Ignition System (QR25DE): Removal & Installation Suzuki Equator I

Ignition System 1 illustration

INSTALLATION

Installation is in the reverse order of removal.

CAUTIONDo not drop or shock the spark plug.
ApplicationUnited States and CanadaMexico
MakeNGK
Standard typeDILFR5A-11PLFR5A-11
Gap (nominal)1.1 mm (0.043 in)

Scheme 5

Scheme 5: Ignition Coil: Exploded View
Scheme 5: Ignition Coil: Exploded View

REMOVAL

  1. Remove intake manifold (except for ignition coil No. 1). Refer to «INTAKE MANIFOLD: REMOVAL AND INSTALLATION»(ref-375720-S41952777752010102800000) .
  2. Disconnect harness connector from ignition coil.
  3. Remove ignition coil. CAUTION: Do not shock ignition coil.

Installation is in the reverse order of removal.
