fail (P0340, P0342, P0343)Not detected
Number of camshaft position sensor signal pulse6 times or more
Battery voltage7 V or more
Lost communication with power management control ECU (U0293)Not detected

P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK OR RATIONALITY

Engine speed signalNo signal

P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)

Engine speed signalNo signal

P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)

Number of crankshaft position sensor signal pulse87 times or less, or 219 times or more

P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK OR RATIONALITY

COMPONENT OPERATING RANGE

Crankshaft position sensorCrankshaft position sensor output voltage fluctuates while crankshaft revolving 34 crankshaft position sensor signals per crankshaft revolution

Scheme 574

Scheme 574: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine.
  8. Idle the engine for 20 seconds or more [B].
  9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  10. Read the DTC [C].
  11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  13. Input the DTC: P0335.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
  15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 575

Scheme 575: WIRING DIAGRAM
Related DTCsP0340: Camshaft position sensor verify pulse input P0342: Camshaft position sensor range check (Low voltage) P0343: Camshaft position sensor range check (High voltage)
Required Sensors/Components (Main)Camshaft position sensor
Required Sensors/Components (Related)Crankshaft position sensor
Frequency of OperationContinuous
Duration5 seconds: Camshaft position / sensor verify pulse input 4 seconds: Camshaft position sensor range check (Low voltage, high voltage)
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Engine speed600 rpm or more
StarterOFF
Camshaft position sensor range check fail (P0342, P0343)Not detected
Camshaft position sensor voltage0.3 to 4.7 V
Lost communication of power management control ECU (U0293)Not detected

P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT

StarterOFF
Time after power switch OFF to on (IG)2 seconds or more
Camshaft position sensor verify pulse input fail (P0340)Not detected
Battery voltage8 V or more

P0342, P0343: CAMSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)

Camshaft position and crankshaft position alignmentMisalignment
Camshaft position sensor signalNo signal

P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT

Camshaft position sensor voltageLess than 0.3 V

P0342: CAMSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE)

Camshaft position sensor voltageMore than 4.7 V

P0343: CAMSHAFT POSITION SENSOR RANGE CHECK (HIGH VOLTAGE)

Camshaft position sensorCamshaft position sensor output voltage fluctuates while camshaft revolving 3 camshaft position sensor signals per 2 crankshaft revolutions
Camshaft position sensor voltage0.3 to 4.7 V

Scheme 576

Scheme 576: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine.
  8. Idle the engine for 10 seconds or more [B].
  9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  10. Read the DTC [C].
  11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  13. Input the DTC: P0340, P0342 or P0343.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
  15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0351: Igniter (cylinder 1) malfunction P0352: Igniter (cylinder 2) malfunction P0353: Igniter (cylinder 3) malfunction P0354: Igniter (cylinder 4) malfunction
Required Sensors/Components (Main)Igniter
Required Sensors/Components (Related)Crankshaft position sensor
Frequency of OperationContinuous
Duration0.256 seconds
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Either of the following conditions A or B is met
A. Engine speed1500 rpm or less
B. StarterOFF
Either of the following conditions C or D met
C. Both of the following conditions (a) and (b) are met
(a) Engine speed500 rpm or less
(b) Battery voltage6 V or more
D. All of the following conditions (c), (d) and (e) are met
(c) Engine speedMore than 500 rpm
(d) Battery voltage10 V or more
(e) Number of sparks after CPU reset5 sparks or more
Lost communication with power management control ECU (U0293)Not detected
All of the following conditions are metConditions A, B and C
A. Ignition signal fail counterMore than 2 times
B. Time after condition A is met0.256 seconds or more
C. Ignition signal fail count after condition B is metMore than 2 times
Confirmed ignition signal input when ignition signal is ON to OFF2 times

Scheme 577

Scheme 577: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine.
  8. Idle the engine for 10 seconds or more [B].
  9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  10. Read the DTC [C].
  11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  13. Input the DTC: P0351, P0352, P0353 or P0354.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
  15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 578

Scheme 578: WIRING DIAGRAM

Scheme 579

Scheme 579
Related DTCP0401: EGR valve high flow rate / low flow rate
Required sensors / components (Main)EGR valve assembly, manifold absolute pressure sensor
Required sensors / components (Related)Engine coolant temperature sensor, vehicle speed sensor
Frequency of operationContinuous
DurationWithin 3 seconds
MIL operation2 driving cycles
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Time after engine started3 seconds or more
Time after engine fuel cut2000 msec or more
Engine speed950 to 1600 rpm
Vehicle speed12.5 mph (20 km/h) or more
Engine speed change (/ 65 msec)20 to 20 rpm
Time after engine load becomes stable (HVAC, Brake, Lockup)More than 1.2 seconds
Engine coolant temperature70°C (158°F) or more
Battery voltage11 V or more
Intake air temperature10°C (14°F) or more
Atmospheric pressure76 kPa (570 mmHg) or more
Manifold pressure changeLess than 1.0 kPa (7.5 mmHg)
At engine speed1050 rpm

Scheme 580

Scheme 580: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or more [B]. HINT: The A/C switch and all accessory switches should be off and shift lever in P or N.
  8. Drive the vehicle at 25 to 37 mph (40 to 60 km/h) for 5 minutes or more [C].
  9. Idle the engine for 30 seconds or more [D].
  10. Accelerate the vehicle to 25 to 37 mph (40 to 60 km/h) with the shift lever in B [E].
  11. Perform fuel cut operation for 5 seconds or more, with the accelerator pedal fully released [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: When fuel cut is operating "Idle Fuel Cut" in Data List is ON.
  12. Enter the following menus: Powertrain / Engine and ECT / Monitor / Exhaust Gas Recirculation/VVT / Status2 [G].
  13. Check that the Exhaust Gas Recirculation/VVT / Status2 monitor is Complete. HINT: If the monitor is Incomplete, perform the driving pattern again.
  14. Enter the following menus: Powertrain / Engine and ECT / Monitor / Exhaust Gas Recirculation/VVT/Details.
  15. Check the Details (EGR FLOW INSUFFICIENCY). HINT: Make sure that the value is between MIN and MAX.
  16. If the monitor is still Incomplete, perform the following procedure.
  17. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  18. Read Pending DTCs.
  19. If a pending DTC is output, the system is malfunctioning, HINT: If a pending DTC is not output, perform the following procedure.
  20. Enter the following menus: Power train / Engine and ECT / Utility / All Readiness.
  21. Input the DTC: P0401.
  22. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgement result shows NORMAL, the system is normal. If the DTC judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, accelerate the vehicle again at 25 to 37 mph (40 to 60 km/h) with the shift lever in B, perform fuel cut operation for 5 seconds or more with the accelerator pedal fully released, and check the DTC judgment result.
  23. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0403: EGR valve circuit range check
Required sensors / components (Main)EGR valve assembly
Required sensors / components (Related)
Frequency of operationContinuous
Duration0.5 seconds
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
EngineRunning
Battery voltage10.5 V or more
Time after power switch off to on (IG)More than 0.5 seconds
One of the following conditions is metConditions A, B, C or D
A. All of the conditions are metConditions 1 and 2
1. EGR1 output terminal voltageLow voltage
2. Either of the following conditions is metCondition (a) or (b)
(a) Step motorDriving
(b) EGR1Not operating
B. All of the following conditions are metConditions 3 and 4
3. EGR2 output terminal voltageLow voltage
4. Either of the following conditions is metCondition (c) or (d)
(c) Step motorDriving
(d) EGR2Not operating
C. All of the following conditions are metConditions 5 and 6
5. EGR3 output terminal voltageLow voltage
6. Either of the following conditions is metCondition (e) or (f)
(e) Step motorDriving
(f) EGR3Not operating
D. All of the following conditions are metConditions 7 and 8
7. EGR4 output terminal voltageLow voltage
8. Either of the following conditions is metCondition (g) or (h)
(g) Step motorDriving
(h) EGR4Not operating

