DRIVE BELT ADJUSTMENT (4-CYL)
| Application (1) | New Belt | (2) Used Belt |
|---|
| ECHO |
| A/C, W/P & Generator | 121-143 (55-65) | 55-88 (25-40) |
| Power Steering | 100-121 (45-55) | 55-77 (25-35) |
| Prius (3) |
| A/C | 99-121 (44-55) | 57-77 (26-35) |
| Water Pump | 99-121 (44-55) | 57-77 (26-35) |
| Tacoma |
| A/C | 135-185 (61-84) | 80-120 (36-54) |
| Generator | 116-169 (53-77) | 95-135 (43-61) |
| Power Steering | 135-180 (61-82) | 85-120 (39-54) |
| (1) Models not listed use an automatic belt tensioner. Adjustment is not required. (2) Used belt is a belt in operation at least 5 minutes. (3) Read service precautions before proceeding with service procedure. See SERVICE PRECAUTIONS . |
| (1) | Models not listed use an automatic belt tensioner. Adjustment is not required. |
| (2) | Used belt is a belt in operation at least 5 minutes. |
| (3) | Read service precautions before proceeding with service procedure. See SERVICE PRECAUTIONS . |
BELT ADJUSTMENT - TENSION IN LBS. (KG) USING BELT TENSION GAUGE (4-CYL)
DRIVE BELT ADJUSTMENT (V6)
| Application (1) | New Belt | (2) Used Belt |
|---|
| Avalon |
| A/C & Generator | 143-187 (65-85) | 66-110 (30-50) |
| Power Steering | 120-185 (54-84) | 95-135 (43-61) |
| Camry & Camry Solara |
| A/C & Generator | 120-185 (54-84) | 95-135 (43-61) |
| Power Steering | 120-185 (54-84) | 95-135 (43-61) |
| Highlander |
| A/C | 135-180 (61-82) | 66-100 (30-45) |
| Sienna |
| Generator | 135-185 (61-84) | 66-100 (30-45) |
| Power Steering | 135-154 (61-70) | 55-88 (25-40) |
| Tacoma |
| A/C | 135-185 (61-84) | 80-120 (36-54) |
| Generator | 140-180 (64-82) | 80-120 (36-54) |
| Power Steering | 135-180 (61-82) | 85-120 (39-54) |
| Tundra |
| A/C | 135-185 (61-84) | 80-120 (36-54) |
| Generator | 135-185 (61-84) | 80-120 (36-54) |
| Power Steering | 135-180 (61-82) | 85-120 (39-54) |
| (1) Models not listed use an automatic belt tensioner. Adjustment is not required. (2) Used belt is a belt in operation at least 5 minutes. |
| (1) | Models not listed use an automatic belt tensioner. Adjustment is not required. |
| (2) | Used belt is a belt in operation at least 5 minutes. |
BELT ADJUSTMENT - TENSION IN LBS. (KG) USING BELT TENSION GAUGE (V6)
DRIVE BELT ADJUSTMENT (V8)
| Application | New Belt | (1) Used Belt |
|---|
| Land Cruiser, Sequoia, Tundra & 4Runner |
| Drive Belt | (2) | (2) |
| (1) Used belt is a belt in operation at least 5 minutes. (2) Automatic belt tensioner is used. Adjustment is not required. Belt must be replaced if arrow mark on automatic belt tensioner is not within area "A". (Scheme 1) |
| (1) | Used belt is a belt in operation at least 5 minutes. |
| (2) | Automatic belt tensioner is used. Adjustment is not required. Belt must be replaced if arrow mark on automatic belt tensioner is not within area "A". (Scheme 1) |
BELT ADJUSTMENT - TENSION IN LBS. (KG) USING BELT TENSION GAUGE (V8)
Scheme 1
