Engine Lubrication System (VQ40DE): Overview Suzuki Equator I

Scheme 27

1. After removing the bolts and nuts, separate the mating surface and remove the old liquid gasket sealing using Tool. Tool number: KV10111100 (J-37228) CAUTION: Do not damage the mating surfaces.
2. Tap (1) the Tool to insert it.
3. In areas where the Tool is difficult to use, lightly tap to slide (2) it.

Scheme 28

Scheme 29

Scheme 30

1. Remove the old liquid gasket adhering to the gasket application surface and the mating surface using suitable tool. Remove the liquid gasket completely from the groove of the liquid gasket application surface, bolts, and bolt holes.
2. Thoroughly clean the mating surfaces and remove adhering moisture, grease and foreign material.
3. Attach the liquid gasket tube to the Tool. Tool number: WS39930000 ( - ) Use Genuine RTV Silicone Sealant or equivalent. Refer to «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-375700-S13998640382010102800000) .
4. Apply the liquid gasket without breaks to the specified location with the specified dimensions. If there is a groove for the liquid gasket application, apply the liquid gasket to the groove. As for the bolt holes, normally apply the liquid gasket inside the holes. If specified in the procedure, it should also be applied outside the holes. Within five minutes of liquid gasket application, install the mating component. If the liquid gasket protrudes, wipe it off immediately. Do not retighten after the installation. Wait 30 minutes or more after installation before refilling the engine with engine oil and engine coolant.

Scheme 31

Scheme 32

Scheme 33

1. Before starting the engine make sure the vehicle is parked on a flat and level surface, then check the oil level. If the engine is already running, turn it off and allow 10 minutes before checking.
2. Pull out oil level gauge and wipe clean.
3. Insert oil level gauge.
4. Check that the oil level is within the low (L) and high (H) range as indicated on the dipstick.
5. If the engine oil level is out of range, add oil as necessary. Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-375712-S04876022172010102800000) . CAUTION: Do not overfill the engine with oil.
