DESCRIPTION
Refer to the description for DTC P0AE6-225.
Refer to DESCRIPTION
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3004-800 | High Voltage Power Resource | High-voltage circuit malfunctions between the HV battery and inverter with converter assembly. Excessive overcurrent occurs during precharge (time from when SMRP turns on until SMRG turns on). (1 trip detection logic) | Wire harness or connector No. 4 engine wire Compressor with motor assembly Inverter with converter assembly Hybrid battery junction block assembly No. 6 floor wire Power management control ECU | Does not come on | Master Warning Light: Comes on |
| P3004-801 | High Voltage Power Resource | High-voltage circuit malfunctions between the HV battery and inverter with converter assembly. Minimal overcurrent occurs during precharge (time from when SMRP turns on until when SMRG turns on). (1 trip detection logic) | Wire harness or connector No. 4 engine wire Compressor with motor assembly Inverter with converter assembly Hybrid battery junction block assembly No. 6 floor wire Power management control ECU | Does not come on | Master Warning Light: Comes on |
| DTC No. | Data List |
|---|---|
| P3004-800 | VH-Voltage after Boosting Power Resource VB |
| P3004-801 |
RELATED DATA LIST
The following items can be helpful when performing repairs
Data List
- VL-Voltage before Boosting
- Power Resource IB
- Ready Signal
Refer to the description for DTC P0AE6-225.
Refer to DESCRIPTION
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3004-803 | High Voltage Power Resource | High-voltage circuit malfunctions between the HV battery and inverter with converter assembly. When the power switch is on (READY), both "VL-Voltage before Boosting" and "VH-Voltage after Boosting" drop abnormally. The EV electric battery fuse is blown, the service plug grip is removed, SMRB or SMRG remains open, or the high-voltage cable has an open circuit. (1 trip detection logic) | Hybrid battery junction block assembly Wire harness or connector | Does not come on | Master Warning Light: Comes on |
| DTC No. | Data List |
|---|---|
| P3004-803 | VL-Voltage before Boosting VH-Voltage after Boosting Power Resource VB Power Resource IB |
RELATED DATA LIST
The following items can be helpful when performing repairs
Data List
- Ready Signal
The power management control ECU detects a problem in the collision signal line from the airbag sensor assembly and alerts the driver.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3107-213 | Lost Communication with Airbag System Control Module | Short to ground in the communication circuit: Communication from the airbag sensor assembly stopped and Circuit Low has been detected for a certain period. (1 trip detection logic) | Wire harness or connector Airbag sensor assembly Power management control ECU | Does not come on | Master Warning Light: Comes on |
| DTC No. | Data List |
|---|---|
| P3107-213 | Collision Signal (Airbag) |
RELATED DATA LIST
Scheme 163
Refer to the description for DTC P3107-213.
Refer to DESCRIPTION
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3107-214 | Lost Communication with Airbag System Control Module | Open or short to +B in the communication circuit (1 trip detection logic) | Wire harness or connector Airbag sensor assembly Power management control ECU | Does not come on | Master Warning Light: Comes on |
| DTC No. | Data List |
|---|---|
| P3107-214 | Collision Signal (Airbag) |
RELATED DATA LIST
Refer to the description for DTC P3107-213.
