Hybrid Control System (Diagnostics - Introduction): Diagnosis Toyota Prius C I facelift

HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]

HINT

1. *: Use the Techstream
2. Use the following procedure to troubleshoot the hybrid control system.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS NEXT: Go to next step
3. CONNECT TECHSTREAM TO THE DLC3* HINT: If the display on the tester indicates a communication fault, inspect the DLC3. NEXT: Go to next step
4. CHECK DTC AND SAVE FREEZE FRAME DATA*. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-651311-S30026564902014081900000) HINT: Make sure to save freeze frame data because the data is necessary for a simulation test. For the hybrid control system, there are many DTCs, many of which can be stored due to a single malfunction. As a result, in some of the diagnosis procedures an instruction is provided to check for other DTCs and their corresponding INF codes. By following the diagnosis path based on the combination of output DTCs and INF codes, it is possible to narrow down the problem early and avoid unnecessary diagnosis. NEXT: Go to next step
5. CLEAR DTC AND FREEZE FRAME DATA*. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-651311-S30026564902014081900000) NEXT: Go to next step
6. CONDUCT VISUAL INSPECTION NEXT: Go to next step
7. CONFIRM PROBLEM SYMPTOMS HINT: If the engine does not start, perform steps 9 and 11 first. Result Result Proceed to Malfunction does not occur. A Malfunction occurs. B B --> GO TO STEP 10 A: Go to next step
8. DUPLICATE CONDITIONS THAT PRODUCE SYMPTOMS NEXT: Go to next step
9. CHECK FOR DTCS*. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-651311-S30026564902014081900000) Result Result Proceed to DTC is output. A DTC is not output. B B --> GO TO STEP 11 A: Go to next step
10. REFER TO «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-651311-S37049002362014081900000) HINT: DTCs for the hybrid control system and hybrid battery system are displayed using the same menus on the Techstream. It is necessary to check the DTC charts for hybrid control system and hybrid battery system. Hybrid Control System - DTC chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-651311-S37049002362014081900000) Hybrid Battery System - DTC chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-651324-S14904481492014081900000) NEXT --> GO TO STEP 13
11. CONDUCT BASIC INSPECTION Result Result Proceed to Malfunctioning parts not confirmed. A Malfunctioning parts confirmed. B B --> GO TO STEP 15 A: Go to next step
12. CHECK ECU POWER SOURCE CIRCUIT NEXT: Go to next step
13. CONDUCT CIRCUIT INSPECTION Result Result Proceed to Malfunction not confirmed. A Malfunction confirmed. B B --> GO TO STEP 16 A: Go to next step
14. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-651311-S05389677472014081900000) NEXT --> GO TO STEP 16
15. CONDUCT PARTS INSPECTION NEXT: Go to next step
16. IDENTIFY PROBLEM NEXT: Go to next step
17. ADJUST AND/OR REPAIR NEXT: Go to next step
18. CONDUCT CONFIRMATION TEST NEXT --> END

PROBLEM SYMPTOMS TABLE [12/2013 - ]

