SPECIFICATION

Item				Specification or identification
ABS wheel speed sensor	ABS wheel speed sensor gap (for reference)	Front		0.77 - 1.43 mm (0.030 - 0.056 in)
	ABS wheel speed sensor gap (for reference)	Rear		0.64 - 1.56 mm (0.025 - 0.061 in)
	Identifications of harness (marks, color)	Front	Except for OBK model	S1 (Pink)
		Front	OBK model	S2 (Blue)
		Rear	RH	S5 (Red)
		Rear	LH	S6 (Light green)
VDCCM&H/U Identification		Models without EyeSight		V6
VDCCM&H/U Identification		Models with EyeSight		V7

Scheme 27: ABS WHEEL SPEED SENSOR

Tightening torque: N.m (kgf-m, ft-lb)

T: 7.5 (0.76, 5.5)

Scheme 28: STEERING ANGLE SENSOR

Scheme 29: VDC CONTROL MODULE AND HYDRAULIC CONTROL UNIT (VDCCM&H/U)

Models without EyeSight Tightening torque: N.m (kgf-m, ft-lb) T1: 7.5 (0.76, 5.5) T2: 15 (1.53, 11.1) T3: 19 (1.94, 14.0) T4: 33 (3.36, 24.3)
Models with EyeSight Tightening torque: N.m (kgf-m, ft-lb) T1: 7.5 (0.76, 5.5) T2: 15 (1.53, 11.1) T3: 18 (1.84, 13.3) T4: 19 (1.94, 14.0) T5: 33 (3.36, 24.3)

< Refer to ELECTRICAL SPECIFICATION , Control Module I/O Signal. >