Refer to DESCRIPTION
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3107-215 | Lost Communication with Airbag System Control Module | Abnormal communication signal: Communication from the airbag sensor assembly stopped and circuit high has been detected for a certain period. (1 trip detection logic) | Wire harness or connector Airbag sensor assembly Power management control ECU | Does not come on | Master Warning Light: Comes on |
| DTC No. | Data List |
|---|---|
| P3107-215 | Collision Signal (Airbag) |
RELATED DATA LIST
The power management control ECU detects a wiring malfunction in the serial communication line between it and the compressor with motor assembly.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3108-536 | Lost Communication with A/C System Control Module | Communication error (air conditioning system to hybrid control system): Error in communication data from the A/C inverter. Although an air conditioning inverter shutdown signal is sent, the air conditioning inverter does not shutdown. (1 trip detection logic) | Wire harness or connector Compressor with motor assembly Power management control ECU | Does not come on | Master Warning Light: Does not come on |
| DTC No. | Data List |
|---|---|
| P3108-536 | A/C Consumption Pwr Aircon Gate Status |
RELATED DATA LIST
Scheme 164
The MG ECU monitors its internal operation for malfunctions.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P310A-711 | Communication Error from MGR to MG2 | Communication error (from the rear motor (MGR) to the motor (MG2)) (1 trip detection logic) | Inverter with converter assembly | Comes on | Master Warning Light: Comes on |
The MG ECU monitors its internal operation for malfunctions.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P310B-662 | Communication Error from MG2 to MGR | Communication error (from the motor (MG2) to the rear motor (MGR)) (1 trip detection logic) | Inverter with converter assembly | Comes on | Master Warning Light: Comes on |
The power management control ECU monitors the IGCT relay and detects the following malfunction.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3110-223 | HV Main Relay | IGCT relay stuck on (+B short): IGCT relay is stuck on or a short to B+ exists. Power to the power management control ECU does not shut down when the power switch is turned off. (1 trip detection logic) | Wire harness or connector IGCT relay Power management control ECU | Does not come on | Master Warning Light: Comes on |
The hybrid vehicle transaxle assembly consists of the planetary gear unit, generator (MG1) and motor (MG2). The planetary gear unit uses a planetary gear to split the engine output into mechanical power and electrical power in accordance with driving requests when the vehicle is being driven or the HV battery is being charged. When accelerating, motor (MG2) assists engine output by increasing vehicle driving force. Motor (MG2) also converts braking energy, which would otherwise be consumed in the form of heat during braking, into electrical energy. This recovered energy is stored in the HV battery. Generator (MG1) supplies power, which is used for charging the HV battery or driving motor (MG2), and also regulates the amount of electricity being generated. In addition, generator (MG1) is used as a starter motor to start the engine.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3147-239 | Transmission system | Drive force from motor (MG2) or the engine cannot be transmitted to the wheels. The engine, generator (MG1), motor (MG2) or hybrid vehicle transaxle assembly does not run smoothly due to a mechanical malfunction. (1 trip detection logic) | Engine Hybrid vehicle transaxle assembly Power management control ECU Transmission input damper assembly | Does not come on | Master Warning Light: Comes on |
| P3147-241 | Transmission system | Hybrid vehicle transaxle malfunction (input system lock): When the vehicle is stopped, an engine cranking signal is sent but the generator (MG1) does not rotate. The generator (MG1) or the engine does not rotate, or the planetary gear unit is malfunctioning. (1 trip detection logic) | Engine Hybrid vehicle transaxle assembly Power management control ECU Transmission input damper assembly | Does not come on | Master Warning Light: Comes on |
| DTC No. | ECU Data List |
|---|---|
| P3147-239 | Motor(MG2) Revolution Motor(MG2) Torq M(MG2) Trq Exec Val Generator(MG1) Rev Generator(MG1) Torq G(MG1) Trq Exec Val Engine Revolution Calculate Load |
| P3147-241 |
RELATED DATA LIST
Refer to the description for DTC P3147-239.
Refer to DESCRIPTION
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P3147-240 | Transmission system | Generator (MG1) locked: The generator (MG1) does not rotate when the vehicle is being driven in EV drive mode. (1 trip detection logic) | Hybrid vehicle transaxle assembly | Does not come on | Master Warning Light: Comes on |
| P3147-242 | Transmission system | Planetary gear locked: The 3 planetary gears rotate all together, not individually. The planetary gear carrier is seized. (1 trip detection logic) | Hybrid vehicle transaxle assembly | Does not come on | Master Warning Light: Comes on |
| DTC No. | ECU Data List |
|---|---|
| P3147-240 | Motor(MG2) Revolution Motor(MG2) Torq M(MG2) Trq Exec Val Generator(MG1) Rev Generator(MG1) Torq G(MG1) Trq Exec Val Engine Revolution |
| P3147-242 |
RELATED DATA LIST
Refer to the description for DTC P0C73-776.
