Automatic Transmission: Adjustments Suzuki Aerio I

Select Cable Adjustment

Reference: SELECT CABLE REMOVAL AND INSTALLATION

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Remove adjuster (cable end) from select lever pin of select lever assembly.
2. Shift manual shift lever (1) to "N" range (transmission range sensor "N" range) aligning arrow (2) of lever (1) with "N" reference line (3).
3. Release lock plate (1) which restricts moving of cable end holder (2).
4. Push cable end holder (1) out from eye-end (2) using an appropriate tool (3) to disengage cable.
5. Shift select lever to "N" position.
6. Apply grease to selector lever pin and install adjuster (cable end) to it. : Grease 99000-25010
7. With both select lever and transmission range sensor kept each "N" position, drive cable end holder (1) in until it locks cable.
8. Slide lock plate (2) to secure cable end holder in position.
9. After select cable was installed, check for the following. Push vehicle with selector lever shifted to "P" range. Vehicle should not move. Vehicle can not be driven in "N" range. Vehicle can be driven in "D", "2" and "L" ranges. Vehicle can be backed in "R" range.

Scheme 16

1. Disconnect transmission range sensor connector (1).
2. Check that continuity exists at terminals as shown in the following figure by moving select lever. If check result is not as specified, adjust switch.

Scheme 17

1. Shift manual shift lever (1) to "N" range.
2. Connect ohmmeter between 6 and 10 terminals of disconnected transmission range sensor connector (3).
3. Turn transmission range sensor (2) gradually to find position where ohmmeter reading indicates continuity. Then fix transmission range sensor (2) at that position by tightening bolts and nut to specified torque. Tightening torque Transmission range sensor bolt a: 25 N.m (2.5 kg-m, 18.0 lb-ft) Transmission range sensor nut b: 7.5 N.m (0.75 kg-m, 5.5 lb-ft)
4. Connect transmission range sensor connector (3).
5. Check that engine starts in "N" and "P" ranges but it doesn't start in "D", "2", "L" or "R" range. Also, check that back-up lamp turn ON in "R" range.

Scheme 18

1. Disconnect negative cable at battery.
2. Disconnect output shaft speed sensor connector (2).
3. Remove output shaft speed sensor (1) by removing its bolt.