Scheme 581

Scheme 581: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine and warm it up [B].
  8. Drive the vehicle at 12 mph (20 km/h) or more for 10 minutes [C].
  9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  10. Read the DTCs [D].
  11. If the DTC P0403 is output, the system is malfunction. HINT: If a DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  13. Input the DTC: P0403.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system has a normal.
  15. If the test result is INCOMPLETE or UNKNOWN, drive the vehicle at 12 mph (20 km/h) or more for 10 minutes, and check the DTC judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system has a normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 582

Scheme 582: WIRING DIAGRAM
Related DTCsP0420: Catalyst Deterioration
Required Sensors/Components (Main)Air fuel ratio sensor Heated oxygen sensor
Required Sensors/Components (Related)Intake air temperature sensor Mass air flow meter sub-assembly Crankshaft position sensor Engine coolant temperature sensor
Frequency of OperationOnce per driving cycle
DurationAbout 30 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not presentP0010 (VVT Oil Control Valve Bank 1) P0011 (VVT System Bank 1 - Advance) P0012 (VVT System Bank 1 - Retard) P0016 (VVT System Bank 1 - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater - Sensor 1) P0037, P0038, P102D (Heated Oxygen Sensor Heater - Sensor 2) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0136, P0137, P0138, P0139 (Rear Oxygen sensor - Sensor 2) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR System (Closed)) P0607 (Heated Oxygen Sensor - Sensor 2) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1)
Battery voltage11 V or more
Intake air temperature10°C (14°F) or more
Engine coolant temperature75°C (167°F) or more
Atmospheric pressure76 kPa (570 mmHg) or more
IdlingOFF
Engine speedLess than 4000 rpm
Air fuel ratio sensorActivated
Fuel system statusClosed loop
Engine load10 to 70%
All of the following conditions are metConditions 1, 2 and 3
1. Mass air flow rate8 to 28 g/sec
2. Front catalyst temperature (estimated)550 to 750°C (1022 to 1382°F)
3. Rear catalyst temperature (estimated)450 to 700°C (842 to 1292°F)
Air fuel ratio sensor monitorCompleted
Rear Heated oxygen sensor monitorCompleted
Oxygen storage capacity of catalystLess than 0.07 g

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

CONFIRMATION DRIVING PATTERN

HINT

Performing this confirmation pattern will activate the catalyst monitor. This is very useful for verifying the completion of a repair.

Scheme 583

Scheme 583: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG).
  3. Turn the Techstream on.
  4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  5. Turn the power switch off.
  6. Turn the power switch on (IG) and turn the Techstream on.
  7. Enter the following menus: Powertrain / Engine and ECT / Monitor.
  8. Check that Catalyst Efficiency / Status2 is Incomplete.
  9. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  10. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
  11. Drive the vehicle at between 47 and 75 mph (75 and 120 km/h) for at least 10 minutes or more [B].
  12. Those items will change to Complete after completing the driving pattern.
  13. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  14. Check if any DTCs (pending DTCs) are set.

HINT

If Catalyst does not change to Complete, and no pending DTCs are stored, extend the driving time.

PROCEDURE

  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 is output A DTC P0420 and other DTCs are output B HINT: If any DTCs other than P0420 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (AIR FUEL RATIO CONTROL) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up. Run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F sensor. Perform the Active Test operation with the engine in an idling condition (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +25% Rich Less than 3.1 V -12.5% Lean More than 3.4 V O2S B1S2 (Heated oxygen) +25% Rich More than 0.55 V -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1S1 Status O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensors Condition Misfire Main Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leaks from exhaust system EGR valve assembly A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system Lean Lean Actual air fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system EGR valve assembly D Rich Rich Actual air fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system EGR valve assembly Lean: During Control the Injection Volume for A/F sensor, the air fuel ratio sensor output voltage (AFS Voltage) is consistently more than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During the AFS Voltage is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F sensor of the Active Test, the output voltage of the heated oxygen sensor alternates correctly. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. D --> See step 11 C --> See step 9 B --> See step 7 A: Go to next step
  3. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
  4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 8 A: Go to next step
  5. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 15 OK --> See step 8
  6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
  7. REPLACE AIR FUEL RATIO SENSOR (SENSOR 1). Refer to «REMOVAL»(ref-393423-S37052851662011040700000)
  8. REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: FRONT AND REAR CATALYST). Refer to «COMPONENTS»(ref-393430-S25319863842011040700000)
  9. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 10
  10. REPLACE HEATED OXYGEN SENSOR (SENSOR 2). Refer to «REMOVAL»(ref-393423-S30854517232011040700000)
  11. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
  12. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 14 A: Go to next step
  13. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 15 OK --> See step 14
  14. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-393421-S09406001672011040700000)
  15. REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-393412-S37278285322011040700000)
Related DTCsP043E: 0.020 inch reference orifice low flow malfunction P043F: 0.020 inch reference orifice high flow malfunction P2401: Leak detection pump stuck off P2402: Leak detection pump stuck on P2419: Vent valve stuck open (vent)
Required Sensors / ComponentsCanister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 2 minutes
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Key-off monitor runs when all of the following conditions are met
Atmospheric pressure70 to 111 kPa (525 to 832 mmHg)
Battery voltage10.5 V or more
Vehicle speedLess than 2.5 mph (4 km/h)
Power switchOFF
Engine conditionNot running
Key-OFF duration5 or 7 or 9.5 hours
Pressure sensor of canister pump module malfunction (P0452 and P0453)Not detected
Fuel tank pressure sensor malfunction (P1452 and P1453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Fuel vapor-containment valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of the following conditions (a) and (b) are met before Key-OFF
(a). Duration that vehicle is being driven5 minutes or more
(b). Purge flowExecuted
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)

Key-off monitor sequence 1 to 15

Next sequence is run if the following condition is met
Atmospheric pressure changeLess than 0.3 kPa (2.25 mmHg) per second

1. ATMOSPHERIC PRESSURE MEASUREMENT

Next sequence is run if all of the following conditions are metConditions 1, 2 and 3
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated

2. FIRST REFERENCE PRESSURE MEASUREMENT

Next sequence is run if the following condition is met
Canister pressure change after vent valve ON (closed)0.3 kPa (2.25 mmHg) or more

3. VENT VALVE STUCK CLOSED CHECK

Next sequence is run if the both of the following condition is met
Vacuum introduction time15 minutes or less
Canister pressureSaturated

4. VACUUM INTRODUCTION FOR CANISTER

Next sequence is run if the following condition is met
Canister pressure change for 10 seconds after purge VSV ON (open)0.3 kPa (2.25 mmHg) or more