Refer to DESCRIPTION
The inverter water pump assembly sends the inverter water pump speed (measured value) signal to the power management control ECU. If the inverter water pump speed (measured value) signal is not sent to the power management control ECU when the power switch is on (READY), this DTC is stored.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P314A-828 | Inverter Coolant Pump Speed Signal | The inverter water pump speed signal is not sent to the power management control ECU when the power switch is turned on (READY). (1 trip detection logic) | Wire harness or connector Power management control ECU Inverter water pump assembly INV W/PMP fuse IGCT relay | Comes on | Master Warning Light: Comes on |
HINT
- A malfunction (open, short to +B or short to ground) in the speed signal line from the inverter water pump assembly to the power management control computer is detected.
- A malfunction in the inverter water pump assembly power source circuit is detected.
- A malfunction in the +B line is detected.
- A malfunction in power management control computer power source circuit is detected.
| DTC No. | Data List |
|---|---|
| P314A-828 | Inverter W/P Revolution (Inverter) W/P Run Control Duty Ready Signal |
RELATED DATA LIST
| DTC No. | Active Test |
|---|---|
| P314A-828 | Activate the (Inverter) Water Pump |
RELATED ACTIVE TEST
MONITOR DESCRIPTION
The power management control ECU monitors speed of the inverter water pump assembly. If the inverter water pump speed signal is not sent to the power management control ECU, the power management control ECU will illuminate the MIL and store a DTC.
The power management control ECU sends a block signal to the motor generator control ECU (MG ECU) to shutdown the power supply to the motor. When the system is not in the on (READY) state, it sends an HSDN (MG shutdown signal) signal from the power management control ECU to the motor generator control ECU (MG ECU) to check the function of the HV gate block. When a malfunction is detected in the HV gate block function, DTCs are stored.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P321E-318 | All HV Gate Blocking Range/Performance | An open or ground short in the HV gate block signal circuit when the gate is operating. When the HV gate block function check is performed (when the power switch is turned from on (READY) to off), the inverter voltage (VH) drops and current flows in the inverter. (The generator (MG1), motor (MG2) and rear motor (MGR) are malfunctioning.) (1 trip detection logic) | Wire harness or connector Power management control ECU Inverter with converter assembly | Does not come on | Master Warning Light: Comes on |
| DTC No. | Data List |
|---|---|
| P321E-318 | VH-Voltage after Boosting Ready Signal Emergency Shutdown |
RELATED DATA LIST
Scheme 165
Refer to the description for DTC P321E-318.
Refer to DESCRIPTION
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P321F-319 | Part of HV Gate Blocking Range/Performance | An open or ground short in the HV gate block signal circuit when the gate is operating. When the HV gate block function check is performed (when the power switch is turned from on (READY) to off), the inverter voltage (VH) drops and current flows in the inverter. (Any of the generator (MG1), motor (MG2) or rear motor (MGR) is malfunctioning.) (1 trip detection logic) | Inverter with converter assembly | Does not come on | Master Warning Light: Comes on |
| DTC No. | Data List |
|---|---|
| P321F-319 | VH-Voltage after Boosting Ready Signal Emergency Shutdown |
RELATED DATA LIST
If the MG ECU, which is built into in the inverter with converter assembly, is reset due to a problem with the power source in the inverter, the power management control ECU will stored this DTC.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| P324E-788 | MG-ECU Power Relay Intermittent Circuit | Error in reset signal from the inverter assembly power source IC: If internal power source voltage drops below the normal CPU operating voltage or the ROM/RAM is malfunctioning, the power source IC resets the MG ECU and stores this DTC. (1 trip detection logic) | Wire harness or connector Inverter with converter assembly | Does not come on | Master Warning Light: Comes on |
Scheme 166
The power management control ECU transmits and receives signals via CAN communication to and from the ECM, skid control ECU assembly, power steering ECU assembly, main body ECU, airbag sensor assembly, and air conditioning amplifier assembly.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| U0100-530 | Lost Communication with ECM / PCM "A" | A CAN communication error between the ECM and power management control ECU (CAN communication system malfunction) occurs (1 trip detection logic) | CAN communication system | Comes on | Master Warning Light: Comes on |
| U0129-527 | Lost Communication with Brake System Control Module | A CAN communication error (V BUS) between the skid control ECU assembly and power management control ECU (CAN communication system malfunction) occurs (1 trip detection logic) | CAN communication system | Does not come on | Master Warning Light: Comes on |
