Power Window Control System (Diagnostics & Symptom Tests): Diagnosis Toyota Matrix E140

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. Use the following procedure to troubleshoot the power window control system.
2. *: Using the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to step 2
2. CUSTOMER PROBLEM ANALYSIS In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points in the problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms NEXT: Go to step 3
3. INSPECT BATTERY VOLTAGE Measure the battery voltage. Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. NEXT: Go to step 4
4. PROBLEM SYMPTOMS TABLE Refer to «PROBLEM SYMPTOMS TABLE»(ref-427569-S27865357282011101200000) . Result Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B --> Go to step 6 A: Go to step 5
5. OVERALL ANALYSIS AND TROUBLESHOOTING* Refer to «DATA LIST / ACTIVE TEST»(ref-427569-S41224618392011101200000) Refer to «OPERATION CHECK»(ref-427569-S31620068142011101200000) Refer to «TERMINALS OF ECU»(ref-427569-S25501152452011101200000) NEXT: Go to step 6
6. REPAIR OR REPLACE NEXT: Go to step 7
7. CONFIRMATION TEST NEXT --> END

Scheme 123

1. CHECK POWER WINDOW MASTER SWITCH (WINDOW LOCK SWITCH) Check that the passenger side power window and rear windows cannot be operated when the window lock switch of the power window master switch is pressed. Check that the passenger side power window and rear windows can be operated when the window lock switch is pressed again.
2. CHECK MANUAL UP / DOWN FUNCTION Check that the driver side power window operates as follows: OK: Condition Master Switch Switch Operation Power Window Ignition switch ON Driver side Pulled up UP (closes) Ignition switch ON Driver side Pushed halfway down DOWN (opens) Check that the passenger side power window operates as follows: OK: Condition Regulator Switch Switch Operation Power Window Ignition switch ON Window lock switch OFF Passenger side Pulled up UP (closes) Ignition switch ON Window lock switch OFF Passenger side Pushed down DOWN (opens) Check that the rear LH power window operates as follows: OK: Condition Regulator Switch Switch Operation Power Window Ignition switch ON Window lock switch OFF Rear LH Pulled up UP (closes) Ignition switch ON Window lock switch OFF Rear LH Pushed down DOWN (opens) Check that the rear RH power window operates as follows: OK: Condition Regulator Switch Switch Operation Power Window Ignition switch ON Window lock switch OFF Rear RH Pulled up UP (closes) Ignition switch ON Window lock switch OFF Rear RH Pushed down DOWN (opens)
3. CHECK AUTO DOWN FUNCTION Check that the driver side power window operates as follows: OK: Condition Master Switch Switch Operation Power Window Ignition switch ON Driver side Fully pushed down AUTO DOWN (fully opens)
4. CHECK REMOTE UP / DOWN FUNCTION Check that the passenger side power window operates as follows: OK: Condition Master Switch Switch Operation Power Window Ignition switch ON Window lock switch OFF Passenger side Pulled up UP (closes) Ignition switch ON Window lock switch OFF Passenger side Pushed down DOWN (opens) Check that the rear LH power window operates as follows: OK: Condition Master Switch Switch Operation Power Window Ignition switch ON Window lock switch OFF Rear LH Pulled up UP (closes) Ignition switch ON Window lock switch OFF Rear LH Pushed down DOWN (opens) Check that the rear RH power window operates as follows: OK: Condition Master Switch Switch Operation Power Window Ignition switch ON Window lock switch OFF Rear RH Pulled up UP (closes) Ignition switch ON Window lock switch OFF Rear RH Pushed down DOWN (opens)
5. CHECK POWER WINDOW OPERATION FUNCTION AFTER IGNITION SWITCH IS TURNED OFF Check that all the power windows can be operated with the power window master switch after the ignition switch is turned off. Check that the key-off operation function does not operate after the driver or passenger side door is opened. Check that all the power windows cannot be operated after more than approximately 45 seconds elapse after the ignition switch is turned off.
6. CHECK PTC OPERATION HINT: PTC operation is a function that prevents overloading of the power window regulator by stopping the motor. PTC operation activates when the power window switch is operated for a predetermined amount of time. Pull up and hold the power window switch for more than 90 seconds. Then release the switch. Check that pressing the switch does not move the window. Wait until 60 seconds have passed since the switch was released in the first step. Check that pressing the switch results in normal window movement.

