INSPECTION
Operating condition
Radiator fan operates depending on the radiator fan speed related to engine coolant temperature or the radiator fan speed related to A/C compressor load, whichever is higher as a load condition.
Scheme 44
Scheme 45
- Radiator fan speed related to engine coolant temperature
- Radiator fan speed related to A/C compressor load
DIAGNOSIS
Radiator main and sub fans do not rotate under the above conditions.
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK MAIN FAN RELAY. Turn the ignition switch to OFF. Remove the main fan relay from the relay holder. Measure the resistance between main fan relay switch terminals. | Is the resistance 1 Mohms or more? | Go to step 2 . | Replace the main fan relay. |
| 2 CHECK MAIN FAN RELAY. Connect the battery to the terminal on main fan relay coil side. Measure the resistance between main fan relay switch terminals. | Is the resistance less than 1 ohms? | Go to step 3 . | Replace the main fan relay. |
| 3 CHECK POWER SUPPLY FOR ECM. Turn the ignition switch to OFF. Disconnect the connectors from ECM. Turn the ignition switch to ON. Measure the voltage between ECM terminal and chassis ground. Connector & terminal (B135) No. 12 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 4 . | Repair the power supply line. |
| 4 CHECK POWER SUPPLY FOR RADIATOR FAN CONTROL UNIT. Turn the ignition switch to OFF. Connect the connector to ECM. Disconnect the connector from radiator fan control unit. Turn the ignition switch to ON. Measure the voltage between radiator fan control unit terminal and chassis ground. Connector & terminal (F106) No. 3 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 5 . | Repair the power supply line. |
| 5 CHECK HARNESS BETWEEN ECM AND RADIATOR FAN CONTROL UNIT. Turn the ignition switch to OFF. Disconnect the connectors from ECM. Measure the resistance between radiator fan control unit and ECM connector. Connector & terminal (B135) No. 11 - (F106) No. 2 | Is the resistance less than 1 ohms? | Go to step 6 . | Repair the open circuit of harness between ECM and radiator fan control unit. |
| 6 CHECK RADIATOR FAN CONTROL UNIT AND GROUND CIRCUIT. Connect the connector to ECM and radiator fan control unit. Measure the resistance between radiator fan control unit connector and chassis ground. Connector & terminal (F106) No. 1 - Chassis ground | Is the resistance less than 5 ohms? | Go to step 7 . | Repair the open circuit of harness between radiator fan control unit connector and chassis ground. |
| 7 CHECK MAIN FAN MOTOR. Disconnect the connector from radiator fan control unit. Connect the battery positive (+) terminal to terminal No. 1 of the main fan motor, and the ground (-) terminal to terminal No. 2. | Does the main fan motor rotate? | Go to step 8 . | Replace the main fan motor. |
| 8 CHECK SUB FAN MOTOR. Disconnect the connector from radiator fan control unit. Connect the battery positive (+) terminal to terminal No. 1 of the sub fan motor, and the ground (-) terminal to terminal No. 2. | Does the sub fan motor rotate? | Go to step 9 . | Replace the sub fan motor. |
| 9 CHECK OUTPUT SIGNAL FROM ECM. Turn the ignition switch to OFF. Connect the delivery mode fuse. Turn the ignition switch to ON. Check the output waveform using oscilloscope. Ref. to RADIATOR FAN CONTROL OUTPUT WAVEFORM , Radiator Fan System. Connector & terminal (B135) No. 11 (+) - Chassis ground (-) | Is waveform being output? | Replace the radiator fan control unit. Ref. to RADIATOR FAN CONTROL UNIT . | Replace the ECM. Ref. to ENGINE CONTROL MODULE (ECM) . |
DIAGNOSIS PROCEDURE
Scheme 46
- Lift up the vehicle.
- Remove the under cover. Ref. to «REMOVAL»(ref-371913-S09538241932010091900000) , Front Under Cover.
- Remove the drain plug to drain engine coolant into container. NOTE: Remove the radiator cap so that engine coolant will drain faster.
- Install the drain plug.
- Install the under cover. Ref. to «INSTALLATION»(ref-371913-S15712020302010091900000) , Front Under Cover.
Scheme 47
- Pour cooling system conditioner from the filler neck of the radiator. Cooling system protecting agent: Refer to "SPECIFICATION" for cooling system protecting agent. Ref. to «SPECIFICATION»(ref-371899-S06182442972010091900000) , General Description.