| U0129-528 | Lost Communication with Brake System Control Module | A CAN communication error between the skid control ECU assembly and power management control ECU (CAN communication system malfunction) occurs (1 trip detection logic) | CAN communication system | Does not come on | Master Warning Light: Comes on |
| U0140-146 | Communication Error from Body ECU to HV ECU | A CAN communication error between the main body ECU and power management control ECU (CAN communication system malfunction) occurs (1 trip detection logic) | CAN communication system | Does not come on | Master Warning Light: Comes on |
| U0151-763 | Communication Error from Airbag ECU to HV ECU | A CAN communication error between the airbag sensor assembly and power management control ECU (CAN communication system malfunction) occurs (1 trip detection logic) | CAN communication system | Does not come on | Master Warning Light: Comes on |
| U0164-827 | Communication Error from A/C ECU to HV ECU | A CAN communication error between the air conditioning amplifier assembly and power management control ECU (CAN communication system malfunction) occurs (1 trip detection logic) | CAN communication system | Does not come on | Master Warning Light: Does not come on |
| U1107-436 | Lost Communication with Power Management Module | A CAN communication error between the power source ECU and power management control ECU (CAN communication system malfunction) occurs (1 trip detection logic) | CAN communication system | Does not come on | Master Warning Light: Comes on |
If the power management control ECU detects a problem with CAN communication with the ECU, it will illuminate the MIL and store a DTC.
For a description of the inverter.
Refer to DESCRIPTION
The MG ECU, which is built into in the inverter with converter assembly, controls motor (MG2) based on commands from the power management control ECU. The MG ECU monitors communication data and detects malfunctions.
The power management control ECU monitors communication data and detects malfunctions.
A communication error between the MG ECU and power management control ECU.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| U0110-159 | Lost Communication with Drive Motor Control Module "A" | Error in reception from inverter with converter assembly (MG ECU) via serial communication (out of communication standard) (1 trip detection logic) | Wire harness or connector Inverter with converter assembly Hybrid vehicle transaxle assembly Power management control ECU PCU fuse | Does not come on | Master Warning Light: Comes on |
| U0110-656 | Lost Communication with Drive Motor Control Module "A" | Error in reception from inverter with converter assembly (MG ECU) via serial communication (out of communication standard) (1 trip detection logic) | Wire harness or connector Inverter with converter assembly Hybrid vehicle transaxle assembly Power management control ECU PCU fuse | Does not come on | Master Warning Light: Comes on |
| U0110-657 | Lost Communication with Drive Motor Control Module "A" | Error in reception from inverter with converter assembly (MG ECU) via serial communication (no reception) (1 trip detection logic) | Wire harness or connector Inverter with converter assembly Hybrid vehicle transaxle assembly Power management control ECU PCU fuse | Does not come on | Master Warning Light: Comes on |
Scheme 167
The MG ECU, which is built into in the inverter with converter assembly, controls motor (MG2) based on commands from the power management control ECU.
The motor generator control ECU (MG ECU) monitors communication data and detects malfunctions.
A communication error between the MG ECU and power management control ECU is detected.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| U0110-160 | Lost Communication with Drive Motor Control Module "A" | Error in signal transmission to the inverter with converter assembly (MG ECU) via serial communication (no transmission, out of communication standard) (1 trip detection logic) | Wire harness or connector Inverter with converter assembly Hybrid vehicle transaxle assembly Power management control ECU | Does not come on | Master Warning Light: Comes on |
If there is a malfunction in the air conditioning amplifier assembly, DTC U0424-537 will be stored.
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | MIL | Warning Indicate |
|---|---|---|---|---|---|
| U0424-537 | Invalid Data Received from HVAC Control Module | Air conditioning amplifier assembly malfunction: The power management control ECU receives a communication error signal from the air conditioning amplifier assembly. (1 trip detection logic) | Air conditioning amplifier assembly | Does not come on | Master Warning Light: Does not come on |
When the vehicle is being driven with the accelerator pedal depressed, depressing the brake pedal without releasing the accelerator pedal will activate the brake override system to restrict driving torque. The conditions for activating the brake override system as well as the items that are controlled are explained below.
Scheme 168
Activation Conditions
- The accelerator pedal and brake pedal are depressed at the same time.
Note. Brake override control may not be performed depending on the relationship between accelerator opening and vehicle speed.
