Engine Controls (2ZZ-GE) - Diagnostics: Wiring Toyota Celica T230 рестайлинг

WIRING DIAGRAM

Refer to DTCs P0010 on DTC P0010 CAMSHAFT POSITION "A" Actuator circuit (Bank 1) .

Refer to DTC P0335 on DTC P0335 Crankshaft Position Sensor "A" Circuit Malfunction : DTC P0339 Crankshaft Position Sensor "A" Circuit Intermittent .

Refer to DTC P0130 on DTC P0130 Oxygen Sensor Circuit (Bank 1 Sensor 1) : DTC P2195 Oxygen Sensor Signal Stuck Lean (Bank 1 Sensor 1) : DTC P2196 Oxygen Sensor Signal Stuck Rich (Bank 1 Sensor 1) .

Refer to DTC P0100 on DTC P0100 Mass or Volume Air Flow Circuit : DTC P0102 Mass or Volume Air Flow Circuit Low Input: DTC P0103 Mass or Volume Air Flow Circuit High Input .

Refer to DTC P0130 on DTC P0130 Oxygen Sensor Circuit (Bank 1 Sensor 1) : DTC P2195 Oxygen Sensor Signal Stuck Lean (Bank 1 Sensor 1) : DTC P2196 Oxygen Sensor Signal Stuck Rich (Bank 1 Sensor 1) .

Refer to DTC P0130 on DTC P0130 Oxygen Sensor Circuit (Bank 1 Sensor 1) : DTC P2195 Oxygen Sensor Signal Stuck Lean (Bank 1 Sensor 1) : DTC P2196 Oxygen Sensor Signal Stuck Rich (Bank 1 Sensor 1) .

Refer to DTC P0130 on DTC P0130 Oxygen Sensor Circuit (Bank 1 Sensor 1) : DTC P2195 Oxygen Sensor Signal Stuck Lean (Bank 1 Sensor 1) : DTC P2196 Oxygen Sensor Signal Stuck Rich (Bank 1 Sensor 1) .

Scheme 636

1. Connect the hand-held tester to the DLC3.
2. Switch the hand-held tester from the normal mode to the check mode (See «PRE-CHECK»(ref-206112-S06872093152005112400000) ).
3. Start the engine and let it idle for 60 seconds or more.
4. Drive the vehicle at 25 mph (40 km/h) or more for 40 seconds or more.
5. Let the engine idle for 10 seconds or more.
6. Perform steps (d) and (e) 12 times.

HINT

If a malfunction exists, the MIL will be illuminated on the multi information display during step (f).

Note. If the conditions in this test are not strictly followed, detection of a malfunction will not occur. If you do not have a hand-held tester, turn the ignition switch OFF after performing steps from (c) to (f), then perform steps from (c) to (f) again.

Refer to DTC P0130 on DTC P0130 Oxygen Sensor Circuit (Bank 1 Sensor 1) : DTC P2195 Oxygen Sensor Signal Stuck Lean (Bank 1 Sensor 1) : DTC P2196 Oxygen Sensor Signal Stuck Rich (Bank 1 Sensor 1) .

Refer to DTC P0351 on DTC P0351 Igniter Coil "A" Primary/Secondary Circuit, DTC P0352 Igniter Coil "B" Primary/Secondary Circuit, DTC P0353 Igniter Coil "C" Primary/Secondary Circuit, DTC P0354 Igniter Coil "D" Primary/Secondary Circuit for the wiring diagram of ignition system.

Scheme 637

Refer to DTC P0335 on DTC P0335 Crankshaft Position Sensor "A" Circuit Malfunction : DTC P0339 Crankshaft Position Sensor "A" Circuit Intermittent .

Refer to DTC P0441 on DTC P0441 Evaporative Emission Control System Incorrect Purge Flow, DTC P0446 Evaporative Emission Control System Vent Control Circuit .

Refer to DTC P2102 on DTC P2102 Throttle Actuator Control Motor Circuit Low, DTC P2103 Throttle Actuator Control Motor Circuit High .

Refer to DTC P2102 on DTC P2102 Throttle Actuator Control Motor Circuit Low, DTC P2103 Throttle Actuator Control Motor Circuit High .

Refer to DTC P2430 on DTC P2430 Secondary Air Injection System Air Flow/Pressure Sensor Circuit Bank 1, DTC P2431 Secondary Air Injection System Air Flow/Pressure Sensor Circuit Range/Performance Bank 1, DTC P2432 Secondary Air Injection System Air Flow/Pressure Sensor Circuit Low Bank 1, DTC P2433 Secondary Air Injection System Air Flow/Pressure Sensor Circuit High Bank 1 .

Refer to DTC P2430 on DTC P2430 Secondary Air Injection System Air Flow/Pressure Sensor Circuit Bank 1, DTC P2431 Secondary Air Injection System Air Flow/Pressure Sensor Circuit Range/Performance Bank 1, DTC P2432 Secondary Air Injection .

