Abbreviations

A
ABSAnti-lock Brake System
ATDCAfter Top Dead Center
APIAmerican Petroleum Institute
ATFAutomatic Transmission Fluid
ALRAutomatic Locking Retractor
ACAlternating Current
A/TAutomatic Transmission
A/CAir Conditioning
ABDCAfter Bottom Dead Center
A/FAir Fuel Mixture Ratio
A-ELRAutomatic-Emergency Locking Retractor
AWDAll Wheel Drive
B
B+Battery Positive Voltage
BTDCBefore Top Dead Center
BBDCBefore Bottom Dead Center
BCMBody Electrical Control Module
BDCBottom Dead Center
C
CANController Area Network
CKTCircuit
CKP SensorCrankshaft Position Sensor
CMP SensorCamshaft Position Sensor
COCarbon Monoxide
CPP SwitchClutch Pedal Position Switch (Clutch Switch, Clutch Start Switch)
CPUCentral Processing Unit
CRSChild Restraint System
D
DCDirect Current
DLCData Link Connector (Assembly Line Diag. Link, ALDL, Serial Data Link, SDL)
DOHCDouble Over Head Camshaft
DOJDouble Offset Joint
DRLDaytime Running Light
DTCDiagnostic Trouble Code (Diagnostic Code)
E
EBCMElectronic Brake Control Module, ABS Control Module
EBDElectronic Brake Force Distribution
ECMEngine Control Module
ECT SensorEngine Coolant Temperature Sensor (Water Temp. Sensor, WTS)
EGRExhaust Gas Recirculation
EGRT SensorEGR Temperature Sensor (Recirculated Exhaust Gas Temp. Sensor, REGTS)
EFE HeaterEarly Fuel Evaporation Heater (Positive Temperature Coefficient, PTC Heater)
ELREmergency Locking Retractor
EPSElectronic Power Steering
EVAPEvaporative Emission
EVAP CanisterEvaporative Emission Canister (Charcoal Canister)
F
FWDFront Wheel Drive
4WD4 Wheel Drive
G
GENGenerator
GNDGround
H
HCHydrocarbons
HO2SHeated Oxygen Sensor
HVACHeating, Ventilating and Air Conditioning
I
IAC ValveIdle Air Control Valve (Idle Speed Control Solenoid Valve, ISC Solenoid Valve)
IAT SensorIntake Air Temperature Sensor (Air temperature Sensor, ATS)
ICMImmobilizer Control Module
IGIgnition
ISC ActuatorIdle Speed Control Actuator (Motor)
L
LHLeft Hand
LSPVLoad Sensing Proportioning Valve
M
MAF SensorMass Air Flow Sensor (Air Flow Sensor, AFS, Air Flow Meter, AFM)
MAP SensorManifold Absolute Pressure Sensor (Pressure Sensor, PS)
MaxMaximum
MFIMultiport Fuel Injection (Multipoint Fuel Injection)
MinMinimum
MILMalfunction Indicator Lamp ("SERVICE ENGINE SOON" Light)
M/TManual Transmission
N
NOxNitrogen Oxides
O
OBDOn-Board Diagnostic System (Self-Diagnosis Function)
OCMOccupant Classification Module
O/DOverdrive
OHCOver Head Camshaft
O2SOxygen Sensor
P
PNPPark / Neutral Position
P/SPower Steering
PSP SwitchPower Steering Pressure Switch (P/S Pressure Switch)
PCMPowertrain Control Module
PCVPositive Crankcase Ventilation
R
RHRight Hand
S
SAESociety of Automotive Engineers
SDMSensing and Diagnostic Module (Air Bag Controller, Air bag Control Module)
SFISequential Multiport Fuel Injection
SOHCSingle Over Head Camshaft
T
TBIThrottle Body Fuel Injection (Single-Point Fuel Injection, SPI)
TCCTorque Converter Clutch
TCMTransmission Control Module (A/T Controller, A/T Control Module)
TDCTop Dead Center
TP SensorThrottle Position Sensor
TVVThermal Vacuum Valve (Thermal Vacuum Switching Valve, TVSV, Bimetal Vacuum Switching Valve, BVSV)
TWCThree Way Catalytic Converter (Three Way Catalyst)
2WD2 Wheel Drive
V
VINVehicle Identification Number
VSSVehicle Speed Sensor
VVTVariable Valve Timing
W
WU-OCWarm Up Oxidation Catalytic Converter
WU-TWCWarm Up Three Way Catalytic Converter

GENERAL INFORMATION ABBREVIATIONS

Fastener Strength Identification

Most commonly used metric fastener strength property classes are 4T, 6.8, 7T, 8.8 and radial line with the class identification embossed on the head of each bolt. Some metric nuts will be marked with punch, 6 or 8 mark strength identification on the nut face.

Figure shows the different strength markings.

When replacing metric fasteners, be careful to use bolts and nuts of the same strength or greater than the original fasteners (the same number marking or higher). It is likewise important to select replacement fasteners of the correct diameter and thread pitch. Correct replacement bolts and nuts are available through the parts division.

Metric bolts: Identification class numbers or marks correspond to bolt strength (increasing numbers represent increasing strength).

Scheme 5

Scheme 5: Fastener Strength Identification

Vehicle Identification Number

The vehicle identification number is attached on the left front top of the instrument panel and punched on the front dash panel in engine room.

Scheme 6

Scheme 6: Vehicle Identification Number

Engine Identification Number

The number is punched on cylinder block.

Scheme 7

Scheme 7: Engine Identification Number

Transmission Identification Number

The automatic transmission identification number is located on transmission case.

Scheme 8

Scheme 8: Transmission Identification Number
