Contents Wiring diagrams Section: Exterior Lights All sections

Lighting System (Except Wrx): Other Subaru XV GP

Exterior Lights 39 illustrations ~3669 words

CAUTION

  1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
  2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
  3. Connect the connectors securely during reassembly.
  4. After reassembly, make sure that the each component operates normally.
  5. Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions for "AIRBAG SYSTEM" in this case. < Refer to «CAUTION»(ref-560375-S15420108262013061300000) , General Description. >
  6. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.
  7. If the steering wheel and steering angle sensor (steering roll connector) are removed, perform "VDC sensor midpoint setting mode" of the VDC. < Refer to «VDC SENSOR MIDPOINT SETTING MODE»(ref-560389-S40582429032013061300000) , ADJUSTMENT, VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). >

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.
Steering wheel pullerUsed for removing the steering wheel.

Scheme 76

Scheme 76: LOCATION
Scheme 76: LOCATION
Main fuse boxHeadlight relay (HI)(A)
Headlight relay (LO)(B)
Fuse 15A (daytime running light relay)(C)
Fuse 15A (front fog light relay, headlight LH / RH (LO))(D)
Fuse 20A (spot map light, room light, ignition switch illumination)(E)
Fuse 15A (tail and illumination relay, daytime running light relay)(F)
Daytime running light relay(G)
Relay & fuse boxFuse 15A (stop light and brake switch)(H)
Fuse 10A (inhibitor switch, back-up light switch, auto headlight beam leveler CM)(I)
Fuse 15A (front fog light relay)(J)
Fuse 7.5A (turn signal & hazard unit)(K)
Relay holder LHTail & Illumination relay(L)
Relay holder RHFront fog light relay(M)

Note. For other related fuses, refer to the Power Supply Circuit in the wiring diagram. < Refer to System Wiring Diagram Article. >

CHECK FUSE

  1. Remove the fuse and inspect visually.
  2. If the fuse is blown out, replace the fuse. NOTE: If the fuse is blown again, check the system wiring harness.

Scheme 77

Scheme 77: CHECK RELAY
Scheme 77: CHECK RELAY

Scheme 78

Scheme 78
Scheme 78
  1. Check the resistance between relay terminals. Terminal No. Inspection conditions Standard Circuit 1 - 2 Always 1 Mohms or more 1 - 2 Apply battery voltage between terminals 4 and 3. Less than 1 ohms Terminal No. Inspection conditions Standard Circuit 1 - 2 Always 1 Mohms or more 1 - 4 Always Less than 1 ohms 1 - 2 Apply battery voltage between terminals 3 and 5. Less than 1 ohms
  2. Replace the relay if the inspection result is not within the standard value.

