Power Window Control System (Diagnostic Codes & Symptom Tests): Overview Toyota Highlander II рестайлинг

DESCRIPTION

The portion of the power window control system that is located in the driver door consists of a power window master switch, regulator, and a motor with an integrated ECU. The driver door power window regulator motor is controlled by the ECU when the power window master switch is operated (models with jam protection).

DTC B2311 is set when the ECU for the driver door power window regulator motor assembly malfunctions.

Note. The power window control system uses a serial communication protocol (LIN) to communicate with the main body ECU. Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly.

HINT

1. Initialization is required only when the power window regulator motor is replaced. However, replacing the motor may cause the motor gear to be engaged in a different position. This can cause a difference to exist between the current door glass position and the position memorized in the ECU. In this case, the jam protection function may work improperly. Return the system to the pre-initialized condition and reinitialize the system.
2. To return the system to the pre-initialized condition: Disconnect the power window regulator motor connector during power window operation. This will return the motor to the pre-initialized condition.

The portion of the power window control system that is located in the driver door consists of a power window master switch, regulator, and a motor with an integrated ECU. The driver door power window regulator motor is controlled by the ECU when the power window master switch is operated (models with jam protection).

When the ECU determines that the power window master switch is stuck, DTC B2312 is set.

Note. The power window control system uses a serial communication protocol (LIN) to communicate with the main body ECU. Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly.

Scheme 121

Scheme 122

Scheme 123

1. CHECK DTC OUTPUT Turn the ignition switch off. Wait for at least 10 seconds, and then turn the ignition switch on (IG). Check whether the DTC output recurs. Result Result Proceed to B2312 A No output B B --> END (DUE TO KEEPING SWITCH OPERATED FOR 20 SECONDS OR MORE) A: Go to next step
2. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 8 (U) - 1 (E) - 4 (A) Auto UP Below 1 ohms 8 (U) - 1 (E) Manual UP Below 1 ohms 5 (D) - 1 (E) Manual DOWN Below 1 ohms 4 (A) - 5 (D) - 1 (E) Auto DOWN Below 1 ohms NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (POWER WINDOW MASTER SWITCH - WINDOW REGULATOR MOTOR) Disconnect the H8 and H1 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-8 (U) - H1-10 (UP1) Always Below 1 ohms H8-3 (LED) - H1-5 (LED) Always Below 1 ohms H8-4 (A) - H1-4 (AUTO) Always Below 1 ohms H8-5 (D) - H1-7 (DWN1) Always Below 1 ohms H8-8 (U) - Body ground Always 10 kohms or higher H8-3 (LED) - Body ground Always 10 kohms or higher H8-4 (A) - Body ground Always 10 kohms or higher H8-5 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
4. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side). Refer to «REMOVAL»(ref-422557-S31617504892011092600000)
5. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)

The portion of the power window control system that is located in the driver door consists of a power window master switch, regulator, and a motor with an integrated ECU. The driver door power window regulator motor is controlled by the ECU when the power window master switch is operated (models with jam protection).

When the ECU determines that the driver's door power window regulator motor assembly has not been initialized, DTC B2313 is set.

Note. The power window control system uses a serial communication protocol (LIN) to communicate with the main body ECU. Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly.

HINT

1. Replacing the door glass or door glass run may cause a difference to exist between the current door glass position and the position memorized in the ECU. In this case, the jam protection function may work improperly. Return the system to the pre-initialized condition and reinitialize the system.
2. To return the system to the pre-initialized condition, refer to «INITIALIZATION»(ref-422307-S33663556452011092600000)

Refer to DTC B2321 (LIN communication system), refer to DESCRIPTION .

With the ignition switch on (IG) , the power window regulator master switch transmits remote switch signals to the regulator switch of the passenger door power window. Then, the regulator switch drives the passenger power window regulator motor.

