Steering Column (Except Hybrid): Removal & Installation Toyota Highlander II

Steering Column 20 illustrations ~854 words

REMOVAL

CAUTIONSome of these service operations affect the SRS airbag system. Read the precautionary notices concerning the SRS airbag system before servicing the steering column (see PRECAUTION ).

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. PRECAUTION HINT: (See «PRECAUTION»(ref-290696-S07634562542008071700000) )
  2. POSITION FRONT WHEELS STRAIGHT AHEAD
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-290683-S20539755842008071700000) ).
  4. REMOVE FRONT WHEEL LH
  5. REMOVE LOWER NO. 3 STEERING WHEEL COVER (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  6. REMOVE LOWER NO. 2 STEERING WHEEL COVER (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  7. REMOVE STEERING PAD (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  8. REMOVE STEERING WHEEL ASSEMBLY (See «REMOVAL»(ref-290696-S08829907222008071700000) )
  9. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-290712-S25593620862008071700000) )
  10. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH (See «REMOVAL»(ref-290712-S25593620862008071700000) )
  11. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY (for Manual Air Conditioning System) (See «REMOVAL»(ref-290705-S36017302052008071700000) )
  12. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY (for Automatic Air Conditioning System) (See «REMOVAL»(ref-290705-S36017302052008071700000) )
  13. REMOVE DRIVER SIDE KNEE AIRBAG ASSEMBLY (See «REMOVAL»(ref-290707-S11697442302008071700000) )
  14. REMOVE BRAKE PEDAL RETURN SPRING (See «REMOVAL»(ref-290699-S25361406682008071700000) )
  15. REMOVE STOP LIGHT SWITCH ASSEMBLY (See «REMOVAL»(ref-290703-S18750515772008071700000) )
  16. SEPARATE BRAKE MASTER CYLINDER PUSH ROD CLEVIS (See «REMOVAL»(ref-290699-S25361406682008071700000) )
  17. REMOVE BRAKE PEDAL SUPPORT SUB-ASSEMBLY (See «REMOVAL»(ref-290699-S25361406682008071700000) )
  18. REMOVE STEERING COLUMN COVER Remove the 2 screws. Disengage the 2 claws to remove the lower steering column cover. Disengage the claw to remove the upper steering column cover.
  19. REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY Disconnect the connectors from the turn signal switch assembly with spiral cable sub-assembly. Using pliers, grip the claws of the clip and remove the turn signal switch assembly with spiral cable sub-assembly.
  20. REMOVE NO. 1 AIR DUCT SUB-ASSEMBLY Disengage the 2 claws and remove the No. 1 air duct sub-assembly.
  21. SEPARATE STEERING INTERMEDIATE SHAFT SUB-ASSEMBLY Loosen the bolt. Remove the bolt and slide the steering intermediate shaft sub-assembly. NOTE: Do not separate the steering intermediate shaft sub-assembly from the power steering link assembly. Put matchmarks on the steering intermediate shaft sub-assembly and the power steering link assembly. Separate the steering intermediate shaft sub-assembly from the power steering link assembly.
  22. REMOVE STEERING COLUMN ASSEMBLY Disconnect the connector from the power steering ECU assembly. HINT: As shown below, turn the lock lever to disconnect the connector. Disconnect the connector from the power steering ECU assembly. Disconnect the connectors and disengage the wire harness clamps from the steering column assembly. Remove the bolt, 2 nuts, and the steering column assembly.
  23. REMOVE STEERING INTERMEDIATE SHAFT SUB-ASSEMBLY Remove the bolt. Put matchmarks on the steering intermediate shaft sub-assembly and the steering column assembly. Remove the steering intermediate shaft sub-assembly from the steering column assembly.
CAUTIONSome of these service operations affect the SRS airbag system. Read the precautionary notices concerning the SRS airbag system before servicing the steering wheel (see PRECAUTION ).

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. POSITION FRONT WHEELS STRAIGHT AHEAD
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-290683-S20539755842008071700000) ).
  3. REMOVE LOWER NO. 3 STEERING WHEEL COVER (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  4. REMOVE LOWER NO. 2 STEERING WHEEL COVER (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  5. REMOVE STEERING PAD (See «REMOVAL»(ref-290707-S07943027742008071700000) )
  6. REMOVE STEERING WHEEL ASSEMBLY Remove the steering wheel assembly set nut. Put matchmarks on the steering wheel assembly and the steering main shaft. Disconnect the connectors from the spiral cable. Using SST, remove the steering wheel assembly. SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021) NOTE: Apply a small amount of grease to the threads and tip of SST (09953-05020) before use.

Scheme 43

Scheme 43: DISASSEMBLY
Scheme 43: DISASSEMBLY

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47
  1. REMOVE CRUISE CONTROL MAIN SWITCH (See «REMOVAL»(ref-290715-S16216082262008071700000) )
  2. REMOVE STEERING PAD SWITCH ASSEMBLY (w/ Steering Pad Switch) (See «REMOVAL»(ref-290716-S24923424592008071700000) )
  3. REMOVE NO. 2 STEERING WHEEL ORNAMENT (w/o Steering Pad Switch) Remove the screw. Disengage the 2 pins to remove the No. 2 steering wheel ornament from the steering wheel spoke sub-assembly.
  4. REMOVE NO. 1 STEERING WHEEL ORNAMENT (w/o Steering Pad Switch) HINT: Perform the same procedure as for the No. 2 steering wheel ornament.
  5. REMOVE LOWER STEERING WHEEL BOSS COVER Remove the 2 screws. Disengage the 4 claws to remove the lower steering wheel boss cover from the steering wheel spoke sub-assembly.
  6. REMOVE STEERING PAD ATTACHING SCREW Remove the 2 steering pad attaching screws from the lower steering wheel boss cover.

INSTALLATION

  1. POSITION FRONT WHEELS STRAIGHT AHEAD
  2. ADJUST SPIRAL CABLE (See «INSTALLATION»(ref-290707-S13983356112008071700000) )
  3. INSTALL STEERING WHEEL ASSEMBLY Align the matchmarks on the steering wheel assembly and steering main shaft. Install the steering wheel assembly set nut. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf) Connect the connectors to the spiral cable sub-assembly.
  4. INSTALL STEERING PAD (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  5. INSTALL LOWER NO. 3 STEERING WHEEL COVER (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  6. INSTALL LOWER NO. 2 STEERING WHEEL COVER (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  7. INSPECT STEERING WHEEL CENTER POINT
  8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-290683-S20539755842008071700000) ).
  9. INSPECT STEERING PAD (See «INSTALLATION»(ref-290707-S42253112992008071700000) )
  10. INSPECT SRS WARNING LIGHT HINT: See «DIAGNOSIS SYSTEM»(ref-290707-S27262572832008071700000) .