Refer to DTC P2645 on DTC P2645 OCV for VVTL Circuit (Bank 1) .

Scheme 638

Scheme 639

Scheme 640

1. Check OCV for VVTL circuit. PREPARATION: Start the engine and warm it up. Connect the hand-held tester to the DLC3. Turn the ignition switch ON and push the hand-held tester main switch ON. Enter the following menus: DIAGNOSIS / ENHANCED OBD II / ACTIVE TEST / ALL/VVTL CTRL B1. Maintain engine speed at 1,500 to 2,500 rpm. CHECK: Check the engine speed when operate the OCV for VVTL by the hand-held tester. OK: TESTER OPERATION AND SPECIFIED CONDITION Tester Operation Specified Condition VVTL CTRL B1 is OFF (OCV is OFF) Normal engine speed VVTL CTRL B1 is ON (OCV is ON) Rough engine speed or engine stalled OK: Check for intermittent problems (See «PRE-CHECK»(ref-206112-S06872093152005112400000) ). NG : Go to next step.
2. Check oil pressure switch for VVTL PREPARATION: Start the engine and warm it up. Connect the hand-held tester to the DLC3. Turn the ignition switch ON and push the hand-held tester main switch ON. Enter the following menu: DIAGNOSIS / ENHANCED OBD II / ACTIVE TEST / ALL / VVTL CTRL B1. Disconnect the oil pressure switch for VVTL connector. Maintain the engine speed at 3,500 to 4,000 rpm. CHECK: Check for continuity between the oil pressure switch and body ground when operating the OCV by handheld tester. OK: TESTER OPERATION AND SPECIFIED CONDITION Tester Operation Specified Condition VVTL CTRL B1 is OFF (OCV is OFF) No continuity VVTL CTRL B1 is ON (OCV is ON) Continuity OK : Replace oil pressure switch. NG : Go to next step.
3. Check for open and short in harness and connector between oil pressure switch for VVTL and ECM (See «HOW TO USE THE DIAGNOSTIC CHART AND INSPECTION PROCEDURE»(ref-206072-S25601918062005112300000) ). NG : Repair or replace harness or connector. OK : Replace ECM (See ENGINE CONTROL MODULE (ECM) in «SFI»(ref-206126) ).
4. Check oil control valve filter. PREPARATION: Remove the generator. (See «REMOVAL & INSTALLATION»(ref-164007-S40900360872004072000000) ) Remove the oil control valve filter. CHECK: Check the oil control valve filter. Confirm that the filter is clear. NG : Replace oil control valve filter. OK : Go to next step.
5. Check operation of OCV for VVTL. PREPARATION: Start the engine and warmed it up. CHECK: Check the engine speed at (1) and (2). Disconnect the C2 camshaft timing oil control valve connector. Apply the battery voltage between the terminals of the camshaft timing oil control valve. RESULT: OK: Engine stalled. B : Replace OCV for VVTL. A : Check for intermittent problems (See «PRE-CHECK»(ref-206112-S06872093152005112400000) ).

Scheme 641

Scheme 642

Scheme 643

1. Check oil pressure switch for VVTL. PREPARATION: Disconnect the oil pressure switch for VVTL connector. Ignition switch OFF. CHECK: Measure continuity between the oil pressure switch and body ground. OK: No continuity PREPARATION: Start the engine and warm it up. Disconnect the OCV for VVTL connector. Maintain engine speed at 6,500 rpm. CHECK: Measure continuity between the oil pressure switch and body ground when applying battery voltage between terminals of the OCV. OK: VVTL system is OFF (OCV is OFF): No continuity VVTL system is ON (OCV is ON): Continuity NG : Replace oil pressure switch. OK : Go to next step.
2. Check for open and short in harness and connector between oil pressure switch for VVTL and ECM (See «HOW TO USE THE DIAGNOSTIC CHART AND INSPECTION PROCEDURE»(ref-206072-S25601918062005112300000) ). NG : Repair or replace harness or connector. OK : Go to next step.
3. Check oil control valve filter. PREPARATION: Remove the generator. (See «REMOVAL & INSTALLATION»(ref-164007-S40900360872004072000000) ) Remove the oil control valve filter. CHECK: Check the oil control valve filter. Confirm that the filter is clear. NG : Replace oil control valve filter. OK : Go to next step.
4. Check operation of OCV for VVTL. PREPARATION: Start the engine and warm it up. CHECK: Check the engine speed at (1) and (2). Disconnect the C2 camshaft timing oil control valve connector. Apply battery voltage between the terminals of the OCV. RESULT: OK: Engine stalled. B : Replace OCV for VVTL. A : Check for intermittent problems (See «PRE-CHECK»(ref-206112-S06872093152005112400000) ).
