Specifications
| Item | Specifications | |||
|---|---|---|---|---|
| Torque converter | Type | 3-element, 1-step, 2-phase type (with TCC (lock-up) mechanism) | ||
| Stall torque ratio | 1.826 | |||
| Oil pump | Type | Vane type oil pump (non crescent type) | ||
| Drive system | Engine drive | |||
| Gear change device | Type | Forward continuously variable, reverse 1-step planetary gear type | ||
| Shift position | "P" range | Gear in neutral, output shaft fixed, engine start | ||
| "R" range | Reverse | |||
| "N" range | Gear in neutral, engine start | |||
| "D" range | Forward continuously variable gear ratio | |||
| Manual mode | UP (+) | 1 --> 2 --> 3 --> 4 --> 5 --> 6 | ||
| DOWN (-) | 6 --> 5 --> 4 --> 3 --> 2 --> 1 | |||
| Gear ratio | Forward (continuously variable) | 2.349 - 0.394 | ||
| Reverse (reverse gear) | 1.750 | |||
| Control elements | Steel belt and pulleys... 1 sets | |||
| Wet type multiple-disc clutch... 1 sets | ||||
| Wet type multiple-disc brake... 1 sets | ||||
| Final gear reduction ratio | 5.798 | |||
| Lubrication | Lubrication system | Force feed system by oil pump | ||
| Cooling | Cooling system | CVT fluid cooler (air-cooled) Radiator assisted cooling (water-cooled) | ||
| Fluid used | SUZUKI CVT FLUID GREEN 1 or Shell GREEN-1 V | |||
| CVT fluid capacity | 8.3 liters (17.54/14.61 US/lmp pt.) | |||
ITEM SPECIFICATION
Scheme 1
Torque Converter Slip (rpm)
This parameter indicates the slip speed of the torque converter according to the difference between engine speed and the secondary pulley speed.
Torque Converter Clutch (Release/Slip/Connect)
This parameter indicates the state of the torque converter clutch according to the difference between engine speed and the secondary pulley speed.
Open: The difference between engine speed and secondly pulley speed is more than specified speed.
Conclude: The speed of engine and secondly pulley is completely corresponding.
Slip: TCC is opening or it is concluding.
Tightening Torque Specifications
Note. For fastener with * (asterisk) below, be sure to tighten it according to specified procedure in "Repair Instructions".
| Fastening part | Tightening torque | ||
|---|---|---|---|
| N.m | Kgf-m | Lbf-ft | |
| Fluid pressure check hole bolt | 7.5 | 0.76 | 5.5 |
| CVT fluid drain plug | 34 | 3.5 | 25.0 |
| Torque converter No. 1 bolt | 23 | 2.3 | 17.0 |
| Torque converter No. 2 bolt | 23 | 2.3 | 17.0 |
| Oil Strainer bolt | 7.9 | 0.81 | 6.0 |
| CVT oil pan bolt* | 7.9 | 0.81 | 6.0 |
| Valve body bolt | 7.9 | 0.81 | 6.0 |
| Manual valve lever nut | 22 | 2.2 | 16.5 |
| Oil strainer bracket bolt | 7.9 | 0.81 | 6.0 |
| Solenoid harness bolt | 7.0 | 0.71 | 5.5 |
| Transmission range sensor bolt | 5.9 | 0.60 | 4.5 |
| Manual select lever nut | 17 | 1.7 | 12.5 |
| Primary pulley speed sensor bolt | 5.9 | 0.60 | 4.5 |
| Secondary pulley speed sensor bolt | 5.9 | 0.60 | 4.5 |
| CVT fluid cooler bracket bolt No. 1 | 20 | 2.0 | 15.0 |
| CVT fluid cooler bracket bolt No. 2 | 85 | 8.7 | 63.0 |
| CVT fluid cooler bolt | 13 | 1.3 | 9.5 |
TIGHTENING TORQUE SPECIFICATIONS
Note. The specified tightening torque is described in the following.
Reference
For the tightening torque of fastener not specified in this section, refer to
- «SELECT LEVER ASSEMBLY COMPONENTS»(ref-585587-S39719190862013111200000)
- «SELECT CABLE COMPONENTS»(ref-585587-S18513163062013111200000)
- «CVT ASSEMBLY COMPONENTS»(ref-585587-S39481336622013111200000)
- «CVT FLUID COOLER COMPONENTS»(ref-585587-S01692458182013111200000)
- «FASTENERS INFORMATION»(ref-585605-S40472959762013111200000)