Items Controlled
- Controls driving force
HINT
- When the control is operating, requested accelerator torque is controlled in accordance with the brake pedal stroke.
- When the driving force is reduced to a specified level because the accelerator pedal and brake pedal are depressed at the same time, an indicator is displayed on the meter. (Operation of the system can be confirmed when the indicator is displayed on the meter.)
Deactivation Conditions
- The accelerator pedal or brake pedal is released.
When the shift lever is in S, different ranges can be chosen using the floor shift sequential gate.
Scheme 169
Refer to the wiring diagram for DTC P0AE6-225.
Refer to WIRING DIAGRAM
Scheme 170
Scheme 171
Scheme 172
- READ VALUE USING TECHSTREAM (SPORTS MODE) Connect the Techstream to the DLC3. Turn the power switch on (IG). Enter the following menus: Powertrain / Hybrid Control / Data List / Sports Mode. Powertrain > Hybrid Control > Data List Tester Display Sports Mode Read the value displayed on the Techstream. Powertrain > Hybrid Control > Data List Tester Display Measurement Item Range Normal Condition Sports Mode Sports shift signal ON or OFF Shift lever in S: ON Shift lever not in S position: OFF Result Result Proceed to The Techstream display changes according to the shift lever operation. A The Techstream display does not change according to the shift lever operation. B Turn the power switch off. Result: 2 B See step 6 Result: 1 A See step 2
- READ VALUE USING TECHSTREAM (SPORT UP SHIFT SENS STATE, SPORT DWN SHIFT SENS STATE) Connect the Techstream to the DLC3. Turn the power switch on (IG). Enter the following menus: Powertrain / Hybrid Control / Data List / Sport Up Shift Sens State, Sport Dwn Shift Sens State. Powertrain > Hybrid Control > Data List Tester Display Sport Up Shift Sens State Sport Dwn Shift Sens State Read the value displayed on the Techstream. Powertrain > Hybrid Control > Data List Tester Display Measurement Item Range Normal Condition Sport Up Shift Sens State Operation of "+" transmission control switch. ON or OFF ON: Shift lever held in "+" operated OFF: Shift lever in S Sport Dwn Shift Sens State Operation of "-" transmission control switch. ON or OFF ON: Shift lever held in "-" operated OFF: Shift lever in S Result Result Proceed to The Techstream display changes according to the transmission control switch (transmission floor shift assembly) operation. A The Techstream display does not change according to the transmission control switch (transmission floor shift assembly) operation. B Turn the power switch off. Result: 2 B See step 4 Result: 1 A See step 3
- CHECK FOR INTERMITTENT PROBLEMS Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644289-S20908109292014072300000) Result Proceed to OK NG Result: 1 OK REPLACE POWER MANAGEMENT CONTROL ECU. Refer to «COMPONENTS [02/2014 - ]»(ref-644295-S12751216452014072300000) Result: 2 NG REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA
- INSPECT TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY) Disconnect the F46 transmission control switch (transmission floor shift assembly) connector. Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard Resistance Tester Connection Condition Specified Condition 2 (SFTU) - 5 (E) Shift lever held in "+" Below 1 ohms 1 (SFTD) - 5 (E) Shift lever held in "-" Below 1 ohms 2 (SFTU) - 5 (E) Shift lever in S 10 kohms or higher 1 (SFTD) - 5 (E) Shift lever in S 10 kohms or higher *a Component without harness connected (to Transmission Control Switch (Transmission Floor Shift Assembly)) Reconnect the F46 transmission control switch (transmission floor shift assembly) connector. Result Proceed to OK NG Result: 2 NG REPLACE TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY). Refer to «COMPONENTS [02/2014 - ]»(ref-644273-S41184565662014072300000) Result: 1 OK See step 5
