SPECIAL TOOL
SPECIAL TOOL REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 18231AA010 CAM SPROCKET WRENCH Used for removing and installing cam sprocket. (LH side) NOTE: CAM SPROCKET WRENCH (499207100) can also be used. 1B022XU0 SUBARU SELECT MONITOR III KIT Used for each inspection. 498267800 CYLINDER HEAD TABLE Used for replacing valve guides. Used for removing and installing valve spring. 498277200 STOPPER SET Used for installing automatic transmission assembly to engine. 498457000 ENGINE STAND ADAPTER RH Used together with ENGINE STAND (499817100). 498457100 ENGINE STAND ADAPTER LH Used together with ENGINE STAND (499817100). 498497100 CRANKSHAFT STOPPER Used for removing and installing drive plate. 498747300 PISTON GUIDE Used for installing piston in cylinder. 498857100 VALVE OIL SEAL GUIDE Used for press-fitting of intake and exhaust valve guide oil seals. 499017100 PISTON PIN GUIDE Used for installing piston pin, piston and connecting rod. 499037100 CONNECTING ROD BUSHING REMOVER AND INSTALLER Used for removing and installing connecting rod bushing. 499587200 CRANKSHAFT OIL SEAL INSTALLER Used for installing crankshaft oil seal. Used together with CRANKSHAFT OIL SEAL GUIDE (499597100). 499587500 OIL SEAL INSTALLER Used for installing the camshaft oil seal. Used together with OIL SEAL GUIDE (499597000). 499587700 CAMSHAFT OIL SEAL INSTALLER Used for installing cylinder head plug. 499097700 PISTON PIN REMOVER ASSY Used for removing piston pin. 499207400 CAM SPROCKET WRENCH Used for removing and installing cam sprocket. (RH side) 499497000 TORX® PLUS Used for removing and installing camshaft cap. 499587100 OIL SEAL INSTALLER Used for installing oil pump oil seal. 499597000 OIL SEAL GUIDE Used for installing the camshaft oil seal. Used together with CAMSHAFT OIL SEAL INSTALLER (499587500). 499597100 CRANKSHAFT OIL SEAL GUIDE Used for installing crankshaft oil seal. Used together with CRANKSHAFT OIL SEAL INSTALLER (499587200). 499718000 VALVE SPRING REMOVER Used for removing and installing valve spring. 499767200 VALVE GUIDE REMOVER Used for removing valve guides. 499767400 VALVE GUIDE REAMER Used for reaming valve guides. 499767700 VALVE GUIDE ADJUSTER Used for installing valve guides. (Intake side) 499767800 VALVE GUIDE ADJUSTER Used for installing valve guides. (Exhaust side) 499817100 ENGINE STAND Stand used for engine disassembly and assembly. Used together with ENGINE STAND ADAPTER RH (498457000) & LH (498457100). 499977100 CRANK PULLEY WRENCH Used for removing and installing the crank pulley. (MT model) 499977400 CRANK PULLEY WRENCH Used for removing and installing the crank pulley. (CVT model) 499987500 CRANKSHAFT SOCKET Used for rotating crankshaft. 18854AA000 ANGLE GAUGE Used for installing the crank pulley. 42099AE000 QUICK CONNECTOR RELEASE Used for disconnecting quick connector of the engine compartment. 18471AA000 FUEL PIPE ADAPTER Used for inspecting the fuel pressure. 42075AG690 FUEL HOSE Used for inspecting the fuel pressure. NOTE: This is the SUBARU genuine part. 18354AA000 VALVE ROCKER HOLDER Used for installing the valve rocker assembly (intake). (2-piece set) 18258AA000 SPRING INSTALLER Used for installing the valve rocker assembly (intake)