AUTO HEADLIGHT SYSTEM CHECK

StepCheckYesNo
1 CHECK HEADLIGHT ILLUMINATION. Set the lighting switch to the switch 1 (TAIL) and switch 2 (HEAD).Do the tail and headlight illuminate?Go to step 2 .Check the combination switch (light) and headlight bulb.
2 CHECK CURRENT DATA. Using the Subaru Select Monitor, display the data of «Lighting AUTO input». NOTE: For detailed procedures, refer to "PC application help for Subaru Select Monitor".Does the display switch between OFF <----> ON when the lighting switch is moved to AUTO position?Go to step 3 .Go to step 8 .
3 CHECK CURRENT DATA. Using the Subaru Select Monitor, display the data of «Illumination Sensor Output». Measure the voltage when the area around the light control sensor, which was dark, becomes bright. Illumination sensor output Dark condition: Approx. 0.6 V or less Bright condition: Approx. 3.0 V or moreIs the voltage output according to the brightness?Check and replace the body integrated unit. Inspection: < Refer to BASIC DIAGNOSTIC PROCEDURE . > Replacement: < Refer to BODY INTEGRATED UNIT . >Go to step 4 .
4 CHECK HARNESS. Disconnect the connectors from body integrated unit and light control sensor. Check the harness between body integrated unit and light control sensor. Connector & terminal (B280) No. 19 - (i226) No. 2: (B280) No. 29 - (i226) No. 1: (B281) No. 1 - (i226) No. 3Is harness normal?Go to step 5 .Repair or replace the harness.
5 CHECK HARNESS. Connect the connector of body integrated unit. Turn the ignition switch to ON. Measure the voltage between light control sensor connector and chassis ground. Connector & terminal (i226) No. 3 (+) - Chassis ground (-)Is the voltage 4.5 - 5.5 V?Go to step 6 .Replace the body integrated unit. < Refer to BODY INTEGRATED UNIT . >
6 CHECK BODY INTEGRATED UNIT. Measure the resistance between the body integrated unit and chassis ground. Connector & terminal (B280) No. 29 - Chassis groundIs the resistance less than 10 ohms?Go to step 7 .Replace the body integrated unit. < Refer to BODY INTEGRATED UNIT . >
7 CHECK LIGHT CONTROL SENSOR. Connect the light control sensor connector. Check the light control sensor. < Refer to INSPECTION , Light Control Sensor. >Is the light control sensor normal?Go to step 8 .Replace the light control sensor.
8 CHECK COMBINATION SWITCH (LIGHT). Check the combination switch (light). < Refer to INSPECTION , Combination Switch (Light). >Is the combination switch (light) normal?Go to step 9 .Replace the combination switch (light).
9 CHECK HARNESS. Disconnect the connectors of body integrated unit and combination switch (light). Check the harness between body integrated unit and combination switch (light). Connector & terminal (B71) No. 19 - (B281) No. 16Is harness normal?Check and replace the body integrated unit. Inspection: < Refer to BASIC DIAGNOSTIC PROCEDURE . > Replacement: < Refer to BODY INTEGRATED UNIT . >Repair or replace the harness.
NOTE
For detailed procedures, refer to "PC application help for Subaru Select Monitor".

CHECK LIGHTING SWITCH

Refer to the "INSPECTION" of the "Combination Switch (Light)". < Refer to INSPECTION , Combination Switch (Light). >

CHECK DIMMER & PASSING SWITCH

Refer to the "INSPECTION" of the "Combination Switch (Light)". < Refer to INSPECTION , Combination Switch (Light). >

NOTE

For operation procedures of each component of the headlight system, refer to the corresponding service information.

  1. Headlight Assembly: < Refer to «HEADLIGHT ASSEMBLY»(ref-560378-S31190217872013061300000) . >
  2. Headlight bulb: < Refer to «HEADLIGHT BULB»(ref-560378-S41737001902013061300000) . >
  3. Combination switch (light): < Refer to «COMBINATION SWITCH (LIGHT)»(ref-560378-S01674953392013061300000) . >
  4. Light control sensor: < Refer to «LIGHT CONTROL SENSOR»(ref-560378-S20600822072013061300000) . >

DAYTIME RUNNING LIGHT SYSTEM CHECK

StepCheckYesNo
1 CHECK BODY INTEGRATED UNIT. Read the DTC using Subaru Select Monitor. NOTE: For detailed procedures, refer to "PC application help for Subaru Select Monitor".Is DTC displayed?Perform the diagnosis according to DTC.Go to step 2 .
2 CHECK CURRENT DATA. Display the following items using Subaru Select Monitor. «Parking Brake Switch Input» «Shift position» «Lighting II Switch Input»Is the input signal normal?Go to step 3 .Check the defective part.
3 CHECK RELAY. Check the daytime running light relay. < Refer to CHECK RELAY , INSPECTION, Relay and Fuse. >Is the relay OK?Go to step 4 .Replace the relay.
4 CHECK HARNESS. Check each harness.Is harness normal?Replace the body integrated unit. < Refer to REMOVAL , Body Integrated Unit. >Repair or replace the harness.
NOTE
For detailed procedures, refer to "PC application help for Subaru Select Monitor".

For operation procedures of each component of the daytime running light system, refer to the appropriate service information.

  1. Headlight Assembly: < Refer to «HEADLIGHT ASSEMBLY»(ref-560378-S31190217872013061300000) . >
  2. Headlight bulb: < Refer to «HEADLIGHT BULB»(ref-560378-S41737001902013061300000) . >
  3. Combination switch (light): < Refer to «COMBINATION SWITCH (LIGHT)»(ref-560378-S01674953392013061300000) . >
  4. Daytime running resistor: < Refer to «DAY TIME RUNNING RESISTOR»(ref-560378-S01293432962013061300000) . >

Refer to the "INSPECTION" of the "Combination Switch (Light)". < Refer to INSPECTION , Combination Switch (Light). >

For operation procedures of each component of the clearance light & illumination light system, refer to the appropriate service information.

