Power Window Control System (Diagnostics & Symptom Tests): Overview Toyota Matrix E140

Scheme 84

Scheme 85

Scheme 86

SYSTEM DESCRIPTION

1. POWER WINDOW CONTROL SYSTEM DESCRIPTION The power window control system controls the power window UP / DOWN function using the regulator motors. The main controls of this system are: the power window master switch, which is built into the driver side door, and the power window switches, which are built into the passenger side door and rear doors. Pressing the switch or any of the switches on the master switch transmits an UP / DOWN signal to the corresponding power window regulator motor.
2. FUNCTION OF MAIN COMPONENTS Component Outline Power Window Master Switch Controls window operations for all windows When window lock switch is set to lock position, window operation is only possible with master switch Power Window Switch Located on passenger side door and rear doors Each regulator switch controls window operations for its respective window Power Window Regulator Motor Assembly Receives switch signals and changes signals into motor activation to change window position
3. SYSTEM FUNCTION The power window control system has the following functions. Function Outline Manual UP / DOWN function Driver side power window: Function that raises window while power window switch is pulled up, and lowers window while pushed halfway down (window stops as soon as switch is released) Other power windows: Function that raises window while power window switch is pulled up, and lowers window while pushed down (window stops as soon as switch is released) AUTO DOWN function Function that enables window of driver side door to be fully opened by one full push downward on power window switch Remote UP / DOWN function Function that allows power window master switch to control manual UP / DOWN operation of passenger side power window and rear power windows Window lock function Function where passenger side power window and rear power window operation is disabled when window lock switch of master switch is pressed Passenger side power window and rear power windows can be operated when window lock switch is pressed again Key-off operation function A fail-safe function partly disable a power window function if a pulse sensor in a power window motor has a malfunction. Driver's door auto up-and-down function and remote control function are disabled.

DESCRIPTION

With the ignition switch ON, the power window master switch transmits remote switch signals to the switches of the passenger door power window and rear door power windows. Then, each regulator switch drives its respective power window regulator motor.

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. CHECK POWER WINDOW MASTER SWITCH Turn the window lock switch OFF and operate the switches on the master switch. Check that the remote UP / DOWN function operates normally. OK Remote UP / DOWN function operates normally. NG --> See step 2 OK --> END
2. CHECK MANUAL UP / DOWN FUNCTION Check that the passenger door power window and rear door power window manual UP / DOWN function operates normally. OK Manual UP / DOWN function operates normally. NG --> See step 3 OK --> See step 7
3. CHECK HARNESS AND CONNECTOR (POWER WINDOW MASTER SWITCH - BATTERY) Disconnect the power window master switch connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition I3-6 (B) - Body ground Ignition switch ON 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 4
4. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (B) - 16 (U) 15 (D) - 1 (E) UP (Front passenger side) Below 1 ohms 6 (B) - 15 (D) 16 (U) - 1 (E) DOWN (Front passenger side) Below 1 ohms 6 (B) - 12 (U) 13 (D) - 1 (E) UP (Rear LH) Below 1 ohms 6 (B) - 13 (D) 12 (U) - 1 (E) DOWN (Rear LH) Below 1 ohms 6 (B) - 10 (U) 18 (D) - 1 (E) UP (Rear RH) Below 1 ohms 6 (B) - 18 (D) 10 (U) - 1 (E) DOWN (Rear RH) Below 1 ohms NG --> See step 7 OK: Go to step 5
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - FRONT PASSENGER, REAR LH/RH SWITCH) Front passenger side: Disconnect the power window switch (passenger side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-16 (U) - H3-5 (SU) Always Below 1 ohms I3-15 (D) - H3-2 (SD) Always Below 1 ohms I3-16 (U) - Body ground Always 10 kohms or higher I3-15 (D) - Body ground Always 10 kohms or higher Rear LH side: Disconnect the power window switch (rear LH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-12 (U) - K1-5 (SU) Always Below 1 ohms I3-13 (D) - K1-2 (SD) Always Below 1 ohms I3-12 (U) - Body ground Always 10 kohms or higher I3-13 (D) - Body ground Always 10 kohms or higher Rear RH side: Disconnect the power window switch (rear RH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-10 (U) - J1-5 (SU) Always Below 1 ohms I3-18 (D) - J1-2 (SD) Always Below 1 ohms I3-10 (U) - Body ground Always 10 kohms or higher I3M1-18 (D) - Body ground Always 10 kohms or higher Result Result Proceed to NG A OK (Front passenger side) B OK (Rear LH side) C OK (Rear RH side) D B --> See step 6 C --> See step 8 D --> See step 9 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR
6. REPLACE POWER WINDOW SWITCH (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-427555-S23541102612011101200000)
7. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-427555-S28439759862011101200000)
8. REPLACE POWER WINDOW SWITCH (REAR LH SIDE). Refer to «REMOVAL»(ref-427555-S22824727722011101200000)
9. REPLACE POWER WINDOW SWITCH (REAR RH SIDE). Refer to «REMOVAL»(ref-427555-S22824727722011101200000)

If the manual UP / DOWN and AUTO DOWN functions do not operate, a malfunction may exist in the power window master switch, power window regulator motor or wire harness.

