Audio System & Visual System (Except Hybrid): Removal & Installation Toyota Highlander II

Antenna Systems 15 illustrations ~2116 words

INSTALLATION

  1. INSTALL AMPLIFIER ANTENNA ASSEMBLY Install the amplifier antenna assembly with the 5 bolts. Engage the 9 clamps.
  2. INSTALL ROOF HEADLINING ASSEMBLY (w/ Sliding Roof) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  3. INSTALL ROOF HEADLINING ASSEMBLY (w/o Sliding Roof) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  4. INSTALL VISOR HOLDER (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  5. INSTALL SUN ROOF OPENING TRIM MOLDING (w/ Sliding Roof) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  6. INSTALL ROOF HEADLINING TRIM CLIP STOPPER (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  7. INSTALL ASSIST GRIP ASSEMBLY (w/ Sliding Roof) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  8. INSTALL REAR ASSIST GRIP SUB-ASSEMBLY (w/o Sliding Roof) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  9. INSTALL FRONT ASSIST GRIP SUB-ASSEMBLY (w/o Sliding Roof) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  10. INSTALL TELEVISION DISPLAY ASSEMBLY (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-290716-S05666858072008071700000) )
  11. INSTALL TELEVISION BASE (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-290716-S05666858072008071700000) )
  12. INSTALL NO. 2 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  13. INSTALL NO. 1 ROOM LIGHT ASSEMBLY (for Standard) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  14. INSTALL NO. 1 ROOM LIGHT ASSEMBLY (for Independent Type) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  15. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER (w/ EC Mirror) (See «INSTALLATION»(ref-290719-S25471414662008071700000) )
  16. INSTALL VISOR ASSEMBLY LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  17. INSTALL VISOR BRACKET COVER (for LH Side) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  18. INSTALL VISOR ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  19. INSTALL VISOR BRACKET COVER (for RH Side) HINT: Use the same procedure for the RH side and the LH side.
  20. INSTALL ROOF CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  21. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY LH (w/ Power Back Door) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  22. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY LH (w/o Power Back Door) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  23. INSTALL QUARTER PILLAR GARNISH LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  24. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  25. CONNECT REAR NO. 1 SEAT OUTER BELT ASSEMBLY LH (See «INSTALLATION»(ref-290708-S28585609242008071700000) )
  26. INSTALL FRONT DECK SIDE TRIM COVER LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  27. INSTALL NO. 2 DECK SIDE TRIM HOOK (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  28. INSTALL ROPE HOOK ASSEMBLY (for LH Side) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  29. INSTALL REAR DECK TRIM COVER (w/o Remote Folding Function) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  30. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL LH (w/ Remote Folding Function) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  31. INSTALL REAR POWER OUTLET SOCKET COVER (See «INSTALLATION»(ref-290713-S03656380682008071700000) )
  32. INSTALL REAR POWER POINT SOCKET ASSEMBLY (See «INSTALLATION»(ref-290713-S03656380682008071700000) )
  33. INSTALL REAR COMBINATION LIGHT SERVICE COVER LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  34. INSTALL SIDE TRIM COVER LH (w/o Rear Seat Entertainment System) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  35. INSTALL POWER OUTLET SOCKET BEZEL (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  36. INSTALL DECK SIDE TRIM LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  37. INSTALL DECK SIDE TRIM COVER LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  38. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY RH (w/ Rear No. 2 Seat) HINT: Use the same procedure for the RH side and the LH side.
  39. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY RH (w/o Rear No. 2 Seat) HINT: Use the same procedure for the RH side and the LH side.
  40. INSTALL QUARTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  41. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  42. CONNECT REAR NO. 1 SEAT OUTER BELT ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  43. INSTALL FRONT DECK SIDE TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
  44. INSTALL NO. 1 LUGGAGE COMPARTMENT TRIM HOOK (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  45. INSTALL ROPE HOOK ASSEMBLY (for RH Side) HINT: Use the same procedure for the RH side and the LH side.
  46. INSTALL REAR COMBINATION LIGHT SERVICE COVER RH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  47. INSTALL REAR ROOM TEMPERATURE SENSOR (w/ Rear Automatic Air Conditioning System) (See «INSTALLATION»(ref-290682-S03722758072008071700000) )
  48. INSTALL SIDE TRIM COVER RH (w/o Rear Automatic Air Conditioning System) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  49. INSTALL DECK SIDE TRIM RH HINT: Use the same procedure for the RH side and the LH side.
  50. INSTALL DECK SIDE TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
  51. INSTALL REAR SEAT SIDE GARNISH CAP (w/ Rear Air Conditioning System) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  52. INSTALL REAR SEAT SIDE GARNISH CAP (w/o Rear Air Conditioning System) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  53. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  54. INSTALL REAR NO. 2 SEAT ASSEMBLY (w/Rear No. 2 Seat) (See «INSTALLATION»(ref-290711-S33905894112008071700000) )
  55. CONNECT REAR SEAT LAP TYPE BELT ASSEMBLY LH (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290708-S31525434142008071700000) )
  56. CONNECT REAR SEAT LAP TYPE BELT ASSEMBLY RH (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290708-S31525434142008071700000) )
  57. INSTALL REAR NO. 2 SEAT INNER BELT ASSEMBLY (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290708-S05631940072008071700000) )
  58. INSTALL REAR DECK FLOOR BOX (w/o Rear No. 2 Seat) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  59. INSTALL DECK FLOOR BOARD ASSEMBLY (w/o Rear No. 2 Seat) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  60. INSTALL REAR MAT (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  61. INSTALL DECK FLOOR BOARD ASSEMBLY (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  62. INSTALL DECK SIDE TRIM BOX LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  63. INSTALL REAR SEAT SIDE COVER LH (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  64. INSTALL DECK SIDE TRIM BOX RH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  65. INSTALL JACK CARRIER ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  66. INSTALL JACK ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  67. INSTALL JACK CARRIER CUSHION (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  68. INSTALL JACK CARRIER SUPPORT
  69. INSTALL REAR SEAT SIDE COVER RH (w/ Rear Air Conditioning System) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  70. INSTALL REAR NO. 1 FLOOR BOARD (w/o Rear Air Conditioning System) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  71. INSTALL TONNEAU COVER ASSEMBLY (w/ Tonneau Cover) (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  72. INSTALL NO. 2 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  73. INSTALL NO. 3 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  74. INSTALL DECK BOARD ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  75. INSTALL CENTER PILLAR GARNISH LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  76. CONNECT FRONT SEAT OUTER BELT ASSEMBLY LH (See «INSTALLATION»(ref-290708-S04899816822008071700000) )
  77. INSTALL LOWER CENTER PILLAR GARNISH LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  78. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  79. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  80. INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  81. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  82. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  83. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  84. INSTALL CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  85. CONNECT FRONT SEAT OUTER BELT ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  86. INSTALL LOWER CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  87. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  88. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
  89. INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  90. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH (See «INSTALLATION»(ref-290712-S17697766732008071700000) )
  91. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  92. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
  93. INSTALL REAR NO. 1 SEAT ASSEMBLY LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  94. CONNECT REAR NO. 1 SEAT LOCK CABLE ASSEMBLY LH (w/ Remote Folding Function) (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  95. INSPECT REAR SEAT SLIDE ADJUSTER LOCK (for LH Side) (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  96. INSTALL REAR SEAT LEG SIDE COVER LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  97. INSTALL REAR INNER TRACK BRACKET COVER LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  98. INSTALL REAR OUTER TRACK BRACKET COVER LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  99. INSTALL REAR SEAT TRACK BRACKET COVER LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  100. INSTALL REAR SEAT HEADREST ASSEMBLY (for LH Side) (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
  101. INSTALL REAR CENTER SEAT ASSEMBLY
  102. INSTALL REAR NO. 1 SEAT ASSEMBLY RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
  103. CONNECT REAR NO. 1 SEAT LOCK CABLE ASSEMBLY RH (w/ Remote Folding Function) (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
  104. INSPECT REAR SEAT SLIDE ADJUSTER LOCK (for RH Side) (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
  105. INSTALL REAR SEAT LEG SIDE COVER RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
  106. INSTALL REAR INNER TRACK BRACKET COVER RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
  107. INSTALL REAR OUTER TRACK BRACKET COVER RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
  108. INSTALL REAR SEAT TRACK BRACKET COVER RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
  109. INSTALL REAR SEAT HEADREST ASSEMBLY (for RH Side) (See «INSTALLATION»(ref-290711-S19126382862008071700000) )

