Engine Cooling System - Cooling (H6DO - 3.6L DOHC): Removal & Installation Subaru Outback BR

INSTALLATION

1. Install a gasket to thermostat. NOTE: Use a new gasket.
2. Install the thermostat and thermostat cover. NOTE: Install the parts with the jiggle pin facing the upside. Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
3. Install the radiator lower hose to the radiator lower and the thermostat cover.
4. Install the under cover. Ref. to «INSTALLATION»(ref-371913-S15712020302010091900000) , Front Under Cover.
5. Lower the vehicle.
6. Fill engine coolant. Ref. to «FILLING OF ENGINE COOLANT»(ref-371899-S36348928632010091900000) , REPLACEMENT, Engine Coolant.

Scheme 56

1. Check that the thermostat does not have deformation, cracks or damage.
2. Check that the thermostat valve closes completely at an ambient temperature.
3. Immerse the thermostat and a thermometer in water. Raise water temperature gradually, and check the temperature and valve lift when the valve begins to open and when the valve is fully opened. Replace the thermostat if faulty. NOTE: During the test, agitate the water for even temperature distribution. Leave the thermostat in the boiling water for five minutes or more before measuring the valve lift. Hold the thermostat with a wire or the like to avoid contacting the container. Starting temperature to open: 80 - 84°C (176 - 183°F) Full open temperature: 95°C (203°F) Total valve lift: 9.0 mm (0.354 in) or more

REMOVAL

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. Remove the collector cover. NOTE: Follow the steps below when removing the collector cover. Lift up (A) in two positions at the rear. Moving (B) in two positions at the front toward the vehicle, lift them up.
2. Disconnect the ground cable from battery.
3. Lift up the vehicle.
4. Remove the under cover. Ref. to «REMOVAL»(ref-371913-S09538241932010091900000) , Front Under Cover.
5. Drain engine coolant completely. Ref. to «DRAINING OF ENGINE COOLANT»(ref-371899-S23258697372010091900000) , REPLACEMENT, Engine Coolant.
6. Disconnect the integrated connector of radiator main fan & fan motor and radiator sub fan & fan motor.
7. Disconnect the radiator lower hose from the radiator lower.
8. Lower the vehicle.
9. Remove the air intake duct. Ref. to «REMOVAL»(ref-371896-S20541353172010091900000) , Air Intake Duct.
10. Remove the grille bracket. NOTE: Remove ten clips when removing the grille bracket.
11. Remove the radiator main fan & fan motor and radiator sub fan & fan motor. Ref. to «REMOVAL»(ref-371899-S35640087102010091900000) , Radiator Main Fan and Fan Motor. Ref. to «REMOVAL»(ref-371899-S04293189452010091900000) , Radiator Sub Fan and Fan Motor.
12. Disconnect the ATF hoses A and B from the radiator. NOTE: Plug the ATF hoses A and B to prevent ATF from leaking.
13. Remove the radiator upper brackets.
14. Lift the radiator up and away from vehicle.
15. Remove the radiator lower cushion.

1. Install the radiator lower cushion.
2. Install the radiator to vehicle. NOTE: Insert pins on the lower side of radiator into the radiator lower cushions on vehicle side.
3. Install the radiator upper brackets. Tightening torque: 12 N.m (1.2 kgf-m, 8.9 ft-lb)
4. Connect the ATF hoses A and B. NOTE: Use a new ATF hose.
5. Attach the grille bracket.
6. Install the radiator main fan & fan motor and radiator sub fan & fan motor. Ref. to «INSTALLATION»(ref-371899-S04472265882010091900000) , Radiator Main Fan and Fan Motor. Ref. to «INSTALLATION»(ref-371899-S08760544642010091900000) , Radiator Sub Fan and Fan Motor.
7. Lift up the vehicle.
8. Connect the radiator lower hose to the radiator lower.
9. Connect the integrated connector of radiator main fan & fan motor and radiator sub fan & fan motor.
10. Install the undercover. Ref. to «INSTALLATION»(ref-371913-S15712020302010091900000) , Front Under Cover.
11. Lower the vehicle.
12. Connect the ground cable to battery.
13. Fill engine coolant. Ref. to «FILLING OF ENGINE COOLANT»(ref-371899-S36348928632010091900000) , REPLACEMENT, Engine Coolant.
14. Check the ATF level and replenish it if necessary. Ref. to «INSPECTION»(ref-371902-S33705940982010091900000) , Automatic Transmission Fluid.
15. Install the air intake duct. Ref. to «INSTALLATION»(ref-371896-S14011537962010091900000) , Air Intake Duct.
16. Install the collector cover.

1. Tighten the bolts on the upper side of radiator fan shroud. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
2. Install radiator upper hoses LH and RH to the radiator.
3. Install the reservoir tank. Ref. to «INSTALLATION»(ref-371899-S33091699452010091900000) , Reservoir Tank.
4. Attach the grille bracket.
5. Install the air intake duct. Ref. to «INSTALLATION»(ref-371896-S14011537962010091900000) , Air Intake Duct.
6. Lift up the vehicle.
7. Connect the integrated connector of radiator main fan & fan motor and radiator sub fan & fan motor.
8. Install the under cover. Ref. to «INSTALLATION»(ref-371913-S15712020302010091900000) , Front Under Cover.
9. Lower the vehicle.
10. Fill engine coolant. Ref. to «FILLING OF ENGINE COOLANT»(ref-371899-S36348928632010091900000) , REPLACEMENT, Engine Coolant.
11. Connect the ground cable to battery.
12. Install the collector cover.

Scheme 63

Scheme 64

Scheme 65

1. Disconnect the connector from the radiator fan control unit, and remove the harness.
2. Remove the radiator main fan.
3. Remove the radiator main fan motor.

Refer to the Radiator Main Fan and Fan Motor. Ref. to REMOVAL , Radiator Main Fan and Fan Motor.

Refer to the Radiator Main Fan and Fan Motor. Ref. to INSTALLATION , Radiator Main Fan and Fan Motor.

Scheme 66

Scheme 67

Scheme 68

1. Disconnect the connector from the radiator fan control unit, and remove the harness.
2. Remove the radiator sub fan.
3. Remove the radiator sub fan motor.

Install in the reverse order of removal.

Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)

Install in the reverse order of removal.

Tightening torque: 2.6 N.m (0.3 kgf-m, 1.9 ft-lb)