- CHECK HARNESS AND CONNECTOR (TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY) - POWER MANAGEMENT CONTROL ECU) Disconnect the F16 power management control ECU connector. Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard Resistance Tester Connection Condition Specified Condition F16-21 (SFTU) - Body ground Shift lever held in "+" Below 1 ohms F16-20 (SFTD) - Body ground Shift lever held in "-" Below 1 ohms F16-21 (SFTU) - Body ground Shift lever in S 10 kohms or higher F16-20 (SFTD) - Body ground Shift lever in S 10 kohms or higher *a Rear view of wire harness connector (to Power Management Control ECU) Reconnect the F16 power management control ECU connector. Result Proceed to OK NG Result: 1 OK REPLACE POWER MANAGEMENT CONTROL ECU. Refer to «COMPONENTS [02/2014 - ]»(ref-644295-S12751216452014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
- CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Disconnect the F46 transmission control switch (transmission floor shift assembly) connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F46-3 (IG) - Body ground Power switch on (IG) 11 to 14 V F46-5 (E) - Body ground Power switch off Below 1 V *a Front view of wire harness connector (to Transmission Control Switch (Transmission Floor Shift Assembly)) Turn the power switch off. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F46-5 (E) - Body ground Power switch off Below 1 ohms Reconnect the F46 transmission control switch (transmission floor shift assembly) connector. Result Proceed to OK NG Result: 2 NG CHECK POWER SOURCE CIRCUIT Result: 1 OK See step 7
- INSPECT TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY) Disconnect the F46 transmission control switch (transmission floor shift assembly) connector. Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard Resistance Tester Connection Condition Specified Condition 3 (IG) - 7 (S) Shift lever in S Below 1 ohms 2 (SFTU) - 5 (E) Shift lever held in "+" Below 1 ohms 1 (SFTD) - 5 (E) Shift lever held in "-" Below 1 ohms 3 (IG) - 7 (S) Shift lever in any position except S 10 kohms or higher 2 (SFTU) - 5 (E) Shift lever in S 10 kohms or higher 1 (SFTD) - 5 (E) Shift lever in S 10 kohms or higher *a Component without harness connected (Transmission Control Switch (Transmission Floor Shift Assembly)) Reconnect the F46 transmission control switch (transmission floor shift assembly) connector. Result Proceed to OK NG Result: 2 NG See step 9 Result: 1 OK See step 8
- CHECK HARNESS AND CONNECTOR (POWER MANAGEMENT CONTROL ECU - TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)) Remove the IG2-EFI fuse from the No. 1 engine room relay block and No. 1 junction block assembly. *1 No. 1 Engine Room Relay Block and No. 1 Junction Block Assembly *2 IG2-EFI Fuse Remove the PM-IGCT fuse from the No. 3 engine room relay block. *1 No. 3 Engine Room Relay Block *2 PM-IGCT Fuse Remove the AM2 fuse and ECU-ACC from the instrument panel junction block assembly. *1 Instrument Panel Junction Block Assembly *2 AM2 Fuse *3 ECU-ACC Fuse Disconnect the A60, A61, F15 and F16 power management control ECU connectors. *a Rear view of wire harness connector (to Power Management Control ECU) Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard Resistance Tester Connection Condition Specified Condition F16-22 (M) - A60-1 (+B2) Power switch off 10 kohms or higher F16-22 (M) - A61-3 (+B1) Power switch off 10 kohms or higher F16-22 (M) - F15-1 (AM22) Power switch off 10 kohms or higher F16-22 (M) - F16-7 (AM21) Power switch off 10 kohms or higher F16-22 (M) - A60-4 (MREL) Power switch off 10 kohms or higher F16-22 (M) - A61-1 (IG2) Power switch off 10 kohms or higher F16-22 (M) - A60-10 (ACCI) Power switch off 10 kohms or higher F16-22 (M) - F16-1 (ACCD) Power switch off 10 kohms or higher F16-22 (M) - F16-2 (IG1D) Power switch off 10 kohms or higher F16-22 (M) - F15-16 (SPDI) Power switch off 10 kohms or higher F16-21 (SFTU) - Body ground Shift lever held in "+" Below 1 ohms F16-21 (SFTU) - Body ground Shift lever in S 10 kohms or higher F16-20 (SFTD) - Body ground Shift lever in S 10 kohms or higher F16-20 (SFTD) - Body ground Shift lever held in "-" Below 1 ohms NOTE: If the power switch is turned on (IG) with the power management control ECU connector disconnected, other DTCs will be stored. After performing the inspection, clear the DTCs. Disconnect the F46 transmission control switch (transmission floor shift assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F16-22 (M) - F46-7 (S) Power switch off Below 1 ohms *a Rear view of wire harness connector (to Power Management Control ECU) *b Front view of wire harness connector (to Transmission Control Switch (Transmission Floor Shift Assembly)) Reconnect the F46 transmission control switch (transmission floor shift assembly) connector. Reconnect the A60, A61, F15 and F16 power management control ECU connectors. Install the AM2 fuse and ECU-ACC fuse. Install the IG2-EFI fuse. Install the PM-IGCT fuse. Result Proceed to OK NG Result: 1 OK REPLACE POWER MANAGEMENT CONTROL ECU. Refer to «COMPONENTS [02/2014 - ]»(ref-644295-S12751216452014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