HYBRID CONTROL SYSTEM

1. *1: w/ Smart Key System
2. *2: w/o Smart Key System

Scheme 150

TEXT IN ILLUSTRATION

POWER MANAGEMENT CONTROL ECU

1. *1: w/ Smart Key System
2. *2: w/o Smart Key System

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

1. Oscilloscope waveforms HINT: Oscilloscope waveform samples are provided here for informational purposes. Noise and fluttering waveforms have been omitted. Waveform 1 (DC/DC operation monitor / voltage change signal) Item Content Terminal A38-11 (VLO) - G57-6 (E1) Equipment Setting 5 V/DIV., 50 ms./DIV. Condition Ignition switch ON (IG) HINT: The cycle will vary depending on the specified voltage of the DC/DC converter. Waveform 2 (Inverter water pump assembly signal) Item Content Terminal CH1: A38-13 (IWP) - G57-6 (E1) CH2: A38-14 (NIWP) - G57-6 (E1) Equipment Setting 5 V/DIV., 50 ms./DIV. Condition Ignition switch ON (READY) Waveform 3 (A/C communication signal) Item Content Terminal CH1: A38-19 (CLK) - G57-6 (E1) CH2: A38-31 (ITE) - G57-6 (E1) CH3: A38-30 (ETI) - G57-6 (E1) CH4: A38-20 (STB) - G57-6 (E1) Equipment Setting 10 V/DIV., 100 ms./DIV. Condition Ignition switch ON (READY), air conditioning system stopped HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 4 (HV battery blower fan operation signal) Item Content Terminal A38-29 (SI0) - G57-6 (E1) Equipment Setting 5 V/DIV., 500 ms./DIV. Condition Ignition switch ON (IG), during Active Test HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 5 (MG communication clock signal) Item Content Terminal CH1: A39-21 (CLK+) - G57-6 (E1) CH2: A39-20 (CLK-) - G57-6 (E1) Equipment Setting 1 V/DIV., 1 μs./DIV. Condition Ignition switch ON (READY) Waveform 6 (communication signal from power management control ECU to MG ECU) Item Content Terminal CH1: A39-24 (HTM+) - G57-6 (E1) CH2: A39-25 (HTM-) - G57-6 (E1) Equipment Setting 1 V/DIV., 200 μs./DIV. Condition Ignition switch ON (IG) HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 7 (communication signal from MG ECU to power management control ECU) Item Content Terminal CH1: A39-30 (MTH+) - G57-6 (E1) CH2: A39-29 (MTH-) - G57-6 (E1) Equipment Setting 1 V/DIV., 200 μs./DIV. Condition Ignition switch ON (IG) HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 8 (MG ECU communication request signal) Item Content Terminal CH1: A39-33 (REQ+) - G57-6 (E1) CH2: A39-32 (REQ-) - G57-6 (E1) Equipment Setting 1 V/DIV., 1 ms./DIV. Condition Ignition switch ON (IG) Waveform 9 (system main relay operation signal) Item Content Terminal CH1: G57-3 (SMRP) - G57-5 (E01) CH2: G57-4 (SMRB) - G57-5 (E01) CH3: G57-2 (SMRG) - G57-5 (E01) Equipment Setting 10 V/DIV., 200 ms./DIV. Condition Ignition switch ON (IG) --> Ignition switch ON (READY) Waveform 10 (vehicle speed signal) Item Content Terminal G57-14 (SPDI) - G57-6 (E1) Equipment Setting 5 V/DIV., 20 ms./DIV. Condition Driving at approximately 20 km/h (12 mph) with ignition switch ON (READY) HINT: The higher the vehicle speed, the shorter the cycle. Waveform 11 (shift P signal) Item Content Terminal G57-15 (P2) - G57-6 (E1) Equipment Setting 5 V/DIV., 10 ms./DIV. Condition Ignition switch ON (IG) Waveform 12 (airbag activation signal) Item Content Terminal G57-29 (ABFS) - G57-6 (E1) Equipment Setting 5 V/DIV., 500 ms./DIV. Condition Ignition switch ON (READY) Waveform 13 (communication signal from battery smart unit to power management control ECU) Item Content Terminal CH1: G57-32 (BTH+) - G57-6 (E1) CH2: G57-33 (BTH-) - G57-6 (E1) Equipment Setting 