  1. Combination switch (light): < Refer to «COMBINATION SWITCH (LIGHT)»(ref-560378-S01674953392013061300000) . >
  2. Parking light bulb: < Refer to «CLEARANCE/PARKING LIGHT BULB»(ref-560378-S18342393362013061300000) . >
  3. Front side marker light bulb: < Refer to «FRONT SIDE MARKER LIGHT BULB»(ref-560378-S33774598772013061300000) . >
  4. Rear combination light assembly: < Refer to «REAR COMBINATION LIGHT ASSEMBLY»(ref-560378-S31845917822013061300000) . >
  5. Tail light/stop light bulb: < Refer to «TAIL/STOP LIGHT BULB»(ref-560378-S32197937152013061300000) . >
  6. Rear side marker light bulb: < Refer to «REAR SIDE MARKER LIGHT BULB»(ref-560378-S37144492852013061300000) . >
  7. License plate light: < Refer to «LICENSE PLATE LIGHT»(ref-560378-S36353244522013061300000) . >
  8. Ignition switch illumination: < Refer to «IGNITION SWITCH ILLUMINATION»(ref-560378-S17465767572013061300000) . >

CHECK FRONT FOG LIGHT SWITCH

Refer to the "INSPECTION" of the "Combination Switch (Light)". < Refer to INSPECTION , Combination Switch (Light). >

For operation procedures of each component of the front fog light system, refer to the appropriate service information.

  1. Combination switch (light): < Refer to «COMBINATION SWITCH (LIGHT)»(ref-560378-S01674953392013061300000) . >
  2. Front fog light assembly: < Refer to «FRONT FOG LIGHT ASSEMBLY»(ref-560378-S14881418712013061300000) . >
  3. Front fog light bulb: < Refer to «FRONT FOG LIGHT BULB»(ref-560378-S05120432512013061300000) . >

CHECK TURN SIGNAL SWITCH

Refer to the "INSPECTION" of the "Combination Switch (Light)". < Refer to INSPECTION , Combination Switch (Light). >

CHECK HAZARD SWITCH

Refer to the "INSPECTION" of the "Hazard Switch". < Refer to INSPECTION , Hazard Switch. >

CHECK TURN SIGNAL AND HAZARD MODULE

Refer to "INSPECTION" of the "Turn Signal Light and Hazard Light System". < Refer to INSPECTION , Turn Signal Light & Hazard Light Module. >

For operation procedures of each component of the turn signal and hazard light system, refer to the appropriate service information.

  1. Combination switch (light): < Refer to «COMBINATION SWITCH (LIGHT)»(ref-560378-S01674953392013061300000) . >
  2. Front turn signal light bulb: < Refer to «FRONT TURN SIGNAL LIGHT BULB»(ref-560378-S32525582542013061300000) . >
  3. Side turn signal light assembly: < Refer to «SIDE TURN SIGNAL LIGHT ASSEMBLY»(ref-560378-S26927002142013061300000) . >
  4. Rear combination light assembly: < Refer to «REAR COMBINATION LIGHT ASSEMBLY»(ref-560378-S31845917822013061300000) . >
  5. Rear turn signal light bulb: < Refer to «REAR TURN SIGNAL LIGHT BULB»(ref-560378-S29165576452013061300000) . >
  6. Hazard switch: < Refer to «HAZARD SWITCH»(ref-560378-S27158781812013061300000) . >
  7. Turn signal and hazard module: < Refer to «TURN SIGNAL LIGHT & HAZARD LIGHT MODULE»(ref-560378-S12133482782013061300000) . >

CHECK BACK-UP LIGHT SWITCH (MT MODEL)

Refer to "INSPECTION" of the "Switches and Harness" in the "MANUAL TRANSMISSION AND DIFFERENTIAL" service information. < Refer to BACK-UP LIGHT SWITCH , INSPECTION, Switches and Harness. >

CHECK INHIBITOR SWITCH (CVT MODEL)

Refer to "INSPECTION" of the "Inhibitor Switch" in "CONTINUOUSLY VARIABLE TRANSMISSION" service information. < Refer to INSPECTION , Inhibitor Switch. >

For operation procedures of each component of the back-up light system, refer to the appropriate service information.

