Starting System: Diagnosis Suzuki Aerio I

Starter 6 illustrations ~337 words

Cranking System Symptom Diagnosis

Possible symptoms due to starting system trouble would be as follows

  1. Starting motor does not run (or runs slowly)
  2. Starting motor runs but fails to crank engine
  3. Abnormal noise is heard

Proper diagnosis must be made to determine exactly where the cause of each trouble lies in battery, wiring harness, (including starting motor switch), starting motor or engine.

Do not remove motor just because starting motor does not run. Check following items and narrow down scope of possible causes.

  1. Condition of trouble
  2. Tightness of battery terminals (including ground cable connection on engine side) and starting motor terminals
  3. Discharge of battery
  4. Mounting of starting motor
ConditionPossible CauseAction
Motor not running (No operating sound of magnetic switch)Clutch pedal is not depressed fully or clutch pedal position switch is maladjusted (M/T)Depress clutch pedal or adjust clutch pedal position switch .
Shift lever switch is not in P or N, or not adjusted (A/T)Shift in P or N, or adjust switch .
Battery run downRecharge battery .
Battery voltage too low due to battery deteriorationReplace battery .
Poor contact in battery terminal connectionRetighten or replace .
Loose grounding cable connectionRetighten .
Fuse set loose or blown offTighten or replace .
Poor contacting action of ignition switch and magnetic switchReplace .
Lead wire coupler loose in placeRetighten .
Open-circuit between ignition switch and magnetic switchRepair .
Open-circuit in pull-in coilReplace magnetic switch .
Brushes are seating poorly or worn downRepair or replace .
Poor sliding of plunger and/or pinionRepair .
Motor not running (Operating sound of magnetic switch heard)Battery run downRecharge battery .
Battery voltage too low due to battery deteriorationReplace battery .
Loose battery cable connectionsRetighten .
Burnt main contact point, or poor contacting action of magnetic switchReplace magnetic switch .
Brushes are seating poorly or worn downRepair or replace .
Weakened brush springReplace .
Burnt commutatorReplace armature .
Layer short-circuit of armatureReplace .
Crankshaft rotation obstructedRepair .
Starting motor running but too slow (small torque) (If battery and wiring are satisfactory, inspect starting motor)Insufficient contact of magnetic switch main contactsReplace magnetic switch .
Layer short-circuit of armatureReplace .
Disconnected, burnt or worn commutatorReplace armature .
Worn brushesReplace brush .
Weakened brush springsReplace spring .
Burnt or abnormally worn end bushReplace bush .
Starting motor running, but not cranking engineWorn pinion tipReplace over-running clutch .
Poor sliding of over-running clutchRepair .
Over-running clutch slippingReplace over-running clutch .
Worn teeth of ring gearReplace flywheel .
NoiseAbnormally worn bushReplace bush .
Worn pinion or worn teeth of ring gearReplace pinion or flywheel .
Poor sliding of pinion (failure in return movement)Repair or replace .
Worn internal or planetary gear teethReplace .
Lack of oil in each partLubricate .
Starting motor does not stop runningFused contact points of magnetic switchReplace magnetic switch .
Short-circuit between turns of magnetic switch coil (layer short-circuit)Replace magnetic switch .
Failure of returning action in ignition switchReplace .

CRANKING SYSTEM SYMPTOM DIAGNOSIS CHART

Cranking System Test

CAUTIONEach test must be performed within 3 - 5 seconds to avoid coil from burning.

Pull-in Test

Connect battery to the magnetic switch as shown.

Check that plunger and pinion move outward.

If plunger and pinion don't move, replace the magnetic switch.

Note. Before testing, disconnect lead wire from terminal M (2).

Scheme 2

Scheme 2: Pull-in Test

Hold-in Test

While connected as the figure with plunger out, disconnect negative lead from terminal "M".

Check that plunger and pinion remain out.

If plunger and pinion return inward, replace the magnetic switch.

Scheme 3

Scheme 3: Hold-in Test

Plunger and Pinion Return Test

Disconnect negative lead from starting motor body.

Check that plunger and pinion return inward.

If plunger and pinion don't return, replace the magnetic switch.

Scheme 4

Scheme 4: Plunger and Pinion Return Test

No-load Performance Test

Connect battery and ammeter to starter as shown.

Check that starter rotates smoothly and steadily with pinion moving out. Check that ammeter indicates specified current.

Specified current (No-load performance test)

90 A MAX. at 11 V

Scheme 5

Scheme 5: No-load Performance Test

Starting Motor Inspection

Reference: STARTING MOTOR DISMOUNTING AND REMOUNTING

Reference: STARTING MOTOR COMPONENTS

Pull-in coil open circuit test

Check for continuity across magnetic switch "S" terminal (1) and "M" terminal (2). If no continuity, coil is open and should be replaced.

Scheme 6

Scheme 6: Pull-in coil open circuit test

Hold-in coil open circuit test

Check for continuity across magnetic switch "S" terminal (1) and coil case. If no continuity, coil is open and should be replaced.

Scheme 7

Scheme 7: Hold-in coil open circuit test