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

1. INSPECT POWER WINDOW MASTER SWITCH (DRIVER SWITCH) Remove the power window master switch. Refer to «REMOVAL»(ref-427555-S28439759862011101200000). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1 (E) - 4 (D) 3 (U) - 6 (B) UP Below 1 ohms 1 (E) - 3 (U) 1 (E) - 4 (D) OFF Below 1 ohms 1 (E) - 3 (U) 6 (B) - 4 (D) DOWN Below 1 ohms 1 (E) - 3 (U) 6 (B) - 4 (D) AUTO DOWN Below 1 ohms NG --> See step 5 OK: Go to 2 step
2. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - MOTOR (DRIVER SIDE)) Disconnect the power window regulator motor assembly (driver side) motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-4 (D) - I6-1 (D) Always Below 1 ohms I3-3 (U) - I6-2 (U) Always Below 1 ohms I3-4 (D) - Body ground Always 10 kohms or higher I3-3 (U) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 3
3. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (DRIVER SIDE) Remove the power window regulator motor assembly (driver side). Refer to «REMOVAL»(ref-427555-S13619526632011101200000). Check power window regulator motor operation: Apply battery voltage to connector terminals 1 and 2. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Check that the motor gear rotates smoothly as follows. OK Measurement Condition Specified Condition Battery positive (+) --> 1 Battery negative (-) --> 2 Motor gear rotates counterclockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Motor gear rotates clockwise Check PTC operation: NOTE: This check must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor assembly (driver side). Refer to «INSTALLATION»(ref-427555-S25052480622011101200000). Connect an electrical tester DC 400 A probe to the wire harness of terminal 2. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pulling up the power window switch. Wait for approximately 60 seconds. Continue to pull up the power window switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (current shut-off inspection). Standard 4 to 90 seconds Wait for 60 seconds after the previous step, and then push down press the power window switch (driver side). OK The driver side window goes down. NG --> See step 6 OK --> See step 4
4. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-427555-S28439759862011101200000)
5. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-427555-S28439759862011101200000)
6. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (DRIVER SIDE). Refer to «REMOVAL»(ref-427555-S13619526632011101200000)

If the passenger side manual UP / DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window switch, power window master switch or wire harness.

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

1. CHECK POWER WINDOW SWITCH (POWER SOURCE) Disconnect the power window switch (front passenger side) connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition H3-3 (B) - Body ground Ignition switch ON 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 2
2. INSPECT POWER WINDOW SWITCH (FRONT PASSENGER SIDE) Remove the power window switch (front passenger side). Refer to «REMOVAL»(ref-427555-S23541102612011101200000). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 3 (B) - 4 (U) 2 (SD) - 1 (D) UP Below 1 ohms 5 (SU) - 4 (U) 2 (SD) - 1 (D) OFF Below 1 ohms 5 (SU) - 4 (U) 3 (B) - 1 (D) DOWN Below 1 ohms NG --> See step 6 OK: Go to step 3
3. CHECK HARNESS AND CONNECTOR (SWITCH (PASSENGER SIDE) - MOTOR (PASSENGER SIDE)) Disconnect the power window regulator motor assembly (front passenger side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H3-1 (D) - H7-1 (D) Always Below 1 ohms H3-4 (U) - H7-2 (U) Always Below 1 ohms H3-1 (D) - Body ground Always 10 kohms or higher H3-4 (U) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 4
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (FRONT PASSENGER SIDE) Remove the power window regulator motor assembly (front passenger side). Refer to «REMOVAL»(ref-427555-S13619526632011101200000). Check power window regulator motor operation: Apply battery voltage to connector terminals 1 and 2. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Check that the motor gear rotates smoothly as follows. OK Measurement Condition Specified Condition Battery positive (+) --> 1 Battery negative (-) --> 2 Motor gear rotates clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Motor gear rotates counterclockwise Check PTC operation: NOTE: This check must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor assembly (front passenger side). Refer to «INSTALLATION»(ref-427555-S25052480622011101200000). Connect an electrical tester DC 400 A probe to the wire harness of terminal 2. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pulling up the power window switch. Wait for approximately 60 seconds. Continue to pull up the power window switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (current shut-off inspection). Standard 4 to 90 seconds Wait for 60 seconds after the previous step, and then push down the power window switch (passenger side). OK The passenger side window goes down. NG --> See step 7 OK: Go to step 5
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (PASSENGER SIDE)) Disconnect the power window master switch connector. Disconnect the power window switch (front passenger side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-16 (U) - H3-5 (SU) Always Below 1 ohms I3-15 (D) - H3-2 (SD) Always Below 1 ohms I3-16 (U) - Body ground Always 10 kohms or higher I3-15 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
6. REPLACE POWER WINDOW SWITCH (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-427555-S23541102612011101200000)
7. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-427555-S13619526632011101200000)
8. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-427555-S28439759862011101200000)