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

1. CHECK POWER WINDOW MASTER SWITCH Turn the window lock switch OFF and operate the switches on the master switch. Check that the remote UP / DOWN function operates normally. OK Remote UP / DOWN function operates normally. NG --> See step 2 OK --> END
2. CHECK MANUAL UP / DOWN FUNCTION Check that the passenger door power window manual UP / DOWN function operates normally. OK Manual UP / DOWN function operates normally. NG --> See step 4 OK --> See step 3
3. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)
4. HARNESS AND CONNECTOR (POWER WINDOW MASTER SWITCH - BATTERY AND BODY GROUND) Disconnect the H8 connector. Measure the voltage and resistance according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition H8-6 (B) - Body ground Ignition switch on (IG) 11 to 14 V Standard resistance Tester Connection Condition Specified Condition H8-1 (E) - Body ground Always Below 1 ohms NG --> REPLACE POWER WINDOW REGULATOR SWITCH ASSY OK: Go to next step
5. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 6 (B) - 16 (U) 15 (D) - 1 (E) UP (Passenger side) Below 1 ohms 6 (B) - 15 (D) 16 (U) - 1 (E) DOWN (Passenger side) Below 1 ohms 6 (B) - 12 (U) 13 (D) - 1 (E) UP (Rear LH) Below 1 ohms 6 (B) - 13 (D) 12 (U) - 1 (E) DOWN (Rear LH) Below 1 ohms 6 (B) - 10 (U) 18 (D) - 1 (E) UP (Rear RH) Below 1 ohms 6 (B) - 18 (D) 10 (U) - 1 (E) DOWN (Rear RH) Below 1 ohms NG --> See step 7 OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - FRONT PASSENGER, REAR LH/RH SWITCH) Front passenger side: Disconnect the H8 and G7 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-16 (U) - G7-5 (SU) Always Below 1 ohms H8-15 (D) - G7-2 (SD) Always Below 1 ohms H8-16 (U) - Body ground Always 10 kohms or higher H8-15 (D) - Body ground Always 10 kohms or higher for Rear LH side: Disconnect the H8 and K2 connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-12 (U) - K2-5 (SU) Always Below 1 ohms H8-13 (D) - K2-2 (SD) Always Below 1 ohms H8-12 (U) - Body ground Always 10 kohms or higher H8-13 (D) - Body ground Always 10 kohms or higher for Rear RH side: Disconnect the H8 and J2 connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-10 (U) - J2-5 (SU) Always Below 1 ohms H8-18 (D) - J2-2 (SD) Always Below 1 ohms H8-10 (U) - Body ground Always 10 kohms or higher H8-18 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE POWER WINDOW SWITCH (APPLICABLE LOCATION)
7. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)

If the manual UP / DOWN and AUTO DOWN functions do not operate, a malfunction may exist in the power window master switch, power window regulator motor or wire harness.

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. INSPECT POWER WINDOW MASTER SWITCH (DRIVER SWITCH) Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 8 (U) - 1 (E) - 4 (A) Auto UP Below 1 ohms 8 (U) - 1 (E) Manual UP Below 1 ohms 5 (D) - 1 (E) Manual DOWN Below 1 ohms 4 (A) - 5 (D) - 1 (E) Auto DOWN Below 1 ohms NG --> See step 5 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - MOTOR (DRIVER SIDE) Disconnect the H8 and H1 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-8 (U) - H1-10 (UP1) Always Below 1 ohms H8-4 (A) - H1-4 (AUTO) Always Below 1 ohms H8-5 (D) - H1-7 (DWN1) Always Below 1 ohms H8-8 (U) - Body ground Always 10 kohms or higher H8-4 (A) - Body ground Always 10 kohms or higher H8-5 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) Remove the power window regulator motor, refer to «REMOVAL»(ref-422557-S31617504892011092600000) . Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1, 2, 4, 7, 9 and 10. OK Switch Condition Measurement Condition Specified Condition Manual Operation Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 10 (UP1) Motor gear rotates clockwise Auto Operation Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 10 (UP1) Motor gear rotates clockwise NG --> See step 6 OK --> See step 4
4. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)
5. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)
6. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side). Refer to «REMOVAL»(ref-422557-S31617504892011092600000)

