SPECIFICATION
| Fuel tank | Capacity | 70 L (18.5 US gal, 15.4 Imp gal) |
|---|---|---|
| Location | Under rear seat | |
| Fuel pump | Type | Impeller |
| Shutoff discharge pressure | 677 kPa (6.9 kgf/cm 2 , 98.2 psi) or less | |
| Discharge rate | 105 L (27.7 US gal, 23.1 Imp gal)/h or more [12 V at 300 kPa (3.06 kgf/cm 2 , 43.5 psi)] | |
| Fuel filter | In-tank type | |
Scheme 97
Tightening torque: N.m (kgf-m, ft-lb)
T1: 2 (0.2, 1.5)
T2: 6 (0.6, 4.4)
T3: 6.4 (0.7, 4.7)
T4: 8.3 (0.8, 6.1)
T5: 25 (2.5, 18.4)
Scheme 98
Tightening torque: N.m (kgf-m, ft-lb)
T: 6.4 (0.7, 4.7)
Scheme 99
Tightening torque: N.m (kgf-m, ft-lb)
T: 8 (0.8, 5.9)
Scheme 100
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 24 (2.4, 17.7)
Scheme 101
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4, 3.2)
T2: 9 (0.9, 6.6)
T3: 18 (1.8, 13.3)
T4: 33 (3.4, 24.3)
Scheme 102
Tightening torque: N.m (kgf-m, ft-lb)
T1: 2 (0.2, 1.5)
T2: 2.5 (0.3, 1.8)
T3: 7.5 (0.8, 5.5)
T4: 8 (0.8, 5.9)
T5: 7.5 (0.8, 5.5)
Scheme 103
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1 (0.1, 0.7)
T2: 7.35 (0.7, 5.4)
T3: 7.5 (0.8, 5.5)
Scheme 104
Scheme 105
- Structural diagram 1
Scheme 106
Tightening torque: N.m (kgf-m, ft-lb)
T1: 7.5 (0.8, 5.5)
T2: 19 (1.9, 14.0)
Scheme 107
- Structural diagram 2
Throttle body is a non-disassembled part, so do not remove the throttle position sensor from throttle body. Refer to REMOVAL and INSTALLATION.
Scheme 108
- Disconnect the ground cable from battery.
- Disconnect the connector (A) from the mass air flow and intake air temperature sensor, and remove the mass air flow and intake air temperature sensor.
