Engine Cooling System - Cooling (H6DO - 3.6L DOHC): Adjustments Subaru Outback BR

Cooling System (Mechanical) 2 illustrations ~241 words

PROCEDURE TO ADJUST THE SUBARU SUPER COOLANT CONCENTRATION

CAUTIONUse the SUBARU Super Coolant with a 50 - 60% concentration in order to obtain maximum antifreeze and anti-rust performance.

To adjust the concentration of SUBARU Super Coolant according to temperature, find the proper SUBARU Super Coolant concentration in the table, and add diluting water to the SUBARU Super Coolant (concentrated type) until it reaches the proper dilution.

Relationship of Subaru Super Coolant concentration and freezing temperature
SUBARU Super Coolant concentration50%55%60%
Freezing temperature36°C (-33°F)41°C (-42°F)50°C (-58°F)

SUBARU SUPER COOLANT CONCENTRATION AND FREEZING TEMPERATURE CHART

Engine coolant and diluting water: Refer to "SPECIFICATION" for the recommended engine coolant and diluting water. Ref. to SPECIFICATION , General Description.

Scheme 42

Scheme 42: REMOVAL
Scheme 42: REMOVAL
  1. Remove the radiator. Ref. to «REMOVAL»(ref-371899-S41079586492010091900000) , Radiator.
  2. Remove the V-belts. Ref. to «REMOVAL»(ref-371890-S42424743962010091900000) , V-belt.
  3. Remove the crank pulley. Ref. to «REMOVAL»(ref-371890-S11461836852010091900000) , Crank Pulley.
  4. Remove the chain cover. Ref. to «REMOVAL»(ref-371890-S03614994732010091900000) , Chain Cover.
  5. Remove the timing chain assembly. Ref. to «REMOVAL»(ref-371890-S10281519252010091900000) , Timing Chain Assembly.
  6. Remove the water pump from the oil pan upper.

Scheme 43

Scheme 43: INSTALLATION
Scheme 43: INSTALLATION
  1. Tighten the bolts in the numerical order as shown in the figure, and install water pump to the oil pan upper. NOTE: Use new O-rings. Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
  2. Install the timing chain assembly. Ref. to «INSTALLATION»(ref-371890-S27655773222010091900000) , Timing Chain Assembly.
  3. Install the chain cover. Ref. to «INSTALLATION»(ref-371890-S20199785232010091900000) , Chain Cover.
  4. Install the crank pulley. Ref. to «INSTALLATION»(ref-371890-S23260494852010091900000) , Crank Pulley.
  5. Install the V-belts. Ref. to «INSTALLATION»(ref-371890-S32448109492010091900000) , V-belt.
  6. Install the radiator. Ref. to «INSTALLATION»(ref-371899-S10711893152010091900000) , Radiator.
  7. Fill engine coolant. Ref. to «FILLING OF ENGINE COOLANT»(ref-371899-S36348928632010091900000) , REPLACEMENT, Engine Coolant.
