Windshield / Windowglass (Service Information): Overview Toyota Highlander II рестайлинг

Scheme 17

Scheme 18

1. REMOVE FRONT ARMREST UPPER BASE PANEL . Refer to «DISASSEMBLY - Step 4»(/toyota/highlander/ii-2010-2013/remont/exterior-body-panels/#engine-hood-door-service-information)
2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Remove the 3 screws and the power window regulator master switch assembly.

Scheme 19

Scheme 20

1. INSPECT POWER WINDOW MASTER SWITCH Check that the switch function. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 8 (U) - 1 (E) - 4 (A) Auto UP (Driver side) Below 1 ohms 8 (U) - 1 (E) Manual UP (Driver side) Below 1 ohms 5 (D) - 1 (E) Manual DOWN (Driver side) Below 1 ohms 4 (A) - 5 (D) - 1 (E) Auto DOWN (Driver side) Below 1 ohms 6 (B) - 16 (U) 15 (D) - 1 (E) UP (Passenger side) Below 1 ohms 6 (B) - 15 (D) 16 (U) - 1 (E) DOWN (Passenger side) Below 1 ohms 6 (B) - 12 (U) 13 (D) - 1 (E) UP (Rear LH) Below 1 ohms 6 (B) - 13 (D) 12 (U) - 1 (E) DOWN (Rear LH) Below 1 ohms 6 (B) - 10 (U) 18 (D) - 1 (E) UP (Rear RH) Below 1 ohms 6 (B) - 18 (D) 10 (U) - 1 (E) DOWN (Rear RH) Below 1 ohms If the result is not as specified, replace the master switch. Check that the LED illuminates. Apply battery voltage to the master switch and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (LED) Battery negative (-) --> Terminal 1 (E) LED illuminates If the result is not as specified, replace the master switch.