5. PURGE VSV STUCK CLOSED CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3 and 4
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the first and secondLess than 0.9 kPa (6.75 mmHg)

6. SECOND REFERENCE PRESSURE MEASUREMENT

One of the sequence 8 or 9 is run if the following condition is met
Canister pressure when vacuum introduction for canister was completeSecond reference pressure or less

7. CANISTER LEAK CHECK

Sequence 14 is run if all of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 kPa (-15 mmHg) or less, or 3 kPa (22.5 mmHg) or more
2. Fuel tank pressure change while TCV and vent valve are open0.5 kPa (3.75 mmHg) or more

8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK

Next sequence is run if both of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 to 3 kPa (-15 to 22.5 mmHg)
2. Vacuum introduction time15 minutes or less

9. VACUUM INTRODUCTION FOR FUEL TANK

Next sequence is run if the following condition is met
Fuel tank pressure change when vacuum introduction for fuel tank0.5 kPa (3.75 mmHg) or more

10. TCV STUCK CLOSED CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change when TCV closed0.35 kPa (2.62 mmHg) or more

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3, and 4
1. Fuel tank pressure when 1.9 seconds after reference pressure measurement0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the second and thirdLess than 0.9 kPa (6.75 mmHg)

12 THIRD REFERENCE PRESSURE MEASUREMENT

Sequence 15 is run if the following condition is met
Fuel tank pressure when vacuum introduction for fuel tank was completeLess than third reference pressure

13. FUEL TANK LEAK CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change while TCV and vent valve are openLess than 0.35 kPa (2.62 mmHg)

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

Monitor is complete if the following condition is met
Atmospheric pressure difference between sequence 1 and 8Less than 0.3 kPa (2.25 mmHg)

15. ATMOSPHERIC PRESSURE MEASUREMENT

Following values are values when atmospheric pressure is 100 kPa (760 mmHg)
One of the following conditions is met
Canister pressure when 1.9 seconds after reference pressure measurement beganMore than -0.25 kPa (-1.87 mmHg)
Reference pressure (vary with atmospheric pressure)Less than -4.85 kPa (-36.38 mmHg)
Reference pressure (vary with atmospheric pressure)1.057 kPa (-7.92 mmHg) or more
Reference pressure (vary with atmospheric pressure)Not saturated
Reference pressure difference between the first and second0.9 kPa (6.75 mmHg) or more

Scheme 584

Scheme 584: CONFIRMATION DRIVING PATTERN

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
  7. After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  8. Read the Pending DTC [B].
  9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  11. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Related DTCsP0441: Purge flow P0441: Purge VSV stuck open/closed
Required Sensors/ComponentsPurge VSV and canister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 15 minutes: Purge VSV stuck open/closed Within 10 minutes: Purge flow
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
EngineRunning
Engine coolant temperature4.4°C (40°F) or more
Intake air temperature4.4°C (40°F) or more
Pressure sensor of canister pump module malfunction (P0451, P0452, P0453)Not detected
Purge VSVNot operated by scan tool
EVAP system checkNot operated by scan tool
Battery voltage10 V or more
Purge duty cycle8% or more

PURGE FLOW MONITOR

Monitor runs whenever following DTCs are not presentNone
Key-off monitor runs when all of the following conditions are met
Atmospheric pressure70 to 111 kPa (525 to 832 mmHg)
Battery voltage10.5 V or more
Vehicle speedLess than 2.5 mph (4 km/h)
Power switchOFF
Engine conditionNot running
Key-OFF duration5 or 7 or 9.5 hours
Pressure sensor of canister pump module malfunction (P0452 and P0453)Not detected
Fuel tank pressure sensor malfunction (P1452 and P1453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Fuel vapor-containment valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of the following conditions (a) and (b) are met before Key-OFF
(a). Duration that vehicle is being driven5 minutes or more
(b). Purge flowExecuted
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)

KEY-OFF MONITOR

Key-off monitor sequence 1 to 15

Next sequence is run if the following condition is met
Atmospheric pressure changeLess than 0.3 kPa (2.25 mmHg) per second

1. ATMOSPHERIC PRESSURE MEASUREMENT

Next sequence is run if all of the following conditions are metConditions 1, 2 and 3
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated

2. FIRST REFERENCE PRESSURE MEASUREMENT

Next sequence is run if the following condition is met
Canister pressure change after vent valve ON (closed)0.3 kPa (2.25 mmHg) or more

3. VENT VALVE STUCK CLOSED CHECK

Next sequence is run if the both of the following condition is met
Vacuum introduction time15 minutes or less
Canister pressureSaturated

4. VACUUM INTRODUCTION FOR CANISTER

Next sequence is run if the following condition is met
Canister pressure change for 10 seconds after purge VSV ON (open)0.3 kPa (2.25 mmHg) or more

5. PURGE VSV STUCK CLOSED CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3 and 4
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the first and secondLess than 0.9 kPa (6.75 mmHg)

6. SECOND REFERENCE PRESSURE MEASUREMENT

One of the sequence 8 or 9 is run if the following condition is met
Canister pressure when vacuum introduction for canister was completeSecond reference pressure or less

7. CANISTER LEAK CHECK

Sequence 14 is run if all of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 kPa (-15 mmHg) or less, or 3 kPa (22.5 mmHg) or more
2. Fuel tank pressure change while TCV and vent valve are open0.5 kPa (3.75 mmHg) or more

8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK

Next sequence is run if both of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 to 3 kPa (-15 to 22.5 mmHg)
2. Vacuum introduction time15 minutes or less

9. VACUUM INTRODUCTION FOR FUEL TANK

Next sequence is run if the following condition is met
Fuel tank pressure change when vacuum introduction for fuel tank0.5 kPa (3.75 mmHg) or more

10. TCV STUCK CLOSED CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change when TCV closed0.35 kPa (2.62 mmHg) or more

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3, and 4
1. Fuel tank pressure when 1.9 seconds after reference pressure measurement0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the second and thirdLess than 0.9 kPa (6.75 mmHg)

12 THIRD REFERENCE PRESSURE MEASUREMENT

Sequence 15 is run if the following condition is met
Fuel tank pressure when vacuum introduction for fuel tank was completeLess than third reference pressure

13. FUEL TANK LEAK CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change while TCV and vent valve are openLess than 0.35 kPa (2.62 mmHg)

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

Monitor is complete if the following condition is met
Atmospheric pressure difference between sequence 1 and 8Less than 0.3 kPa (2.25 mmHg)

15. ATMOSPHERIC PRESSURE MEASUREMENT

Canister pressure when vacuum introduction for canister was completeHigher than reference pressure x 0.2

PURGE VSV STUCK OPEN

Canister pressure change for 10 seconds after purge VSV ON (open)Less than 0.3 kPa (2.25 mmHg)

PURGE VSV STUCK CLOSED

Both of the following conditions are metConditions 1 and 2
1. Canister pressure change when purge operation is startedLess than 0.1 kPa (0.75 mmHg)
2. Canister pressure change during purge operation when vent valve is closedLess than 0.5 kPa (3.75 mmHg)

