Starting System: Other Suzuki Aerio I

Dismounting

1. Disconnect negative (-) battery lead at battery.
2. Disconnect magnetic switch lead wire (1) and battery cable (2) from starting motor terminals.
3. Remove starting motor mount bolts (3).
4. Remove starting motor (4). Starting motor plate (5) should also come down.

Remounting

Reverse the dismounting procedure.

Tightening torque

Starting motor battery cable nut a: 11 N.m (1.1 kg-m, 8.0 lb-ft)

Starting motor mount bolt b: 23 N.m (2.3 kg-m, 17.0 lb-ft)

Scheme 8

Scheme 9

Plunger

Inspect plunger for wear. Replace if necessary.

Scheme 10

Magnetic Switch

Push in plunger and release it. The plunger should return quickly to its original position. Replace if necessary.

Scheme 11

Rear Bracket Bush

Inspect bush for wear or damage. Replace if necessary.

Scheme 12

Scheme 13

1. Check brushes for wear. Measure length of brushes and if below the limit, replace the brush. Brush length Standard: 12.3 mm (0.48 in.) Limit: 7.0 mm (0.28 in.)
2. Install brushes to each brush holder and check for smooth movement.

Spring

Inspect brush springs for wear, damage or other abnormal conditions. Replace if necessary.

Brush spring tension

Standard: 2.2 kg (4.85 lb)

Limit: 0.6 kg (1.32 lb)

Scheme 14

1. Check movement of brush in brush holder. If brush movement within brush holder is sluggish, check brush holder for distortion and sliding faces for contamination. Clean or correct as necessary.
2. Check for continuity across insulated brush holder (positive side) and grounded brush holder (negative side). If continuity exists, brush holder is grounded due to defective insulation and should be replaced.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Inspect commutator for dirt or burn. Correct with sandpaper or lathe, if necessary.
2. Check commutator for uneven wear with armature (1) supported on V-blocks (2). If deflection of dial gauge (4) pointer exceeds limit, repair or replace. NOTE: The following specification presupposes that the armature is free from bend. Bent armature must be replaced. Commutator out of round Standard: 0.05 mm (0.002 in.) or less Limit: 0.4 mm (0.015 in.)
3. Inspect the commutator for wear. If diameter is below limit, replace the armature. Commutator outside diameter Standard: 29.4 mm (1.16 in.) Limit: 28.8 mm (1.13 in.)
4. Inspect the commutator (1) for insulator (2) depth. Correct or replace if below limit. Commutator insulator depth "a" Standard: 0.4 - 0.6 mm (0.015 - 0.024 in.) Limit: 0.2 mm (0.008 in.)
5. Check the commutator and armature core. If there is continuity, the armature is grounded and must be replaced.
6. Check for continuity between segments. If there is no continuity at any test point, there is an open circuit and the armature must be replaced.

Gears

Inspect the internal gear and the planetary gears for wear, damage or other abnormal conditions. Replace if necessary.

Scheme 21

Scheme 22

Scheme 23

1. Inspect the pinion for wear, damage or other abnormal conditions. Check that clutch locks up when turned in direction of drive and rotates smoothly in reverse direction. Replace if necessary.
2. Inspect the spline teeth for wear or damage. Replace if necessary. Inspect the pinion for smooth movement.

Front Housing Bush

Inspect the bush for wear or damage. Replace if necessary.

Scheme 24