Scheme 204

Scheme 204: COMPONENTS
Scheme 204: COMPONENTS

Scheme 205

Scheme 205: REMOVAL
Scheme 205: REMOVAL
  1. REMOVE POWER OUTLET SOCKET BEZEL (See «REMOVAL»(ref-290712-S25593620862008071700000) )
  2. REMOVE VIDEO TERMINAL Disengage the clamp and 4 claws and remove the video terminal.

Scheme 206

Scheme 206: INSTALLATION
Scheme 206: INSTALLATION
  1. INSTALL VIDEO TERMINAL Engage the 4 claws and install the video terminal. Engage the clamp.
  2. INSTALL POWER OUTLET SOCKET BEZEL (See «INSTALLATION»(ref-290712-S17697766732008071700000) )

Scheme 207

Scheme 207: COMPONENTS
Scheme 207: COMPONENTS

Scheme 208

Scheme 208: REMOVAL
Scheme 208: REMOVAL

Scheme 209

Scheme 209
Scheme 209
  1. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (w/o Smart Key System) (See «REMOVAL»(ref-290705-S36017302052008071700000) )
  2. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (w/ Smart Key System) (See «REMOVAL»(ref-290705-S36017302052008071700000) )
  3. REMOVE STEREO JACK ADAPTER ASSEMBLY (w/o Seat Heater System) Disengage the 2 claws and remove the stereo jack adapter assembly.
  4. REMOVE STEREO JACK ADAPTER ASSEMBLY (w/ Seat Heater System) Disengage the 2 claws and remove the stereo jack adapter assembly.
  1. INSTALL STEREO JACK ADAPTER ASSEMBLY (w/o Seat Heater System) Engage the 2 claws and install the stereo jack adapter assembly.
  2. INSTALL STEREO JACK ADAPTER ASSEMBLY (w/ Seat Heater System) Engage the 2 claws and install the stereo jack adapter assembly.
  3. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (w/o Smart Key System) (See «INSTALLATION»(ref-290705-S10272961962008071700000) )
  4. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (w/ Smart Key System) (See «INSTALLATION»(ref-290705-S10272961962008071700000) )