- Pour engine coolant into the radiator up to the filler neck position. Recommended engine coolant: Refer to "SPECIFICATION" for recommended engine coolant. Ref. to «SPECIFICATION»(ref-371899-S06182442972010091900000) , General Description. Engine coolant level: Refer to "SPECIFICATION" for engine coolant level. Ref. to «SPECIFICATION»(ref-371899-S06182442972010091900000) , General Description. Engine coolant concentration: Refer to "ADJUSTMENT" for the recommended engine coolant concentration. Ref. to «ADJUSTMENT»(ref-371899-S27705026852010091900000) , Engine Coolant. NOTE: The SUBARU Super Coolant is especially made for SUBARU engine, which has an aluminum cylinder block, and contains anti-freeze and anti-rust agents. Always use SUBARU Super Coolant, since other coolant may cause corrosion.
- Fill engine coolant into the reservoir tank up to "FULL" level.
- Close the radiator cap and start the engine. Race 5 to 6 times at 3,000 RPM or less, then stop the engine. (Complete this operation within 40 seconds.)
- Wait for one minute after the engine stops, and open the radiator cap. If the engine coolant level drops, add engine coolant into radiator up to the filler neck position.
- Perform the procedures 4) and 5) again.
- Attach the radiator cap and reservoir tank cap properly.
- Start the engine and operate the heater at maximum hot position and the blower speed setting to "LO".
- Run the engine at 2,000 RPM or less until radiator fan starts and stops. NOTE: Be careful with the engine coolant temperature gauge to prevent overheating. If the radiator hose becomes hardened with the pressure of engine coolant, air bleeding operation seems to be almost completed.
- Stop the engine and wait until the engine coolant temperature lowers to 30°C (86°F) or less.
- Open the radiator cap. If the engine coolant level drops, fill engine coolant up to the radiator filler neck position and to the reservoir tank "FULL" level.
- Attach the radiator cap and reservoir tank cap properly.
- Set the heater setting to maximum hot position and the blower speed setting to "LO" and start the engine. Perform racing at 3,000 RPM or less. If the flowing sound is heard from heater core, repeat the procedures from step 9 ).
- Check the water pump bearing for smooth rotation.
- Check the water pump sprocket for abnormalities.
- Make sure the impeller is not abnormally deformed or damaged.
- After water pump installation, check pulley shaft for engine coolant leaks or noise. If leaks or noise are noted, replace the water pump assembly.
Scheme 48
Scheme 49
- Lift up the vehicle.
- Remove the under cover. Ref. to «REMOVAL»(ref-371913-S09538241932010091900000) , Front Under Cover.
- Drain engine coolant completely. Ref. to «DRAINING OF ENGINE COOLANT»(ref-371899-S23258697372010091900000) , REPLACEMENT, Engine Coolant.
- Remove the radiator lower hose from the radiator lower and the thermostat cover.
- Remove the thermostat cover, and then remove the thermostat.
- Check that the radiator does not have deformation, cracks or damage.
- Check that the hose has no cracks, damage or loose part.
- Remove the radiator cap, fill the radiator with engine coolant, and then install the radiator cap tester to the filler neck of radiator.
- Apply a pressure of 157 kPa (1.6 kgf/cm 2 , 23 psi) to the radiator, and check the following items. Leakage from the radiator or its vicinity Leakage from the hose or its connections CAUTION: Engine should be turned off. Wipe engine coolant from check points in advance. Be careful of engine coolant from spurting out when removing the radiator cap tester. Be careful not to deform the filler neck of radiator when installing and removing the radiator cap tester.
Scheme 50
- Check that the radiator cap does not have deformation, cracks or damage.
- Attach the radiator cap tester to radiator cap.
- Increase pressure until the radiator cap tester gauge needle stops. Radiator cap is functioning properly if it holds the service limit pressure for 5 - 6 seconds. Replace the radiator cap if its valve opens at less than the service limit. Standard: 93 - 123 kPa (0.95 - 1.25 kgf/cm 2 , 14 - 18 psi) Service limit: 83 kPa (0.85 kgf/cm 2 , 12 psi) CAUTION: Be sure to remove foreign matter and rust from the cap in advance. Otherwise, results of pressure test will be incorrect.