If the rear LH side manual UP / DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window switch, power window master switch or wire harness.

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

1. CHECK POWER WINDOW SWITCH (POWER SOURCE) Disconnect the power window switch (rear LH side) connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition K1-3 (B) - Body ground Ignition switch ON 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 2
2. INSPECT POWER WINDOW SWITCH (REAR LH SIDE) Remove the power window switch (rear LH side). Refer to «REMOVAL»(ref-427555-S22824727722011101200000). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1(D) - 2 (SD) 3 (B) - 4 (U) UP Below 1 ohms 4 (U) - 5 (SU) 1 (D) - 2 (SD) OFF Below 1 ohms 2 (SD) - 3 (B) 4 (U) - 5 (SU) DOWN Below 1 ohms NG --> See step 6 OK: Go to step 3
3. CHECK HARNESS AND CONNECTOR (SWITCH (REAR LH) - MOTOR (REAR LH)) Disconnect the power window regulator motor assembly (rear LH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition K1-4 (U) - K3-1 (U) Always Below 1 ohms K1-1 (D) - K3-2 (D) Always Below 1 ohms K1-4 (U) - Body ground Always 10 kohms or higher K1-1 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 4
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR LH SIDE) Remove the power window regulator motor assembly (rear LH side). Refer to «REMOVAL»(ref-427555-S02845628362011101200000). Check power window regulator motor operation: Apply battery voltage to connector terminals 1 and 2. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Check that the motor gear rotates smoothly as follows. OK Measurement Condition Specified Condition Battery positive (+) --> 1 Battery negative (-) --> 2 Motor gear rotates clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Motor gear rotates counterclockwise Check PTC operation: NOTE: This check must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor assembly (rear LH side). Refer to «INSTALLATION»(ref-427555-S03662465012011101200000). Connect an electrical tester DC 400 A probe to the wire harness of terminal 1. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pulling up the power window switch. Wait for approximately 60 seconds. Continue to pull up the power window switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (current shut-off inspection). Standard 4 to 90 seconds Wait for 60 seconds after the previous step, and then push down the power window switch (rear LH side). OK The rear LH side window goes down. NG --> See step 7 OK: Go to step 5
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (REAR LH)) Disconnect the power window master switch connector. Disconnect the power window switch (rear LH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-12 (U) - K1-5 (SU) Always Below 1 ohms I3-13 (D) - K1-2 (SD) Always Below 1 ohms I3-12 (U) - Body ground Always 10 kohms or higher I3-13 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
6. REPLACE POWER WINDOW SWITCH (REAR LH SIDE). Refer to «REMOVAL»(ref-427555-S22824727722011101200000)
7. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR LH SIDE). Refer to «REMOVAL»(ref-427555-S02845628362011101200000)
8. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-427555-S28439759862011101200000)

If the rear RH side manual UP / DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window switch, power window master switch or wire harness.

