MONITOR DESCRIPTION
After the ECM sends the "target" duty-cycle signal to the OCV (Oil Control Valve), the ECM monitors the OCV current to establish an "actual" duty-cycle. When the actual duty-cycle ratio varies from the forget duty-cycle ratio, the ECM sets a DTC.
Scheme 1
Scheme 2
The ECM optimizes the valve timing using the VVT (Variable Valve Timing) system to control the intake valve camshaft. The VVT system includes the ECM, the OCV (Oil Control Valve) and the VVT controller. The ECM sends a target "duty-cycle" control signal to the OCV. This control signal, applied to the OCV, regulates the oil pressure supplied to the VVT controller. The VVT controller can advance or retard the intake valve camshaft.
Example
A DTC will set if: 1) the difference between the target and actual valve timing is more than 5 degrees of the crankshaft angle (CA) and the condition continues for more than 5 sec.; or 2) the OCV is forcibly activated 63 times or more.
Advanced cam DTCs are subject to "1 trip" detection logic.
Retarded cam DTCs are subject to "2 trip" detection logic.
Scheme 3
Scheme 4
The ECM optimizes the valve timing using the VVT (Variable Valve Timing) system to control the intake valve camshaft. The VVT system includes the ECM, the OCV (Oil Control Valve) and the VVT controller. The ECM sends a target duty-cycle control signal to the OCV. This control signal, applied to the OCV, regulates the oil pressure supplied to the VVT controller. The VVT controller can advance or retard the intake valve camshaft. The ECM calibrates the valve timing of the VVT system by setting the camshaft to the maximum retard angle when the engine speed is idling. The ECM closes the OCV to retard the cam. The ECM stores this value as VVT learned value (When the difference between the target valve timing and the actual valve timing is 5 degrees or less, the ECM stores this in its memory).
If the learned value meets both of the following conditions ((a) and (b)), the ECM interprets this as a defect in the VVT system and set a DTC.
- VVT learning value is less than 24°CA (crankshaft angle) or more than 46°CA.
- Above condition continues for more than 18 sec.
Scheme 5
Scheme 6
The sending portion of the heated oxygen sensor has a zirconia element which is used to detect oxygen concentration in the exhaust. If the zirconia element is at the proper temperature and difference of the oxygen concentration between the inside and outside surface of sensor is large, the zirconia element will generate voltage signals. In order to increase the oxygen concentration detecting capacity in the zirconia element, the ECM supplements the heat from the exhaust with heat from a heating element inside the sensor. When current in the sensor is out of the standard operating range, the ECM interprets this as a fault in the heated oxygen sensor and sets a DTC.
Example
The ECM will set a high current DTC if the current in the sensor is more than 2 A when the heater is OFF. Similarly, the ECM will set a low current DTC if the current is less than 0.25 A when the heater is ON.
Scheme 7
Scheme 8
Scheme 9
Scheme 10
If there is a defect in the MAF (Mass Air Flow) meter or an open or short circuit, the voltage level will deviate outside the normal operating range. The ECM interprets this deviation as a defect in the MAF meter and sets a DTC.
Example
When the MAF meter voltage output is less than 0.2 V, or more than 4.9 V, and if either the condition continues for more than 3 sec.
Scheme 11
The MAF (Mass Air Flow) meter helps the ECM calculate the amount of air flowing through the throttle valve. The ECM uses this information to determine the fuel injection time and provide a proper air fuel ratio. Inside the MAF meter, there is a heated platinum wire exposed to the flow of intake air. By applying a specific current to the wire, the ECM heats this wire to a given temperature. The flow of incoming air cools the wire and an internal thermistor, affecting their resistance. To maintain a constant current value, the ECM varies the voltage applied to these components in the MAF meter. The voltage level is proportional to the air flow through the MAF meter. The ECM interprets this voltage as the intake air amount. If there is a defect in the MAF meter or an open or short circuit, the voltage level will deviate outside the normal operating range. The ECM interprets this deviation as a defect in the MAF meter and sets a DTC.
Example
If the voltage is more than 2.2 V at idle or less than 0.4 V at idle OFF, the ECM interprets this as a defect in the MAF meter and sets a DTC.
Scheme 12
Scheme 13
The ECM monitors the sensor voltage and uses this value to calculate the intake air temperature. When the sensor output voltage deviates from the normal operating range, the ECM interprets this as a fault in the IAT (Intake Air Temperature) sensor and sets a DTC.
Example
When the sensor voltage output equal to -40°C (-40°F), or more than 140°C (284°F).
Scheme 14
The ECT (Engine Coolant Temperature) sensor is used to monitor the engine coolant temperature. The ECT sensor has a thermistor that varies its resistance depending on the temperature of the engine coolant. When the coolant temperature is low, the resistance in the thermistor increases. When the temperature is high, the resistance drops. The variations in resistance are reflected in the voltage output from the sensor.
The ECM monitors the sensor voltage and uses this value to calculate the engine coolant temperature.