  1. Rear combination light assembly: < Refer to «REAR COMBINATION LIGHT ASSEMBLY»(ref-560378-S31845917822013061300000) . >
  2. Back-up light bulb: < Refer to «BACK-UP LIGHT BULB»(ref-560378-S10524304062013061300000) . >

CHECK STOP LIGHT SWITCH

Refer to "INSPECTION" of the "Stop Light Switch" in the "BRAKE" section.. < Refer to INSPECTION , Stop Light Switch. >

For operation procedures of each component of the stop light system, refer to the respective service information.

  1. Rear combination light assembly: < Refer to «REAR COMBINATION LIGHT ASSEMBLY»(ref-560378-S31845917822013061300000) . >
  2. Tail light/stop light bulb: < Refer to «TAIL/STOP LIGHT BULB»(ref-560378-S32197937152013061300000) . >
  3. High-mounted stop light: < Refer to «HIGH-MOUNTED STOP LIGHT»(ref-560378-S35334998042013061300000) . >

CHECK DOOR SWITCH

Refer to the "INSPECTION" of the "Door Switch". < Refer to INSPECTION , Door Switch. >

CHECK REAR GATE LATCH SWITCH

Refer to "INSPECTION" of the "Rear Gate Latch and Actuator Assembly" in "SECURITY AND LOCKS" service information. < Refer to ACTUATOR , INSPECTION, Rear Gate Latch and Actuator Assembly. >

CHECK TRUNK LID LATCH SWITCH

Refer to "INSPECTION" of the "Trunk Lid Latch and Actuator Assembly" in "SECURITY AND LOCKS" service information. < Refer to ACTUATOR , INSPECTION, Trunk Lid Latch and Actuator Assembly. >

For operation procedures of each component of the interior light system, refer to the appropriate service information.

  1. Spot map light: < Refer to «SPOT MAP LIGHT»(ref-560378-S27066308102013061300000) . >
  2. Room light: < Refer to «ROOM LIGHT»(ref-560378-S08723241442013061300000) . >
  3. Luggage room light: < Refer to «LUGGAGE ROOM LIGHT»(ref-560378-S11189491512013061300000) . >
  4. Trunk room light: < Refer to «TRUNK ROOM LIGHT»(ref-560378-S07078190432013061300000) . >
  5. Glove box light: < Refer to «GLOVE BOX LIGHT»(ref-560378-S27379573782013061300000) . >
  6. Door switch: < Refer to «DOOR SWITCH»(ref-560378-S21130154582013061300000) . >

PROCEDURE

When parts related to the auto headlight beam leveler system are removed or replaced, perform the following procedures to initialize or reinitialize.

Note. Before performing initialization or reinitialization, check the following

  1. Vehicle is parked on a level surface.
  2. The inflation pressure of tires is correct.
  3. Unload any cargo from the vehicle.
  4. Vehicle's fuel tank is fully filled.
  5. Refer to the following chart to determine whether to initialize or reinitialize.
InitializationWhen the auto headlight beam leveler CM was replaced with a new module.
ReinitializationWhen the auto headlight beam leveler CM was replaced with a part from another vehicle. When suspension parts have been removed or replaced. (Crossmember, front arm, sub frame, lateral link, housing, strut etc.) When the vehicle height sensor has been replaced or removed.
CAUTIONIf the indicator does not flash three times or the headlight beam does not operate, it can be assumed that there is an open circuit or faulty wiring in the harness of the auto headlight beam leveler CM, vehicle height sensors or headlight assembly. Perform inspection and repair according to the inspection results, then perform initialization/reinitialization again. Initialization: < Refer to INITIALIZATION , PROCEDURE, Auto Headlight Beam Leveler System. > Reinitialization: < Refer to REINITIALIZATION , PROCEDURE, Auto Headlight Beam Leveler System. >