If the passenger side manual UP/DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. CHECK POWER WINDOW SWITCH (FRONT PASSENGER SIDE) (POWER SOURCE) Disconnect the G7 connector. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition G7-3 (B) - Body ground Ignition switch on (IG) 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT POWER WINDOW SWITCH (FRONT PASSENGER SIDE) Measure the resistance when the switch is operated according to the value(s) in the table below. Standard resistance Tester Connection Switch Condition Specified Condition 1 (D) - 2 (SD) UP Below 1 ohms 3 (B) - 4 (U) Below 1 ohms 1 (D) - 2 (SD) OFF Below 1 ohms 4 (U) - 5 (SU) Below 1 ohms 4 (U) - 5 (SU) DOWN Below 1 ohms 1 (D) - 3 (B) Below 1 ohms NG --> See step 7 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (SWITCH (FRONT PASSENGER SIDE) - MOTOR (FRONT PASSENGER SIDE) Disconnect the G7 and G1 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition G7-4 (U) - G1-2 (U) Always Below 1 ohms G7-1 (D) - G1-1 (D) Always Below 1 ohms G7-4 (U) - Body ground Always 10 kohms or higher G7-1 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (FRONT PASSENGER SIDE) Check power window regulator motor operation. Remove the power window regulator motor, refer to «REMOVAL»(ref-422557-S31617504892011092600000) Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. OK Measurement Condition Specified Condition Battery negative (-) --> Terminal 2 Battery positive (+) --> Terminal 1 Motor gear rotates clockwise Battery negative (-) --> Terminal 1 Battery positive (+) --> Terminal 2 Motor gear rotates counterclockwise Check PTC operation: NOTE: The work must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor, refer to «INSTALLATION»(ref-422557-S39261339442011092600000) Connect an electrical tester DC 400 A probe to the wire harness of terminal 2. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pressing the power window UP switch. Wait for approximately 60 seconds. Continue to press the power window UP switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (Inspection of current shut-off). Standard 4 to 90 seconds 60 seconds after the previous step, press the power window DOWN switch (passenger side). OK The passenger side window goes down. NG --> See step 8 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (FRONT PASSENGER SIDE) Disconnect the H8 and G7 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-16 (U) - G7-5 (SU) Always Below 1 ohms H8-15 (D) - G7-2 (SD) Always Below 1 ohms H8-16 (U) - Body ground Always 10 kohms or higher H8-15 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)
7. REPLACE POWER WINDOW SWITCH (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-422557-S30035771112011092600000)
8. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (FRONT PASSENGER SIDE). Refer to «REMOVAL»(ref-422557-S31617504892011092600000)

If the rear LH side manual UP/DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

1. CHECK POWER WINDOW REGULATOR SWITCH (REAR LH) (POWER SOURCE) Disconnect the K2 connector. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition K2-3 (B) - Body ground Ignition switch on (IG) 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT POWER WINDOW SWITCH (REAR LH) Measure the resistance when the switch is operated according to the value(s) in the table below. Standard resistance Tester Connection Switch Condition Specified Condition 1 (D) - 2 (SD) UP Below 1 ohms 3 (B) - 4 (U) Below 1 ohms 1 (D) - 2 (SD) OFF Below 1 ohms 4 (U) - 5 (SU) Below 1 ohms 4 (U) - 5 (SU) DOWN Below 1 ohms 1 (D) - 3 (B) Below 1 ohms NG --> See step 7 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (SWITCH (REAR LH) - MOTOR (REAR LH) Disconnect the K2 and K3 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition K2-4 (U) - K3-1 (U) Always Below 1 ohms K2-1 (D) - K3-2 (D) Always Below 1 ohms K2-4 (U) - Body ground Always 10 kohms or higher K2-1 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR LH) Check power window regulator motor operation. Remove the power window regulator motor, refer to «REMOVAL»(ref-422557-S31617504892011092600000) . Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. OK Measurement Condition Specified Condition Battery negative (-) --> Terminal 1 Battery positive (+) --> Terminal 2 Motor gear rotates clockwise Battery negative (-) --> Terminal 2 Battery positive (+) --> Terminal 1 Motor gear rotates counterclockwise Check PTC operation: NOTE: The work must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor, refer to «INSTALLATION»(ref-422557-S39261339442011092600000) . Connect an electrical tester DC 400 A probe to the wire harness of terminal 1. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pressing the power window UP switch. Wait for approximately 60 seconds. Continue to press the power window UP switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (Inspection of current shut-off). Standard 4 to 90 seconds 60 seconds after the previous step, press the power window DOWN switch (rear LH side). OK The rear LH side window goes down. NG --> See step 8 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (REAR LH) Disconnect the H8 and K2 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-12 (U) - K2-5 (SU) Always Below 1 ohms H8-13 (D) - K2-2 (SD) Always Below 1 ohms H8-12 (U) - Body ground Always 10 kohms or higher H8-13 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)
7. REPLACE POWER WINDOW SWITCH (REAR LH). Refer to «REMOVAL»(ref-422557-S00924286452011092600000)
8. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR LH). Refer to «REMOVAL»(ref-422557-S31617504892011092600000)