PURGE FLOW

Scheme 585

Scheme 585: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine and wait 15 minutes or more [B].
  8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes/ Pending.
  9. Read the pending DTC [C].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  12. Input the DTC: P0441.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NOTE: The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
  14. Turn the power switch on (IG) and turn the Techstream on.
  15. Clear the DTCs (even if no DTCs are stored, perform the clear the DTC operation). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  16. Turn the power switch off and wait for 30 seconds.
  17. Turn the power switch on (IG) and turn the Techstream on.
  18. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [D].
  19. After the Evaporative System is completed, check for DTC by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / pending.
  20. Read the pending DTC [E].
  21. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  22. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  23. Input the DTC: P0441.
  24. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D].
  25. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  26. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  27. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P0441) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTC. Result Result Proceed to DTC P0441 is output A DTC P0441 and other DTCs are output B B --> See step 4 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. Result Result Proceed to Outside standard range A Within standard range B B --> See step 6 A: Go to next step
  3. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 5 OK --> See step 6
  4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
  5. REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-393412-S37278285322011040700000)
  6. GO TO EVAP SYSTEM. Refer to «EVAP System»(ref-393419-S37940908042011040700000)
Related DTCsP0451: Evaporative emission control system canister pressure sensor noise P0452: Evaporative emission control system canister pressure sensor/switch low input P0453: Evaporative emission control system canister pressure sensor/switch high input
Required Sensors / ComponentsCanister pump module
Frequency of OperationContinuous
DurationLess than 15 seconds: P0451 0.5 seconds: P0452, P0453
MIL OperationImmediately: P0452, P0453 2 driving cycles: P0451
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Atmospheric pressure70 to 111 kPa (525 to 832 mmHg)
Battery voltage10.5 V or more
Intake air temperature4.4 to 50°C (40 to 122°F)
Pressure sensor of canister pump module malfunction (P0452, P0453)Not detected
Either of the following conditions 1 or 2 is met
1. EngineRunning
2. Key-off duration5, 7 or 9.5 hours

P0451: NOISE MONITOR

Power switchOn (IG)
Battery voltage8 V or more

P0452 AND P0453

Frequency that canister pressure change is 0.3 kPa (2.25 mmHg) or more10 times or more in 10 seconds

P0451: NOISE MONITOR

EVAP pressureLess than 42.11 kPa (316 mmHg)

P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE

EVAP pressureMore than 123.761 kPa (928.5 mmHg)

P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE

Scheme 586

Scheme 586: CONFIRMATION DRIVING PATTERN

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air.
  4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  5. Turn the power switch off and wait for 30 seconds.
  6. Turn the power switch on (IG) and turn the Techstream on.
  7. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
  8. After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  9. Read the pending DTC [B].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  12. Input the DTC: P0451, P0452 or P0453.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 587

Scheme 587: WIRING DIAGRAM

Scheme 588

Scheme 588
Related DTCsP0505: Idle speed control function
Required Sensors/Components (Main)Electronic throttle control system
Required Sensors/Components (Related)Crankshaft position sensor Engine coolant temperature sensor Vehicle speed sensor
Frequency of OperationOnce per driving cycle
Duration10 minutes (Idling after warming up)
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0010 (Camshaft Timing Oil Control Valve Bank 1) P0011 (VVT System Bank 1 - Advance) P0012 (VVT System Bank 1 - Retard) P0016 (VVT System Bank 1 - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater - Sensor 1) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR System (Closed)) P0451, P0452, P0453, P1451, P1452, P1453 (EVAP System) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1)
EngineRunning
Either of the following conditions is metCondition 1 or 2
1. Frequency that both of the following conditions (a) and (b) are met5 times or more
(a) Engine rpm - Target engine rpmLess than -100 rpm, or 200 rpm or more
(b) Vehicle conditionStop after vehicle was driven by 34.375 mph (56 km/h) or more
2. Frequency that both of the following conditions (c) and (d) are metOnce
(c) Engine rpm - Target engine rpmLess than -100 rpm, or 200 rpm or more
(d) Idle air control flow rate learning valve0.5 L/sec or less, or 6.1 L/sec or more

Scheme 589

Scheme 589: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
  4. Make sure that the coolant temperature is 60°C (140°F) or less [A]. HINT: If the coolant temperature is 60°C (140°F) or more, the engine may stop when idling. Make sure to keep the coolant temperature at 60°C (140°F) or less during the driving pattern.
  5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  7. Start the engine and drive the vehicle until the coolant temperature reaches 70°C (158°F) [B].
  8. Stop the vehicle (0 mph (0 km/h)) [C].
  9. Accelerate the vehicle to 34 to 37 mph (55 to 60 km/h) or more, and then idle the engine [D]. HINT: If the vehicle speed reaches more than 37 mph (60 km/h), the engine may stop while decelerating.
  10. Stop the vehicle (0 mph (0 km/h)) [E].
  11. Repeat steps [D] and [E] for 5 times or more.
  12. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  13. Read the pending DTC [F].
  14. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  16. Input the DTC: P0505.
  17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, repeat steps [D] and [E] for 5 times or more.
  18. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  19. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  20. If the test result is INCOMPLETE or UNKNOWN, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If a permanent DTC is not output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
  2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
  3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-393426-S19662706812011040700000) . OK No leaks from the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
  4. INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing and then check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 10 OK: Go to next step
  5. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 7 A: Go to next step
  6. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 11 OK: Go to next step
  7. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000) . NEXT: Go to next step
  8. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0505. Check the DTC judgment result. NEXT --> END
  9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
  10. REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-393423-S42932276002011040700000)
  11. REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-393412-S37278285322011040700000)
Related DTCsP050A: Idle speed control problem at cold
Required Sensors/Components (Main)Mass air flow meter sub-assembly
Required Sensors/Components (Related)Engine coolant temperature sensor, throttle position sensor, vehicle speed sensor
Frequency of OperationOnce per driving cycle
Duration10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0010 (Camshaft Timing Oil Control Valve Bank 1) P0011 (VVT System Bank 1- Advance) P0012 (VVT System Bank 1- Retard) P0016 (VVT System Bank 1 - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR System (Closed)) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1)
Battery voltage8 V or more
Time after engine start3 seconds or more
StarterOFF
Engine coolant temperature at engine start10°C (14°F) or more
Engine coolant temperature10 to 65°C (14 to 149°F)
Engine idling time10 seconds or more
Fuel-cutOFF
Vehicle speedLess than 37.5 mph (60 km/h)
Atmospheric pressure76 kPa (570 mmHg) or more
Accumulated mass air flowLess than 10 g (varies with engine coolant temperature)