Scheme 210

Scheme 210: COMPONENTS
Scheme 210: COMPONENTS

Scheme 211

Scheme 211: REMOVAL
Scheme 211: REMOVAL

Scheme 212

Scheme 212
Scheme 212
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait for 90 seconds after disconnecting the cable to prevent airbag deployment (See «PRECAUTION»(ref-290707-S36769722372008071700000) ). NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-290683-S20539755842008071700000) ).
  2. REMOVE LOWER NO. 3 STEERING WHEEL COVER (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  3. REMOVE LOWER NO. 2 STEERING WHEEL COVER (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  4. REMOVE STEERING PAD (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  5. REMOVE STEERING PAD SWITCH ASSEMBLY Disconnect the pad switch connector from the spiral cable. Remove the screw. Disengage the 2 pins and remove the steering pad switch. Remove the screw. Disengage the 2 pins and remove the steering pad switch assembly.

Scheme 213

Scheme 213: INSPECTION
Scheme 213: INSPECTION
  1. INSPECT STEERING PAD SWITCH Disconnect the steering pad switch assembly connector. Measure the resistance according to the values in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION TABLE Tester connection Condition Specified condition AU1-EAU No switch is pushed Approx. 100 kohms AU1-EAU SEEK+ switch: push 0 to 2.5 ohms AU1-EAU SEEK- switch: push Approx. 0.3 kohms AU1-EAU VOL+ switch: push Approx. 1 kohms AU1-EAU VOL- switch: push Approx. 3.1 kohms AU2-EAU No switch is pushed Approx. 100 kohms AU2-EAU MODE switch: push 0 to 2.5 ohms AU2-EAU VOICE switch: push ( (1) ) Approx. 3.1 kohms AU2-EAU ON HOOK switch: push ( (2) ) Approx. 0.3 kohms AU2-EAU OFF HOOK switch: push ( (2) ) Approx. 1 kohms (1) w/ Navigation System (2) for Premium models If the result is not as specified, replace the steering pad switch.
  1. INSTALL STEERING PAD SWITCH ASSEMBLY Engage the 2 pins and install the steering pad switch. Install the screw. Torque: 2.4 N*m (24 kgf*cm, 21 in.*lbf) Engage the 2 pins and install the steering pad switch assembly. Install the screw. Torque: 2.4 N*m (24 kgf*cm, 21 in.*lbf) Connect the pad switch connector to the spiral cable.
  2. INSTALL STEERING PAD (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  3. INSTALL LOWER NO. 3 STEERING WHEEL COVER (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  4. INSTALL LOWER NO. 2 STEERING WHEEL COVER (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-290683-S20539755842008071700000) ).
  6. INSPECT STEERING PAD (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  7. INSPECT SRS WARNING LIGHT See «DIAGNOSIS SYSTEM»(ref-290707-S27262572832008071700000)

Scheme 214

Scheme 214: COMPONENTS
Scheme 214: COMPONENTS

Scheme 215

Scheme 215: REMOVAL
Scheme 215: REMOVAL
  1. REMOVE ROOF CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-290712-S25593620862008071700000) )
  2. REMOVE TELEPHONE MICROPHONE ASSEMBLY Disengage the clamp. Disengage the 2 claws and remove the telephone microphone assembly.
  1. INSTALL TELEPHONE MICROPHONE ASSEMBLY Engage the 2 claws and install the telephone microphone assembly. Engage the clamp.
  2. INSTALL ROOF CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-290712-S17697766732008071700000) )

Scheme 216

Scheme 216: ON-VEHICLE INSPECTION
Scheme 216: ON-VEHICLE INSPECTION
  1. INSPECT WINDOW GLASS ANTENNA WIRE Check for continuity of the antenna. HINT: Check for continuity at the center of each antenna wire as shown below. NOTE: When cleaning the glass, wipe it in the direction of the wire with a soft, dry cloth. Take care not to damage the wire. Do not use detergents or glass cleaners with abrasive ingredients. When measuring resistance, wrap a piece of tin foil around the tip of the negative probe and press the foil against the wire with your finger as shown below. OK: There is continuity in the antenna. If the result is not as specified, repair the window glass antenna wire.

Scheme 217

Scheme 217: REPAIR
Scheme 217: REPAIR

Scheme 218

Scheme 218
Scheme 218
  1. REPAIR WINDOW GLASS ANTENNA WIRE Clean the broken wire tips with a grease, wax and silicone remover. Place masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent (Dupont paste No. 4817 or equivalent). Using a fine tip brush, apply a small amount of the repair agent to the wire. After a few minutes, remove the masking tape.
