Window / Glass (Service Information): Overview Toyota Matrix E140

Scheme 5

Scheme 6

1. REMOVE FRONT ARMREST UPPER BASE PANEL LH. Refer to «DISASSEMBLY - Step 5»(ref-427505-S14800765912011101200000)
2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Remove the 3 screws and the power window regulator master switch assembly.

Scheme 7

1. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1 (E) - 4 (D) 3 (U) - 6 (B) UP (Driver side) Below 1 ohms 1 (E) - 3 (U) 6 (B) - 4 (D) DOWN (Driver side) Below 1 ohms 1 (E) - 3 (U) 6 (B) - 4 (D) AUTO DOWN (Driver side) Below 1 ohms 6 (B) - 16 (U) 15 (D) - 1 (E) UP (Front passenger side) Below 1 ohms 6 (B) - 15 (D) 16 (U) - 1 (E) DOWN (Front passenger side) Below 1 ohms 6 (B) - 12 (U) 13 (D) - 1 (E) UP (Rear LH) Below 1 ohms 6 (B) - 13 (D) 12 (U) - 1 (E) DOWN (Rear LH) Below 1 ohms 6 (B) - 10 (U) 18 (D) - 1 (E) UP (Rear RH) Below 1 ohms 6 (B) - 18 (D) 10 (U) - 1 (E) DOWN (Rear RH) Below 1 ohms If the result is not specified, replace the power window master switch.
