REMOVAL & INSTALLATION
| WARNING | On Prius, when performing any inspection or service procedure on this vehicle, ensure service precautions are followed to prevent personal injury or death due to the extremely high voltage. See SERVICE PRECAUTIONS (PRIUS) . |
Remove door trim panel and waterproof shield. Remove glass retaining bolts and glass. If removing rear quarter window motor on Celica convertible, remove quarter trim panel. On all models, remove window regulator nuts and remove window regulator. Remove power window motor retaining screws, and remove motor from window regulator. To install, reverse removal procedure. On Avalon, reset power window motor reset and pulse switch. See RESETTING POWER WINDOW MOTOR RESET & PULSE SWITCH under PROGRAMMING.
Disconnect negative battery cable. Pry out power window switch from door panel or trim panel using flat screwdriver. Disconnect power window switch connectors and remove switch. To install, reverse removal procedure.
Power Window System Wiring Diagram (Avalon). Scheme 18
Scheme 18: Power Window System Wiring Diagram (Avalon)
Power Window System Wiring Diagram (Camry 2.2L & 3.0L). Scheme 19
Scheme 19: Power Window System Wiring Diagram (Camry 2.2L & 3.0L)
Power Window System Wiring Diagram (Camry 2.2L CNG). Scheme 20
Scheme 20: Power Window System Wiring Diagram (Camry 2.2L CNG)
Power Window System Wiring Diagram (Camry Solara). Scheme 21
Scheme 21: Power Window System Wiring Diagram (Camry Solara)
Power Window System Wiring Diagram (Camry Solara Convertible). Scheme 22
Scheme 22: Power Window System Wiring Diagram (Camry Solara Convertible)
Power Window System Wiring Diagram (Celica). Scheme 23
Scheme 23: Power Window System Wiring Diagram (Celica)
Power Window System Wiring Diagram (Corolla). Scheme 24
Scheme 24: Power Window System Wiring Diagram (Corolla)
Power Window System Wiring Diagram (ECHO). Scheme 25
Scheme 25: Power Window System Wiring Diagram (ECHO)
Power Window System Wiring Diagram (MR2). Scheme 26
Scheme 26: Power Window System Wiring Diagram (MR2)
Power Window System Wiring Diagram (Prius). Scheme 27
Scheme 27: Power Window System Wiring Diagram (Prius)