INITIALIZATION

  1. Check that the indicator in the meter is flashing twice repeatedly.
  2. Bounce the vehicle several times to normalize the suspension.
  3. Make certain that someone is seated in the driver's seat.
  4. Turn the ignition switch to ON, and within 1.5 - 20 seconds, turn the headlight switch OFF --> ON for three successive times.
  5. Make sure that the indicator in the meter flashes three times and then turns OFF, indicating that initialization has been successfully completed. (At this time, the headlight beam drops once, and then returns to the original position.)
  6. Perform beam adjustment for the headlight. < Refer to «ADJUSTMENT»(ref-560378-S10386782442013061300000) , Headlight Assembly. >

REINITIALIZATION

  1. Bounce the vehicle several times to normalize the suspension.
  2. Make certain that someone is seated in the driver's seat.
  3. Turn the ignition switch to ON, and, within 1.5 - 10 seconds, turn the headlight switch OFF --> ON five or more successive times.
  4. Check that the headlight beam drops once, then returns to normal.
  5. After confirming 4), turn the ignition switch to OFF within 30 seconds.
  6. Turn the ignition switch to ON again, and, within 1.5 - 10 seconds, turn the headlight switch OFF --> ON five or more successive times.
  7. Make sure that the indicator in the meter flashes three times and then turns OFF, indicating that reinitialization has been successfully completed. (At this time, the headlight beam drops once, and then returns to the original position.)
  8. Perform beam adjustment for the headlight. < Refer to «ADJUSTMENT»(ref-560378-S10386782442013061300000) , Headlight Assembly. >

For operation procedures of each component of the auto headlight beam leveler system, refer to the respective article.

  1. Auto headlight beam leveler CM: < Refer to «AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE»(ref-560378-S06746074472013061300000) . >
  2. Vehicle height sensor: < Refer to «REAR HEIGHT SENSOR»(ref-560378-S31727746222013061300000) . >

Scheme 79

Scheme 79: REMOVAL
Scheme 79: REMOVAL

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85
  1. Position the front wheels straight ahead. (After moving a vehicle 5 m (16 ft) or more with front wheels positioned straight ahead, make sure that the vehicle moves straight ahead.)
  2. Turn the ignition switch to OFF.
  3. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
  4. Remove the driver's airbag module. CAUTION: Before handling the airbag module, refer to "CAUTION" of "General Description" in "AIRBAG SYSTEM". < Refer to «CAUTION»(ref-560375-S15420108262013061300000) , General Description. > Using a hexagon wrench wrapped with protective tape, push in the snap pins to disengage the locks (3 places). Disconnect the horn harness and airbag connector, and remove the driver's airbag module. < Refer to «DRIVER'S AIRBAG MODULE»(ref-560375-S42651612422013061300000) , CURTAIN AIRBAG MODULE & PRETENSIONER, PROCEDURE, Airbag Connector. >
  5. Remove the steering wheel. CAUTION: Always use the steering wheel puller for removal to avoid deforming the steering wheel. If the steering wheel has been removed, make sure that the steering roll connector is not turned from the original position. Disconnect the connector and remove the nut. Put alignment marks and remove the steering wheel using a steering wheel puller. Preparation tool: Steering wheel puller
  6. Remove the cover assembly - column. Remove the screws. Release the claw, and remove the cover assembly - column UPR and the cover assembly - column LWR.
  7. Remove the steering roll connector. CAUTION: Make sure that the steering roll connector is not turned from the original position. Disconnect the connector under the steering roll connector. Release the claws and remove the steering roll connector.
  8. Remove the switch assembly - combination wiper select. Disconnect the connector. Release the claws, and pull out the switch assembly - combination wiper select. CAUTION: Do not press the claws with excessive force. They may be damaged.
  9. Remove the switch assembly - combination turn dimmer. Disconnect the connector, and loosen the clamp to release the claws. Pull out the switch assembly - combination turn dimmer from the column assembly - steering.

WHEN REMOVING RH SIDE

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONThe HID type uses very high voltages for the lighting circuit. Make sure that the power supply is turned OFF before working.

