SPECIFICATION
| Fuel tank | Capacity | 70 L (18.5 US gal, 15.4 Imp gal) |
|---|---|---|
| Location | Rear floor under | |
| Fuel pump | Type | Impeller |
| Shutoff discharge pressure | 850 kPa (8.67 kg/cm 2 , 123.3 psi), or less | |
| Discharge rate | 155 L (41 US gal, 34.1 Imp gal)/h or more [12 V at 300 kPa (3.06 kg/cm 2 , 43.5 psi)] | |
| Fuel filter | In-tank type | |
Scheme 264
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.25 (0.1, 0.9)
T2: 6.4 (0.7, 4.7)
T3: 17 (1.7, 12.5)
T4: 19 (1.9, 14.0)
T5: 25 (2.5, 18.4)
Scheme 265
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.25 (0.1, 0.9)
T2: 6.4 (0.7, 4.7)
T3: 19 (1.9, 14.0)
T4: 21.6 (2.2, 15.9)
Scheme 266
Tightening torque: N.m (kgf-m, ft-lb)
T: 8 (0.8, 5.9)
Scheme 267
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 22 (2.2, 16.2)
T3: 25 (2.5, 18.4)
Scheme 268
Scheme 269
Scheme 270
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4, 3.2)
T2: 9 (0.9, 6.6)
T3: 18 (1.8, 13.3)
T4: 33 (3.4, 24.3)
Scheme 271
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.25 (0.1, 2.9)
T2: 2 (0.2, 1.5)
T3: 2.5 (0.3, 1.8)
T4: 7.5 (0.8, 5.5)
T5: 8 (0.8, 5.9)
T6: 7.5 (0.8, 5.5)
Scheme 272
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1 (0.1, 0.7)
T2: 7.35 (0.7, 5.4)
T3: 7.5 (0.8, 5.5)
Scheme 273
Throttle body is a non-disassembled part, so do not remove the throttle position sensor from throttle body.
Refer to REMOVAL and INSTALLATION.
Scheme 274
Scheme 275
- Remove the collector cover. NOTE: Follow these procedures for removal of the collector cover. Lift up the rear side holding two positions (A). Lift up the front side holding two positions (B) while moving it in the forward direction of the vehicle.
- Disconnect the ground cable from battery.
- Disconnect the manifold pressure sensor connector.
- Remove the manifold pressure sensor and the filter and hose from intake manifold.