If the rear RH side manual UP / DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

1. CHECK POWER WINDOW SWITCH (REAR RH) (POWER SOURCE) Disconnect the J2 connector. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition J2-3 (B) - Body ground Ignition switch on (IG) 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT POWER WINDOW SWITCH (REAR RH) Measure the resistance when the switch is operated according to the value(s) in the table below. Standard resistance Tester Connection Switch Condition Specified Condition 1 (D) - 2 (SD) UP Below 1 ohms 3 (B) - 4 (U) Below 1 ohms 1 (D) - 2 (SD) OFF Below 1 ohms 4 (U) - 5 (SU) Below 1 ohms 4 (U) - 5 (SU) DOWN Below 1 ohms 1 (D) - 3 (B) Below 1 ohms NG --> See step 7 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (SWITCH (REAR RH) - MOTOR (REAR RH) Disconnect the J2 and J3 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition J2-4 (U) - J3-1 (U) Always Below 1 ohms J2-1 (D) - J3-2 (D) Always Below 1 ohms J2-4 (U) - Body ground Always 10 kohms or higher J2-1 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR RH) Check power window regulator motor operation. Remove the power window regulator motor, refer to «REMOVAL»(ref-422557-S31617504892011092600000) . Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. OK Measurement Condition Specified Condition Battery negative (-) --> Terminal 1 Battery positive (+) --> Terminal 2 Motor gear rotates clockwise Battery negative (-) --> Terminal 2 Battery positive (+) --> Terminal 1 Motor gear rotates counterclockwise Check PTC operation: NOTE: The work must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor, refer to «INSTALLATION»(ref-422557-S39261339442011092600000) . Connect an electrical tester DC 400 A probe to the wire harness of terminal 1. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pressing the power window UP switch. Wait for approximately 60 seconds. Continue to press the power window UP switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (Inspection of current shut-off). Standard 4 to 90 seconds 60 seconds after the previous step, press the power window DOWN switch (rear RH side). OK The rear RH side window goes down. NG --> See step 8 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (REAR RH) Disconnect the H8 and J2 connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-10 (U) - J2-5 (SU) Always Below 1 ohms H8-18 (D) - J2-2 (SD) Always Below 1 ohms H8-10 (U) - Body ground Always 10 kohms or higher H8-18 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)
7. REPLACE POWER WINDOW SWITCH (REAR RH). Refer to «REMOVAL»(ref-422557-S00924286452011092600000)
8. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR RH). Refer to «REMOVAL»(ref-422557-S31617504892011092600000)