PROBLEM SYMPTOMS TABLE

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

POWER WINDOW CONTROL SYSTEM

Scheme 124

Scheme 125

Scheme 126

Scheme 127

1. CHECK POWER WINDOW MASTER SWITCH Disconnect the I3 power window master switch connector. Measure the voltage and resistance according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition I3-6 (B) - Body ground W - Body ground Ignition power supply Ignition switch OFF Below 1 V I3-6 (B) - Body ground W - Body ground Ignition power supply Ignition switch ON 11 to 14 V I3-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the I3 power window master switch connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition I3-3 (U) - I3-1 (E) G - W-B Power window motor UP output (driver side) Ignition switch ON, driver side power window switch OFF --> UP (manual operation) Below 1 V --> 11 to 14 V I3-4 (D) - I3-1 (E) Y - W-B Power window motor DOWN output (driver side) Ignition switch ON, driver side power window switch OFF --> DOWN (manual operation) Below 1 V --> 11 to 14 V I3-4 (D) - I3-1 (E) Y - W-B Power window motor DOWN output (driver side) Ignition switch ON, driver side power window fully closed --> driver side power window switch DOWN (AUTO operation) --> driver side power window fully open Below 1 V --> 11 to 14 V --> Below 1 V I3-16 (U) - I3-1 (E) G - W-B Power window motor UP output (passenger side) Ignition switch ON, passenger side power window switch OFF --> UP Below 1 V --> 11 to 14 V I3-15 (D) - I3-1 (E) BR - W-B Power window motor DOWN output (passenger side) Ignition switch ON, passenger side power window switch OFF --> DOWN Below 1 V --> 11 to 14 V I3-12 (U) - I3-1 (E) R - W-B Power window motor UP output (rear LH) Ignition switch ON, rear LH side power window switch OFF --> UP Below 1 V --> 11 to 14 V I3-13 (D) - I3-1 (E) L - W-B Power window motor DOWN output (rear LH) Ignition switch ON, rear LH side power window switch OFF --> DOWN Below 1 V --> 11 to 14 V I3-10 (U) - I3-1 (E) B - W-B Power window motor UP output (rear RH) Ignition switch ON, rear RH side power window switch OFF --> UP Below 1 V --> 11 to 14 V I3-18 (D) - I3-1 (E) Y - W-B Power window motor DOWN output (rear RH) Ignition switch ON, rear RH side power window switch OFF --> DOWN Below 1 V --> 11 to 14 V If the result is not as specified, the power window master switch may have a malfunction.
2. CHECK POWER WINDOW SWITCH (FRONT PASSENGER SIDE) Disconnect the H3 power window switch (front passenger side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition H3-3 (B) - Body ground Y - Body ground Ignition power supply Ignition switch OFF Below 1 V H3-3 (B) - Body ground Y - Body ground Ignition power supply Ignition switch ON 11 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the H3 power window switch (front passenger side) connector. Tester Connection Wiring Color Terminal Description Condition Specified Condition H3-1 (D) - Body ground B - Body ground Power window motor DOWN output Ignition switch ON, power window switch OFF --> DOWN Below 1 V --> 11 to 14 V H3-2 (SD) - Body ground BR - Body ground Power window motor DOWN input (Remote) Ignition switch ON, power window master switch OFF --> DOWN (Remote) Below 1 V --> 11 to 14 V H3-4 (U) - Body ground L - Body ground Power window motor UP output Ignition switch ON, power window switch OFF --> UP Below 1 V --> 11 to 14 V H3-5 (SU) - Body ground G - Body ground Power window motor UP input (Remote) Ignition switch ON, power window master switch OFF --> UP (Remote) Below 1 V --> 11 to 14 V If the result is not as specified, the power window switch (front passenger side) may have a malfunction.
3. CHECK POWER WINDOW SWITCH (REAR LH SIDE) Disconnect the K1 power window switch (rear LH side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition K1-3 (B) - Body ground P - Body ground Ignition power supply Ignition switch OFF Below 1 V K1-3 (B) - Body ground P - Body ground Ignition power supply Ignition switch ON 11 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the K1 power window switch (rear LH side) connector. Tester Connection Wiring Color Terminal Description Condition Specified Condition K1-4 (U) - Body ground G - Body ground Power window motor UP output Ignition switch ON, power window switch OFF --> UP Below 1 V --> 11 to 14 V K1-1 (D) - Body ground Y - Body ground Power window motor DOWN output Ignition switch ON, power window switch OFF --> DOWN Below 1 V --> 11 to 14 V K1-5 (SU) - Body ground R - Body ground Power window motor UP input (Remote) Ignition switch ON, power window master switch OFF --> UP (Remote) Below 1 V --> 11 to 14 V K1-2 (SD) - Body ground L - Body ground Power window motor DOWN input (Remote) Ignition switch ON, power window master switch OFF --> DOWN (Remote) Below 1 V --> 11 to 14 V If the result is not as specified, the power window switch (rear LH side) may have a malfunction.
4. CHECK POWER WINDOW SWITCH (REAR RH SIDE) Disconnect the J1 power window switch (rear RH side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-3 (B) - Body ground BE - Body ground Ignition power supply Ignition switch OFF Below 1 V J1-3 (B) - Body ground BE - Body ground Ignition power supply Ignition switch ON 11 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the J1 power window switch (rear RH side) connector. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-4 (U) - Body ground R - Body ground Power window motor UP output Ignition switch ON, power window switch OFF --> UP Below 1 V --> 11 to 14 V J1-1 (D) - Body ground G - Body ground Power window motor DOWN output Ignition switch ON, power window switch OFF --> DOWN Below 1 V --> 11 to 14 V J1-5 (SU) - Body ground B - Body ground Power window motor UP input (Remote) Ignition switch ON, power window master switch OFF --> UP (Remote) Below 1 V --> 11 to 14 V J1-2 (SD) - Body ground Y - Body ground Power window motor DOWN input (Remote) Ignition switch ON, power window master switch OFF --> DOWN (Remote) Below 1 V --> 11 to 14 V If the result is not as specified, the power window switch (rear RH side) may have a malfunction.

DIAGNOSIS SYSTEM

1. CHECK DLC3 Check the DLC3. Refer to «GENERAL INFORMATION»(ref-427305-S15629809542011101200000) .
2. INSPECT BATTERY VOLTAGE Measure the battery voltage. Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step.

DATA LIST / ACTIVE TEST

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Select: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY (MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy SW Driver side door courtesy switch signal/ON or OFF ON: Driver side door is open OFF: Driver side door is closed
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the ignition switch to the ON position. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Active Test. Perform the Active Test according to the display on the Techstream. MAIN BODY (MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK) Tester Display Test Part Control Range Diagnostic Note IG OFF P/W Control Permission Output Power window ON or OFF (After ignition switch is turned off)