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89
  1. Disconnect the ground cable from battery.
  2. Remove the clips and remove the air intake duct.
  3. Remove the clip, and remove the bracket - grille. CAUTION: To prevent damage to the bracket - grille, make sure to remove all clips.
  4. Detach the flange section on the right side of the bumper face - front. Apply protective tape (A) to the light assembly - head. Release the clips, and while pushing up the lower side (a) of the bumper face - front, remove from (b) to (e). CAUTION: Do not pull forcibly. It may damage the flange sections of the bumper face - front.
  5. Remove the light assembly - head. CAUTION: Be careful not to damage the light assembly - head, fender COMPL - front, and bumper face - front. Disconnect connectors. Remove the bolts and clips, and remove the light assembly - head.

WHEN REMOVING LH SIDE

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONThe HID type uses very high voltages for the lighting circuit. Make sure that the power supply is turned OFF before working.

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91
  1. Disconnect the ground cable from battery.
  2. Detach the flange section on the bumper face - front left side. Apply protective tape (A) to the light assembly - head. Release the clips, and while pushing up the lower side (a) of the bumper face - front, remove in the order from (b) to (e). CAUTION: Do not pull forcibly. It may damage the flange sections of the bumper face - front.
  3. Remove the light assembly - head. CAUTION: Be careful not to damage the light assembly - head, fender COMPL - front, and bumper face - front. Disconnect connectors. Remove the bolts and clips, and remove the light assembly - head.

WHEN REMOVING BOTH SIDE

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONThe HID type uses very high voltages for the lighting circuit. Make sure that the power supply is turned OFF before working.

Scheme 92

Scheme 92
Scheme 92
  1. Disconnect the ground cable from battery.
  2. Remove the clips and remove the air intake duct.
  3. Remove the bumper face - front. < Refer to «REMOVAL»(ref-560372-S09988890992013061300000) , Front Bumper. >
  4. Remove the light assembly - head. Disconnect connectors. Remove the bolts and clips, and remove the light assembly - head.

Scheme 93

Scheme 93: INSTALLATION
Scheme 93: INSTALLATION
  1. Install each part in the reverse order of removal.
  2. Secure the flange section of the bumper face - front to the bracket - front bumper side. CAUTION: Install the bumper face - front so that the front end of the under cover (b) comes inside the bumper face - front (a). Tightening torque: Light assembly - head: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
  3. Adjust the headlight beam and fog light beam. Adjust the headlight beam. < Refer to «HEADLIGHT BEAM ADJUSTMENT»(ref-560378-S41708817942013061300000) , ADJUSTMENT, Headlight Assembly. > Adjust the fog light beam. (Model with fog light) < Refer to «FOG LIGHT AIMING»(ref-560378-S04419752142013061300000) , ADJUSTMENT, Front Fog Light Assembly. >

HID HEADLIGHT BALLAST

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONThe HID type uses very high voltages for the lighting circuit. Make sure that the power supply is turned OFF before working. Do not leave the light assembly - head without the ballast - headlight for a long time. Dust, moisture, etc. entering the light assembly - head may affect its performance.

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97
  1. Disconnect the ground cable from battery.
  2. Remove the light assembly - head. RH side: < Refer to «WHEN REMOVING RH SIDE»(ref-560378-S21755302272013061300000) , REMOVAL, Headlight Assembly. > LH side: < Refer to «WHEN REMOVING LH SIDE»(ref-560378-S42407634612013061300000) , REMOVAL, Headlight Assembly. > Both sides: < Refer to «WHEN REMOVING BOTH SIDE»(ref-560378-S32863330592013061300000) , REMOVAL, Headlight Assembly. >
  3. Remove the cover - headlight.
  4. Disconnect the bulb socket.
  5. Remove the ballast - headlight. Disconnect the connector. Remove the screws and remove the ballast - headlight. Guiding the bulb socket through the gap between housing and reflector, pull out the ballast - headlight.
CAUTIONWhen installing the ballast - headlight, be sure to install the gasket. After installing the ballast to the vehicle, be sure to perform beam adjustment.

Assemble each part in the reverse order of disassembly.

Tightening torque

Light assembly - head: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

HIGH BEAM

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONBecause the halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb. Never touch the glass portion. Do not leave the light assembly - head without the bulb for a long time. Dust, moisture, etc. entering the light may affect its performance.

Scheme 98

Scheme 98
Scheme 98
  1. Disconnect the ground cable from battery.
  2. Remove the clips and remove the air intake duct. (When removing the high beam bulb RH)
  3. Disconnect the connector and remove the high beam bulb.

