CAUTION
- Prior to starting work, pay special attention to the following: Always wear work clothes, a safety cap, protective shoes. Additionally, wear a helmet, protective goggles, etc. if necessary. Protect the vehicle using a seat cover, fender cover, etc. Prepare the service tools, clean cloth, containers to catch grease and oil, etc.
- Vehicle components are extremely hot immediately after driving. Be wary of receiving burns from heated parts.
- When performing a repair, identify the cause of trouble and avoid unnecessary removal, disassembly and replacement.
- Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from battery.
- Always use the jack-up point when the shop jacks or rigid racks are used to support the vehicle.
- Remove contamination including dirt and corrosion before removal, installation, disassembly or assembly.
- Keep the removed parts in order and protect them from dust and dirt.
- All removed parts, if to be reused, should be reinstalled in the original positions with attention to the correct directions, etc.
- Bolts, nuts and washers should be replaced with new parts as required.
- Be sure to tighten the fasteners including bolts and nuts to the specified torque.
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|
| Circuit tester | Used for measuring voltage. |
Scheme 6
Scheme 7
- Disconnect the ground cable from battery.
- Disconnect the connector (A).
- Remove the nut (B) securing accelerator pedal assembly, and remove the accelerator pedal assembly.
CHECK ACCELERATOR PEDAL SENSOR AREA (METHOD WITH SUBARU SELECT MONITOR)
- Turn the ignition switch to ON. (engine OFF)
- Read the accelerator pedal opening angle signal and voltage of accelerator pedal sensor using Subaru Select Monitor. < Refer to «DISPLAY OF ENGINE FREEZE FRAME DATA»(ref-565182-S42652795882013071000000) , OPERATION, Subaru Select Monitor. > Accelerator pedal sensor Accelerator pedal opening angle signal Standard Main 0.0% 0.4 - 1.0 V 100.0% 2.4 - 3.7 V Sub 0.0% 0.3 - 1.1 V 100.0% 2.3 - 3.8 V
