Ignition System (VQ40DE): Removal & Installation Suzuki Equator I

Ignition System 1 illustration ~150 words

INSTALLATION

Installation is in the reverse order of removal.

CAUTIONDo not drop or shock the spark plug.
ApplicationUnited States and CanadaMexico
MakeNGK
Standard typeDILFR5A-11PLFR5A-11
Gap (nominal)1.1 mm (0.043 in)

Scheme 10

Scheme 10: Ignition Coil: Exploded View
Scheme 10: Ignition Coil: Exploded View

REMOVAL (LH)

  1. Remove engine room cover using power tool. Refer to [ «ENGINE ROOM COVER: REMOVAL AND INSTALLATION»(ref-375721-S37910005862010102800000) ]
  2. Remove air cleaner case and air duct and resonator assembly. Refer to [ «AIR CLEANER AND AIR DUCT: REMOVAL AND INSTALLATION»(ref-375721-S30855040562010102800000) ]
  3. Move aside harness, harness bracket, and hoses located above ignition coil.
  4. Disconnect the harness connector from ignition coil.
  5. Remove the ignition coil. CAUTION: Do not shock ignition coil.

INSTALLATION (LH)

Installation is in the reverse order of removal.

REMOVAL (RH)

  1. Remove intake manifold collector. Refer to [ «INTAKE MANIFOLD COLLECTOR: REMOVAL AND INSTALLATION»(ref-375721-S21195183772010102800000) ]
  2. Move aside harness, harness bracket, and hoses located above ignition coil.
  3. Disconnect the harness connector from ignition coil.
  4. Remove the ignition coil. CAUTION: Do not shock ignition coil.

INSTALLATION (RH)

Installation is in the reverse order of removal.
