INSTALLATION
Install in the reverse order of removal.
| CAUTION | Be sure to use SUBARU genuine air cleaner element depending on the engine type when replacing the air cleaner elements. Using other air cleaner element may affect the engine performance. |
Note. Check that there are no foreign objects in the air cleaner case. When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.
Tightening torque
Clamp (A)
3 N.m (0.3 kgf-m, 2.2 ft-lb)
Scheme 428
Install in the reverse order of removal.
Tightening torque
Clamp (A), (B)
3 N.m (0.3 kgf-m, 2.2 ft-lb)
Install in the reverse order of removal.
REMOVAL
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to "Air Cleaner Case" for removal procedure. Ref. to REMOVAL , Air Cleaner Case.
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to "Air Cleaner Case" for installation procedure. Ref. to INSTALLATION , Air Cleaner Case.