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

1. CHECK POWER WINDOW SWITCH (POWER SOURCE) Disconnect the power window switch (rear RH side) connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition J1-3 (B) - Body ground Ignition switch ON 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 2
2. INSPECT POWER WINDOW SWITCH (REAR RH SIDE) Remove the power window switch (rear RH side). Refer to «REMOVAL»(ref-427555-S22824727722011101200000). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1 (D) - 2 (SD) 3 (B) - 4 (U) UP Below 1 ohms 1 (D) - 2 (SD) 4 (U) - 5 (SU) OFF Below 1 ohms 2 (SD) - 3 (B) 4 (U) - 5 (SU) DOWN Below 1 ohms NG --> See step 6 OK: Go to step 3
3. CHECK HARNESS AND CONNECTOR (SWITCH (REAR RH) - MOTOR (REAR RH)) Disconnect the power window regulator motor assembly (rear RH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J1-4 (U) - J3-1 (U) Always Below 1 ohms J1-1 (D) - J3-2 (D) Always Below 1 ohms J1-4 (U) - Body ground Always 10 kohms or higher J1-1 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to step 4
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR RH SIDE) Remove the power window regulator motor assembly (rear RH side). Refer to «REMOVAL»(ref-427555-S02845628362011101200000). Check power window regulator motor operation: Apply battery voltage to connector terminals 1 and 2. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Check that the motor gear rotates smoothly as follows. OK Measurement Condition Specified Condition Battery positive (+) --> 1 Battery negative (-) --> 2 Motor gear rotates counterclockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Motor gear rotates clockwise Check PTC operation: NOTE: This check must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor assembly (rear RH side). Refer to «INSTALLATION»(ref-427555-S03662465012011101200000). Connect an electrical tester DC 400 A probe to the wire harness of terminal 1. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pulling up the power window switch. Wait for approximately 60 seconds. Continue to pull up the power window switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (current shut-off inspection). Standard 4 to 90 seconds Wait for 60 seconds after the previous step, and then push down the power window switch (rear RH side). OK The rear RH side window goes down. NG --> REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR RH SIDE) OK: Go to step 5
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (REAR RH)) Disconnect the power window master switch connector. Disconnect the power window switch (rear RH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-10 (U) - J1-5 (SU) Always Below 1 ohms I3-18 (D) - J1-2 (SD) Always Below 1 ohms I3-10 (U) - Body ground Always 10 kohms or higher I3-18 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
6. REPLACE POWER WINDOW SWITCH (REAR RH SIDE). Refer to «REMOVAL»(ref-427555-S22824727722011101200000)
7. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-427555-S28439759862011101200000)

If none of the power windows operate, the power window master switch may have no power or be malfunctioning.

Scheme 117

Scheme 118

Scheme 119

1. CHECK HARNESS AND CONNECTOR (POWER WINDOW POWER SOURCE) Disconnect the power window master switch connector. Measure the voltage according to the value(s) table below. Standard Voltage Tester Connection Switch Condition Specified Condition I3-6 (B) - Body ground Ignition switch ON 11 to 14 V NG --> See step 4 OK: Go to step 2
2. CHECK HARNESS AND CONNECTOR (POWER WINDOW MASTER SWITCH - BODY GROUND) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition I3-1 (E)- Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
3. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-427555-S28439759862011101200000)
4. CHECK HARNESS AND CONNECTOR (MAIN BODY ECU - BODY GROUND) Disconnect the instrument panel junction block connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2E-17 (PWS) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)

1. When the driver door has not been opened and fully closed, each door power window regulator motor can control its power window operation for approximately 45 seconds after the ignition switch is turned from the ON position to off (the key is removed) by receiving operation permission signals from the main body ECU. However, when approximately 45 seconds have elapsed, or the driver door or front passenger side door is opened within approximately 45 seconds of the ignition switch being turned off (the key is removed), the power window regulator motor stops operating.

Scheme 120

Scheme 121

Scheme 122

1. CHECK OPERATION FUNCTION AFTER IGNITION SWITCH IS TURNED OFF Check the power window operation function after the ignition switch is turned off. RESULT Status Proceed to When power window can still be operated even after opening driver door or front passenger door within approximately 45 seconds of ignition switch being turned off A When power window can still be operated even after approximately 45 seconds have elapsed after ignition switch is turned off B B --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK) A: Go to step 2
2. READ VALUE USING TECHSTREAM (FRONT DOOR COURTESY LIGHT SWITCH) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menu items: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY (MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy Switch Driver side door courtesy switch signal / ON or OFF ON: Driver door open OFF: Driver door closed - OK On the Techstream screen, the item changes between ON and OFF according to the chart above. NG --> See step 3 OK --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)
3. INSPECT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (Driver Side) Remove the front door courtesy light switch (driver side). Refer to «REMOVAL»(/toyota/matrix/e140-2008-2014/remont/interiorillumination-lights/#lighting-system-interior-service-information) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 1 - Switch body Pushed 10 kohms or higher 1 - Switch body Free Below 1 ohms NG --> See step 5 OK: Go to step 4
4. CHECK HARNESS AND CONNECTOR (FRONT DOOR COURTESY LIGHT SWITCH - MAIN BODY ECU) Disconnect the instrument panel junction block connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition L18-1 - 2A-21 (DCTY) Always Below 1 ohms L18-1 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)
5. REPLACE DOOR COURTESY LIGHT SWITCH ASSEMBLY (Driver Side). Refer to «REMOVAL»(/toyota/matrix/e140-2008-2014/remont/interiorillumination-lights/#lighting-system-interior-service-information)
