Speed Control System (Except Wrx): Other Subaru XV GP

CAUTION

1. Prior to starting work, pay special attention to the following: Always wear work clothes, a safety cap, protective shoes. Additionally, wear a helmet, protective goggles, etc. if necessary. Protect the vehicle using a seat cover, fender cover, etc. Prepare the service tools, clean cloth, containers to catch grease and oil, etc.
2. Vehicle components are extremely hot immediately after driving. Be wary of receiving burns from heated parts.
3. When performing a repair, identify the cause of trouble and avoid unnecessary removal, disassembly and replacement.
4. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from battery.
5. Always use the jack-up point when the shop jacks or rigid racks are used to support the vehicle.
6. Remove contamination including dirt and corrosion before removal, installation, disassembly or assembly.
7. Keep the removed parts in order and protect them from dust and dirt.
8. All removed parts, if to be reused, should be reinstalled in the original positions with attention to the correct directions, etc.
9. Bolts, nuts and washers should be replaced with new parts as required.
10. Be sure to tighten the fasteners including bolts and nuts to the specified torque.

GENERAL TOOL

Scheme 5

Scheme 6

1. Disconnect the ground cable from battery.
2. Disconnect the connector (A).
3. Remove the nut (B) securing accelerator pedal assembly, and remove the accelerator pedal assembly.

CHECK ACCELERATOR PEDAL SENSOR AREA (METHOD WITH SUBARU SELECT MONITOR)

1. Turn the ignition switch to ON. (engine OFF)
2. Read the accelerator pedal opening angle signal and voltage of accelerator pedal sensor using Subaru Select Monitor. < Refer to «READ CURRENT DATA FOR ENGINE (NORMAL MODE)»(ref-560373-S14668176562013061300000) , OPERATION, Subaru Select Monitor. >
