Windows / Glass (Service Information): Overview Toyota Corolla XI

Scheme 15

Scheme 16

1. REMOVE FRONT ARMREST ASSEMBLY LH Refer to «PROCEDURE - Step 4»(ref-635639-S06621207882014070300000)
2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 5»(ref-635639-S06621207882014070300000)
3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Remove the 3 screws. Disengage the 4 claws and remove the power window regulator master switch assembly.

Scheme 17

Scheme 18

1. INSPECT POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY *a Component without harness connected (Power Window Regulator Master Switch Assembly) Check the switch function. Turn the window lock switch off and operate the switches on the power window regulator master switch assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance DRIVER SIDE SWITCH Tester Connection Condition Specified Condition 4 (A) - 1 (E) Auto up Below 1 ohms 8 (U) - 1 (E) Auto up Below 1 ohms 5 (D) - 6 (B) Auto up Below 1 ohms 8 (U) - 1 (E) Manual up Below 1 ohms 5 (D) - 6 (B) Manual up Below 1 ohms 8 (U) - 5 (D) Off Below 1 ohms 8 (U) - 6 (B) Off Below 1 ohms 5 (D) - 1 (E) Manual down Below 1 ohms 8 (U) - 6 (B) Manual down Below 1 ohms 4 (A) - 1 (E) Auto down Below 1 ohms 5 (D) - 1 (E) Auto down Below 1 ohms 8 (U) - 6 (B) Auto down Below 1 ohms Standard Resistance FRONT PASSENGER SIDE SWITCH Tester Connection Condition Specified Condition 6 (B) - 16 (U) Up Below 1 ohms 1 (E) - 15 (D) Up Below 1 ohms 1 (E) - 16 (U) Off Below 1 ohms 1 (E) - 15 (D) Off Below 1 ohms 1 (E) - 16 (U) Down Below 1 ohms 6 (B) - 15 (D) Down Below 1 ohms Standard Resistance REAR LH SIDE SWITCH Tester Connection Condition Specified Condition 6 (B) - 12 (U) Up Below 1 ohms 1 (E) - 13 (D) Up Below 1 ohms 1 (E) - 13 (D) Off Below 1 ohms 1 (E) - 12 (U) Off Below 1 ohms 6 (B) - 13 (D) Down Below 1 ohms 1 (E) - 12 (U) Down Below 1 ohms Standard Resistance REAR RH SIDE SWITCH Tester Connection Condition Specified Condition 6 (B) - 10 (U) Up Below 1 ohms 1 (E) - 18 (D) Up Below 1 ohms 1 (E) - 18 (D) Off Below 1 ohms 1 (E) - 10 (U) Off Below 1 ohms 6 (B) - 18 (D) Down Below 1 ohms 1 (E) - 10 (U) Down Below 1 ohms If the result is not as specified, replace the power window regulator master switch assembly. Check that the LEDs illuminate. *a Component without harness connected (Power Window Regulator Master Switch Assembly) Apply battery voltage to the power window regulator master switch assembly and check that the LEDs illuminate. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (LED) Battery negative (-) --> Terminal 1 (E) LEDs illuminate If the result is not as specified, replace the power window regulator master switch assembly.