Scheme 590

Scheme 590: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
  7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
  8. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  9. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
  10. Idle the engine for 1 minute or more [B].
  11. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  12. Read the pending DTC [C].
  13. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  15. Input the DTC: P050A.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [B].
  17. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  18. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  19. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 22 A: Go to next step
  2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total Fuel Trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 9 OK: Go to next step
  3. INSPECT THROTTLE BODY ASSEMBLY Check that there are no deposits around the throttle valve. OK No deposits around the throttle valve. NG --> See step 7 OK: Go to next step
  4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR VALVE STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 6 A: Go to next step
  5. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 19 OK: Go to next step
  6. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000) . NEXT --> See step 8
  7. REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-393423-S42932276002011040700000) . NEXT --> See step 8
  8. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. NEXT --> END
  9. CHECK PCV HOSE Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> See step 16 OK: Go to next step
  10. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-393426-S19662706812011040700000) . OK No leaks from the intake system. NG --> See step 17 OK: Go to next step
  11. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK The air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 18 OK: Go to next step
  12. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR VALVE POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 14 A: Go to next step
  13. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 19 OK: Go to next step
  14. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Result Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from OFF to ON) HINT: If the result is not acceptable, cool the engine and perform the Active Test again. Start the engine when the engine coolant temperature is 30°C (86°F) or less. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream with the engine coolant temperature at 50°C (122°F) or less. Result Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from OFF to ON) NG --> See step 20 OK: Go to next step
  15. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-393423-S19194059732011040700000) . NEXT --> See step 21
  16. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 21
  17. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 21
  18. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 21
  19. REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . NEXT --> See step 21
  20. CHECK AND REPAIR VVT SYSTEM HINT: Check the VVT system. NEXT: Go to next step
  21. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED (DTC P050A) NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. NEXT --> END
  22. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
Related DTCsP050B: Idle ignition timing problem at cold
Required Sensors / Components (Main)Mass air flow meter sub-assembly
Required Sensors / Components (Related)Engine coolant temperature sensor, throttle position sensor, vehicle speed sensor
Frequency of OperationOnce per driving cycle
Duration10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0010 (Camshaft Timing Oil Control Valve Bank 1) P0011 (VVT System Bank 1- Advance) P0012 (VVT System Bank 1- Retard) P0016 (VVT System Bank 1 - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR System (Closed)) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1)
Battery voltage8 V or more
Time after engine start3 seconds or more
StarterOFF
Engine coolant temperature at engine start10°C (14°F) or more
Engine coolant temperature10 to 50°C (14 to 122°F)
Fuel-cutOFF
Engine idling time0 second or more
Vehicle speedLess than 37.5 mph (60 km/h)
Atmospheric pressure76 kPa (570 mmHg) or more
Accumulated time when ignition timing retard is cut off5 seconds or more

Scheme 591

Scheme 591: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on [A].
  6. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
  7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
  8. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  9. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
  10. Idle the engine for 1 minute or more [B].
  11. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  12. Read the pending DTC [C].
  13. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  15. Input the DTC: P050B.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [B].
  17. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  18. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  19. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following the menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 22 A: Go to next step
  2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Short FT #1 and Long FT #1. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20 % and 20 %. NG --> See step 9 OK: Go to next step
  3. CHECK THROTTLE BODY ASSEMBLY Check for deposits around the throttle valve and throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. NG --> See step 7 OK: Go to next step
  4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 6 A: Go to next step
  5. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 19 OK: Go to next step
  6. REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000) . NEXT --> See step 8
  7. REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-393423-S42932276002011040700000) . NEXT: Go to next step
  8. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED (DTC P050B) NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. NEXT --> END
  9. CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> See step 16 OK: Go to next step
  10. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-393426-S19662706812011040700000) . OK No leaks in intake system. NG --> See step 17 OK: Go to next step
  11. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK Air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 18 OK: Go to next step
  12. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling MAP (Data List) MAP value is 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. Result Result Proceed to Outside of standard range A Within standard range B B --> See step 14 A: Go to next step
  13. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly. Refer to «INSTALLATION»(ref-393412-S01056565372011040700000) . NG --> See step 19 OK: Go to next step
  14. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Result Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from OFF to ON) HINT: If the result is not acceptable, cool the engine and perform the Active Test again. Start the engine when the engine coolant temperature is 30°C (86°F) or less. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream with the engine coolant temperature at 50°C (122°F) or less. Result Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from OFF to ON) NG --> See step 20 OK: Go to next step
  15. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-393423-S19194059732011040700000) . NEXT --> See step 21
  16. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 21
  17. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 21
  18. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 21
  19. REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL»(ref-393412-S37278285322011040700000) . NEXT --> See step 21
  20. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
  21. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED (DTC P050B) NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. NEXT --> END
  22. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
Related DTCsP0560: ECM system voltage
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration3 seconds
MIL OperationImmediately (MIL illuminated after next engine start)
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
ECM power sourceLess than 3.5 V

Scheme 592

Scheme 592: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Wait 5 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P0560.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 593

Scheme 593: WIRING DIAGRAM
  1. CHECK HARNESS AND CONNECTOR (ECM - EFI MAIN FUSE) Disconnect the negative battery terminal. Disconnect the positive battery terminal. Remove the EFI MAIN fuse from the engine room relay block. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition EFI MAIN fuse (2) - A57-20 (BATT) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition EFI MAIN fuse (2) or A57-20 (BATT) - Body ground Always 10 kohms or higher Reinstall the EFI MAIN fuse. Reconnect the ECM connector. Reconnect the positive battery terminal. Reconnect the negative battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - EFI MAIN FUSE) OK: Go to next step
  2. INSPECT BATTERY Check that the battery is not discharged or weak. OK Battery is not discharged or weak. NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
  3. CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR OR REPLACE BATTERY TERMINAL OK: Go to next step
  4. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and turn the Techstream off. Turn the power switch on (IG) and turn the Techstream on. Wait for 5 seconds. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0560 is output A DTC is not output B B --> See step 5 A --> See step 6
  5. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
  6. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
Related DTCsP0604: ECM RAM error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)None
Frequency of operationContinuous
Duration6 times
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
RAM mirror checkFail

Scheme 594

Scheme 594: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Wait 16 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P0604.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P0604) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0604 is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
Related DTCP0606: ECM range check
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of OperationContinuous
DurationWithin 1 second
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever the following DTCs are not presentNone
Either of the following conditions is metCondition A or B
A. DMA communicationNo response
B. Watching from monitoring processorNot toggle

Scheme 595

Scheme 595: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Wait 16 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P0606.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0606 is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
Related DTCsP0607: Control Module Performance
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)Heated oxygen sensor
Frequency of OperationContinuous
Duration60 seconds
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not storedNone
EngineRunning
Estimated heated oxygen sensor temperature450 to 750°C (842 to 1382°F)
Heated oxygen sensor transistorsFail

Scheme 596

Scheme 596: CONFIRMATION DRIVING PATTERN
  1. Stop the engine for 30 minutes or more [A].
  2. Connect the Techstream to the DLC3.
  3. Turn the power switch on (IG) and turn the Techstream on.
  4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  5. Turn the power switch off and wait for 30 seconds.
  6. Turn the power switch on (IG) and turn the Techstream on [B].
  7. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  8. Start the engine, and wait 2 minutes [C].
  9. Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [D].
  10. Idle the engine for 1 minute [E].
  11. Accelerate the vehicle to 50 mph (80 km/h) and stop the vehicle [F].
  12. Drive the vehicle at 35 to 50 mph (56 to 80 km/h) for 5 minutes or more [G].
  13. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  14. Read the pending DTC [H].
  15. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  16. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  17. Input the DTC: P0607, P0136, P0137 or P0138.
  18. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] through [G].
  19. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  20. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  21. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 597