2 V/DIV., 500 μs./DIV. Condition Ignition switch ON (IG) HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 14 (CAN communication signal) Item Content Terminal CH1: G58-25 (CA1H) - G57-6 (E1) CH2: G58-24 (CA1L) - G57-6 (E1) Equipment Setting 1 V/DIV., 50 μs./DIV. Condition Ignition switch ON (IG) HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 15 (CAN communication signal) Item Content Terminal CH1: G58-31 (CA3P) - G57-6 (E1) CH2: G58-30 (CA3N) - G57-6 (E1) Equipment Setting 1 V/DIV., 50 μs./DIV. Condition Ignition switch ON (IG) HINT: The waveform will vary depending on the content of the digital communication (digital signal). TEXT IN ILLUSTRATION *1 Inverter with Converter Assembly - - HINT: Since the inverter with converter assembly uses waterproof connectors, the voltage and waveform cannot be inspected directly. Standard voltage readings and waveforms are indicated for reference only. INVERTER WITH CONVERTER ASSEMBLY Terminal No. (Symbol) Wiring Color Terminal Description Condition Standard Condition A47-1 (IGCT) - A47-28 (GND1) B - W MG ECU power source Ignition switch ON (IG) 11 to 14 V A47-2 (IDH) - A47-28 (GND1) L - W PTC heater prohibit signal Ignition switch ON (IG) 4 to 6 V A47-3 (VLO) - A47-28 (GND1) R - W DC/DC operation monitor / voltage change signal Ignition switch ON (IG) Pulse generation (Waveform 1) A47-5 (CLK+) - A47-28 (GND1) B - W MG ECU communication clock signal Ignition switch ON (READY) Pulse generation (Waveform 2) A47-6 (REQ+) - A47-28 (GND1) B - W MG ECU communication request signal Ignition switch ON (READY) Pulse generation (Waveform 3) A47-7 (MTH+) - A47-28 (GND1) B - W Communication signal from MG ECU to power management control ECU Ignition switch ON (READY) Pulse generation (Waveform 4) A47-8 (HTM+) - A47-28 (GND1) B - W Communication signal from power management control ECU to MG ECU Ignition switch ON (READY) Pulse generation (Waveform 5) A47-9 (+B2) - A47-28 (GND1) G - W MG ECU power source Ignition switch ON (IG) 11 to 14 V A47-10 (+B) - A47-28 (GND1) G - W MG ECU power source Ignition switch ON (IG) 11 to 14 V A47-12 (NODD) - A47-28 (GND1) W - W DC/DC operation DC/DC converter operating normally 5 to 7 V DC/DC converter not operating normally 2 to 4 V DC/DC converter operation prohibited 0.1 to 0.5 V A47-15 (CLK-) - A47-28 (GND1) W - W MG ECU communication clock signal Ignition switch ON (READY) Pulse generation (Waveform 2) A47-16 (REQ-) - A47-28 (GND1) W - W MG ECU communication request signal Ignition switch ON (READY) Pulse generation (Waveform 3) A47-17 (MTH-) - A47-28 (GND1) W - W Communication signal from MG ECU to power management control ECU Ignition switch ON (READY) Pulse generation (Waveform 4) A47-18 (HTM-) - A47-28 (GND1) W - W Communication signal from power management control ECU to MG ECU Ignition switch ON (READY) Pulse generation (Waveform 5) A47-29 (GI) - A47-28 (GND1) B - W Camshaft position sensor signal Ignition switch ON (READY), with engine running Pulse generation (Waveform 6) A47-31 (HSDN) - A47-28 (GND1) B - W MG shutdown signal Ignition switch ON (READY) 0 to 1 V A47-35 (ILKI) - A47-28 (GND1) V - W Interlock switch signal Ignition switch ON (IG), inverter terminal cover, high-voltage input cables and service plug grip installed correctly Below 1 V Ignition switch ON (IG), inverter terminal cover, high-voltage input cables or service plug grip not installed 11 to 14 A47-36 (ILKO) - A47-28 (GND1) LG - W Interlock switch signal Ignition switch ON (IG), inverter