When the sensor output voltage deviates from the normal operating range, the ECM interprets this as a fault in the ECT sensor and sets a DTC.
Example
When the ECM calculates that the ECT is less than -40°C (-40°F), or more than 140°C (284°F), and if either condition continues for 0.5. sec. or more, the ECM will set a DTC.
Scheme 15
The ECT (Engine Coolant Temperature) sensor is used to monitor the engine coolant temperature. The ECT sensor has a thermistor that varies its resistance depending on the temperature of the engine coolant. When the coolant temperature is low, the resistance in the thermistor increases. When the temperature is high, the resistance drops. The variations in resistance are reflected in the voltage output from the sensor. The ECM monitors the sensor voltage and uses this value to calculate the engine coolant temperature. When the sensor output voltage deviates from the normal operating range, the ECM interprets this as a fault in the ECT sensor and sets a DTC.
Examples
- Upon starting the engine, the ECT is between 35°C (95°F) and 60°C (140°F). If after driving for 250 sec., the ECT still remains within 3°C (5.4°F) of the starting temperature, a DTC will be set (2 trip detection logic).
- Upon starting the engine, the ECT is over 60°C (140°F). If after driving for 250 sec., the ECT still remains within 1°C (1.8°F) of the starting temperature, a DTC will be set (6 trip detection logic).
Scheme 16
Scheme 17
Scheme 18
The throttle position sensor varies its resistance with the angle of the throttle valve. The ECM applies a regulated reference voltage to the throttle position sensor positive terminal and calculates the angle of the throttle valve based on the current voltage at the throttle position sensor "signal" terminal.
When the throttle valve is near the fully closed position, the output voltage of the throttle position sensor is low. When it is near the fully open position, the output voltage is high.
If the ECM detects that the output voltage of the throttle position sensor is out of the normal range, the ECM interprets this as a malfunction in the throttle position sensor and sets a DTC.
Scheme 19
The throttle position sensor varies its resistance with the angle of the throttle valve. The ECM applies a regulated reference voltage to the throttle position sensor positive terminal and calculates the angle of the throttle valve based on the current voltage at the throttle position sensor "signal" terminal.
When the throttle valve is near the fully closed position, the output voltage of the throttle position sensor is low. When it is near the fully open position, the output voltage is high.
The ECM checks the indicated angle of the throttle valve during "stop and go" conditions. If the indicated angle (or voltage) in the "closed throttle" position is out of the specified range 8 times or more, the ECM interprets this as a malfunction in the throttle position sensor and sets a DTC.
Scheme 20
Scheme 21
The ECT (Engine Coolant Temperature) sensor is used to monitor the temperature of the engine coolant.
The resistance of the sensor varies with the actual coolant temperature. The ECM applies a voltage to the sensor and the varying resistance of the sensor causes the signal voltage to vary. The ECM monitors the ECT signal voltage after engine start-up. If, after sufficient time has passed, the sensor still reports that the engine is not warmed up enough for closed-loop fuel control, the ECM interprets this as a fault in the sensor or cooling system and sets a DTC.
Example
The engine coolant temperature is 0°C (32°F) at engine start. After 5 min. running time, the ECT sensor still indicates that the engine is not warmed up enough to begin air fuel ratio feedback control of the air-fuel ratio.
The ECM interprets this as a fault in the sensor or cooling system and will set a DTC.
Scheme 22
Scheme 23
Scheme 24
The ECM uses the heated oxygen sensor to optimize the air-fuel mixture in closed-loop fuel control. This control helps decrease exhaust emissions by providing the catalyst with a nearly stoichiometric mixture.
The sensor detects the oxygen level in the exhaust gas and the ECM uses this data to control the air-fuel ratio. The sensor output voltage ranges from 0 V to 1 V. If the signal voltage is less than 0.4 V, the air-fuel ratio is LEAN. If the signal voltage is more than 0.55 V, the air-fuel ratio is RICH. If the conditions for the closed-loop fuel control are met and after a specified time-period, the sensor's output signal never indicates RICH, the ECM will conclude that the closed-loop fuel control is malfunctioning. The ECM will illuminate the MIL and a DTC is set.
Scheme 25
Scheme 26
The heated oxygen sensor generates waveform of a voltage between 0 V and 1 V in response to the oxygen concentration in the exhaust gas. When the output voltage of the heated oxygen sensor is 0.5 V or more, the ECM judges that the air-fuel ratio is RICH. When it is 0.4 V or less, the ECM judges that the air-fuel ratio is LEAN.
If the rear heated oxygen sensor output does not change between RICH and LEAN during "Stop and Go" driving, the ECM interprets this as a malfunction in the rear heated oxygen sensor and sets a DTC. Also, if the rear heated oxygen sensor output remains at less than 0.05 V for more than 114 sec. when ECM monitored the heated oxygen sensor for 190 sec. while the air-fuel feed back is being performed (The detecting condition differs depending on the type of vehicles), the ECM will interpret this as a fault. In either case, the ECM will turn on the MIL and set a DTC.