Scheme 597: PROCEDURE
  1. CHECK ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P0607 and P0136, P0137 or P0138 are output A P0607 is output B B --> See step 3 A: Go to next step
  2. INSPECT DTC (P0136, P0137 OR P0138) Inspect the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-393421-S14535032142011040700000) . Then proceed to "INSPECT ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-393421-S14535032142011040700000) . Then proceed to "INSPECT ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-393421-S14535032142011040700000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT --> See step 6
  3. CHECK FOR EXHAUST GAS LEAK Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Allow the engine to idle and rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to 4 "PERFORM CONFIRMATION DRIVING PATTERN". If no exhaust gas leaks are present, proceed to «CONFIRMATION DRIVING PATTERN»(ref-393420-S42548005632011040700000) "PERFORM CONFIRMATION DRIVING PATTERN". HINT: If no exhaust gas leaks are present, a malfunction in the heated oxygen sensor circuit is suspected. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
  4. PERFORM CONFIRMATION DRIVING PATTERN Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or more. Perform the driving pattern. Accelerate the vehicle to 50 mph (80 km/h) and stop the vehicle. Drive the vehicle between 38 and 50 mph (60 and 80 km/h) for 5 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 B No DTC output C C --> See step 6 B --> See step 7 A: Go to next step
  5. INSPECT DTC (P0136, P0137 OR P0138) Inspect the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-393421-S14535032142011040700000) . Then proceed to "INSPECT ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-393421-S14535032142011040700000) . Then proceed to "INSPECT ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-393421-S14535032142011040700000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT: Go to next step
  6. INSPECT ECM Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) . Start the engine and allow it to idle for 2 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTCs. Result Result Proceed to DTC is not output A P0607 is output B B --> See step 7 A --> END
  7. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
Related DTCsP060A: ECM CPU error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationContinuous
DurationWithin 1 second
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Either of the following conditions is metCondition 1 or 2
1. All of the following conditions are metCondition (a), (b) and (c)
(a) CPU reset1 time or more
(b) Leaned throttle position2.6 V or more
(c) Electronic throttle actuatorOFF
2. CPU reset2 times or more
Either of the following conditions is metCondition 3 or 4
3. DMA communication errorDetected
4. Watching from Monitoring Processor not toggle0.088 seconds or more

Scheme 598

Scheme 598: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Wait 16 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P060A.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060A is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
Related DTCsP060B: ECM main CPU communication error
Required sensors/components (Main)ECM
Required sensors/components (Related)
Frequency of operationContinuous
Duration2 times: AD converter 30 times: Knock control circuit
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
One of the following conditions is met(a) or (b)
(a) AD converterFail
(b) Knock sensor circuitFail

Scheme 599

Scheme 599: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Wait 16 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P060B.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327 or P0328 are output C C --> See step 4 B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
  4. GO TO DTC (P0327 AND P0328). Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)»(ref-393420-S01447487752011040700000)
Related DTCsP060E: Internal control module, Throttle position
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationContinuous
Duration1 second
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever the following DTCs are not presentNone
DMA communication errorNot detected
Either of the following conditions is met(a) or (b)
(a) Difference of main throttle position and sub throttle position0.3 V or more
(b) Difference of main brake switch signal and sub brake switch signalDifferent

Scheme 600

Scheme 600: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Wait 16 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P060E.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060E is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
Related DTCsP062F: Internal control module EEPROM error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationOnce per driving cycle
Duration11 seconds
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Time after engine start10 seconds or more
Battery voltage8 V or more
Power switchOn (IG)
Permanent fault code dataMismatch (3 times or more)

Scheme 601

Scheme 601: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Wait 30 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P062F.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 30 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P062F is output B B --> See step 2 A --> See step 3
  2. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
  3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
Related DTCsP0657: Electronic throttle control system power supply
Required sensors/Components (Main)ECM
Required sensors/Components (Related)Throttle actuator
Frequency of operationOnce per driving cycle
Duration1 second
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Throttle actuator power supply voltage7 V or more
Power switchOn (IG) to off
Electric throttle actuator power supplyON

Scheme 602

Scheme 602: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and turn the Techstream off.
  5. Wait for 30 seconds.
  6. Turn the power switch on (IG) and turn the Techstream on.
  7. Wait 5 seconds or more [A].
  8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
  9. Read the DTC [B].
  10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  12. Input the DTC: P0657.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
  14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P0657) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Turn the power switch on (IG) for 10 seconds. Turn the power switch off. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 5 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0657 is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-393417-S08075097832011040700000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-393423-S41700152002011040700000)
Related DTCP106A: Absolute pressure sensor rationality
Required sensors/Components (Main)Canister pressure sensor Manifold absolute pressure sensor
Required sensors/Components (Related)
Frequency of OperationContinuous
DurationWithin 65 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0106, P0107, P0108 (Manifold Absolute Pressure) P0401 (EGR System (Closed)) P0452, P0453 (Evaporative Emission System Pressure Sensor)
Arrive at after engine stop50 minutes
Time after ECM started by soak-timer60 seconds or more
Battery voltage10.5 V or more
Intake air temperature10°C (14°F) or more
Engine coolant temperature sensor10°C (14°F) or more
Judgement counter5 times
Judgement timeEvery 260 msec
Fail counter3 times or more
Difference between EVAP pressure and manifold absolute pressureMore than 7.442 kPa (55.82 mmHg)

Scheme 603

Scheme 603: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) [A].
  4. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-393299-S13482363572011040700000) .
  5. Start the engine and Idle for 10 seconds [B]
  6. Turn the power switch off and wait for 30 seconds.
  7. Leave the power switch off for 55 minutes [C]
  8. Connect the Techstream to the DLC3.
  9. Turn the power switch on (IG) and turn the Techstream on.
  10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  11. Read the pending DTC [D].
  12. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Input the DTC: P106A.
  15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C].
  16. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  17. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  18. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P106A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P106A is output A DTC P106A and other DTCs are output B HINT: If any DTCs other than P106A are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
  2. READ VALUE USING TECHSTREAM (VAPOR PRESSURE PUMP AND MAP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Vapor Pressure Pump and MAP. Compare the Vapor Pressure Pump and MAP data from the Data List with day's atmospheric pressure*. HINT: *: Standard atmospheric pressure is 101 kPa (760 mmHg) at sea level. The atmospheric pressure decreases by approximately 1 kPa (7.5 mmHg) for every 100 m of elevation increase. Atmospheric pressure is also affected by weather conditions. The Atmosphere pressure listed in the Data List cannot be used as a reference for this check. If you do not know the atmospheric pressure refer to the Vapor Pressure Pump value of other vehicles in the workshop and check the difference in pressure. RESULT Result Proceed to If the Vapor Pressure Pump value differs from the atmospheric pressure by +/- 3.5 kPa (+/- 26.25 mmHg) or more A If the MAP value differs from the atmospheric pressure by +/- 3.5 kPa (+/- 26.25 mmHg) or more B B --> See step 4 A: Go to next step
  3. REPLACE CANISTER Replace the canister. Refer to «REMOVAL»(ref-393412-S26183763292011040700000) . NEXT --> See step 5
  4. REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL»(ref-393412-S38654987542011040700000) . NEXT: Go to next step
  5. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG) and the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAP and Vapor Pressure Pump. Confirm that the difference between Vapor Pressure Pump and MAP are 3.5 kPa (+/- 26.25 mmHg) or less. NEXT --> END
  6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-393417-S03455429922011040700000)
Related DTCsP1420: Canister small leak P1421: Canister gross leak
Required Sensors/ComponentsPurge VSV and canister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 15 minutes
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Key-off monitor runs when all of the following conditions are met
Atmospheric pressure70 to 111 kPa (525 to 832 mmHg)
Battery voltage10.5 V or more
Vehicle speedLess than 2.5 mph (4 km/h)
Power switchOFF
Engine conditionNot running
Key-OFF duration5 or 7 or 9.5 hours
Pressure sensor of canister pump module malfunction (P0452 and P0453)Not detected
Fuel tank pressure sensor malfunction (P1452 and P1453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Fuel vapor-containment valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of the following conditions (a) and (b) are met before Key-OFF
(a). Duration that vehicle is being driven5 minutes or more
(b). Purge flowExecuted
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)