terminal cover, high-voltage input cables and service plug grip installed correctly Below 1 V Ignition switch ON (IG), inverter terminal cover, high-voltage input cables or service plug grip not installed 11 to 14 C28-1 (MRF) - C28-2 (MRFG) BR - G Motor resolver signal Motor resolver running Pulse generation (Waveform 7) C28-3 (MSN) - C28-4 (MSNG) L - R Motor resolver signal Motor resolver running Pulse generation (Waveform 7) C28-6 (MCS) - C28-5 (MCSG) W - Y Motor resolver signal Motor resolver running Pulse generation (Waveform 7) C28-7 (GSN) - C28-8 (GSNG) L - R Generator resolver signal Generator resolver running Pulse generation (Waveform 8) C28-10 (GCS) - C28-9 (GCSG) W - Y Generator resolver signal Generator resolver running Pulse generation (Waveform 8) C28-11 (GRF) - C28-12 (GRFG) BR - G Generator resolver signal Generator resolver running Pulse generation (Waveform 8) NOTE: Do not measure the voltage or waveform directly at the sealed side of the inverter with converter assembly connector. Doing so may damage the connector because the connector is waterproof.
2. Oscilloscope waveforms HINT: Oscilloscope waveform samples are provided here for informational purposes. Noise and fluttering waveforms have been omitted. Waveform 1 (DC/DC operation monitor / voltage change signal) Item Content Terminal A47-3 (VLO) - A47-28 (GND1) Equipment Setting 5 V/DIV., 50 ms./DIV. Condition Ignition switch ON (IG) HINT: The cycle will vary depending on the specified voltage of the DC/DC converter. Waveform 2 (MG ECU communication clock signal) Item Content Terminal CH1: A47-5 (CLK+) - A47-28 (GND1) CH2: A47-15 (CLK-) - A47-28 (GND1) Equipment Setting 1 V/DIV., 1 μs./DIV. Condition Ignition switch ON (READY) Waveform 3 (MG ECU communication request signal) Item Content Terminal CH1: A47-6 (REQ+) - A47-28 (GND1) CH2: A47-16 (REQ-) - A47-28 (GND1) Equipment Setting 1 V/DIV., 1 ms./DIV. Condition Ignition switch ON (READY) Waveform 4 (communication signal from MG ECU to power management control ECU) Item Content Terminal CH1: A47-7 (MTH+) - A47-28 (GND1) CH2: A47-17 (MTH-) - A47-28 (GND1) Equipment Setting 1 V/DIV., 200 μs./DIV. Condition Ignition switch ON (READY) HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 5 (communication signal from power management control ECU to MG ECU) Item Content Terminal CH1: A47-8 (HTM+) - A47-28 (GND1) CH2: A47-18 (HTM-) - A47-28 (GND1) Equipment Setting 1 V/DIV., 200 μs./DIV. Condition Ignition switch ON (READY) HINT: The waveform will vary depending on the content of the digital communication (digital signal). Waveform 6 (Camshaft position sensor signal) Item Content Terminal A47-29 (GI) - A47-28 (GND1) Equipment Setting 5 V/DIV., 20 ms./DIV. Condition Ignition switch ON (READY), with engine running HINT: The pulse cycle becomes shorter as the engine speed increases. Waveform 7 (motor resolver signal) Item Content Terminal CH1: C28-1 (MRF) - C28-2 (MRFG) CH2: C28-3 (MSN) - C28-4 (MSNG) CH3: C28-6 (MCS) - C28-5 (MCSG) Equipment Setting CH1: 10 V/DIV., 1 ms./DIV. CH2, 3: 5 V/DIV., 1 ms./DIV. Condition Motor resolver running HINT: Pulse cycle A becomes shorter as the rotor speed increases. Waveform 8 (generator resolver signal) Item Content Terminal CH1: C28-11 (GRF) - C28-12 (GRFG) CH2: C28-7 (GSN) - C28-8 (GSNG) CH3: C28-10 (GCS) - C28-9 (GCSG) Equipment Setting CH1: 10 V/DIV., 1 ms./DIV. CH2, 3: 5 V/DIV., 1 ms./DIV. Condition Generator resolver running HINT: Pulse cycle A becomes shorter as the rotor speed increases.