- INSPECT FUSE (SHIFT SW) Remove the SHIFT SW fuse from the No. 3 engine room relay block. *1 No. 3 Engine Room Relay Block *2 SHIFT SW Fuse Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition SHIFT SW fuse terminals Always Below 1 ohms Install the SHIFT SW fuse. Result Proceed to OK NG Result: 2 NG REPLACE FUSE (SEQUENTIAL) Result: 1 OK See step 10
- INSPECT HARNESS OR CONNECTOR (TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY) - POWER MANAGEMENT CONTROL ECU) Disconnect the F46 transmission control switch (transmission floor shift assembly) connector. Disconnect the A60 power management control ECU connector. Measure the resistance according to the value(s) in the table below. *a Front view of wire harness connector (to Transmission Control Switch (Transmission Floor Shift Assembly)) *b Rear view of wire harness connector (to Power Management Control ECU) Standard Resistance Tester Connection Condition Specified Condition F46-3 (IG) - A60-9 (PSFT) Power switch off Below 1 ohms F46-3 (IG) or A60-9 (PSFT) - Body ground and other terminals Power switch off 10 kohms or higher Reconnect the A60 power management control ECU connector. Reconnect the F46 transmission control switch (transmission floor shift assembly) connector. Result Proceed to OK NG Result: 1 OK REPAIR OR REPLACE POWER SOURCE CIRCUIT Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
The EV drive mode signal will be sent to the power management control ECU when the EV drive mode switch (pattern select switch assembly) is operated. If the specified conditions are met, the system enters EV drive mode and the vehicle will be driven using EV drive mode. This signal is then transmitted from the power management control ECU via CAN to the combination meter assembly to illuminate the EV drive mode indicator.
Scheme 173
When selecting ECO mode, the ECO mode switch (heater switch assembly) operation signal is sent to the air conditioning amplifier assembly. Following this, ECO mode control is activated for the heater and air conditioning system.
Scheme 174
Scheme 175
- READ VALUE USING TECHSTREAM (CAN BUS CHECK) See step 2 Result Result Proceed to All of the ECUs and sensors that are currently connected to the CAN communication system are displayed. A None of the ECUs and sensors that are currently connected to the CAN communication system are displayed, or some of them are not displayed. B Result: 2 B GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [02/2014 - ]»(ref-644298-S11625065512014072300000) Result: 1 A See step 2
- CHECK DTC OUTPUT (HEALTH CHECK) See step 3 Result Result Proceed to No DTCs are output.(for multi-information display (monochrome type)) A No DTCs are output.(for multi-information display (color type)) B DTCs are output. C Result: 3 B See step 4 Result: 2 C GO TO DTC CHART Result: 1 A See step 3
- PERFORM ACTIVE TEST USING TECHSTREAM (INDICAT. ECO MODE) Connect the Techstream to the DLC3. Turn the power switch on (IG). Enter the following menus: Body Electrical / Combination Meter / Active Test / Indicat. ECO MODE. Body Electrical > Combination Meter > Active Test Tester Display Indicat. ECO MODE Read the value displayed on the Techstream. Turn the power switch off. Result Proceed to OK NG Result: 2 NG REPLACE COMBINATION METER ASSEMBLY. Refer to «COMPONENTS [02/2014 - ]»(ref-644299-S00850024762014072300000) Result: 1 OK See step 4
