INSTALLATION
| CAUTION | Before handling the airbag module, refer to "CAUTION" of "General Description" in "AIRBAG SYSTEM". < Refer to CAUTION , General Description. > Do not allow harness and connectors to interfere or get tangled up with other parts. If the steering wheel and steering angle sensor (steering roll connector) are removed, perform "VDC sensor midpoint setting mode" of the VDC. < Refer to VDC SENSOR MIDPOINT SETTING MODE , ADJUSTMENT, VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). > |
- Before installing steering wheel, be sure to adjust the direction of steering roll connector with steering wheel. < Refer to «ADJUSTMENT»(ref-560375-S32259960362013061300000) , Roll Connector. >
- Install each part in the reverse order of removal. NOTE: Align the alignment marks on the steering wheel and the column assembly - steering. Tightening torque: Steering wheel: 39 N.m (3.98 kgf-m, 28.8 ft-lb) Clearance: Between cover assembly - column and steering wheel: +4 - 6 mm (0.16 - 0.24 in)
Install each part in the reverse order of removal.
- Install each part in the reverse order of removal.
- When performing the work of HID type low beam RH, secure the flange section of the bumper face - front to the bracket - front bumper side. CAUTION: Install the bumper face - front so that the front end of the under cover (b) comes inside the bumper face - front (a). Tightening torque: Light assembly - head: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb) Battery holder: 3.5 N.m (0.36 kgf-m, 2.6 ft-lb)
- When performing the work of HID type low beam RH, adjust the fog light beam. (Model with fog light) < Refer to «FOG LIGHT AIMING»(ref-560378-S04419752142013061300000) , ADJUSTMENT, Front Fog Light Assembly. >
| CAUTION | After installing the panel center assembly, check that the air vent grille of the panel center assembly is inserted correctly into the air vent duct. |
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Note. Refer to "INSTALLATION" of "Knee Airbag Module". < Refer to INSTALLATION , Knee Airbag Module. >
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
- Install each part in the reverse order of removal. Tightening torque: Fog light assembly - front: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
- Adjust the fog light beam. < Refer to «FOG LIGHT AIMING»(ref-560378-S04419752142013061300000) , ADJUSTMENT, Front Fog Light Assembly. >
Scheme 64
Scheme 65
- Before checking the fog light assembly - front beam level, be sure of the following: The area around the fog light assembly - front has not sustained any scratches, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
- Bounce the vehicle several times to normalize the suspension.
- Make certain that someone is seated in the driver's seat.
- Place the vehicle with the front end facing to the measurement panel. h mm (in) at 3 m (10 ft) 40 (1.58)
- Adjust the fog light assembly - front beam. Remove the screw and clips, and turn over the front side of the mud guard - front. Adjust the beam direction by turning the aiming screw from the bottom of the bumper face - front.
Scheme 66
- Disconnect the ground cable from battery.
- Remove the screw and clips, and turn over the front side of the mud guard - front.
- From the bottom of the bumper face - front, remove the front fog light bulb. Disconnect the connector. Remove the bulb.
| CAUTION | After connecting the connector, make sure that the bulb is locked securely. |
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
| CAUTION | For 4 door model, replace the gasket - rear combination (b) of the light assembly - rear combination (a) with a new part. If the gasket - rear combination is reused, water may come inside of the vehicle. |
Scheme 67
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination (5 door model/XV model): 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination (5 door model/XV model): 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination (5 door model/XV model): 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination (5 door model/XV model): 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Tightening torque
Light assembly - high-mounted (5 door model/XV model): 4.5 N.m (0.46 kgf-m, 3.3 ft-lb)
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
REMOVAL
Note. The ignition switch illumination is integrated into the immobilizer antenna assembly.
Scheme 68
Scheme 69
Scheme 70
- Disconnect the ground cable from battery.
- Remove the cover assembly - column. Remove the screws by turning the steering wheel to right and left. Release the claw, and remove the cover assembly - column UPR and the cover assembly - column LWR.
- Disconnect the connector and remove the ignition switch illumination. CAUTION: Do not apply excessive force to remove the ignition switch illumination lock. Otherwise they may be broken because those parts are the products made of a plastic.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Note. Refer to "INSTALLATION" of "Knee Airbag Module". < Refer to INSTALLATION , Knee Airbag Module. >
Tightening torque
Relay & fuse box: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Note. When the auto headlight beam leveler CM is removed, perform initialization or reinitialization. < Refer to PROCEDURE , Auto Headlight Beam Leveler System. >
| CAUTION | Always remove the sensor assembly - headlight beam leveler before removing any parts related to the suspension. |
Scheme 71
- Disconnect the ground cable from battery.
- Lift up the vehicle body, and remove the left rear wheel.
- Remove the sensor assembly - headlight beam leveler. CAUTION: Do not disassemble the sensor and lever. Disconnect the connector. Remove the nuts, and remove the sensor assembly - headlight beam leveler.
- Install each part in the reverse order of removal. Tightening torque: Sensor assembly - headlight beam leveler: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb) Rear wheel: 120 N.m (12.24 kgf-m, 88.5 ft-lb)
- Perform reinitialization of the sensor assembly - headlight beam leveler. < Refer to «REINITIALIZATION»(ref-560378-S01185818442013061300000) , PROCEDURE, Auto Headlight Beam Leveler System. > NOTE: When replacing the sensor assembly - headlight beam leveler with a new part, perform the initialization. < Refer to «INITIALIZATION»(ref-560378-S22413842202013061300000) , PROCEDURE, Auto Headlight Beam Leveler System. >
Install each part in the reverse order of removal.
Tightening torque
Resistor assembly - daytime running light: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
From behind the bumper face - rear, release the claws and remove the reflex reflector assembly.
Scheme 72
Install each part in the reverse order of removal.
Scheme 73
- Disconnect the ground cable from battery.
- Remove the switch assembly - door. Remove the screws, and pull out the switch assembly - door toward you. Disconnect the connector and remove the switch assembly - door.
Install each part in the reverse order of removal.