Scheme 27
Scheme 28
Scheme 29
The knock sensor located on the cylinder block, detects spark knock.
When spark knock occurs, the sensor pick-up vibrates in a specific frequency range. When the ECM detects the voltage in this frequency range, it retards the ignition timing to suppress the spark knock.
The ECM also senses background engine noise with the knock sensor and uses this noise to check for faults in the sensor. If the knock sensor signal level is too low for more than 10 sec., and if the knock sensor output voltage is out of normal range, the ECM interprets this as a fault in the knock sensor and sets a DTC.
Scheme 30
Scheme 31
If there is no signal from the crankshaft sensor even though the engine is revolving, the ECM interprets this as a malfunction of the sensor.
Scheme 32
Scheme 33
If there is no signal from the camshaft position sensor even though the engine is turning, or if the rotation of the camshaft and the crankshaft is not synchronized, the ECM interprets this as a malfunction of the sensor.
Scheme 34
Scheme 35
Scheme 36
The vehicle is equipped with two heated oxygen sensors. One is mounted upstream from the TWC (Three-Way Catalytic) converter (Front Oxygen Sensor, "sensor 1"), the second is mounted downstream (Rear Oxygen Sensor "sensor 2"). The catalyst efficiency monitor compares the sensor 1 and sensor 2 signals in order to calculate TWC ability to store the oxygen.
During normal operation, the TWC stores and releases oxygen as needed. This results in low oxygen variations in the post TWC exhaust stream as shown below.
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
The evaporative emission system consists of the vapor pressure sensor, the CCV (Canister Close Valve), the pressure switching valve and the EVAP VSV (Purge VSV), those are used to detect malfunction in the system by ECM.
This test will run once per driving cycle provided the ECM when detects stable vapor pressure in the fuel tank. While the vehicle is being driven on rough or winding roads, the movement of the fuel in the tank will cause unstable fuel tank vapor pressure and the diagnostic test will not executed.
The ECM performs the following steps
- The CCV is closed, (shutting the system)
- The fuel tank pressure stability is checked. The diagnostic is disabled if the pressure change is more than specified value.
- The EVAP VSV is opened. This introduces a negative pressure from the intake manifold to the fuel tank.
- The EVAP VSV is closed and the negative pressure is sealed in the fuel tank.
- The ECM monitors the increase in fuel tank pressure for; Rapid increase in the internal pressure, i. e. a large leak: 0.040" or more A pressure rise just above normal, i. e. a small leak: 0.020". If the ECM detects either of above conditions, it will interpret this as a leak in the EVAP system. The ECM will illuminate the MIL (2 trip detection logic) and set a DTC.
Scheme 42
Scheme 43
Scheme 44
Scheme 45
DTC P0451 is recorded by the ECM when the vapor pressure sensor malfunctions.
The ECM sensor pressure in the fuel tank using the vapor pressure sensor. The ECM supplies the sensor with a regulated 5 V reference voltage and the sensor returns a signal voltage between 0.5 V and 4.5 V according to the pressure level in the fuel tank.
When the pressure in the fuel tank is low, the output voltage of the vapor pressure sensor is low. When it is high, the output voltage is high.
For this DTC P0451, the ECM checks for a "noisy" sensor or a "stuck" sensor.
The ECM checks for a "noisy" sensor by monitoring the fuel tank pressures when the vehicle is stationary and there should be little variation in the tank pressure. If the indicated pressure varies beyond specified limits, the ECM will illuminate the MIL (2-trip detection logic) and a DTC is set.
The ECM checks for a "stuck" sensor by monitoring the fuel tank pressure for an extended time period. If the indicated pressure does not change over this period, the ECM will conclude that the fuel tank pressure sensor is malfunctioning, The ECM will illuminate the MIL and a DTC is set.
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
The ECM assumes that the vehicle is driven when the over 30 sec. have passed since the park/neutral position switch was turned OFF. If there is no signal from the vehicle speed sensor with these conditions satisfied, the ECM concludes that the vehicle speed sensor is malfunctioning. The ECM will turn on the MIL and a DTC is set.
Scheme 51
Scheme 52
The battery supplies electricity to the ECM even when the ignition switch is OFF. This electricity allows the ECM store data such as DTC history, freeze frame data, fuel trim values, and other data.
If the battery voltage falls below a minimum level, the ECM will conclude that there is a fault in the power supply circuit. The next time the engine starts, the ECM will turn on the MIL and a DTC will be set.
Scheme 53
HINT
If DTC P0560 present, the ECM will not store another DTC.
Scheme 54
Scheme 55
While the engine is being cranked, the battery positive voltage is applied to terminal STA of the ECM If the vehicle is being driven and the ECM detects the starter control signal (STA), the ECM concludes that the starter control circuit is malfunctioning. The ECM will turn on the MIL and a DTC is set.
Scheme 56
Scheme 57
Scheme 58
