Continuously Variable Transaxle (Cvt): Adjustments Suzuki Kizashi I

Select Cable Adjustment

Reference: SELECT CABLE REMOVAL AND INSTALLATION

Scheme 4

Scheme 5

1. Apply parking brake and block wheels.
2. Push engine switch to change ignition mode to "ON", shift select lever to "N" range.
3. Remove air cleaner assembly, see «AIR CLEANER ASSEMBLY REMOVAL AND INSTALLATION»(ref-585578-S10930133882013111200000) .
4. Remove console box, see «CENTER CONSOLE BOX REMOVAL AND INSTALLATION»(ref-585603-S01735880062013111200000) .
5. Remove adjuster case (cable end) from select lever pin of select lever assembly, see «SELECT CABLE COMPONENTS»(ref-585587-S18513163062013111200000) .
6. Release lock plate (1) which restricts moving of lock piece (2).
7. Pull out lock piece (2) from adjuster case (3) using pliers or the like to disengage cable.
8. Check that manual select lever is "N" range, refer to Step 4 ) of «TRANSMISSION RANGE SENSOR INSPECTION»(ref-585587-S31814284752013111200000) .
9. Apply grease to select lever pin (1), and then install adjuster case (2) into select lever pin securely. "A": Grease 99000-25011 (SUZUKI Super Grease A)
10. Push lock piece (3) in arrow direction [a] as shown in figure.
11. Slide lock plate (4) in arrow direction [b] as shown in figure, until it gets over the claw (5).
12. After installing select cable, check the following points. Perform «"P" RANGE TEST»(ref-585587-S24900184782013111200000) . Check back-up light is turned on when shifting select lever to "R" range. Check shift position indicated in information display is consistent with select lever range. Check engine starts at "P" and "N" ranges but does not start at other than "P" and "N" ranges.
13. Install air cleaner assembly, see «AIR CLEANER ASSEMBLY REMOVAL AND INSTALLATION»(ref-585578-S10930133882013111200000) .

Scheme 6

Scheme 7

Transmission Range Sensor Adjustment

Scheme 8

Scheme 9

1. Disconnect negative (-) cable at battery.
2. Remove air cleaner assembly, see «AIR CLEANER ASSEMBLY REMOVAL AND INSTALLATION»(ref-585578-S10930133882013111200000) .
3. Shift select lever to "N" position and loosen transmission range sensor bolts (1).
4. Use special tool to align aligning holes on manual select lever (2) and transmission range sensor (3) as shown in figure.
5. Tighten transmission range sensor bolts to specified torque. Special Tool 09916-44310 Tightening torque Transmission range sensor bolt (a): 5.9 N.m (0.60 kg-m, 4.5 lbf-ft)
6. Check transmission range sensor for the following points. Check engine starts at "P" and "N" ranges but does not start at other than "P" and "N" ranges. Perform «"P" RANGE TEST»(ref-585587-S24900184782013111200000) . Check back-up light is turned on when shifting select lever to "R" range. Check shift position indicated in information display is consistent with select lever range.

Scheme 10

Scheme 11

1. Disconnect negative (-) cable at battery.
2. Remove air cleaner assembly, see «AIR CLEANER ASSEMBLY REMOVAL AND INSTALLATION»(ref-585578-S10930133882013111200000) .
3. Shift manual select lever (1) to "N" position. Insert special tool to aligning hole on manual select lever (1) and check that the position of aligning hole on transmission range sensor (2) as shown in figure.
4. Remove clip of select cable and disconnect select cable from manual select lever, see «SELECT CABLE COMPONENTS»(ref-585587-S18513163062013111200000) . Special Tool 09916-44310
5. Disconnect transmission range sensor connector.
6. Remove manual select lever nut (1) and manual select lever (2).
7. Remove transmission range sensor bolts (3) and transmission range sensor (4).