HALOGEN TYPE LOW BEAM

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONBecause the halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb. Never touch the glass portion. Do not leave the light assembly - head without the bulb for a long time. Dust, moisture, etc. entering the light may affect its performance.

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100
  1. Disconnect the ground cable from battery.
  2. Remove the clips and remove the air intake duct. (When removing the low beam bulb RH)
  3. Turn the filler neck of the tank - washer front clockwise. (When removing the low beam bulb LH)
  4. Disconnect the connector and remove the low beam bulb. CAUTION: Make sure to check if any bulb O-ring is remained on the housing side as this may sometimes happen.

HID TYPE LOW BEAM

When removing RH side

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONBecause the lighting circuit uses high voltage, be sure to confirm that the power supply is turned off before operation. When replacing bulb, hold the flange area. Be careful not to touch the glass area. Do not leave the light assembly - head without the bulb and cover - headlight for a long time. Dust, moisture, etc. entering the light may affect its performance.

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103
  1. Disconnect the ground cable from battery.
  2. Remove the clips and remove the air intake duct.
  3. Remove the clip, and remove the bracket - grille. CAUTION: To prevent damage to the bracket - grille, make sure to remove all clips.
  4. Detach the flange section on the right side of the bumper face - front. Apply protective tape (A) to the light assembly - head. Release the clips, and while pushing up the lower side (a) of the bumper face - front, remove from (b) to (e). CAUTION: Do not pull forcibly. It may damage the flange sections of the bumper face - front.
  5. Remove the light assembly - head. CAUTION: Be careful not to damage the light assembly - head, fender COMPL - front, and bumper face - front. Disconnect connectors. Remove the bolts and clips, and remove the light assembly - head.
  6. Remove the low beam bulb. Remove the cover - headlight. Remove the valve socket. Unlock the bulb spring, and remove the low beam bulb.
WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONBecause the lighting circuit uses high voltage, be sure to confirm that the power supply is turned off before operation. When replacing bulb, hold the flange area. Be careful not to touch the glass area. Do not leave the light assembly - head without the bulb and cover - headlight for a long time. Dust, moisture, etc. entering the light may affect its performance.

Scheme 104

Scheme 104
Scheme 104

Scheme 105

Scheme 105
Scheme 105
  1. Remove the battery. Disconnect the negative terminal of battery, and then the positive terminal, and remove the battery cable holder from the battery rod. Remove the flange nut from battery rod and remove battery holder.
  2. Remove the low beam bulb. Remove the cover - headlight. Remove the valve socket. Unlock the bulb spring, and remove the low beam bulb.

HALOGEN TYPE

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONBecause the halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb. Never touch the glass portion. Do not leave the light assembly - head without the bulb and cover - headlight for a long time. Dust, moisture, etc. entering the headlight may affect its performance.
  1. Visually check the bulb for blow out.
  2. Check the bulb specification. < Refer to «SPECIFICATION»(ref-560378-S11796275892013061300000) , General Description. >
  3. Replace the bulb if it is found defective.

HID TYPE

WARNINGBecause the headlight system uses high voltage, be careful not to perform work with wet hands. There is a possibility of electrical shock.
CAUTIONDo not leave the light assembly - head without the bulb and cover - headlight for a long time. Dust, moisture, etc. entering the headlight may affect its performance. When lit (lighting switch is ON), do not touch the harness, light internals, or metal parts of the light. When performing a lighting test, make sure that the headlight is mounted on the vehicle, and the power supply is connected to the connector on the vehicle's side.
  1. Check the bulb specification. < Refer to «SPECIFICATION»(ref-560378-S11796275892013061300000) , General Description. >
  2. Install the factory HID bulb to check whether it lights properly.
  3. If it does not light properly, replace with a new bulb.
  4. Inspect the HID ballast. Inspect the ballast in the following manner, and determine whether or not to reuse. Perform cold starts (light the headlight after turning off for 10 minutes or more), and hot starts (light the headlight for 15 minutes or more, then turn off for 1 minute and relight) several times, to make sure that the headlight lights properly. Monitor the lighting condition right after a cold start up to a stable state (approx. 5 min.), to see if there are any unstable conditions such as flickering. Install bulbs with the same number of operating hours on both headlights, and light for approximately 30 minutes. Check for whether there is a difference in brightness on the right and left sides.
  5. Replace the ballast if it is found defective.