Key-off monitor sequence 1 to 15

Next sequence is run if the following condition is met
Atmospheric pressure changeLess than 0.3 kPa (2.25 mmHg) per second

1. ATMOSPHERIC PRESSURE MEASUREMENT

Next sequence is run if all of the following conditions are metConditions 1, 2 and 3
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated

2. FIRST REFERENCE PRESSURE MEASUREMENT

Next sequence is run if the following condition is met
Canister pressure change after vent valve ON (closed)0.3 kPa (2.25 mmHg) or more

3. VENT VALVE STUCK CLOSED CHECK

Next sequence is run if the both of the following condition is met
Vacuum introduction time15 minutes or less
Canister pressureSaturated

4. VACUUM INTRODUCTION FOR CANISTER

Next sequence is run if the following condition is met
Canister pressure change for 10 seconds after purge VSV ON (open)0.3 kPa (2.25 mmHg) or more

5. PURGE VSV STUCK CLOSED CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3 and 4
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the first and secondLess than 0.9 kPa (6.75 mmHg)

6. SECOND REFERENCE PRESSURE MEASUREMENT

One of the sequence 8 or 9 is run if the following condition is met
Canister pressure when vacuum introduction for canister was completeSecond reference pressure or less

7. CANISTER LEAK CHECK

Sequence 14 is run if all of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 kPa (-15 mmHg) or less, or 3 kPa (22.5 mmHg) or more
2. Fuel tank pressure change while TCV and vent valve are open0.5 kPa (3.75 mmHg) or more

8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK

Next sequence is run if both of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 to 3 kPa (-15 to 22.5 mmHg)
2. Vacuum introduction time15 minutes or less

9. VACUUM INTRODUCTION FOR FUEL TANK

Next sequence is run if the following condition is met
Fuel tank pressure change when vacuum introduction for fuel tank0.5 kPa (3.75 mmHg) or more

10. TCV STUCK CLOSED CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change when TCV closed0.35 kPa (2.62 mmHg) or more

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3, and 4
1. Fuel tank pressure when 1.9 seconds after reference pressure measurement0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the second and thirdLess than 0.9 kPa (6.75 mmHg)

12 THIRD REFERENCE PRESSURE MEASUREMENT

Sequence 15 is run if the following condition is met
Fuel tank pressure when vacuum introduction for fuel tank was completeLess than third reference pressure

13. FUEL TANK LEAK CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change while TCV and vent valve are openLess than 0.35 kPa (2.62 mmHg)

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

Monitor is complete if the following condition is met
Atmospheric pressure difference between sequence 1 and 8Less than 0.3 kPa (2.25 mmHg)

15. ATMOSPHERIC PRESSURE MEASUREMENT

Canister pressure when vacuum introductions for canister completeBetween conditions 1 and 2
Condition 1Higher than second reference pressure
Condition 2Lower than reference pressure x 0.2

P1420: EVAP SMALL LEAK

Canister pressure when vacuum introduction for canister was completeHigher than reference pressure x 0.2

P1421: EVAP GROSS LEAK

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
  7. After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  8. Read the Pending DTC [B].
  9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  11. Input the DTC: P1420 or P1421.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP1422: Fuel tank small leak P1423: Fuel tank gross leak
Required Sensors/ComponentsFuel tank and canister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 15 minutes (varies with the amount of fuel in tank)
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Key-off monitor runs when all of the following conditions are met
Atmospheric pressure70 to 111 kPa (525 to 832 mmHg)
Battery voltage10.5 V or more
Vehicle speedLess than 2.5 mph (4 km/h)
Power switchOFF
Engine conditionNot running
Key-OFF duration5 or 7 or 9.5 hours
Pressure sensor of canister pump module malfunction (P0452 and P0453)Not detected
Fuel tank pressure sensor malfunction (P1452 and P1453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Fuel vapor-containment valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of the following conditions (a) and (b) are met before Key-OFF
(a). Duration that vehicle is being driven5 minutes or more
(b). Purge flowExecuted
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)

Key-off monitor sequence 1 to 15

Next sequence is run if the following condition is met
Atmospheric pressure changeLess than 0.3 kPa (2.25 mmHg) per second

1. ATMOSPHERIC PRESSURE MEASUREMENT

Next sequence is run if all of the following conditions are metConditions 1, 2 and 3
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated

2. FIRST REFERENCE PRESSURE MEASUREMENT

Next sequence is run if the following condition is met
Canister pressure change after vent valve ON (closed)0.3 kPa (2.25 mmHg) or more

3. VENT VALVE STUCK CLOSED CHECK

Next sequence is run if the both of the following condition is met
Vacuum introduction time15 minutes or less
Canister pressureSaturated

4. VACUUM INTRODUCTION FOR CANISTER

Next sequence is run if the following condition is met
Canister pressure change for 10 seconds after purge VSV ON (open)0.3 kPa (2.25 mmHg) or more

5. PURGE VSV STUCK CLOSED CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3 and 4
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the first and secondLess than 0.9 kPa (6.75 mmHg)

6. SECOND REFERENCE PRESSURE MEASUREMENT

One of the sequence 8 or 9 is run if the following condition is met
Canister pressure when vacuum introduction for canister was completeSecond reference pressure or less

7. CANISTER LEAK CHECK

Sequence 14 is run if all of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 kPa (-15 mmHg) or less, or 3 kPa (22.5 mmHg) or more
2. Fuel tank pressure change while TCV and vent valve are open0.5 kPa (3.75 mmHg) or more

8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK

Next sequence is run if both of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 to 3 kPa (-15 to 22.5 mmHg)
2. Vacuum introduction time15 minutes or less

9. VACUUM INTRODUCTION FOR FUEL TANK

Next sequence is run if the following condition is met
Fuel tank pressure change when vacuum introduction for fuel tank0.5 kPa (3.75 mmHg) or more

10. TCV STUCK CLOSED CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change when TCV closed0.35 kPa (2.62 mmHg) or more

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3, and 4
1. Fuel tank pressure when 1.9 seconds after reference pressure measurement0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the second and thirdLess than 0.9 kPa (6.75 mmHg)

12 THIRD REFERENCE PRESSURE MEASUREMENT

Sequence 15 is run if the following condition is met
Fuel tank pressure when vacuum introduction for fuel tank was completeLess than third reference pressure

13. FUEL TANK LEAK CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change while TCV and vent valve are openLess than 0.35 kPa (2.62 mmHg)