1. When the AUTO UP/DOWN does not function, the power window control system may be in fail-safe mode. If the system has not been initialized after replacement of the driver door power window regulator motor, it also results in the same problem. NOTE: The power window control system uses a multiplex communication system (LIN). Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly. When the power window regulator motor assembly (on the driver side) is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the AUTO UP function is used. In such cases, the AUTO UP function can be resumed by repeating the following operation at least 5 times: Close the power window by fully pulling up the power window switch and holding it in the AUTO UP position. Open the power window by fully pushing down the switch. HINT: If the pulse sensor built into the power window regulator motor assembly (on the driver side) malfunctions, the power window control system enters fail-safe mode. The remote UP/DOWN and AUTO UP/DOWN functions cannot be operated during fail-safe mode. (However, the power window can be closed by holding the power window switch at the AUTO UP position, and opened manually by pushing down the switch.)

Scheme 156

Scheme 157

Scheme 158

1. CHECK DTC Check for DTCs. Connect Techstream to the DLC3. By following the tester screen display, check whether any DTCs are output. RESULT Result Proceed to No output A DTC output B B --> PROCEED TO INSPECTION PROCEDURE RELEVANT TO OUTPUT DTC A: Go to next step
2. READ VALUE ON TECHSTREAM (D-DOOR MOTOR) Use the Data List to check the function of the power window master switch. D-DOOR MOTOR Item Measurement Item / Display (Range) Normal Condition Diagnostic Note D P/W Auto Switch Driver side power window AUTO switch signal / ON or OFF ON: Driver side power window AUTO switch operates OFF: Driver side power window AUTO switch does not operate - D P/W Up Switch Driver side power window UP switch signal / ON or OFF ON: Driver side power window UP switch operates OFF: Driver side power window UP switch does not operate - D P/W Down Switch Driver side power window DOWN switch signal / ON or OFF ON: Driver side power window DOWN switch operates OFF: Driver side power window DOWN switch does not operate - OK ON (switch operates) appears on screen. NG --> See step 3 OK --> See step 6
3. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 8 (U) - 1 (E) - 4 (A) Auto UP Below 1 ohms 4 (A) - 5 (D) - 1 (E) Auto Down Below 1 ohms NG --> See step 7 OK: Go to next step
4. INSPECT FUSE (DOOR NO. 2) Remove the DOOR NO. 2 fuse from the instrument panel junction block. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition DOOR NO. 2 Always Below 1 ohms NG --> REPLACE FUSE (DOOR NO. 2) OK: Go to next step
5. CHECK WIRE HARNESS (MASTER SWITCH - REGULATOR MOTOR) Disconnect the H8 and H1 connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition H8-4 (A) - H1-4 (AUTO) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side). Refer to «REMOVAL»(ref-422557-S31617504892011092600000)
7. REPLACE POWER WINDOW MASTER SWITCH. Refer to «REMOVAL»(ref-422557-S33766315772011092600000)

1. When the driver door has not been opened and fully closed, each door power window regulator motor can control its power window operation for approximately 45 seconds after the ignition switch is turned from on (IG) to off (the key is removed) by receiving operation permission signals from the main body ECU. However, when approximately 45 seconds have elapsed, or the driver door or front passenger side door is opened within approximately 45 seconds of the ignition switch being turned off (the key is removed), the power window regulator motor stops operating. During AUTO function operation, the window operation will continue until complete even if 45 seconds have passed or a door is opened. NOTE: The power window control system uses a multiplex communication system (LIN). Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly. The power window control system prohibits the AUTO UP / DOWN function when the jam protection function malfunctions. Therefore, troubleshoot the power window control system after confirming that no diagnostic codes are displayed.

Scheme 159

The driver door power window regulator motor is activated by operating the power window regulator master switch. The driver door power window regulator motor has motor, regulator and ECU functions. DTC B2311 is set when the main body ECU determines that the driver door power window regulator motor malfunctions.

HINT

If the pulse sensor in the power window regulator motor assembly (on the driver side) malfunctions, the power window control system enters fail-safe mode. The remote UP / DOWN and AUTO UP / DOWN functions cannot be operated during fail-safe mode. (However, the power window can be closed by holding the power window switch at the AUTO UP position, and opened manually by pushing down the switch.)