Scheme 106

Scheme 106: REMOVAL
Scheme 106: REMOVAL

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108
  1. Disconnect the ground cable from battery.
  2. On manual A/C models, disconnect the control cables from both sides of the heater and cooling unit assembly.
  3. Remove the panel center assembly. CAUTION: Do not put your finger on the fin of the air vent grille. Doing so may damage the fin. Insert a plastic remover to the three areas shown by the arrows, and lift up the panel center assembly slightly. With the panel center assembly lifted up slightly, release the claw by using a clip remover wrapped with protective tape. Release the rest of the claws, and remove the panel center assembly.
  4. Release the claws, and remove the switch - hazard from the panel center assembly.

4 DOOR MODEL

It is integrated with the tail light bulb. For details concerning operation procedures, refer to "REMOVAL" of "Tail/Stop Light Bulb". < Refer to REMOVAL , Tail/Stop Light Bulb. >

Scheme 109

Scheme 109
Scheme 109
  1. Disconnect the ground cable from battery.
  2. Remove the light assembly - rear combination. CAUTION: Be careful not to damage the clips. Release the bolts and clips, then pull out the light assembly - rear combination to the vehicle rear. Disconnect the connector and remove the light assembly - rear combination.
  3. Remove the bulb socket and rear side marker light bulb.
  1. Visually check the bulb for blow out.
  2. Check the bulb specification. < Refer to «SPECIFICATION»(ref-560378-S11796275892013061300000) , General Description. >
  3. Replace the bulb if it is found defective.

5 DOOR MODEL/XV MODEL

  1. Install the light to test if it illuminates normally.
  2. If it fails to illuminate normally, replace the light assembly - high-mounted with a new part. NOTE: Since LED (Light Emitting Diode) is used for the light, replace the light assembly - high-mounted if the LED burns out.

Scheme 110

Scheme 110: REMOVAL
Scheme 110: REMOVAL

Scheme 111

Scheme 111
Scheme 111
  1. Disconnect the ground cable from battery.
  2. Remove the light assembly - map. CAUTION: When using a flat tip screwdriver, apply protective tape or cloth and be careful not to cause damage. Release the claws and remove the lens. Remove the screws and pull out the light assembly - map. Model without sunroof Model with sunroof Disconnect the connector and remove the light assembly - map and the bulb.

SPOT MAP LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. < Refer to «SPECIFICATION»(ref-560378-S11796275892013061300000) , General Description. >
  3. Replace the bulb if it is found defective.

SPOT MAP LIGHT SWITCH

Unit inspection

Preparation tool

Circuit tester

Scheme 112

Scheme 112: SPOT MAP LIGHT SWITCH
Scheme 112: SPOT MAP LIGHT SWITCH
  1. Check the resistance between switch terminals. Model without sunroof Terminal No. Inspection conditions Standard Connection diagram 1 - 2 Switch OFF 1 Mohms or more Switch ON Approx. 18 ohms Model with sunroof Terminal No. Inspection conditions Standard Connection diagram 1 - 2 Switch OFF 1 Mohms or more Switch ON Approx. 18 ohms
  2. Replace the light assembly - map if the inspection result is not within the standard value.

Scheme 113

Scheme 113: REMOVAL
Scheme 113: REMOVAL

Scheme 114

Scheme 114
Scheme 114
  1. Disconnect the ground cable from battery.
  2. Remove the light assembly - room. CAUTION: When using a flat tip screwdriver, apply protective tape or cloth and be careful not to cause damage. Release the claws and remove the lens. Remove the screws and pull out the light assembly - room. Disconnect the connector and remove the light assembly - room and the bulb.

ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. < Refer to «SPECIFICATION»(ref-560378-S11796275892013061300000) , General Description. >
  3. Replace the bulb if it is found defective.

LUGGAGE ROOM LIGHT BULB

  1. Visually check the bulb for blow out.
  2. Check the bulb specification. < Refer to «SPECIFICATION»(ref-560378-S11796275892013061300000) , General Description. >
  3. Replace the bulb if it is found defective.

More articles — Lighting System (Except Wrx)