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

Monitor is complete if the following condition is met
Atmospheric pressure difference between sequence 1 and 8Less than 0.3 kPa (2.25 mmHg)

15. ATMOSPHERIC PRESSURE MEASUREMENT

Fuel tank pressure when vacuum introduction for fuel tank was completeBetween conditions 1 and 2
Condition 1Higher than reference pressure
Condition 2Lower than reference pressure x 0.2

P1422: FUEL TANK SMALL LEAK

Fuel tank pressure when vacuum introduction for fuel tank was completeHigher than reference pressure x 0.2

P1423: FUEL TANK GROSS LEAK

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
  7. After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  8. Read the Pending DTC [B].
  9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  11. Input the DTC: P1422 or P1423.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP1451: Pressure sensor noise P1451: Pressure sensor stuck P1452: Pressure sensor low voltage P1453: Pressure sensor high voltage
Required Sensors/ComponentsCanister pump module
Frequency of OperationOnce per driving cycle: P1451 sensor stuck Continuous: P1451 sensor noise, P1452 and P1453
DurationWithin 15 minutes: P1451 0.5 seconds: P1452,1453
MIL Operation2 driving cycles: P1451 Immediately: P1452, P1453
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Fuel tank pressure15 to 20 kPa (-113 to 150 mmHg)
Battery voltage10.5 V or more
Intake air temperature4.4 to 50°C (40 to 122°F)
Pressure sensor of canister pump module malfunction (P0452 and P0453)Not detected
Either of the following conditions is metA or B
A. EngineRunning
B. Key-off duration5 or 7 or 9.5 hours

P1451 (NOISE MONITOR)

Monitor runs whenever following DTCs are not presentNone
Key-off monitor runs when all of the following conditions are met
Atmospheric pressure70 to 111 kPa (525 to 832 mmHg)
Battery voltage10.5 V or more
Vehicle speedLess than 2.5 mph (4 km/h)
Power switchOFF
Engine conditionNot running
Key-OFF duration5 or 7 or 9.5 hours
Pressure sensor of canister pump module malfunction (P0452 and P0453)Not detected
Fuel tank pressure sensor malfunction (P1452 and P1453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Fuel vapor-containment valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of the following conditions (a) and (b) are met before Key-OFF
(a). Duration that vehicle is being driven5 minutes or more
(b). Purge flowExecuted
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)

P1451 (STUCK MONITOR)

Key-off monitor sequence 1 to 15

Next sequence is run if the following condition is met
Atmospheric pressure changeLess than 0.3 kPa (2.25 mmHg) per second

1. ATMOSPHERIC PRESSURE MEASUREMENT

Next sequence is run if all of the following conditions are metConditions 1, 2 and 3
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated

2. FIRST REFERENCE PRESSURE MEASUREMENT

Next sequence is run if the following condition is met
Canister pressure change after vent valve ON (closed)0.3 kPa (2.25 mmHg) or more

3. VENT VALVE STUCK CLOSED CHECK

Next sequence is run if the both of the following condition is met
Vacuum introduction time15 minutes or less
Canister pressureSaturated

4. VACUUM INTRODUCTION FOR CANISTER

Next sequence is run if the following condition is met
Canister pressure change for 10 seconds after purge VSV ON (open)0.3 kPa (2.25 mmHg) or more

5. PURGE VSV STUCK CLOSED CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3 and 4
1. Canister pressure when reference pressure measurement started0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the first and secondLess than 0.9 kPa (6.75 mmHg)

6. SECOND REFERENCE PRESSURE MEASUREMENT

One of the sequence 8 or 9 is run if the following condition is met
Canister pressure when vacuum introduction for canister was completeSecond reference pressure or less

7. CANISTER LEAK CHECK

Sequence 14 is run if all of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 kPa (-15 mmHg) or less, or 3 kPa (22.5 mmHg) or more
2. Fuel tank pressure change while TCV and vent valve are open0.5 kPa (3.75 mmHg) or more

8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK

Next sequence is run if both of the following conditions are metConditions 1 and 2
1. Fuel tank pressure when EVAP monitor started2 to 3 kPa (-15 to 22.5 mmHg)
2. Vacuum introduction time15 minutes or less

9. VACUUM INTRODUCTION FOR FUEL TANK

Next sequence is run if the following condition is met
Fuel tank pressure change when vacuum introduction for fuel tank0.5 kPa (3.75 mmHg) or more

10. TCV STUCK CLOSED CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change when TCV closed0.35 kPa (2.62 mmHg) or more

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

Next sequence is run if all of the following conditions are metConditions 1, 2, 3, and 4
1. Fuel tank pressure when 1.9 seconds after reference pressure measurement0.25 kPa (-1.87 mmHg) or less
2. Reference pressure4.85 to -1.057 kPa (-36.38 to -7.92 mmHg)
3. Reference pressureSaturated
4. Reference pressure difference between the second and thirdLess than 0.9 kPa (6.75 mmHg)

12 THIRD REFERENCE PRESSURE MEASUREMENT

Sequence 15 is run if the following condition is met
Fuel tank pressure when vacuum introduction for fuel tank was completeLess than third reference pressure

13. FUEL TANK LEAK CHECK

Next sequence is run if the following condition is met
Fuel tank pressure change while TCV and vent valve are openLess than 0.35 kPa (2.62 mmHg)

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

Monitor is complete if the following condition is met
Atmospheric pressure difference between sequence 1 and 8Less than 0.3 kPa (2.25 mmHg)

15. ATMOSPHERIC PRESSURE MEASUREMENT

Monitor runs whenever following DTCs are not presentNone
Battery voltage8 V or more
One of the following conditions is metCondition (a), (b) or (c)
(a) ECM statusON by power switch
(b) ECM statusON by internal engine off timer
(c) ECM statusON by fuel lid opener switch

P1452 AND P1453

Frequency that canister pressure change is 0.3 kPa (2.25 mmHg) or more10 times or more in 10 seconds

P1451: PRESSURE SENSOR NOISE

Either of the following conditions 1 or 2 is met
1. Following conditions met when fuel tank pressure is -2 kPa (-15 mmHg) or less, or 3 kPa (22.51 mmHg) or moreA and B
A. Fuel tank pressure change while TCV and vent valve are openLess than 0.35 kPa (2.62 mmHg)
B. Fuel tank pressure change while TCV and vent valve is closedLess than 0.35 kPa (2.62 mmHg)
2. Following conditions met when fuel tank pressure is between -2 kPa (-15 mmHg) and 3 kPa (22.51 mmHg)
Fuel tank pressure change when vacuum introduction for fuel tankLess than 0.5 kPa (3.75 mmHg)

P1451: PRESSURE SENSOR STUCK

Fuel tank pressureLess than -17.1875 kPa (-128.93 mmHg)

P1452: PRESSURE SENSOR LOW VOLTAGE

Fuel tank pressureMore than 23.9375 kPa (179.57 mmHg)

P1453: PRESSURE SENSOR HIGH VOLTAGE

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the power switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) .
  4. Turn the power switch off and wait for 30 seconds.
  5. Turn the power switch on (IG) and turn the Techstream on.
  6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
  7. After the Evaporative System Check is completed, check for DTC by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  8. Read the Pending DTC [B].
  9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  11. Input the DTC: P1451, P1452 or P1453.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-393417-S07712997152011040700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