Scheme 51
Scheme 52
Scheme 53
- Remove the collector cover. NOTE: Follow the steps below when removing the collector cover. Lift up (A) in two positions at the rear. Moving (B) in two positions at the front toward the vehicle, lift them up.
- Disconnect the ground cable from battery.
- Lift up the vehicle.
- Remove the under cover. Ref. to «REMOVAL»(ref-371913-S09538241932010091900000) , Front Under Cover.
- Drain engine coolant completely. Ref. to «DRAINING OF ENGINE COOLANT»(ref-371899-S23258697372010091900000) , REPLACEMENT, Engine Coolant.
- Disconnect the integrated connector of radiator main fan & fan motor and radiator sub fan & fan motor.
- Lower the vehicle.
- Remove the air intake duct. Ref. to «REMOVAL»(ref-371896-S20541353172010091900000) , Air Intake Duct.
- Remove the grille bracket. NOTE: Remove ten clips when removing the grille bracket.
- Remove the reservoir tank. Ref. to «REMOVAL»(ref-371899-S02283336512010091900000) , Reservoir Tank.
- Remove radiator upper hoses LH and RH only on radiator side.
- Remove the ATF hose from the clip of radiator fan shroud.
- Remove bolts on the upper side of radiator fan shroud.
- Remove the radiator fan shroud. NOTE: When pulling up the radiator fan shroud, be careful not to damage the radiator hose or AFT hose.
Check that the radiator main fan, radiator main fan shroud and main fan motor do not have deformation, cracks or damage.
Check that the radiator sub fan, radiator sub fan shroud and sub fan motor do not have deformation, cracks or damage.
Scheme 54
- Pull out the over flow hose.
- Remove bolts which secure the reservoir tank, and remove the reservoir tank.
- Check that the reservoir tank does not have deformation, cracks or damage.
- Check the over flow hose for cracks or damage.
- Make sure the engine coolant level is between "FULL" and "LOW".
Scheme 55
- Disconnect the ground cable from battery.
- Remove the radiator fan control unit. Disconnect the connector (A) from the radiator fan control unit. Remove screws which secure the radiator fan control unit.
| Trouble | Possible cause | Corrective action |
|---|---|---|
| Over-heating | A. Insufficient engine coolant | Replenish engine coolant, inspect for leakage, and repair it if necessary. |
| B. Defective thermostat | Replace. | |
| C. Malfunction of water pump | Replace. | |
| D. Clogged engine coolant passage | Clean. | |
| E. Improper ignition timing | Inspect and repair the ignition control system. Ref. to PROCEDURE , Basic Diagnostic Procedure. | |
| F. Clogged or leaking radiator | Clean, repair or replace. | |
| G. Defective radiator cap | Replace. | |
| H. Improper engine oil in engine coolant | Replace the engine coolant. If ineffective, check, repair or replace engine components. | |
| I. Air/fuel mixture ratio too lean | Inspect and repair the fuel injection system. Ref. to PROCEDURE , Basic Diagnostic Procedure. | |
| J. Excessive back pressure in exhaust system | Clean or replace. | |
| K. Insufficient clearance between piston and cylinder | Adjust or replace. | |
| L. Dragging brake | Adjust. | |
| M. Defective radiator fan | Inspect the radiator fan relay, engine coolant temperature sensor or fan motor and replace them. | |
| Over-cooling | A. Ambient temperature extremely low | Partly cover radiator front area. |
| B. Defective thermostat | Replace. | |
| Engine coolant leaks | A. Loosened or damaged connecting units on hoses | Repair or replace. |
| B. Leakage from water pump | Replace. | |
| C. Leakage from water pipe | Repair or replace. | |
| D. Leakage around cylinder head gasket | Retighten cylinder head bolts or replace cylinder head gasket. | |
| E. Damaged or cracked cylinder head and cylinder block | Repair or replace. | |
| F. Damaged or cracked thermostat cover | Repair or replace. | |
| G. Leakage from radiator | Repair or replace. | |
| Noise | A. Defective radiator fan | Replace. |
| B. Defective water pump bearing | Replace water pump. | |
| C. Defective water pump mechanical seal | Replace water pump. |
ENGINE COOLING SYSTEM INSPECTION CHART
