A/c-Heater System - Automatic: Diagnosis Toyota 4Runner III

Automatic HVAC System 1 illustration ~153 words

SELF-DIAGNOSTICS

A/C-heater control assembly monitors system circuits and stores a code in memory if a problem is detected. All codes are stored in memory. To retrieve stored codes, see RETRIEVING DIAGNOSTIC TROUBLE CODES. Codes are displayed at A/C-heater control assembly temperature display. see scheme 2

TESTING

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG SYSTEM SAFETY article in GENERAL SERVICING.

Air Outlet Servomotor Functional Test

  1. Remove air outlet servomotor. Unplug air outlet servomotor connector. Connect air outlet servomotor terminal No. 2 (Black/Yellow wire) to battery voltage. (Scheme 4) Connect terminal No. 1 (White/Black wire) to ground. Air outlet servomotor lever should move to specified position when the appropriate terminal is grounded. See «AIR OUTLET SERVOMOTOR LEVER POSITIONS»(ref-374-S05584844292000030800000) table.
  2. Replace air outlet servomotor if it does not operate as specified. If servomotor operates correctly, inspect wiring harness and connectors between servomotor and A/C control assembly. If items are okay, substitute known-good A/C control assembly. Retest system.
Ground Terminal No.Lever Position
4Face
5Bi-Level
6Foot
7Foot/Defrost
8Defrost

AIR OUTLET SERVOMOTOR LEVER POSITIONS

Scheme 4

Scheme 4