Scheme 167

Scheme 168

1. DESCRIPTION The power management control ECU has a self-diagnosis system. If the computer, hybrid control system, or a component is not working properly, the ECU records the conditions that relate to the fault. The ECU also illuminates the master warning light in the combination meter assembly and provides other appropriate messages on the multi-information display, such as the HV system warning message, the HV battery warning message, on the discharge warning message. TEXT IN ILLUSTRATION *1 READY Light *2 Multi-information Display *3 Master Warning Light *4 MIL *5 Auxiliary Battery Charging Warning Light - - HINT: The master warning light will illuminate when the hybrid control system malfunctions and the light will blink when in inspection mode. When troubleshooting OBD II (On-Board Diagnostics) vehicles, the Techstream (complying with SAE J1987) must be connected to the DLC3 (Data Link Connector 3) of the vehicle. Various data in the vehicle ECM (Engine Control Module) can then be read. OBD II regulations require that the vehicle's on-board computer illuminate the MIL (Malfunction Indicator Lamp) on the instrument panel when the computer detects a malfunction in: The emission control system components. The powertrain control components (which affect vehicle emissions). The computer itself. In addition, the applicable DTCs prescribed by SAE J2012 are recorded in the power management control ECU memory. If the malfunction does not recur in 3 consecutive trips, the MIL turns off automatically but the DTCs remain recorded in the power management control ECU memory. To check for DTCs, connect the Techstream to the DLC3. The Techstream displays DTCs, freeze frame data, and a variety of hybrid control system data. The DTCs and freeze frame data can be cleared with the Techstream. In order to enhance the OBD function on vehicles and develop the Off-Board diagnosis system, Controller Area Network (CAN) communication is used in this system. CAN is a network which uses a pair of data transmission lines spanning multiple computers and sensors. It allows for high speed communications between the systems and simplification of the wire harness connections.
2. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the power management control ECU memory (1st trip). If the same malfunction is detected during the next drive cycle, the MIL is illuminated (2nd trip).
3. FREEZE FRAME DATA The power management control ECU records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, as well as other data recorded at the time of a malfunction.
4. AUXILIARY BATTERY VOLTAGE Standard Voltage Switch Condition Specified Condition Ignition switch ON (IG) 11 to 14 V If voltage is below 11 V, replace or recharge the auxiliary battery. NOTE: After turning the ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to «PRECAUTION [12/2013 - ]»(ref-651169-S11524377852014081900000) .
5. MIL (Malfunction Indicator Lamp) The MIL is illuminated when the ignition switch is first turned on (IG), before the READY indicator comes on. When the READY indicator turns on, the MIL should turn off. If the MIL remains illuminated, the diagnosis system has detected a malfunction or abnormality in the system. HINT: If the MIL is not illuminated when the ignition switch is first turned on (IG), check the MIL circuit. Refer to «MIL Circuit [12/2013 - ]»(ref-651307-S07652644952014081900000) .

Scheme 169

1. CHECK FOR DTCS Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Hybrid Control / Trouble Codes. Check the DTCs and freeze frame data, and then write them down. Check the details of the DTCs. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-651311-S37049002362014081900000) .
2. CHECK FREEZE FRAME DATA AND INFORMATION If a DTC is present, select it in order to display its freeze frame data. Read the freeze frame data recorded when the DTC was set. NOTE: A 3-digit information code (INF code) will be displayed as the value for one of the Information 1 to Information 5 lines. Read the information for the information code. Select the item from among Information 1 to Information 5 that has an information code and click the engine icon to view the additional information.
3. CHECK FOR DTCS (SYSTEMS OTHER THAN POWER MANAGEMENT CONTROL ECU) HINT: The power management control ECU maintains communication with other computers, including the ECM, skid control ECU and power steering ECU. Therefore, if the power management control ECU outputs a warning, it is necessary to check and record the DTCs of all systems. If DTCs are present, check the relevant systems. HINT: If DTCs for the CAN communication system are present in addition to other DTCs, first troubleshoot and repair any malfunctions in the CAN communication system.
4. CLEAR DTCS NOTE: Clearing the DTCs will also clear the freeze frame data, information. Refer to «INFORMATION / FREEZE FRAME DATA [12/2013 - ]»(ref-651326-S10752234802014081900000) , and operation history data. Refer to «OPERATION HISTORY DATA [12/2013 - ]»(ref-651326-S04889869512014081900000) . Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Check that the shift lever in P. Enter the following menus: Powertrain / Hybrid Control / Trouble Codes. Clear DTCs and freeze frame data.
5. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared by obtaining a normal judgment during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Powertrain / Hybrid Control / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear the DTCs. Perform the respective confirmation driving patterns in order to obtain a normal judgment for the output DTCs. HINT: Confirmation driving patterns do not need to be performed for misfire and fuel system DTCs. For the confirmation driving pattern, refer to the procedures for the relevant DTC. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-651311-S37049002362014081900000) . Perform the universal trip. HINT: The driving pattern to obtain a normal judgment and the universal trip driving can be performed consecutively in the same driving cycle. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE [12/2013 - ]»(ref-651169-S20116998062014081900000) . Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. Allow 10 minutes or more to elapse from the time the engine is started. Enter the following menus: Powertrain / Hybrid Control / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: The permanent DTCs are cleared when the universal trip is completed.
