HEADLIGHT BEAM ADJUSTMENT
| CAUTION | Turn off the light before adjusting the beam level of the light assembly - head. If it is necessary to inspect the beam level, do not keep the light on for two minutes or more. When blocking the light that come from outside, use a closure plate or the like. Do not apply tape to the lens or cover it with a cloth. It may raise the temperature in the light and cause deformation/bubble formations of the plastic lens. |
Scheme 5
Scheme 6
Scheme 7
- Before checking the beam level of the light assembly - head, be sure of the following: The area around the light assembly - head has not sustained any scratches, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
- Bounce the vehicle several times to normalize the suspension.
- Make certain that someone is seated in the driver's seat.
- Measure the distance between the low beam bulb centers and the height of the bulb center.
- Adjust the beam level of the light assembly - head. Place the vehicle with the front end facing to the measurement panel, then illuminate the low beam. W mm (in) 1, 281 (50.44) Adjust the low beam by turning the aiming screw.