- READ VALUE USING TECHSTREAM (ECO MODE) Connect the Techstream to the DLC3. Turn the power switch on (IG). Enter the following menus: Powertrain / Hybrid Control / Data List / ECO Mode. Powertrain > Hybrid Control > Data List Tester Display ECO Mode Read the value displayed on the Techstream. Powertrain > Hybrid Control > Data List Tester Display Measurement Item Range Normal Condition ECO Mode ECO mode transition availability ON or OFF In ECO mode: ON Result Result Proceed to The Techstream display changes according to the ECO mode switch (heater switch assembly) operation. A The Techstream display does not change according to the ECO mode switch (heater switch assembly) operation. B Turn the power switch off. Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644289-S20908109292014072300000) Result: 3 B See step 5
- READ VALUE USING TECHSTREAM (ECO SWITCH) Connect the Techstream to the DLC3. Turn the power switch on (IG). Enter the following menus: Body Electrical / Air Conditioning / Data List / ECO Switch. Body Electrical > Air Conditioner > Data List Tester Display ECO Switch Read the value displayed on the Techstream. Body Electrical > Air Conditioner > Data List Tester Display Measurement Item Range Normal Condition ECO Switch ECO mode switch (heater switch assembly) condition ON or OFF ECO mode switch (heater switch assembly) being pushed and held at ECO position: ON Mode switch not turned: OFF Result Result Proceed to The Techstream display changes according to the ECO mode switch (heater switch assembly) operation. A The Techstream display does not change according to the ECO mode switch (heater switch assembly) operation. B Turn the power switch off. Result: 1 A REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY. Refer to «COMPONENTS [02/2014 - ]»(ref-644284-S07496609352014072300000) Result: 2 B See step 6
- INSPECT ECO MODE SWITCH (HEATER SWITCH ASSEMBLY) Remove the ECO mode switch (heater switch assembly). Refer to «REMOVAL [02/2014 - ]»(ref-644284-S36017302352014072300000) Measure the resistance according to the value(s) in the table below. *a Component without harness connected (ECO Mode Switch (Heater Switch Assembly)) Standard Resistance Tester Connection Condition Specified Condition 4 (ECU) - 1 (E) ECO mode switch (heater switch assembly) being pushed and held Below 1 ohms ECO mode switch (heater switch assembly) not pushed 10 kohms or higher Install the ECO mode switch (heater switch assembly). Result Proceed to OK NG Result: 2 NG REPLACE ECO MODE SWITCH (HEATER SWITCH ASSEMBLY). Refer to «COMPONENTS [02/2014 - ]»(ref-644284-S07784696822014072300000) Result: 1 OK See step 7
- CHECK HARNESS AND CONNECTOR (ECO MODE SWITCH (HEATER SWITCH ASSEMBLY) - BODY GROUND) Disconnect the F44 ECO mode switch (heater switch assembly) connector. Measure the resistance according to the value(s) in the table below. *a Front view of wire harness connector (to ECO Mode Switch (Heater Switch Assembly)) Standard Resistance Tester Connection Condition Specified Condition F44-1 (E) - Body ground Always Below 1 ohms Reconnect the F44 ECO mode switch (heater switch assembly) connector. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 8
- CHECK HARNESS AND CONNECTOR (AIR CONDITIONING AMPLIFIER ASSEMBLY - ECO MODE SWITCH (HEATER SWITCH ASSEMBLY)) Disconnect the F80 air conditioning amplifier assembly connector. Disconnect the F44 ECO mode switch (heater switch assembly) connector. Measure the resistance according to the value(s) in the table below. *a Front view of wire harness connector (to Air Conditioning Amplifier Assembly) *b Front view of wire harness connector (to Mode Switch (Heater Switch Assembly)) Standard Resistance Tester Connection Condition Specified Condition F80-4 (ECON) - F44-4 (ECU) Always Below 1 ohms F80-4 (ECON) or F44-4 (ECU) - Body ground Always 10 kohms or higher Reconnect the F44 ECO mode switch (heater switch assembly) connector. Reconnect the F80 air conditioning amplifier assembly connector. Result Proceed to OK NG Result: 1 OK REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY. Refer to «COMPONENTS [02/2014 - ]»(ref-644284-S07496609352014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
In accordance with the shift lever position, each shift position indicator light will turn on.
Scheme 176
If the power switch is on (IG), the power management control ECU applies current to the MREL terminal to turn the IGCT relay on. This supplies power to the +B1 and +B2 terminals.
